- Page 1 HV-32D40BK HV-28D40BK Integrated Digital Colour Television Trade Mark of the DVB Digital Video Broadcasting Project (1991 to 1996) Number: 3081 INSTRUCTIONS...
- Page 2 Make special arrangements for infirm or handicapped persons. • Never watch TV while operating a motor vehicle. It is illegal to watch TV while driving. • Never listen to headphones at high volume. Doing so may damage your hearing.
- Page 3 How to move the TV When moving the TV, make sure that it is held by two people as shown in the illustration. Be careful not to trap your hands when putting the TV down.
- Page 4 Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
- Page 5 Digital terrestrial broadcasting (DVB-T) service area Although this TV can receive both Digital terrestrial broadcasting (DVB-T) and Analogue terrestrial broadcasting, depending on the area in which you live, you may not be able to receive Digital terrestrial broadcasting (DVB-T). For details of the Digital terrestrial broadcasting (DVB-T) service area, refer to the FREEVIEW...
-
Page 6: Table Of Contents
Using the FREEZE function ... 20 Using the MULTI-PICTURE function ... 20 Using the GUIDE ... 22 Displaying the Subtitles... 24 Operating a JVC brand VCR or DVD player... 24 Teletext function ...25 Basic operation (Digital)... 25 Basic operation (Analogue)... 26 Using the List Mode ... -
Page 7: Setting Up Your Tv
Setting up your TV Caution • Turn off all the equipment including the TV before connecting anything. Connecting the aerial • The connecting cables are not provided. • For further details, refer to the manuals provided with the devices to be connected. -
Page 8: Connecting The Power Cord To The Ac Outlet
Initial settings When the TV is first turned on, it goes into the initial settings mode, and you will see the JVC logo. Follow the instructions on the screen display to make the initial settings. TV/DTV buttons... - Page 9 The power lamp lights green and the JVC logo appears. Main power button • If the JVC logo does not appear this is because your TV has already been turned on for the first time: Perform the initial settings with “Installation”...
- Page 10 (PR) will not be set. Programme number PR6 is not normally set. • If a TV channel you want to view is not set to a programme number (PR), you can set it manually. To set an Analogue terrestrial broadcasting channel, see “EDIT/MANUAL (Analogue)”...
-
Page 11: T-V Link Functions
T-V LINK functions When you have a T-V LINK compatible VCR connected to the EXT-2 Terminal on the TV, it is easier to set up the VCR and to view videos. T-V LINK uses the following features: To use T-V LINK functions: A “T-V LINK compatible VCR”... - Page 12 Generally, the VCR cannot record a TV channel that it cannot receive properly on its own tuner, even if you can view that TV channel on the TV. However, some VCRs can record a TV channel by using the TV’s output if that channel can be viewed on the TV.
-
Page 13: Tv Buttons And Functions
7 EXT-5 terminal (pages 42, 53) Turn the main power on Press the main power button on the The power lamp lights red and your TV is in standby mode. • If the power lamp lights green, the TV is already on. -
Page 14: Adjust The Volume
TV buttons and functions Adjust the volume 1 Press the r (Volume) button once The volume level indicator appears. 2 Press the q buttons while the volume level indicator is displayed... -
Page 15: Remote Control Buttons And Functions
TV position and press the # button. If the VCR/TV/DVD switch on the remote control is set to a position other than TV, the TV will not be turned on or off even if the # button is pressed. button, p p buttons or... -
Page 16: Choose A Tv Channel And Watch Images From External Devices
• If you choose an EXT terminal with no input signal, the EXT terminal number becomes fixed on the screen. • This TV set has a function which can automatically change over the input according to a special signal output from an external device. -
Page 17: Adjust The Volume
To use the programme number PR 0 (AV): When the TV and VCR are connected only by the aerial cable, choosing the programme number PR 0 (AV) allows you to view images from the VCR. Set the VCR RF channel to the programme number PR 0 (AV) manually. -
Page 18: Zoom Function
Time display: The current time of the teletext data is displayed. If the TV has not received a TV channel that has teletext programmes since it was turned on, the time display is blank. To view the current time, choose a TV channel that has teletext programmes. - Page 19 (4:3 aspect ratio), use the FULL mode to restore the picture to its original shape. • When you use this TV’s output signal to record a Digital terrestrial broadcasting (DVB-T) 16:9 broadcast, it will be recorded with its picture squeezed into a 4:3 aspect ratio picture.
-
Page 20: 3D Cinema Sound Function
(DVB-T) in the main- picture is 16:9 FULL, the main-picture aspect ratio is 16:9. • The main-picture sound is emitted from the TV speaker. If headphones are connected, you can listen to the sub-picture sound. Adjust the headphone volume with HEADPHONE VOLUME in the SOUND menu. - Page 21 Sub- picture Still pictures Moving picture view a TV picture and a picture from an external device. You can not view a TV picture on more than one screen at the same time. from external devices are not displayed. picture can be changed by pressing the p p buttons.
