AD-50 / AD-50DR
Installation Manual
Phase 5 / Dual Timer
! ! ! ! !
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliances.
● ● ● ● ●
● ● ● ● ●
Do not touch any electrical switch;
do not use any phone in your
building.
● ● ● ● ●
Clear the room, building or area of
all occupants.
● ● ● ● ●
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
● ● ● ● ●
If you cannot reach your gas
supplier, call the fire department.
– Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
! ! ! ! !
AVERTISSEMENT:
RISQUE D'INCENDIE OU D'EXPLOSION
Le non-respect des avertissements de
sécurité pourrait entraîner des blessures
graves, la mort ou des dommages
matériels.
– N'entreposer pas et n'utilisez pas
d'essence ni d'autres vapeurs ou
liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ
● ● ● ● ●
Ne tentez pas d'allumer d'appareil.
● ● ● ● ●
Ne touchez à aucun interrupteur. Ne
vous servez pas des téléphones se
trouvant dans le bâtiment où vous
vous trouvez.
● ● ● ● ●
Évacuez la pièce, le bâtiment ou la zone.
● ● ● ● ●
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
● ● ● ● ●
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
– L'installation et l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.
American Dryer Corporation
88 Currant Road, Fall River MA 02720-4781 USA
Telephone: +1 (269) 923-3000 / Fax: +1 (508) 678-9447
e-mail: mdl-service@whirlpool.com / www.adclaundry.com
ADC Part No. 113066- 17
Advertisement
Table of Contents
Related Manuals for ADC AD-50
Summary of Contents for ADC AD-50
- Page 1 American Dryer Corporation 88 Currant Road, Fall River MA 02720-4781 USA Telephone: +1 (269) 923-3000 / Fax: +1 (508) 678-9447 e-mail: mdl-service@whirlpool.com / www.adclaundry.com ADC Part No. 113066- 17...
- Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.
- Page 3 In the State of Massachusetts, the following installation instructions apply: ■ Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gas fitter qualified or licensed by the State of Massachusetts. ■ Acceptable Shut-off Devices: Gas Cocks and Ball Valves installed for use shall be listed. ■...
- Page 4 WARNING UNDER NO CIRCUMSTANCES should the dryer door switch or the heat circuit devices ever be disabled. WARNING DO NOT MODIFY THIS APPLIANCE. WARNING The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
-
Page 5: Table Of Contents
Table of Contents SECTION I IMPORTANT INFORMATION ................3 A. Receiving and Handling ....................... 3 B. Safety Precautions ........................4 SECTION II SPECIFICATIONS ....................7 A. Specifications ..........................7 SECTION III INSTALLATION PROCEDURES ................9 A. Unpacking/Setting Up ......................... 9 B. - Page 6 SECTION VI ROUTINE MAINTENANCE .................. 44 A. Cleaning ........................... 44 B. Adjustments ..........................45 C. Lubrication ..........................45 SECTION VII TROUBLESHOOTING ................... 46 Microprocessor Controller (Computer) Models ................46 Dual Timer Models ......................... 52 SECTION VIII DATA LABEL INFORMATION ................55 SECTION IX REVERSING TIMER SPIN/DWELL ADJUSTMENTS ........
-
Page 7: Important Information
5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end. ADC assumes no responsibility for freight claims or damages. 6. If you need assistance in handling the situation, please contact the ADC Traffic Manager at +1 (269) 923-3000. -
Page 8: Safety Precautions
5. Installation and service must be performed by a qualified installer, service agency, or gas supplier. 6. Dryer(s) must be exhausted to the outdoors. 7. Although ADC produces a very versatile dryer, there are some articles that, due to fabric composition or cleaning method, should not be dried in it. - Page 9 8. The possible presence of residual quantities of aggressive or decomposed chemicals in the load may produce damage to the machine and harmful fumes. 9. A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork, and area around the back of the dryer.
- Page 10 CE ONLY IMPORTANT: This appliance must only be installed and operated in the country of destination indicated on the dryer’s data plate. If the appliance is to be installed and operated in a country other than the one indicated on the data plate, a data plate amendment must be obtained from American Dryer Corporation.
