Quick Guide Using Easily in Order 1. Connecting the smartphone to earbuds with Bluetooth ([ Please refer to “Connecting the Smartphone to Earbuds via Bluetooth” on page 11.) a Press the settings app [ / ] of the smartphone. Then select Bluetooth and turn on the Bluetooth function.
Page 3
2. Wearing Earbuds a In the charging case, bend the inside of the earbuds outward and separate it. b Wear the ear hook so that the tip of the wing is on the bottom marked part of the pinna. When wearing, rotate the earbuds little by little to wear it in the most comfortable position.
Page 4
Replacing the Ear hooks a Grasp the end of the wing of the ear hooks from the earbuds and separate it. b Choose an ear hooks that is the right size for your ear, and then insert the ear hooks into the earbuds. Hold the wing of the ear hooks and turn it little by little to align the hole of the ear hooks with the protrusion of the earbuds.
Page 5
Noise Cancellation (ANC)” on pages 15, 16, and 17.) You can touch the earbuds to play or pause music, or receive or reject a phone call. You can change how the function operates in the touch pad settings of the LG TONE Free app. Receiving phone call...
Page 6
4. Charging ([ Please refer to “Charging by Wire”, “Description on UVnano” on pages 19, 20.) Wired charging Connect the charging cable to charge the charging case with earbuds. The earbuds and charging case are charged at the same time. • If you charge the device with the earbuds attached and the cover closed, the UVnano LED operates for 10 minutes.
Page 7
5. Connecting the LG TONE Free app ([ Please refer to “Connecting the LG TONE Free App” on page 23.) a Search for “LG TONE Free” on Google Play Store or App Store on your smartphone or scan the QR code below to install the LG TONE Free app.
16 Receiving Phone Call 31 Open Source Information 17 Listening to Ambient Sound/Active Noise Cancellation (ANC) Charging 19 Charging by Wire 20 Description on UVnano 21 Checking Battery Status Connecting to the Bluetooth App 23 Connecting the LG TONE Free App...
Exploring the Product Charging Case A Mood light: When you open the charging case, the mood light turns on and off. B Case charging port: You can charge a device. C UVnano LED: If you charge the device with the earbuds attached and the cover closed, the UVnano LED operates for 10 minutes.
Earbuds A Ear hooks B Speaker mesh (microphone) C Touch pad D Microphone E Earbuds charging terminals Note • Be careful that foreign substances are not over the Earbuds charging terminals.
Connecting with Bluetooth for Use Connecting the Smartphone to Earbuds via Bluetooth a Turn on the Bluetooth® function of your smartphone or a device you want to connect. b Open the cover with earbuds attached to the charging case. The blue battery status indicator on the front blinks.
Multiple Connections If you use the LG TONE Free app, you can connect and use two devices, such as a smartphone and a PC at the same time. a Please activate Multi-Point & Multi-Paring on the LG TONE Free app.
Listening to Sound with Earbuds Wearing Earbuds a In the charging case, bend the inside of the earbuds outward and separate it. Note • If you use an ear gel sized to fit your ears, you can improve performance of active noise cancellation (ANC). You can then listen to music with rich sound quality. b Wear the ear hook so that the tip of the wing is on the bottom marked part of the pinna. When wearing, rotate the earbuds little by little to wear it in the most comfortable position.
Replacing the Ear hooks a Grasp the end of the wing of the ear hooks from the earbuds and separate it. b Choose an ear hooks that is the right size for your ear, and then insert the ear hooks into the earbuds. Hold the wing of the ear hooks and turn it little by little to align the hole of the ear hooks with the protrusion of the earbuds.
: Touch the left (volume down) or right (volume up) earbud Volume control twice. Next song : Touch the left or right earbud three times. Note • You can change how to use the function in the touch pad settings of the LG TONE Free app.
Receiving Phone Call Function How to Use Receiving calls : Touch the left or right earbud once. Hanging up calls : Touch the left or right earbud twice. Rejecting calls : Touch and hold the left or right earbud. Smartphone call function Function/Status Description Receiving calls/When receiving phone...
Listening to Ambient Sound/Active Noise Cancellation (ANC) Listening to ambient sound The listening to ambient sound function makes you hear outside sounds, so that you can be aware about your surroundings and hazards.
