  • Page 1 Desktop 3 Microfilmer User’s Guide A-61036 Part No. 4C2063...
  • Page 2 Safety Information for the Kodak Desktop 3 Microfilmer IMPORTANT: Equipment shall be installed by qualified personnel. WARNING: Dangerous voltage. Disconnect the main power before installation. CAUTION: Moving parts, avoid contact ATTENTION: Eviter le contact, pieces en mouvement VORSICHT: Bewegliche teile, berüehrung vermeiden...
  • Page 3 Acoustic Emission Maschinenläerminformations verordnung – 3, GSGV Der arbeitsplatzbezogene Emissionswert betraegt <70 dB(A). [ Machine Noise Information Ordinance – 3, GSGV – The operator-position noise emission value is <70 dB(A) ]. This equipment was designed for connection to IT Power Systems. Following is some additional safety and regulatory Safety and Regulatory information.
  • Page 4 The Kodak Imagelink Desktop 3 Microfilmer (including the Regulatory Information Image Mark and Endorser accessories) has been tested and complies with the following standard. Product Safety • CSA NRTL/C marked and certified by Canadian Standards Association to CSA 22.2 No. 950 and UL 1950.
  • Page 5 Introduction The Kodak Desktop 3 Microfilmer is intended for medium-to low-volume operations that require rapid, high-reduction microfilming. Documents up to 9.00 inches (22.9 cm) wide and 11.7 inches (29.7 cm) long can be microfilmed, with images captured on 16 mm film at a 40:1 reduction ratio.

  • Page 6: Product Description

    1 Overview Product description You should become acquainted with the Kodak Desktop 3 Microfilmer before operating it. Important parts of the microfilmer are identified in Figure 1. Control Panel Cabinet Document Cover Exit Guides and Stop Receiving Area Power Switch...
  • Page 7 The control panel contains the following displays and switches, plus the Desktop Image Marker switches (See Optional Accessories later in this section). Document Counter Reset 1 Out of Film Lamp Indicator Failure Feeder Adjust Indicators Reset 2 Film Odometer Slow Film Advance Endorser On/Off...
  • Page 8 Document Counter: An eight-digit counter that shows how many documents have been processed by the microfilmer. Pressing the button below the display resets the counter to zero. It is possible to count documents without microfilming them (See Filming Switch on the previous page).

  • Page 9: Optional Accessories

    Optional accessories Kodak Desktop III Endorser The Desktop Endorser automatically endorses checks and other documents after they are microfilmed but before they are discharged into the receiving area. Features include: • Disposable ink supply rollers available in red, purple, green or black •...

  • Page 10: Document Requirements

    2 Document/Film Overview Film requirements The Kodak Desktop 3 Microfilmer uses single, 16 mm rolls of Kodak Microfilm or equivalent. Recommended films include: • Kodak Imagelink HQ Microfilm 1461 • Kodak Imagelink HQ Microfilm 3461 NOTE: When using Kodak Imagelink FS Microfilm, an exposure adjustment and a filter addition must be made.

  • Page 11: Operating Requirements

    3 Operating Requirements Physical dimensions The Kodak Desktop 3 Microfilmer has the following physical dimensions: Height: 13.0 inches (33.0 cm) Width: 19.0 inches (48.3 cm) Depth: 23.0 inches (58.4 cm) Weight: 98.0 pounds (44.5 kg) Space planning You should allow for additional space in which to operate the microfilmer: •...

  • Page 12: Power Requirements

    A standard three-prong, grounded power outlet is required for operation within the United States and Canada. CAUTION: The Desktop 3 Microfilmer is set at the factory for 120 volts ac operation in the United States and Canada. If you require a different power configuration, contact your Equipment Services Representative for Kodak products.

  • Page 13: Standard Operation

    (21°C), the microfilmer should be powered up for 10 minutes before microfilming is begun. Standard operation The Desktop 3 Microfilmer is capable of either duplex or duo microfilming. In the duplex mode, the front and back of each document are microfilmed simultaneously and imaged side-by-side across the film width.

