INSTALLATION GUIDE
Protective skid plate
TGB Blade 600 LTX
Full protection and ultra-light protection of your quad bottom, made of high quality
HrdPE material, equipped with water and mud holes drainage.
HrdPE cover characterizes good impact and deformation resistance.
Enjoy using it!
ver. 04.04.2022
Advertisement
Summary of Contents for Shark TGB Blade 600 LTX
- Page 1 INSTALLATION GUIDE Protective skid plate TGB Blade 600 LTX Full protection and ultra-light protection of your quad bottom, made of high quality HrdPE material, equipped with water and mud holes drainage. HrdPE cover characterizes good impact and deformation resistance. Enjoy using it!
-
Page 2: Installation Kit
Read the instructions before starting the assembly. The assembly instructions are for the TGB Blade 600 LTX model only and cannot be used with other quad models. The surface of the material is easy to clean. Another advantage is easy access to changing fluids without the need to disassemble the plates. -
Page 3: Installation
INSTALLATION CAUTI O N The easiest way to mount it is in a tilted position on the rear part of the quad bike. ATTENTION: CAREFULLY SECURE ALL FASTENERS TO ENSURE SAFETY The manual provides a view of the placement of elements helping to localize fasteners and the use of individual connecting elements. - Page 4 Diagram of the arrangement of mounting elements - TGB BLADE 600 LTX Elements A for mounting PLATE No. 1 from the inside Fig. 3 PLATE No. 4 PLATE No. 5 Symbol of the hooks on the rocker Mounting plate A1...
- Page 5 Arrangement of mounting plates connecting the protective plates - TGB BLADE 600 LTX Through holes Mounting plate A1 assembled from the inside Threaded holes Through holes Mounting plate A2 assembled from the inside Threaded holes...
- Page 6 List of mounting elements - TGB BLADE 600 LTX PLATE No. 1 WASHER WASHER 36 mm M6/M8 24 mm M8 4 pcs. 4 pcs. WASHER 36 mm M6/M8 7 pcs. 33 mm right 28 mm M6 NUT left 4 pcs.
- Page 7 4 pcs. WASHER 24 mm M8 4 pcs. MOUNTING PLATES TGB BLADE 600 LTX MOUNTING PLATE A1 MOUNTING PLATE A2 PROTECTIVE PLATES USE You have just set up your hood, uh, it wasn’t that bad. During the crossings - when using, watch out for protruding stones, trunks or roots.