-
Page 11: Specifications
BOILER HORSEPOWER (NORMAL LOAD) 4.1 Bhp SUPPLY CONNECTION 1” F.N.P.T. RETURN CONNECTION 1” F.N.P.T. Shaded areas are stated in metric equivalents 2/24/22 NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. 113066 - 17 www.adclaundry.com... - Page 12 SPECIFICATIONS NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. American Dryer Corp. 113066 - 17...
-
Page 13: Installation Procedures
SECTION III INSTALLATION PROCEDURES Installation should be performed by competent professional in accordance with local, state, and country codes. In the absence of these codes, the installation must conform to applicable American National Standards: National Fuel Gas Code ANSI Z223.1/NFPA 54 and National Electric Code ANSI/NFPA 70, or in Canada, the installation must conform to applicable Canadian Standards: Natural Gas and Propane Installation Code CSA B149.1 and Canadian Electric Code CSA C22.1. -
Page 14: Location Requirements
1. Leveling Dryer The dryer is equipped with four (4) leveling legs, one (1) at each corner of the base. Two (2) are located at the rear of the dryer base, and two (2) are located in the lint chamber (coop). To increase bearing life and improve efficiency, the dryer should be tilted slightly to the rear. -
Page 15: Dryer Enclosure Requirements
C. DRYER ENCLOSURE REQUIREMENTS Bulkheads and partitions should be made of noncombustible materials and must be located a minimum of 12-inches (30.48 cm) above the dryer’s outer top; 18-inches (45.72 cm) for steam dryers, except along the front of the dryer which may be closed if desired. NOTE: Allowances must be made for opening the control door. -
Page 16: Fresh Air Supply Requirements
D. FRESH AIR SUPPLY REQUIREMENTS This appliance may only be installed in a room that meets the appropriate ventilation requirements specified in the national installation regulations. Air supply (make-up air) must be given careful consideration to assure proper performance of each dryer. An unrestricted source of replenished air in the amount of 600 cfm (17 cmm) is necessary for each dryer. -
Page 17: Exhaust Requirements
E. EXHAUST REQUIREMENTS Exhaust ductwork should be designed and installed by a qualified professional. Improperly sized ductwork will create excessive back pressure which results in slow drying, increased use of energy, and shutdown of the burner by the airflow (sail) switch, burner hi-limit, or lint chamber hi-heat protector thermostat. The dryer must be installed with a proper exhaust duct connection to the outside. - Page 18 NOTE: It is recommended that exhaust or booster fans not be used in the exhaust ductwork system except where necessary to maintain exhaust back pressure (in the exhaust duct) between zero and 0.3 in WC (0.74 mb). Where employed, booster fans must not activate the dryer airflow proving switch (sail switch) when the dryer is not in operation.
- Page 19 VERTICAL VENTING For single vertical venting, a minimum duct size of 10-inches (25.4 cm) must be used (refer to Illus. B below), the ductwork from the dryer to the outside outlet cannot exceed 60 feet (18.29 meters), refer to Illus. B below. This calculation compensates for the use of a maximum of three (3) elbows including the two (2) elbows creating the 180°...
- Page 20 MULTIPLE DRYER (COMMON) VENTING If it is not feasible to provide separate exhaust ducts for each dryer, ducts for individual dryers may be channeled into a common main duct. Each dryer is provided with a back draft damper. The individual ducts should enter the bottom or side of the main duct at an angle not more than 45°...
- Page 21 HORIZONTAL VENTING Illus. C VERTICAL VENTING Illus. D 113066 - 17 www.adclaundry.com...
-
Page 22: Electrical Information
F. ELECTRICAL INFORMATION 1. Electrical Requirements ALL electrical connections must be made by a properly licensed and competent electrician. This is to ensure that the electrical installation is adequate and conforms to local, state, and national regulations or codes of the country of destination. In the absence of such codes, ALL electrical connections, materials, and workmanship must conform to the applicable requirements of National Electric Code ANSI/NFPA 70, or in Canada, Canadian Electric Code CSA C22.1. - Page 23 2) Electric Models ONLY ALL electrically heated dryers must be connected to the electric service shown on the dryer’s data label, which is affixed to either the back side of the upper control door or left side panel/wall area behind the control door. The connecting wires must be properly sized to handle the rated current.