  • Page 14: Loading Film

    To load a new roll of film: 1. Select the desired film and appropriate cassette. Thick-base (5 mil) film is inserted into a Kodak Reliant Cassette 100; thin-base (2.5 mil) film is inserted into a Kodak Reliant Cassette 215. 2. Place the cassette on a flat surface, latch side up. Press down on the cover latch and turn it counterclockwise.
  • Page 15 6. Hold the roll with its No. 2 side up and place it on the supply spindle so that the No. 2 on the spool is aligned with the No. 2 on the spindle. Rotate the spool so that the spindle hole and post holes line up with the supply spindle and its flange posts in the cassette.
  • Page 16 11. Seat the spool on the spindle. Be sure the film can move freely and is not twisted. When properly loaded, it will look like Figure 6. Figure 6 Properly Loaded Microfilm Cassette 12. Place the cover on the cassette. To secure the cover, press down on the latch and turn it clockwise.
  • Page 17 Unloading full rolls When a roll of film is almost at its end, an alarm will sound and the supply indicator will be at or near the clear circle on the cassette label. IMPORTANT: Unload film in an area with subdued lighting. To unload the film and prepare it for processing: 1.
  • Page 18 Unloading partial rolls A partial roll can also be removed for processing. It can be cut and removed, leaving the remaining film in the cassette for additional microfilming. Have a pair of scissors and an extra film box handy and proceed as follows: CAUTION: Advance film before removing and opening cassette for cutting the film to avoid fogging images.

  • Page 19: Adjusting Exposure

    Adjusting exposure CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film. A rotating thumbwheel control at the inside rear of the microfilmer calibrates film exposure.

  • Page 20: Adjusting The Feeder

    Adjusting the feeder Feed rollers may need to be adjusted when there has been a significant change in document thickness. When adjusted properly, the feeder allows one document at a time to enter the microfilmer. This controls document feeding and avoids overlapping or lost images. Various conditions may require readjustment of the feeder rollers.
  • Page 21 6. If the test document does not feed into the microfilmer, the gap is too small. Turn the feeder adjustment knob two clicks to the left until the document feeds into the microfilmer and unfolds as it passes between the feed rollers. 7.
  • Page 22 Microfilming documents Before you start microfilming, be sure documents are free of paper clips, rubber bands, staples, and loose pieces of tape. Foreign objects can cause document jams and damage the feeder and conveyor system. Also determine how much film is available by checking the film supply indicator on the film cassette.
  • Page 23 7. Fan the stack of documents by alternating pressure at the front and back edges as shown in Figure 10. Figure 10 Fanning a Stack of Documents 8. Place the fanned stack of documents into the feeder. The leading edge of the first document should be between the feed rollers. The documents will be discharged face down into the receiving area in their original sequence.

  • Page 24: Clearing A Jam

    Clearing a jam 1. Turn the microfilmer off. CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film. 2.
  • Page 25 7. Lift the document guides, remove any documents and replace the guides. Figure 14 8. Lower the upper transport and latch. 9. Remove any documents under the lower conveyor belt assembly by pushing the two latches outward to release the assembly. Figure 15 10.

  • Page 26: Operating Controls And Indicators

    5 Operating the Desktop Endorser Operating controls You should become acquainted with the Endorser controls and indicators before operating the Endorser. and indicators Imprint Mode Swtich Die Drum Location Control Date Knob Figure 16 CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film.
  • Page 27 The date knob rotates to change the date and code number. To change either, slide the knob to the right, from its “run position.” The index label indicates the correct knob position for changing the date and code number. Before you begin to use the Endorser, make certain that the: •...

  • Page 28: Setting The Mode Switch

    Setting the mode switch The mode switch is a two-position switch that sets the Endorser to imprint check-size documents or documents having a feeding length greater than 5 inches (12.7 cm). To set the mode switch: CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film.
  • Page 29 Setting the imprint The imprint location control can be set so the Endorser will imprint the document at any point between approximately 1 and 12 inches (2.5 and location control 30.5 cm) from its leading edge, depending upon document length. To set the imprint location control: CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be...
  • Page 30 2. The imprint location control rotates between two limits, fully clockwise and fully counterclockwise. Adjusting this control varies the location of the imprint. IMPORTANT: Each of the following adjustments begins with the imprint location control turned fully clockwise. • To imprint 1 inch (2.5 cm) from the document's leading edge, set the control one-tenth of the distance it can rotate.
  • Page 31 Endorser accessory — If an Endorser is installed, follow the steps below to clear a jam that occurs in the upper transport area. clearing a jam To clear a jam: CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film.
  • Page 32 Changing the ink roller The ink roller will need to be replaced when the entire imprint on documents becomes uniformly weak. CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film.
  • Page 33 4. Discard the roller. 5. Remove the new ink roller from the container and take it out of the plastic bag. 6. While holding ink roller handle down, lower the new ink roller into its brackets as shown. 7. Close the microfilmer cover. 8.
  • Page 34 Removing and replacing The Endorser die drum can be easily removed for cleaning, exchanging the Endorser die drum die drums, or replacing Endorser dies. CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film.
  • Page 35 3. Use a plastic glove or paper towel to hold the die drum while sliding the date knob to the right. Figure 24 Removing the Endorser Die Drum 4. Slide the die drum off of the die drum holders. Figure 25 Removing the Endorser Die Drum 5.
  • Page 36 Changing Endorser dies The Endorser dies are two identical curved printing plates mounted on the exterior of the die drum. New dies will be necessary when the old dies become worn. CAUTION: Any time the microfilmer cover is opened with the film cassette installed, the film compartment latch must be unlocked (by rotating the latch downward) to prevent room light from exposing (fogging) the film.
  • Page 37 6 Operating the Image Marker Image marks are rectangular, black exposures placed along the edge of the film by the microfilmer. The marks are used to locate individual documents and sets of documents during retrieval. Image marks can also separate jobs on the processed roll of film. Three image mark sizes or levels can be thought of in terms of books, chapters, and pages.
  • Page 38 3. To turn off automatic decrement: Lift the microfilmer cover. At the left rear side of the microfilmer, slide automatic decrement switch #5 to the OFF position. Figure 29 Setting the Automatic Decrement Switch (Switch #5) Notice that switch #5 is one of eight switches located next to each other on a circuit board at the left rear side of the microfilmer.

