- Page 1 OPERATION MANUAL MODEL G55H GASOLINE VIBRATOR (HONDA GX160K1QX2 GASOLINE ENGINE) Revision #1 (07/08/21) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
- Page 2 @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
-
Page 3: Proposition 65 Warning
PROPOSITION 65 WARNING PAGE 2 — G-55H GASOLINE VIBRATOR — OPERATION MANUAL — REV. #1 (07/08/21) -
Page 4: Table Of Contents
TABLE OF CONTENTS G-55H GASOLINE VIBRATOR Proposition 65 Warning ............. 2 Table Of Contents ............. 3 Specifications ..............4 Safety Message Alert Symbols ........5-6 Rules For Safe Operation ..........7-8 Operation and Safety Decals ..........9 General Information ............10 Major Components ............ -
Page 5: Specifications
SPECIFICATIONS r o t t f a t i n . n i r t s v l a i l y . n i o r t p s i . n i . P . y t i . -
Page 6: Safety Message Alert Symbols
Safety precautions should be followed Potential hazards associated with the operation of an STOW at all times when operating this G55H Gasoline Vibrator will be referenced with Hazard equipment. Failure to read and Symbols which appear throughout this manual, and will be... - Page 7 SAFETY MESSAGE ALERT SYMBOLS Equipment Damage CAUTION CAUTION CAUTION CAUTION CAUTION CAUTION CAUTION CAUTION CAUTION CAUTION Rotating Parts Hazards Hazards NEVER operate equipment with covers, Other important messages are provided throughout this or guards removed. Keep fingers, hands, manual to help prevent damage to your equipment, other hair and clothing away from all moving property, or the surrounding environment.
-
Page 8: Rules For Safe Operation
■ NEVER use accessories or attachments, which are not recommended by Multiquip for this equipment. Damage to the equipment and/or injury to user may result. G-55H GASOLINE VIBRATOR — OPERATION MANUAL — REV. #1 (07/08/21) — PAGE 7... - Page 9 ■ Refer to the HONDA Engine Owner's Manual for engine technical questions or information recommended by Multiquip for this equipment. Damage to the equipment and/or injury to user may result. ■ In emergencies always know the location of the nearest phone or keep a phone on the job site .
-
Page 10: Operation And Safety Decals
OPERATION AND SAFETY DECALS Operation And Safety Decals The MQ/STOW G-55H Gasoline Vibrator is equipped with a number of operation and safety decals (Figure 1). These decals are provided for operator safety and maintenance information. Should any of these decals become unreadable, replacements can be obtained from your dealer. -
Page 11: General Information
GENERAL INFORMATION General Information Theory Of Concrete Vibration The G-55H Gasoline Vibrator employs a 5.5 HP Honda engine. The G-55H Vibrator is designed for the compaction of It comes standard with a quick-disconnect coupling and an concrete by removal of air pockets and voids. eccentric belt tensioner. -
Page 12: Major Components
MAJOR COMPONENTS Figure 2. G-55H Gasoline Vibrator Components Figure 2 shows the location of the components and general maintenance parts. The function of each component is described below: 1. Eccentric Bell End – Supports the spindle shaft and 5. Rear Belt Guard – Attaches to the V-belt housing and upper pulley which drives the vibration function of the prevents access to the pulleys or V-belts while the vibrator G-55H. -
Page 13: Engine Components
ENGINE COMPONENTS 5.5 HP Honda Gasoline Engine The engine (Figure 3) must be checked for proper lubrication and filled with fuel prior to operation. Refer to the manufacturer's engine manual for instructions & details of operation and servicing. The engine shown above is a HONDA engine. -
Page 14: Inspection
4. If the oil level is low (Figure 5), fill to the edge of the oil filler hole with the recommended oil type (Table 3). Maximum oil capacity is 0.63 quarts (.60 liters). Before Starting Before starting and operating the G55H Gasoline Vibrator, NOTICE perform the following: Reference manufacturer engine manual for specific ■... - Page 15 INSPECTION V-Belt Check WARNING WARNING WARNING WARNING WARNING Explosive Fuel Hazards A worn or damaged V-belt can adversely affect the performance of the vibrator. Gasoline is extremely flammable, and its vapors can cause an explosion if 1. Unscrew the bolts securing the front belt guard to the ignited.
-
Page 16: Startup Procedures
START-UP PROCEDURES This section is intended to assist the operator 3. Place the engine choke lever (Figure 8) in the CLOSED with initial start-up. It is extremely important position if starting a cold engine. Place the choke lever in the OPEN position if starting a warm engine or the that this section be read carefully before temperature is warm. -
Page 17: Shutdown Procedures
START-UP/SHUTDOWN PROCEDURES 7. If the engine has started, slowly return the choke lever Stopping The Engine (Figure 6) to the OPEN position. If the engine has not 1. Move the throttle lever to the IDLE or SLOW position started repeat steps 1 through 6. (Figure 11) and run the engine for three minutes at low 8. -
Page 18: Operation
Using head attachments not listed above may create a hazardous condition when using the vibrator. The G55H Gasoline Vibrator, flexible shafting, and head are shipped from the factory ready for assembly. Follow the instructions listed below when connecting these parts before using the gasoline vibrator. - Page 19 OPERATION 1. Start the engine as previously described and procede to Use the flexible shaft in as straight a position as possible and do not bend the flexible shaft sharply at any point. Sharp insert the vibrator head into the concrete. bends may cause a permanent kink, requiring early 2.
-
Page 20: Maintenance
■ Remove and clean the spark plug (Figure 24), then adjust Maintenance Instructions the spark gap to 0.024 ~0.028 inch (0.6~0.7 mm). This To receive trouble-free service from your STOW G55H unit has electronic ignition, which requires no gasoline vibrator, follow these instructions, as well as the adjustments. - Page 21 G55H GASOLINE VIBRATOR — MAINTENANCE Engine Air Cleaner V-Belt Tension 1. Remove the air cleaner cover and foam filter element as The belt can be tightened by rotating the eccentric shown in Figure 26. countershaft assembly clockwise. When the belts are properly tensioned, they should deflect approximately 5 to 2.
-
Page 22: Troubleshooting (Gasoline Engine)
G55H GASOLINE VIBRATOR — TROUBLESHOOTING (ENGINE) i t a l i r b t i s c i f f t l u t r a f " , s i l l i a t r o r i c... - Page 23 @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
- Page 24 OPERATION MANUAL HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING...