- Page 24 INGLE HASE Ø LECTRICAL ONNECTIONS EADS Black White Green Positive Neutral Ground If local codes permit, power to the dryer can be made by the use of a flexible U.L. listed power cord or pigtail (wire size must conform to rating of dryer), or the dryer can be hard wired directly to the service breaker panel.
- Page 25 5. 3-Phase (3ø) Wiring Connections/Hookup The only electrical input connections to the dryer are the 3-phase (3ø) power leads (L1, L2, L3, and sometimes Neutral) and ground. Single-phase (1ø) power for the control circuit is done internally to the dryer. No single-phase (1ø) input connection is required on a 3-phase (3ø) dryer. IMPORTANT: A SEPARATE CIRCUIT SERVICING EACH DRYER MUST BE PROVIDED.
- Page 26 CAUTION: The dryer must be grounded. A ground lug has been provided for this purpose. IMPORTANT: A SEPARATE CIRCUIT SERVICING EACH DRYER MUST BE PROVIDED. The only electrical connections to the dryer are the 3-phase (3ø) leads (L1, L2, L3, and sometimes Neutral) and ground.
- Page 27 WARNING: 208 VAC AND 240 VAC ARE NOT THE SAME. Any damage done to dryer components due to improper voltage connections will automatically VOID THE WARRANTY. NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. 113066 - 17...
- Page 28 ELECTRIC ELECTRIC ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET) ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET) IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. specify exact voltage. NOTES: When fuses are used they must be dual element, time delay, current NOTES:...
- Page 29 WARNING: 208 VAC AND 240 VAC ARE NOT THE SAME. Any damage done to dryer components due to improper voltage connections will automatically VOID THE WARRANTY. NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation. NOTES _____________________________________________________________________________________________________________________...
-
Page 30: Gas Information
The adjustment or conversion of dryers in the field for elevations over 2,000 feet (609.6 meters) is made by changing each burner orifice. If this conversion is necessary, contact the reseller who sold the dryer or contact the ADC factory. American Dryer Corp. - Page 31 There is no regulator or regulation provided in a propane dryer. The water column pressure must be regulated at the source (propane tank) or an external regulator must be added to each dryer. Propane TYPE OF GAS Conversion Natural Propane kcal/hr ADC Model Btu/hr Part Rating Number Rating Qty. D.M.S.* Part No.
- Page 32 3. Piping Connections ALL components/materials must conform to National Fuel Gas Code Specifications ANSI Z223.1-LATEST EDITION, or in Canada, CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Propane Gas) or LATEST EDITION (for General Installation and Gas Plumbing), as well as local codes and ordinances and must be done by a qualified professional.
- Page 33 The size of the main gas supply line (header) will vary depending on the distance this line travels from the gas meter or, in the case of propane gas, the supply tank, other gas-operated appliances on the same line, etc. Specific information regarding supply line size should be determined by the gas supplier. NOTE: Undersized gas supply piping can create a low or inconsistent pressure, which will result in erratic operation of the burner ignition system.
-
Page 34: Steam Information
H. STEAM INFORMATION It is your responsibility to have ALL steam plumbing connections made by a qualified professional to assure that the installation is adequate and conforms to local and state regulations or codes. Care must be exercised when leveling steam dryers into final position. After leveling the dryer, check the downward pitch of the heat exchanger from front to rear with a level. - Page 35 a. The presence of condensate in the steam supply will cause water hammer and subsequent heat exchanger (steam coil) failure. The steam supply connection into the main supply line must be made with a minimum 10-inch (25.4 cm) riser. This will prevent any condensate from draining towards the dryer. b.
- Page 36 4. Steam Damper Air System Connections This dryer is manufactured with a pneumatic (piston) damper system, which requires an external supply of compressed air. The air connection is made to the steam damper solenoid valve, which is located at the rear inner top area of the dryer just in front of the electric service relay box.
- Page 37 5. Steam Damper System Operation The steam damper, as shown in the illustration below, allows the coil to stay constantly charged eliminating repeated expansion and contraction. When the damper is opened, the air immediately passes through the already hot coil, providing instant heat to start the drying process. When the damper is closed, ambient air is drawn directly into the tumbler, allowing a rapid cool down.