  • Page 39: Operating The Footswitch

    This optional accessory allows you to change image mark levels with your foot without using the control panel. (Your Equipment Service Representative for Kodak products will install and preset the Footswitch to meet your needs.) Actuating the Footswitch changes the image mark level to the level which has been preselected.

  • Page 40: Maintenance Procedures

    8 Maintenance Procedures Use of attachments that are not recommended may cause hazards and serious damage to the equipment. Microfilmer care IMPORTANT: DO NOT use commercial cleaning solvents in any of the following cleaning instructions. Wipe the exterior of the microfilmer with a soft cloth, water-dampened if necessary, to remove fingerprints, stains, or other soil marks.
  • Page 41 4. Press the upper transport latch to the left; then, lift up the upper transport. Upper Transport Latch Figure 30 Lifting the Upper Transport 5. Lift the document guides out of the spring holder on the left side and pull up both guides simultaneously. Document Guides Figure 31 Lifting the Document Guides for Cleaning...

  • Page 42: Cleaning The Mirrors

    Cleaning the mirrors Four mirrors in the optical system of the microfilmer must be kept clean to maintain high-quality film images. The mirrors are the Front 45° Mirror, two Rear 45° Mirrors, and the Lens Mirror. Lens Mirror Rear 45° Mirror Rear Lamp Housing...
  • Page 43 For lamp replacement, contact your equipment service representative for Kodak products. Caring for the Endorser Routine maintenance will keep the Endorser in good operating condition and printing high-quality impressions.
  • Page 44 If in doubt, call your service representative for Kodak products. CAUTION: Be careful not to break the fuses when you remove them. 3. The fuses are located in the lower portion of the module. Verify that a fuse has blown.

  • Page 45: Troubleshooting Charts

    9 Troubleshooting Charts Microfilmer Trouble Probable Cause Remedy Microfilmer does not start. Power cord not connected properly. Push the plug all the way into receptacle and into the power module. Power supply fuse blown. Check fuses in power module. Replace blown fuse(s) with identical type and rating.
  • Page 46 Trouble Probable Cause Remedy No images on film. Filming switch in the Not Filming Press filming switch to turn on mode. filming mode. Dot (.) appears in upper left corner Counter needs to be reset or Press the reset button. If this does of document counter and/or film batteries are weak.
  • Page 47 Kodak Imagelink HQ Microfilm 3461 (Estar Thin Base) 16 mm x 215 feet (65.5 m)........CAT 845 1502 Acceptable but not recommended for the Desktop 3 Microfilmer: (Equipment requires modification by an Equipment Service Representative for Kodak products if these film products are used.) Kodak Imagelink FS Microfilm 1455 (Estar Base) 16 mm x 100 feet (30.5 m)........

  • Page 48: Appendix A Duo Microfilming

    Appendix A Duo Microfilming If duo microfilming mode is desired, a special mask must be ordered from and installed by your Equipment Service Representative for Kodak products. The mask prevents the other half of the film from being exposed to light.

  • Page 49: New Equipment Warranty

    This limitation of liability will not apply to claims for injury to persons or damage to property caused by the sole negligence or fault of Kodak or by persons under its direction or control. A-61036 July 2000...
  • Page 50 For installations in countries other than the United States, the terms and conditions of the new equipment warranty will be provided by the Kodak company in the country in which the sale is finalized, or by a Kodak- appointed distributor in those countries where Kodak does not have direct sales representation.
  • Page 51 EASTMAN KODAK COMPANY Document Imaging Rochester, New York 14650 Kodak, Recordak, Reliant, Infocapture, Imagecapture, AHU, and Estar are trademarks. Printed on recycled paper. DOCUMENT A-61036 7/00 Eastman Kodak Company, 2000 IMAGING Printed in U.S.A.
