MVOICE 1000-T
Wireless Daisy-Chain Conference Speakerphone
Thank you for your purchase of the MVOICE1000-T. This device is the first in the industry to provide a
wireless daisy-chain function .The MVOICE 1000-T's cutting-edge speakerphone combines 2
conference speakerphones(Master Slave speakerphone + Slave speakerphone), each speakerphone is
built with a wideband speaker and 3 embedded directional microphones, resulting in top-quality audio
performance.
Highlights:
1. Uses digital wireless technology and strong anti-interference technology.
2. Each speakerphone employs 3 microphones, broadband speaker output and speech enhancement.
3. Supporting operating systems Windows, Mac and Android.
4.Slave speakerphone connect with master device via 2.4G Wireless technology transmission, the
master speakerphone simply to connect with PC/ laptop by USB cable
5. Master speakerphone and Slave speakerphone can used alone.
6. Extra-low power consumption technology.
7. Algorithms for echo cancellation, noise cancellation, automatic gain control are built in.
What's in the box:
MVOICE1000-T Speakerphone (included MASTER&SLAVE units)
User Manual
USB 2.0 Cable x2 ( 2meters)
Preparation for use
MVOICE1000-T can be used as an external microphone and speaker for a computer or conference
system, enabling software based teleconferencing.
It is compatible with operating systems including Microsoft Windows 7/8/10, Android and Apple iOS.
A USB 2.0 or above port and network connection are required; an IM application or VoIP package
(e.g. WebEx, Zoom.us, Skype, GotoMeeting) with network conferencing function should be installed.
USB connection for Master unit
Plug and play, simply connect the MVOICE 1000-T Master to the USB port on your PC with USB cable.
Wireless Connection for Slave unit
Step 1: Connect Master Speakerphone to your computer via usb cable.
Step 2: Turn the power button to ON side of Slave speakerphone, all 3 microphone indicators
lighted up in orange.
Step 3: Long press (2sec.) the wireless pairing button
on the Slave speakerphone, until the button
indicator light blinking.
Step4: Long press (2sec.) the wireless pairing button
on the Master Speakerphone, until the button
indicator light turns to solid blue, the wireless connection is established. The pairing button indicator
on Slave unit keeps blinking.
Turn off the wireless connection
Long press the wireless pairing button
on Master speakerphone to close the wireless connection,
the Master unit's wireless pairing button indicator turns off when the connection is stopped. The
