- Page 1 ELECTRONIC DRUM RACK RACK DE BATTERIE ÉLECTRONIQUE 電子 ドラムラック Owner’s Manual Benutzerhandbuch Mode d’emploi Manual do Proprietário EN PT 取 扱説明書...
-
Page 2: Precautions
• Keep small parts out of the reach of infants. Your children may accidentally swallow them. Yamaha cannot be held responsible for damage caused by improper use or modifications to the product. NOTICE • Do not step on or place heavy objects on the product. It may result in damage. -
Page 3: Table Of Contents
Contents Precautions ..............2 Package Contents ............4 Assembling the Rack ........... 6 Attaching the Holders..........10 Troubleshooting............12 Specifications............. 12 ELECTRONIC DRUM RACK Owner’s Manual... -
Page 4: Package Contents
Package Contents After opening up the package containing your electronic drum rack, please verify that all of the follow- ing components are present. Main frame (×1) Left arm (×1) Right arm (×1) Left leg (×1) Right leg (×1) Tom holder (×3) Hi-hat holder (×1) Cymbal holder (×2) Snare holder (×1) - Page 5 Fully-assembled rack Left arm Clamp w Clamp r Clamp q Clamp t Right arm Left leg Right leg Clamp e Main frame For instruction on assembling the hi-hat holder, refer to the Assembly Manual that came with this electronic drum kit. ELECTRONIC DRUM RACK Owner’s Manual...
-
Page 6: Assembling The Rack
Assembling the Rack Lay the main frame down on a solid, level surface and loosen the key bolts in clamps q and w using the drum key. Clamp q Clamp w Drum key Key bolt Key bolt Drum key The drum key can be found in the pad set package. Loosen the bolts on clamps q, w, and e and move the clamps all the way down to the center strut. - Page 7 Push the left arm as far as it will go into clamp q on the main frame. When inserted, ensure that the arrow sticker ( ) on the left arm is lined up with the slit in clamp q. Left arm Arrow Clamp q...
- Page 8 Take the right arm from the package and push it as far as it will go into clamp w. When inserted, ensure that the arrow sticker ( ) on the right arm is lined up with the slit in clamp w. Clamp t Right arm Right arm...
- Page 9 Lift up the main frame and open up the left arm, the right arm, and the snare arm. Left arm Right arm Snare arm CAUTION Do not open up the rack’s left and right legs any more than shown in the figure below. Failure to observe this precaution can lead to the rack toppling over and causing injury.
-
Page 10: Attaching The Holders
Attaching the Holders Loosen the bolts on the following seven clamps (A to G) and rotate or move the clamps to the positions shown below. Following this, securely tighten all of the bolts to lock the clamps in place. • One snare clamp (A) •... - Page 11 Attach a tom holder to each of the three tom clamps. CAUTION Take special care with tom holders as they have sharp tips that could cause injury. Tom holder Bolt Tom clamp 2-1. Loosen the bolt on the tom clamp. 2-2.
-
Page 12: Troubleshooting
*: The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. Since specifications, equipment or separately sold accessories may not be the same in every locale, please check with your Yamaha dealer. - Page 13 Clarissenhof 5b, 4133 AB Vianen, The Netherlands P.O Box 10245, Petach-Tikva, 49002 Tel: +31-347-358040 Tel: (972) 3-925-6900 Head Office/Manufacturer: Yamaha Corporation 10-1, Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650, Japan DMI27 (For European Countries) Importer: Yamaha Music Europe GmbH Siemensstrasse 22-34, 25462 Rellingen, Germany...
