JBL Studio S36 Owner's Manual

S P E C I F I C A T I O N S
S36
Description: 3-Way 6" horizontal/vertical mirror-image
wall-mount/bookshelf loudspeakers
Maximum Recommended
Amplifier Power*: 150W
Nominal Impedance: 8 Ohms
Sensitivity (2.83V/1m): 90dB
Frequency Response (–3dB): 60Hz – 20kHz
Crossover Frequencies: 650Hz, 3000Hz
High-Frequency Transducer: 1" Pure-titanium dome, with rubber surround,
shielded; Elliptical Oblate Spheroidal™ (EOS)
waveguide
Midrange Transducer: 4" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, shielded; Linear Field
Proximity™ (LFP) bezel
Low-Frequency Transducer: 6" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, SFG™ , magnetic shorting
rings, high-temp oversized Kapton
HeatScape™ motor structure, cast-aluminum
baskets, shielded
Baffles: Low diffraction, IsoPower™
Enclosure: Sealed
Network: Straight-Line Signal Path™ (SSP)
Terminals: All-metal, gold-plated 5-way binding posts
Dimensions (H x W x D): 10-1/4" x 14-5/8" x 5"
260mm x 371mm x 127mm
Weight: 11 lb/5kg
*The maximum recommended amplifier power rating will ensure proper system headroom to allow
for occasional peaks. We do not recommend sustained operation at these maximum power levels.
Occasional refinements may be made to existing products without notice but will always meet or
exceed original specifications unless otherwise stated.
O W N E R ' S G U I D E
S T U D I O S E R I E S
P R O D U C T L I N E :
S36
M O D E L
N U M B E R :
D E S I G N G O A L : Bring the thrill of live performance and movie sound to
the home environment by calling on JBL's professional engineering leadership.
T W E E T E R T Y P E : Pure-titanium dome with EOS™ waveguide
W O O F E R T Y P E : Cast-aluminum basket with HeatScape™ motor structure
C R O S S O V E R N E T W O R K : Straight-Line Signal Path™ (SSP)
E N C L O S U R E D E S I G N : Sealed
P R O F E S S I O N A L R E F E R E N C E : Studio Monitor
® voice coil,
P R O S O U N D
C O M E S H O M E ™
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2000 JBL, Incorporated. JBL is a registered trademark
of JBL, Incorporated.
Part No. qi0424
T H A N K Y O U F O R C H O O S I N G J B L
For more than 50 years, JBL note of enjoyment that you
has been involved in every expected – and that when you
aspect of music and film think about purchasing
recording and reproduction, additional audio equipment
from live performances to the for your home, car or
recordings you play in your office, you will once again
home, car or office. choose JBL.
We're confident that the JBL Please take a moment to
loudspeakers you have complete the enclosed
chosen will provide every profile card. It enables us
X +
0 +
Y
2
0
M H Z
X + 0 + Y
X + 0 + Y
O W N E R ' S G U I D E
S T U D I O S E R I E S
P R O D U C T L I N E :
M O D E L S36
N U M B E R :
D E S I G N G O A L : Bring the thrill of live performance and movie sound to
the home environment by calling on JBL's professional engineering leadership.
T W E E T E R T Y P E : Pure-titanium dome with EOS™ waveguide
W O O F E R T Y P E : Cast-aluminum basket with HeatScape™ motor structure
C R O S S O V E R N E T W O R K : Straight-Line Signal Path™ (SSP)
E N C L O S U R E D E S I G N : Sealed
P R O F E S S I O N A L R E F E R E N C E : Studio Monitor
to keep you posted on our
latest advancements, and
helps us to better understand
our customers and build
products that meet their
needs and expectations.
JBL Consumer Products
2 0 M H Z "
