Summary of Contents for ALDI Auto XS FLX-WH-01

  • Page 1 Original Instructions HYDRAULIC TROLLEY JACK...
  • Page 3: Table Of Contents

    Contents Overview ������������������������������������������������������������������������������ 4 Use ���������������������������������������������������������������������������������������� 5 Total content /parts ������������������������������������������������������������� 6 General information ������������������������������������������������������������� 8 Please read and store the instructions ����������������������������������� 8 Explanation of symbols ������������������������������������������������������������ 8 Safety ����������������������������������������������������������������������������������� 9 Correct use ��������������������������������������������������������������������������������� 9 Safety instructions �������������������������������������������������������������������� 9 First use ������������������������������������������������������������������������������14 Check the car jack and the total content �������������������������������...
  • Page 6: Use

    Total content / parts Saddle holder Saddle bolt Saddle sleeve Saddle Lifting arm Cover plate Handle sleeve Jack handle Carry handle Release valve Carry handle nut Jack handle clip, 4× Drilled hole – User Manual / Warranty Card...
  • Page 8: General Information

    General information GENERAL INFORMATION Please read and store the instructions These instructions for use are valid for this hydraulic trolley jack for vehicles (hereafter referred to as “car jack”), and contain important information of its setup and use� Before using the car jack, carefully read the instructions� This applies primarily to the safety instructions�...
  • Page 9: Safety

    Safety Declaration of conformity (see the “Declaration of conformity” section): Products marked with this symbol fulfil all of the rules, which they must adhere to, of the European Economic Area� The symbol GS confirms that the product is safe when used correctly� The symbol “GS”...
  • Page 10 Safety – The car jack should only be used for lifting and lowering vehicles� Danger of personal injury! DANGER! To avoid danger, the car jack and the vehicle must always be monitored during use� Failure to do so could lead to serious personal injury or even death�...
  • Page 11 Safety – Before each use examine the car jack� If you notice loose parts or damage, do not use the car jack� In this case, do not use the car jack; a qualified professional should examine it� – The car jack should only be used for the lifting and lowering of vehicles;...
  • Page 12 Safety − Do not approach the vehicle during lifting and lowering� − Always lower the vehicle slowly� − Before lifting the vehicle, apply the hand brake and place wedges under the wheels which will stay on the ground� − Only raise the vehicle where the manufacturer recommends� −...
  • Page 13 Safety Risk of injury! NOTICE With inappropriate handling, the car jack can be damaged� − Always ensure safe placement of the car jack (for the correct position, study the vehicle instructions)� The base must be hard (e�g� concrete), stable and flat and must withstand a load of up to 2 tonnes�...
  • Page 14: First Use

    First use FIRST USE Check the car jack and the total content Risk of injury! NOTICE Be very careful when opening the packaging� 1� Ensure that all parts and accessories are present (see picture A)� 2� Remove the car jack from the packaging and check if there is any damage to it or to any of the parts�...
  • Page 15: Saddle Assembling/Dismantling

    Saddle assembling/dismanteling Saddle assembling/dismantling Damage and injury risks! WARNING! If the saddle is removed from the saddle holder, the load will not lift equally and stably, which can lead to personal injury and material damage� − Never use the car jack if the saddle and/or saddle sleeve are not attached�...
  • Page 16: Assembling The Car Jack

    Assembling the car jack ASSEMBLING THE CAR JACK Fitting the carry handle On each side of the jack handle sleeve is a nut, where the carry handle is attached � 1� Place one of the “eyes” of the carry handle over the carry hand- (see picture C)�...
  • Page 17: Car Jack Use

    Car jack use CAR JACK USE Danger of personal injury! DANGER! If the car jack is not properly placed (under a vehicle), it will not be possible to lift vehicles steadily and they could also fall suddenly� This can cause serious injury or death� –...
  • Page 18: Vehicle Lifting

    Car jack use Vehicle lifting Danger of personal injury! DANGER! Never conduct work on, under or around a vehicle which is solely supported by a car jack� The vehicle is not stable and can fall suddenly and cause personal injury or even death� –...
  • Page 19: Vehicle Lowering

    Car jack use Vehicle lowering Danger of personal injury! DANGER! If there are people, animals or other objects in or under the vehicle, before lowering, this can cause personal injury or even death� − Always ensure that the area under the vehicle is clear, that there are no people, animals or objects under the vehicle, before lowering�...
  • Page 20: Troubleshooting

    Troubleshooting Troubleshooting Problem Possible reasons Solution The car jack will – Low on oil� – Add oil (see “Maintenance, not lift the repair and inspection” section)� vehicle� – Dirty oil is blocking the – Change the oil (see release valve� “Maintenance, repair and inspection”...
  • Page 21: Maintenance, Repair And Inspection

    Maintenance, repair and inspection MAINTENANCE, REPAIR AND INSPECTION Damage and injury risks! CAUTION! When the car jack is being used in a working area where oil is spilled, it can slip and cause material damage and/or personal injury� – Thoroughly clean the area where work will be carried out or where the vehicle will be lowered and raised�...
  • Page 22: Adding Oil

    Maintenance, repair and inspection Adding oil Damage and injury risks! WARNING! If too much oil is added to the reservoir, the car jack will become overloaded and can cause injury� – Only fill as much oil in the reservoir as recommended in this section�...
  • Page 23: Changing Oil

    Maintenance, repair and inspection Changing oil • Check the oil at least once a year; if dirt or foreign objects are noticed, change the oil� • If using the car jack regularly, the oil should be checked regularly� 1� Fully release the car jack and ensure that the release valve is turned clockwise, then lift the cover plate �...
  • Page 24: Cleaning And Storing

    Cleaning and storing CLEANING AND STORING Danger due to incorrect use! NOTICE With inappropriate handling, the car jack can be damaged� − Do not use abrasive cleaning products, brushes with metallic or nylon bristles, sharp or metallic cleaning aids, such as knives, hard scrapers and so on�...
  • Page 25: Technical Details

    Technical details / Waste disposal TECHNICAL DETAILS Model: FLX-WH-01 Lowest saddle height – with the sleeve: 150 mm – without the sleeve: 135 mm Highest saddle height with the sleeve – with a load: 350 mm – without a load: 357 mm Highest saddle height without the sleeve –...
  • Page 26: Declaration Of Conformity

    Declaration of conformity DECLARATION OF CONFORMITY...
  • Page 28 PRODUCED IN CHINA FOR: ALDI STORES LTD� PO BOX 26, ATHERSTONE WARWICKSHIRE, CV92SH� ALDI STORES (IRELAND) LTD�...
