Summary of Contents for Philips Efficia Rack
- Page 1 Installation and Configuration Guide Efficia Rack Release A.01 Revision B English...
- Page 2 Part Number 453564626901 Revision B First Edition ...
- Page 3 Efficia Rack I N S T A L L A T I O N A N D CO NF I G U RA T I O N G UI DE Release A.01 Revision B English...
- Page 4 Copyright Copyright © 2016 Koninklijke Philips N.V. All Rights Reserved Trademark Acknowledgements Efficia is a registered trademark of Koninklijke Philips N.V. Other product names may be trademarks of their respective owners. Manufacturer Philips Goldway (Shenzhen) Industrial, Inc. Goldway Building, No.2 North Keji No. 3 Road , Nanshan District Shenzhen, P.R.China 518057...
- Page 5 A Caution calls attention to a condition or possible situation that could damage or destroy the product or the user’s work. Warning A Warning calls attention to a condition or possible situation that could cause injury to the user, patient, or both. Efficia Rack Installation and Configuration Guide iii...
- Page 6 Stacking limit by Humidity limitation number Atmospheric pressure limitation Input/Output Connector Port Symbols The following symbols appear next to the input/output ports on the rear panel of the rack. Description Symbol PoweredUSB port iv Efficia Rack Installation and Configuration Guide...
- Page 7 Serial number Part number Model number Unique Device Identification code (barcode) Caution, consult Ingress protection accompanying against vertically documents falling water drops Compliance with INMETRO mark WEEE standard Made in Manaus mark Efficia Rack Installation and Configuration Guide v...
- Page 8 Anyone who connects additional equipment to the signal input port or signal output port configures a medical system and is therefore responsible to ensure compliance with the system requirements of NBR IEC 60601-1. If in doubt, contact the Philips Customer Care Solutions Center or your local Philips representative. Warning If multiple instruments are interconnected or if multiple instruments are connected to a patient, the sum of the leakage currents may exceed the limits given in ABNT NBR IEC 60601-1 system requirements.
-
Page 9: Table Of Contents
Connecting the Plug-in Modules to the Rack ....................2-11 Returning the Rack ............................3-1 Submitting a Damage Claim ........................... 3-1 Returning the Rack For Service ........................3-1 Disposing of the Rack ............................. 3-2 Contents-1 Efficia Rack Installation and Configuration Guide... -
Page 11: Introduction
1 Introduction Overview This guide describes how to install and configure an Efficia Rack. This rack shall be referred to as the “Efficia rack” throughout this guide. The Efficia rack expands the capabilities of physiological parameters measurement of the Efficia CM120 and CM150 patient monitors (with software version B.XX or newer). -
Page 12: Efficia Rack Documentation
Efficia Rack Documentation Efficia rack documentation includes: • Manual de Operação do Rack Efficia: Provides information for day to day operation of the Efficia rack. Also includes safety information, rack specifications, and compatible accessories. Note — For information about purchasing additional copies of the Manual de Operação do Rack Efficia, contact the Philips Customer Care Center. -
Page 13: Unpacking And Installing The Rack
• Bottom support • Support plate • Universal clamp • Arm mount • Rail Note — For information about purchasing the support accessories, contact the Philips Customer Care Center. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide... -
Page 14: Part Numbers
Unpacking the Rack Warning • Unless otherwise specified, hardware products and accessories not supplied by Philips are not approved or supported for use with the Efficia CM Series monitors and the Efficia Rack. • Properly secure the rack when in use to avoid injury to patient and staff. -
Page 15: Installing The Optional Bottom Support With The Universal Clamp
Installing the Optional Bottom Support with the Universal Clamp The optional bottom support can be installed on the Efficia rack to serve as an interface for the connection of the support accessories. To install the optional bottom support with the universal clamp: Step First you need to assemble the support accessory into the bottom support. - Page 16 If you connect the Dixtal Gases module, ensure that the rack is positioned in a way that watertrap can be used in the vertical position. Otherwise the efficacy of the filter of the watertrap cannot be guaranteed. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide...
-
Page 17: Installing The Optional Support Plate With The Universal Clamp
Installing the Optional Support Plate with the Universal Clamp Installing the Optional Support Plate with the Universal Clamp The optional support plate can be installed on the Efficia rack to serve as an interface for the connection of the support accessories. - Page 18 If you connect the Dixtal Gases module, ensure that the rack is positioned in a way that watertrap can be used in the vertical position. Otherwise the efficacy of the filter of the watertrap cannot be guaranteed. Note — The maximum aperture of the Universal Clamp is 40mm. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide...
-
Page 19: Installing The Optional Support Plate With The Arm Mount
Tighten the screws that come with the support accessory into the center of the support plate. Note — Ensure to follow any additional instructions that comes with the support accessory. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide... -
Page 20: Connecting The Rack To The Monitor
Do not allow liquid to enter the connectors. Wet connectors could prevent connected devices from operating. If liquid spills on the connectors, clean and dry it thoroughly before reuse. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide... - Page 21 Connect the other end of the PoweredUSB cable into the PoweredUSB connector located on the rear panel of the monitor. Ensure that cable is safely attached to both the rack and the monitor. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide...
-
Page 22: Powering Up
The rack LED turns on with the color blue. After a few seconds the rack LED turns green. The rack icon appears on the bottom of the main screen of the monitor. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide 2-10... -
Page 23: Connecting The Plug-In Modules To The Rack
If you connect the Dixtal Gases module, ensure that the rack is positioned in a way that watertrap can be used in the vertical position. Otherwise the efficacy of the filter of the watertrap cannot be guaranteed. Unpacking and Installing the Rack Efficia Rack Installation and Configuration Guide 2-11... -
Page 25: Returning The Rack
Returning the Rack For Service To return the rack for service, call the Philips Customer Care Solutions Center or your local Philips representative for a Returned Materials Authorization (RMA) number. Have all equipment serial numbers available when calling. Mark the shipping carton and any shipping documents with the RMA number. -
Page 26: Disposing Of The Rack
- including all Instructions for Use - are passed on to the new user. A new user should be made aware of the support services that Philips Customer Care Solutions Center provides for installing, commissioning and maintaining the equipment or system, and for the comprehensive training of operators. - Page 27 Previous users who are not able or prepared to do this should inform the Philips Customer Care Solutions Center about the new user, so that Philips Customer Care Solutions Center can provide the new user with safety-related information.