- Page 38 6. Steam Damper Air Piston (Flow Control) Operation Adjustment Damper operation was tested and adjusted prior to shipping at 80 PSI (5.51 bars). If damper air adjustment is necessary, locate the flow control valve and make the necessary adjustments as noted below. American Dryer Corp.
-
Page 39: Preparation For Operation/Start-Up
I. PREPARATION FOR OPERATION/START-UP The following items should be checked before attempting to operate the dryer: 1. Read ALL “CAUTION,” “WARNING,” and “DIRECTION” labels attached to the dryer. 2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label that is affixed to either the back side of the upper control door or left side panel/wall area behind the control door. -
Page 40: Preoperational Test
J. PREOPERATIONAL TEST ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. Installer must instruct the user on how to correctly operate the dryer before leaving. -
Page 41: Preoperational Instructions
5. Make a complete operational check of ALL operating controls. NOTE: If computer program changes are required, refer to the computer programming section of the manual supplied with the dryer. 6. The dryer should be operated through one (1) complete cycle to assure that no further adjustments are necessary and that ALL components are functioning properly. - Page 42 NOTES: 1. If the Anti-Wrinkle program is active, the light emitting diode (L.E.D.) display will continue to read “donE,” and the microprocessor controller (computer) will proceed through the Anti-Wrinkle program until the maximum “Active Guard Time” has expired or until the door is opened, whichever comes first. The L.E.D. display will read “FILL” and/or “Amount To Start.”...
- Page 43 b. Select Temperature... The dryer will start, the light emitting diode (L.E.D.) display will read the temperature cycle selected, and the drying time portion of the L.E.D. display will read “00” and count upward as time elapses, or the vended time will count downward, depending on the program parameter setting. IMPORTANT: If the door is opened during a cycle, both the heat and motor will stop.
-
Page 44: Shut Down Instructions
2) Press the “E” on the keypad. 3) The light emitting diode (L.E.D.) display will quickly show “Ld30,” “LC04,” “F180.” The dryer will start, and the L.E.D. display will show “dr30.” b. Dual timer dryers... 1) Turn drying timer knob for a time of 20 minutes. 2) Select “High Temp.”... -
Page 45: Service/Parts Information
1. Replacement parts should be purchased from the reseller from whom the ADC equipment was purchased. If the reseller cannot be contacted or is unknown, contact the ADC Parts Department for a reseller in your area. Parts may also be purchased directly from the factory by calling the ADC Parts Department at +1 (269) 923-3000 or you may FAX in your order at +1 (508) 678-9447. -
Page 46: Warranty Information
A. RETURNING WARRANTY CARDS 1. Before any dryer leaves the ADC factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim. - Page 47 IMPORTANT: No replacements, credits, or refunds will be issued for merchandise damaged in transit. 5. ALL returns should be shipped to the ADC factory in such a manner that they are insured and a proof of delivery can be obtained by the sender.
-
Page 48: Routine Maintenance
Maximum operating efficiency is dependent upon proper air circulation. The accumulation of lint can restrict this airflow. If the guidelines in this section are met, an ADC dryer will provide many years of efficient, trouble-free, and most importantly, safe operation. -
Page 49: Adjustments
Use Shell Alvania #2 or its equivalent. The tumbler bearings used in the dryer DO NOT have a grease fitting. Provisions are made in the bearing housing for the addition of a grease fitting which can be obtained elsewhere, or from ADC by ordering kit Part No. 882159, which includes two (2) grease fittings. -
Page 50: Troubleshooting
SECTION VII TROUBLESHOOTING IMPORTANT: YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health Administration) STANDARDS. - Page 51 C. Drive motor (reversing) operates in one (1) direction only...stops and restarts in same direction... 1. Failed drive motor contactor (relay). 2. Failed arc suppressor (A.S.) board (for reversing models only). 3. Failed microprocessor controller (computer). D. Drive motor operates okay for a few minutes and then stops and will not restart... 1.
- Page 52 H. Both drive motor and blower motor run a few minutes and then stop...microprocessor controller (computer) display continues to read time or percent of extraction and ALL indicator dots are off... 1. Fault in main door switch circuit... a. Failed main door switch. b.
