AV-29RX
FEATURES
" By preference, users can select the picture size from REGULAR,
ZOOM, 16:9 modes.
" Users can make fun to connect the Digital Video Disk player by
using the component video signal input terminal.
" Built-in ECO (ECONOMY, ECOLOGY) MODE.
In accordance with the brightness in a room, the brightness
and/or contrast of the picture can be adjusted automatically to
make the optimum picture which is easy on the eye.
2
I
C BUS CONTROL SYSTEM CHART
TU1001
TU1001
TUNER
TUNER
IC1701
IC1701
MICRO
MICRO
COMPUTER
COMPUTER
4
IC1301
IC1301
VIDEO
VIDEO
CHROMA
CHROMA
SCL3 / SDA3
No.51729
" I
2
C Bus controls the many ICs which have various functions each
other.
IC1501
IC1201
IC1501
IC1201
DEF CTRL
SRT
DEF CTRL
SRT
SCL1 / SDA1
SCL2 / SDA2
IC301 [0S]
IC301 [0S]
DIGI COMB
DIGI COMB
IC1702
IC1702
MEMORY
MEMORY
IC8801
IC8801
LED CTRL
LED CTRL
IC101 [0S]
IC101 [0S]
AV SW
AV SW
