ADC HiGain H2TU-R-402 List 4B Quick Installation

Remote unit
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
HiGain
HiGain
HiGain
HDSL2
L
4B
STAT
LOSW
H
LLOS
D
S
RLOS
L
2
HBER
MARG
B8ZS
LBK
RCV
BRG
XMT
RS-232
DCE
H
2
T
.
U
R
4
0
2
Q
UICK
H2TU-R-402 L
R
U
EMOTE
NIT
I
NSTALLATION
4B
IST

Advertisement

loading

Related Manuals for ADC HiGain H2TU-R-402 List 4B

Summary of Contents for ADC HiGain H2TU-R-402 List 4B

  • Page 1 HiGain HiGain UICK NSTALLATION HiGain HDSL2 STAT LOSW LLOS RLOS HBER MARG B8ZS H2TU-R-402 L EMOTE RS-232...

  • Page 2: Specifications

    H2TU-R-402 L The H2TU-R-402 List 4B functions as the remote end of a repeaterless T1 transmission system when connected to a HiGain HDSL2 line unit (H2TU-C). Setting new standards for interoperability and efficiency, HiGain HDSL2 modules transmit a 1.544 Mbps T1 payload on one unconditioned copper pair over the full Carrier Service Area (CSA) range.

  • Page 3: Installation

    NSTALLATION Remote enclosure H2TU-R-402 - 2 3 Wear an antistatic wrist strap when installing the H2TU-R. Avoid touching components on the circuit board. Align the H2TU-R with the enclosure slot guides and slide the unit in. Push the unit back until it touches the backplane card-edge connector. Place your thumbs on the H2TU-R front panel and push the unit into the card-edge connector.

  • Page 5: Status Led Descriptions

    H2TU-C. Once logged on, you can view system settings and inventory, initiate loopbacks, monitor performance, and configure the circuit. Monitor Performance Event Log Config Inventory Rlogon Help +------------------------------------------+ ADC DSL Systems, Inc. HiGain HDSL2 Voice: 800.638.0031 714.832.9924 +------------------------------------------+ ID: xxxx--xxxx--xxxx--xxxx 09/20/2000 01:35:13 H2TU-C System:...
  • Page 6 For more information about the HiGain HDSL2 maintenance screens, refer to the technical practice for the H2TU-C line unit. Publications can be downloaded from the ADC website at www.adc.com. To order a hard copy, please contact ADC Product Literature at 1.800.370.9670 (extension 14) or 1.714.832.9922 (extension 14) or email ADC at...
  • Page 7 © 2001 ADC DSL Systems, Inc. All rights reserved. Information contained in this document is company private to ADC DSL Systems, Inc., and shall not be modified, used, copied, reproduced or disclosed in whole or in part without the written consent of ADC.
