Owner's Manual
VBXR1090DCC/WW – Hotpoint Extra-Large 2.7 Cu. Ft. Capacity Washer
Washer Dimensions (in inches)
25-1/2
36
Side View
Specification Created 6/03
®
27
51
42
Rear View
Circuit Requirements: An individual, properly-grounded branch circuit,
with a three-prong grounding-type receptacle, protected by a 15 or
20 amp circuit breaker or a time-delay fuse, is required.
Electrical Rating: 115V, 60Hz, 10 Amps
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
Washer Note: Washer wall outlet must be located within 36" of
service cord entry. Wall outlet must not be located behind dryer.
Listed by
Underwriters
R
Laboratories
