11. ESPECIFICACIONES
Sintonizador de FM Generales
Game de frecuencias: 87,9 MHz a 107,9 MHz Tensión de alimentación: 14,4 V CC (permisible
Sensibilidad útil: 11 dBf de 10,8 V a 15,6 V), negativo a masa
Sensibilidad a 50 dB de silenciamiento: 17 dBf Consumo de corriente: Menos de 15 A
Selectividad de canal alternativo: 75 dB Impedancia de los altavoces: 4
Separación estéreo (1 kHz): 35 dB 4 a 8
Respuesta en frecuencia (±3 dB): 30 Hz a 15 kHz Peso: 3,97 lb. (1,8 kg)
Dimensiones:
Sintonizador de AM 7" (178 mm) de anchura
altura 6" (152 mm) de fondo
Respuesta en frecuencia: 530 kHz a 1.710 kHz
Sensibilidad útil: 25 µV
(178 mm)
Reproductor de discos compactos
Sistema: Sistema de audio de discos compactos
Discos utilizables: Discos compactos
±
Respuesta en frecuencia: 10 Hz a 20 kHz ( 1dB)
Relación señal-ruido: 96 dB (1 kHz) IHF-A
Gama dinámica: 95 dB (1 kHz)
(188 mm)
Audio Notas:
• Las especificaciones están de acuerdo con las nor-
Salida de potencia máxima:
mas de la EIA.
180 W (45 W 4 ch)
• Las especificaciones y el diseño están sujetos a cam-
Salida de potencia media continua:
bio sin previo aviso por motivo de mejoras.
14 W 4, con 4 , 20 Hz a 20 kHz,1% de
distorsión armónica total
±
Acción de control de graves (100 Hz): 10 dB
±
Acción de control de agudos (10 kHz): 10 dB
Salida de línea (con CA, 1 kHz, 10 k ): 1,8 V
Clarion Co., Ltd.
All Rights Reserved. Copyright © 1999: Clarion Co., Ltd.
1999/10 (S C)
• Printed in China / Imprimé en Chine / Impreso en China
(permisible de
)
2" (50 mm) de Contents
English
1. PRECAUTIONS ..........................................................2
7" 2"
2. CONTROLS ................................................................3
(50 mm)
3. BUTTON TERMINOLOGY..........................................4
4. FEATURES..................................................................5
5. HANDLING COMPACT DISCS...................................6
6. DCP (Detachable Control Panel)..............................7
7. REMOTE CONTROLL ................................................8
8. OPERATION..............................................................10
9. TROUBLESHOOTING ..............................................16
10.ERROR DISPLAYS ...................................................17
7-3/8" 2-1/4" 11.SPECIFICATIONS.....................................................18
(58 mm)
Table des matières
Français
1. PRÉCAUTIONS ........................................................19
2. COMMANDES.............................................................3
3. NOMENCLATURE DES TOUCHES .........................20
4. CARACTÉRISTIQUES..............................................21
5. MANIPULATION DES DISQUES COMPACTS ........22
6. CLAVIER DE COMMANDE AMOVIBLE (DCP) .......23
7. TÉLÉCOMMANDE....................................................24
8. FONCTIONNEMENT.................................................26
9. DÉPISTAGE DES PANNES......................................32
10.AFFICHAGE DES ERREURS ..................................33
11.SPÉCIFICATIONS.....................................................34
Índice
Español
1. PRECAUCIONES......................................................35
2. CONTROLES ..............................................................3
3. NOMENCLATURA DE LOS BOTONES...................36
4. CARACTERÍSTICAS ................................................37
5. MANEJO DE LOS DISCOS COMPACTOS..............38
6. PANEL DE CONTROL DESMONTABLE (DCP) ......39
7. CONTROLADOR REMOTO .....................................40
8. OPERACIÓN.............................................................42
9. SOLUCIÓN DE PROBLEMAS .................................48
10.INDICACIONES DE ERROR ....................................49
11.ESPECIFICACIONES ...............................................50
PE-2310B
280-7426-00
1. PRECAUTIONS
Owner's manual
Mode d'emploi
1. When the inside of the car is very cold and
Manual de instrucciones
the player is used soon after switching on
the heater, moisture may form on the disc
or the optical parts of the player and proper
playback may not be possible. If moisture
forms on the disc, wipe it off with a soft
cloth. If moisture forms on the optical parts
of the player, do not use the player for
about one hour and the condensation will
disappear naturally to allow normal opera-
tion.
2. Driving on extremely bumpy roads which
cause severe vibration may cause the
sound to skip.
3. This unit uses a precision mechanism.
Even in the event that trouble arises, never
open the case, disassemble the unit, or
lubricate the rotating parts.
DRX5675
USE OF CONTROLS, ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN, MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
AM/FM CD PLAYER
THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE
WITH CD CHANGER CONTROL
EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.
•
RADIO AM/FM-LECTEUR CD
AVEC PILOTAGE DE CHANGEUR CD
•
RADIO AM/FM Y REPRODUCTOR CD
CON CONTROL DE CAMBIADOR DE CD
INFORMATION FOR USERS:
CHANGES OR MODIFICATIONS TO THIS PRODUCT WILL VOID THE WARRANTY AND
WILL VIOLATE FCC APPROVAL.
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reason-
able protection against harmful interference in
a residential installation. This equipment gen-
erates, uses, and can radiate radio frequency
energy and, if not installed and used in accor-
dance with the instructions, may cause harmful
interference to radio
However, there is no guarantee that interfer-
ence will not occur in a particular installation. If
this equipment does cause harmful interfer-
ence to radio or television reception, which can
be determined by turning the equipment off
and on, the user is encouraged to consult the
dealer or an experienced radio/TV technician
for help.
CAUTION
DRX5675
MODEL
12V GROUND
AM 530-1710kHz/FM 87.9-107.9MHz
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR
SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.
CLARION CO.,LTD.
50 KAMITODA,TODA-SHI,SAITAMA-KEN,JAPAN
051 722 877
Bottom View of Source Unit
MANUFACTURED:
SERIAL No.
PE-2310B
Be sure to unfold and read the next page.
Veuillez déployer et vous référer à la page suivante.
Cerciórese de desplegar y de leer la página siguiente.
communications.
286- 324-00
Clarion Co.,Ltd.
MADE IN CHINA