- Page 53 N. Dryer stops during a cycle and light emitting diode (L.E.D.) display returns to “FILL”... 1. Fault in microprocessor heat sensor circuit... a. Loose connection in wires between temperature sensor and microprocessor controller (computer). 2. Loose connection somewhere in main power circuit to microprocessor controller (computer). O.
- Page 54 ELECTRIC MODELS ONLY 1. Fault in sail switch circuit... a. Sail switch is out of adjustment and/or failed. b. Sail switch is not closing or fluttering... 1) Check blower (impellor/fan) motor and rotation direction. 2) Restriction in location exhaust system. 2.
- Page 55 10. Failed microprocessor temperature sensor...calibration is inaccurate. 11. Failed burner/oven hi-limit (for gas and electric models only). 12. Failed lint compartment hi-limit. 13. Steam damper system is not functioning properly (for steam models only)... a. Damper sticking closed. b. Leak in pneumatic (air) system. 14.
-
Page 56: Dual Timer Models
U. Main burners are burning with a yellow flame (for gas models only)... 1. Burner air shutters are out of adjustment. 2. Insufficient make-up air. 3. Dust and/or lint in burner. 4. Insufficient gas pressure. DUAL TIMER MODELS A. Dryer will not start...both drive motor and blower motor are not operating (indicator light is off)... - Page 57 E. Reversing drive motor operates in one (1) direction only, stops, and restarts in same direction (for reversing models only)... 1. Failed reversing contactor (relay). 2. Failed reversing timer. Heating unit is not operating (ALL temperature selections)... GAS MODELS ONLY 1.
- Page 58 G. Heat unit is not operating for only one (1) temperature selection... 1. Failed thermostat corresponding to selection made. 2. Failed heat selector switch. H. Dryer operates but is taking too long to dry load... 1. Heating unit cycling on hi-limit thermostat (for gas and electric models only). 2.
-
Page 59: Data Label Information
When contacting American Dryer Corporation certain information is required to ensure proper service/parts information from ADC. This information is on the data label either located to the back side of the upper control door or left side panel/wall area behind the control door. -
Page 60: Reversing Timer Spin/Dwell Adjustments
SECTION IX REVERSING TIMER SPIN/DWELL ADJUSTMENTS Dual timer models with “reversing option” have an electric reversing timer in the electric service box, which is located in the upper rear area of the dryer. Both the dwell (stop) time and tumbler spin time are adjustable by mode selection switches located on the electronic timer (as noted in the illustration below). -
Page 61: Procedure For Functional Check
SECTION X PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor Controller (Computer) Board a. Upon completing installation of the replacement microprocessor controller (computer) board, reestablish power to the dryer. b. Start the drying cycle. c. Verify that the motor(s) and the heat indicator dots, in the microprocessor controller (computer) light emitting diode (L.E.D.) display are on. - Page 62 e. Open main door. The dryer must stop and ALL output indicator lights on the back side of the microprocessor controller (computer) board must go out. (Refer to the illustration on the previous page.) f. Try to restart the dryer with the main door open. g.
- Page 63 3. For Direct Spark Ignition (DSI) System Models Manufactured With ADC Module Part No. 880815 a. Upon completing installation of the replacement DSI module, reestablish power to the dryer. b. Starting the drying cycle. c. The ignition DSI module’s light emitting diode (L.E.D.) indicator will light “red”...
-
Page 64: Burner And Tumbler/Lint Chamber
The location of the manual reset hi-limit switch is on the right side of the burner box. IMPORTANT This dryer is equipped with a burner hi-limit and tumbler/lint chamber hi-limit thermostat which must be reset manually. WARNING: Discontinue power to dryer before attempting to reset hi-limit. ADC P/N:114093 American Dryer Corp. 113066 - 17... -
Page 65: Electric Or Steam Models Only
WARNING: Discontinue power to dryer before attempting to reset hi-limit. IMPORTANT This dryer is equipped with a lint chamber hi-limit thermostat which must be reset manually. WARNING: Discontinue power to dryer before attempting to reset hi-limit. ADC P/N:114501 113066 - 17 www.adclaundry.com... - Page 66 ADC Part No. 113066 17 - 05/13/22...