-
Page 22: Using The Guide
• Do not press the g (swap) button while you are recording the TV output on the VCR. If you do, the TV output signal will change. • You cannot view a scrambled channel in the sub-picture. If the g (swap) - Page 23 • When the b buttons are pressed, the guide screen disappears and the normal screen returns. When the TV is being watched, it automatically changes to the channel of the scheduled programme when the start time of the scheduled program is reached.
-
Page 24: Displaying The Subtitles
2 Press the VCR/DVD Control Button to control your VCR or DVD player • If your device is not made by JVC, • Even if your device is made by JVC, • You can use the p buttons to choose •... -
Page 25: Teletext Function
• When the g (Text) button is pressed, the TV returns to television broadcasting. • With Digital terrestrial broadcasting (DVB-T), in addition to digital teletext broadcasting at the same time as normal broadcasting, there are also channels with just digital teletext broadcasting. -
Page 26: Basic Operation (Analogue)
Basic operation (Analogue) You can view two types of teletext broadcasts on the TV: FLOF (Fastext) and WST. 1 Choose a TV channel with a teletext broadcast 2 Set the VCR/TV/DVD switch to the TV position 3 Press g (Text) button to display... -
Page 27: Hold
3 Press H (Cancel) button to return to a teletext page when the page number is on the screen • The TV mode cannot be resumed by pressing the H (Cancel) button. To return to the TV mode press b. -
Page 28: Using The Tv's Menu
Using the TV’s menu This TV has a number of functions you can operate using menus. To use all your TV’s functions, you need to understand the basic menu operating techniques fully. Buttons used to operate the menus TV/DTV Basic operation... -
Page 29: Picture Menu
PICTURE menu PICTURE PICTURE MODE CONTRAST BRIGHT SHARP COLOUR COLOUR TEMP. FEATURES D0014-EN • While the PICTURE menu is displayed, pressing the blue button will set the CONTRAST, BRIGHT, SHARP, COLOUR, HUE settings to their default settings. PICTURE MODE You can choose one of three PICTURE MODEs to adjust the picture settings automatically. -
Page 30: Features
You can choose from the four DIGITAL VNR function settings of AUTO(LOW), AUTO(HIGH), MIN and MAX. AUTO(LOW)/AUTO(HIGH): The TV will automatically adjust the level of the DIGITAL VNR effect to match the amount of noise in the picture, giving you the best possible picture. -
Page 31: Colour System
MIN: The level of DigiPure effect is set to the minimum. When you set the Super DigiPure function to AUTO and notice some noise, change the setting from AUTO to MIN. • The MIN setting is not suitable for high- quality pictures which contain very little noise. - Page 32 PICTURE menu AUTO: This function detects a colour system from the input signal. You can only use this when you are viewing a picture from programme number PR 0 (AV), or an EXT terminal. • The AUTO function may not function properly if you have poor signal quality.
-
Page 33: Sound Menu
3D CINEMA SOUND D0019-EN • Functions in the “SOUND” menu other than “HEADPHONE VOLUME” work for the TV speakers. They do not work for the sound from the headphones. • When the headphones are connected and only one screen is displayed, only “HEADPHONE VOLUME”... -
Page 34: Features Menu
“OFF”. TYPE A CHILD LOCK When there is a TV channel you do not want your children to watch, you can use the CHILD LOCK function to lock out the TV channel. Even when a child chooses a... -
Page 35: Appearance
CHILD LOCK function set for the TV channel is cancelled. The next time anyone tries to view the TV channel, it will be locked again. • When you want to cancel the CHILD LOCK function, you must perform the operation “To set the CHILD LOCK... -
Page 36: Set Up Menu
(PR) of a TV channel. This function registers a channel name (ID) to a TV channel. INSERT: This function adds a new TV channel in the current programme numbers (PR) list by using the CH number. • You cannot use the INSERT function if you do not know the channel number of a TV channel. - Page 37 1 Press the 6 buttons to choose a TV channel Every time you press the 6 buttons, the programme number (PR) changes and the picture of the TV channel stored in the MANUAL programme number (PR) appears on the DELETE screen.
- Page 38 CH 25 CH 26 CH 27 Before performing INSERT or CH 28 CH 29 MANUAL operation ID LIST • A CH number unique to this TV and CH 21 CH 22 CH 23 CH 24 CH 25 CH 26 CH 27...
- Page 39 CH number The TV shifts to registration mode. When the registration is completed, the picture of the TV channel appears on the screen. • The CH number is a number given to each broadcast frequency that carries a TV channel.