Page 18
• If you touch and hold the left or right earbud, you can switch between active noise cancellation (ANC) and listening to ambient sound. • You can set listening to ambient sound or active noise cancellation (ANC) functions in the LG TONE Free app. • You can set listening mode and conversation mode in the LG TONE Free app.
Charging Charging by Wire If you connect the charging cable, the charging status shows up on the charging case. Note • The earbuds and charging case are charged at the same time. • The Case charging port of the charging case does not support the power supply function to other devices such as smartphone.
Description on UVnano The charging case has a built-in UVnano LED to keep the earbuds clean. If you charge the device with the earbuds attached and the cover closed, the UVnano LED operates for 10 minutes. * UVnano is a compound word of UV and nanometer, the unit of UV. Note • The UVnano indicator is blue while the UVnano LED is in operation.
Checking Battery Status If you open the charging case, the battery status of the earbuds is displayed. When the earbuds are not attached, the battery status of the charging case is displayed. Battery level state (charger not connected) / Battery status indicator Charging status (charger connected) 20% or less / Charging...
Page 22
Battery status indicator Status Operation Bluetooth® search mode The blue battery status indicator blinks. Battery 20% or less The red battery status indicator turns on and off. Battery 20% ~ 80% The yellow battery status indicator turns on and off. Battery 80% or higher The green battery status indicator turns on and off.
Connecting to the Bluetooth App Connecting the LG TONE Free App a Search for “LG TONE Free” on Google Play Store or App Store on your smartphone or scan the QR code below to install the LG TONE Free app.
Safety Precautions Safety Notices and Warnings The following “Safety Precautions” are to prevent unexpected dangers or damages, so be sure to read them thoroughly. ‘Safety Precautions’ are divided into ‘Warning’ and ‘Caution’ . . WARNING: Failure to follow the instructions may result in serious injury or death. >...
If it gets wet, dry it with a dry towel or cloth and use it after drying. If the earbuds are washed or wet during use, the touch may malfunction. the touch may malfunction due to water. To prevent touch malfunction, turn on the touchpad lock function in the LG TONE Free app. Do not swim or enter sea water while wearing the product.
Things to Check before Reporting Malfunction Troubleshooting If you experience the following symptoms while using the product, please check them again. They may not be malfunctions. Symptom Cause and Solution If the power does not • Check the battery level and charge it. turn on If a call cannot be made • If your smartphone does not support the hands-free function, you cannot...
Appendix Product Specifications General Description Bluetooth® V 5.3 (HSP/HFP/A2DP/AVRCP) specifications Earbuds: 3.7 V / 68 mAh, Lithium ion Battery Charging case: 3.7 V / 390 mAh, Lithium ion ANC Off: Up to 10 & Up to 30 hours* Play time ANC On: Up to 6 &...
Page 28
Operation temperature 0 °C ~ +40 °C Operation humidity 5 % ~ 60 % Earbud: 24.8 mm (W) X 23.5 mm (L) X 26.7 mm (H) / 5.95 g (One earbud) Dimensions (mm) / Weight (g) Charging case: 65.5 mm (W) X 51.9 mm (L) X 32.7 mm (H) / 43 g Frequency 2402 MHz ~ 2480 MHz Duration of use may vary depending on the connected mobile device, features being used, settings, signal strength,...
Logos of Android, Google Play, and Google Play, and other related marks and logos are trademarks of Google LLC. Radio frequency exposure This Bluetooth LG Stereo Headset is a radio transmitter and receiver. When in operation, it communicates with a Bluetooth-equipped mobile device by receiving and transmitting radio frequency (RF) electromagnetic fields (microwaves) in the frequency range 2402 to 2480 MHz.
Bluetooth connection precautions The following environments affect the range and reception of Bluetooth signals: - When walls, metal, human bodies, or other obstacles exist between the Bluetooth device and the connected device. - When equipment that uses 2.4 GHz frequency signals (wireless LANs, wireless phones, microwave ovens, etc.) is placed near the devices being used. - When using a Bluetooth device (TV, laptop, etc.) other than the mobile phone, the sound quality may be affected by the specifications and performance of the device.
: Dangerous voltage The spelling errors or inaccurate contents in this user manual are subject to change without prior notice by LG Electronics. The output level shall automatically return to an output level not exceeding RS1 when the power is...