-
Page 40: Picture Tilt
• When you want to use the INSERT function on page 39, find the CH/CC number corresponding to the channel number of the TV channel from this table. If you want to know a particular TV channel’s channel menu, look in TV listings magazines or contact the broadcaster. -
Page 41: Decoder (Ext-2)
Decoder, repeat steps 2 to 6 If the DECODER (EXT-2) function has been set to “ON” but the TV channel cannot be unscrambled, check the following: • Has the decoder been connected to the... -
Page 42: Ext Setting
Preparation: • First read the device’s instruction manual and “Additional preparation” on page 53 to connect the device to the TV properly. Second, follow the device’s instruction manual to set the device so that it sends an S-VIDEO signal (Y/C signal) to the TV. - Page 43 EXT-2 terminal. You can do this with the output signals of the devices connected to other EXT terminals, or with the picture and sound from a TV channel you are currently viewing. Caution: Every time you dub, check this DUBBING setting beforehand.
-
Page 44: Attenuator
EXT-2 terminal. • During dubbing, you cannot turn off the TV. Turning off the TV also turns off the output from the EXT-2 terminal. • When you choose an EXT terminal as... -
Page 45: Dtv Menu
VCR” on page 54. • When you have a T-V LINK compatible VCR connected to EXT-2, all you need to do is set the TV timer settings and the programme will be recorded. By using “Direct Rec” of the T-V LINK... - Page 46 “When recording on a T-V LINK incompatible VCR:”. While the timer is in operation: • You can turn the TV on or off (Standby). WARNING: Do not turn off the main power. • You can watch Analogue terrestrial broadcasting channels or the pictures via an EXT terminal.
-
Page 47: Configuration
“Aborting the timer recording” to abort the recording. After this is done, reset the timer. • When you are watching TV at the recording start time, you may encounter an error message stating that recording could not start because of a VCR-related problem. -
Page 48: Receiver Upgrade
Enable (factory settings): The Digital terrestrial broadcasting (DVB-T) software is automatically updated every day at 3:00 am. When enabled, the TV also searches for new software whenever it goes to standby. Disable: The Digital terrestrial broadcasting (DVB-T) software is not automatically... -
Page 49: Edit Pr List
Enter PIN code Choose Enter PIN code to change the PIN code for the Edit PR List menu’s “Lock”. The PIN code factory setting (how it is set when you purchase the television) is 0000. 1 Press the 6 buttons and choose Enter PIN code, then press a button 2 Input the current PIN code... -
Page 50: Deleting A Channel
DTV menu • When the b button is pressed, the previous screen is returned to. When the TV/DTV or H buttons are pressed, the menu disappears. • When the h (Information) button is pressed, the help screen appears. When it is pressed again, the previous screen is returned to. -
Page 51: Locking A Channel
Locking a channel Digital terrestrial broadcasting (DVB-T) channels can be locked in the same way as the FEATURES menu CHILD LOCK. 1 Press the 5 buttons and choose Lock on the bar at the bottom of the screen 2 Press the 6 buttons and choose the channel to be locked, and then press the a button The Enter PIN code input window... -
Page 52: Installation
Common Interface Choose when a pay television reception module is inserted into the Common Interface slot on the back of the TV, and you want to set the module. When Common Interface is chosen and the a button is pressed, the name of the inserted module appears. -
Page 53: Additional Preparation
Additional preparation Connecting external equipment Connect the equipment to the TV, making the correct rear panel and front panel connections. Before connecting anything: • Read the manuals that came with the equipment. Depending on the equipment, the connection method may be different from the diagram. -
Page 54: Connecting Headphones
Connect the headphones with a stereo mini- jack (3.5 mm diameter) to the headphone socket at the TV rear panel. • No sound comes from the TV speakers when the headphones are connected and only one screen is displayed. Video or sound signal output from... - Page 55 TV. You can use external front speakers to listen to the TV sound instead of the TV speakers. Before connecting anything: • Read the manuals provided with the amplifier and speakers.
-
Page 56: Troubleshooting
If a problem arises while you are using the TV, please read this troubleshooting guide carefully before you ask to have the TV repaired. You may be able to fix it easily by yourself. For example, if the mains plug is disconnected from the mains outlet, or the TV aerial has problems, you may think there is a problem with the TV itself. -
Page 57: Other Issues
This is due to the condition of the video signal. There is nothing wrong with the TV. • Since this TV is designed to make full use of the resolution of the original video source, the motion may appear unnatural when the video source is input with 625p progressive-scanning component signals. - Page 58 Troubleshooting • The TV may make a crackling sound due to a sudden change in temperature. The picture or sound may be normal. If you hear crackling sounds frequently while you are viewing the TV, there may be other causes. As a precaution, ask your service technician to inspect it.
-
Page 59: Specifications
AA/R6 dry cell battery × 2 We may change the design and specifications without notice. Pictures displayed on the screen using this TV’s ZOOM functions should not be shown for any commercial or demonstration purpose in public places (cafes, hotels, etc.) without the consent of the owners of copyright of the original picture sources, as this would be an infringement of copyright. - Page 60 LCT1596-001A-U © 2004 VICTOR COMPANY OF JAPAN, LIMITED 0404-T-CR-JMUK...
