Aiwa CX-NAJ50 Service Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

SERVICE MANUAL

COMPACT DISC STEREO

SYSTEM

NSX-AJ50

NSX-SZ50

• This Service Manual is the "Revision Publishing" and replaces "Simple Manual",

(S/M Code No. 09-99C-424-6T1).

• If requiring information about the CD mechanism, see Service Manual

of AZG-1, (S/M Code No. 09-001-335-3N6).

NSX-AJ50

NSX-SZ50

BASIC TAPE MECHANISM : ZZM-3 PR1NM

BASIC CD MECHANISM : AZG-1 ZD8RDM

CASSEIVER

SX-WNAJ50

CX-NAJ50

SX-WNSZ50

CX-NSZ50

S/M Code No. 09-003-424-6R1

REMOTE

SPEAKER

CONTROLLER

RC-ZAS02

RC-ZAS01

MC-Service

2ZM-3MK2 PR4NM

Table of Contents

Summary of Contents for Aiwa CX-NAJ50

Page 1 REMOTE SPEAKER SYSTEM CASSEIVER CONTROLLER SX-WNAJ50 RC-ZAS02 NSX-AJ50 CX-NAJ50 SX-WNSZ50 RC-ZAS01 NSX-SZ50 CX-NSZ50 • This Service Manual is the "Revision Publishing" and replaces "Simple Manual", (S/M Code No. 09-99C-424-6T1). • If requiring information about the CD mechanism, see Service Manual of AZG-1, (S/M Code No.
Page 2: Specifications
SPECIFICATIONS Main unit CX-NAJ50(U)/CX-NSZ50(LH) <FM tuner section> <Compact disc player section> Tuning range 87.5 MHz to 108 MHz Laser Semiconductor laser (λ = 780 nm) Usable sensitivity (IHF) 13.2 dBf D-A converter 1 bit dual Antenna terminals 75 ohms (unbalanced)
Page 3: Protection Of Eyes From Laser Beam During Servicing
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully the CAUTION instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous WARNING! radiation exposure.
Page 4: Note On Before Starting Repair
NOTE ON BEFORE STARTING REPAIR 1. Forced discharge of electrolytic capacitor of power supply block When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across the electrolytic capacitors (C101, 102) even though AC power cord is removed.
Page 5 In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not. 2-2. Regarding reset There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power cord is re-inserted, or the software reset (pressing the STOP key + POWER key) is performed.
Page 6: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-012-368-080 C-CAP,S 0.1-50 F 87-012-368-080 C-CAP,S 0.1-50 F 87-A21-417-010 IC,STK490-310 87-012-368-080 C-CAP,S 0.1-50 F 8A-NF8-610-010 C-IC,LC866548V-5P03 87-016-520-000 CAP,E 3300-65 M SMG 87-A21-396-010 IC,STK490-040 87-016-520-000 CAP,E 3300-65 M SMG 87-A21-482-010 IC,RPM6938-H4...
Page 7 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C317 87-010-546-080 CAP, ELECT 0.33-50V C784 87-010-197-080 CAP, CHIP 0.01 DM C318 87-010-546-080 CAP, ELECT 0.33-50V C785 87-010-197-080 CAP, CHIP 0.01 DM C326 87-010-198-080 CAP, CHIP 0.022 C786 87-010-197-080 CAP, CHIP 0.01 DM C327...
Page 8 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION J204 87-A61-153-010 JACK,PIN 4P R/W(BL) (SEPA) KM C339 87-012-156-080 C-CAP,S 220P-50 CH J205 87-A61-157-010 JACK,PIN 2P R/W/BL V(SEPA) KM<LH> C340 87-010-197-080 CAP, CHIP 0.01 DM J602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN C341 87-010-194-080 CAP, CHIP 0.047...
Page 9 REF. NO. PART NO. KANRI DESCRIPTION S434 87-A91-024-180 SW,TACT KSH0611BT S435 87-A91-024-180 SW,TACT KSH0611BT SW252 87-A91-555-010 SW,RTRY EC12E24504 SW253 87-A91-542-010 SW,RTRY EC12E12504 VR501 86-NFA-607-010 VR,RTRY 10K15AX1 1 V XV0121PVN<LH> PT C.B 87-010-387-080 CAP,E 470-25 SME 87-010-403-040 CAP,E 3.3-50 SME 87-A61-122-010 CONN,11P V TID-A 8A-NF8-673-010 PT,SUB ANF-8 (H)KAMI<LH>...
Page 10: Transistor Illustration
TRANSISTOR ILLUSTRATION E C B E C B E C B B C E 2SB1370 KTA1266GR 2SC3331(T/U) CSC4115BC KTC3198GR CD1585BC CSA952K E C B S D G DTC114ES 2SJ460 2SK2158 2SA1235F RT1N441C KTC3199GR 2SK2541 2SJ461-T1 2SC3052F RT1N141C RT1P144C CMBT5551 2SC2714O CMBT5401 RT1P141C CHIP RESISTOR PART CODE...
Page 11 FL (HNA-11MM30) GRID ASSIGNMENT / ANODE CONNECTION GRID ASSIGNMENT – 11 –...
Page 12 ANODE CONNECTION MC-Service – 12 –...
Page 13: Wiring - 1 (Main)
WIRING - 1 (MAIN) MC-Service – 13 –...
Page 14 SCHEMATIC DIAGRAM – 1 (MAIN 1 / 2 : AMP) MC-Service – 14 –...
Page 15 SCHEMATIC DIAGRAM – 2 (MAIN 2 / 2 : TUNER) (VT) TP3, 4 (DC BALANCE) MC-Service – 15 –...
Page 16: Wiring - 2 (Front)
WIRING - 2 (FRONT) MC-Service – 16 –...
Page 17: Schematic Diagram - 3 (Front)
SCHEMATIC DIAGRAM – 3 (FRONT) MC-Service – 17 –...
Page 18: Schematic Diagram - 4 (Front)
SCHEMATIC DIAGRAM – 4 (FRONT)<LH> MC-Service – 18 –...
Page 19 WIRING - 3 (PT) CNA001 – 19 –...
Page 20: Schematic Diagram - 5 (Pt)
SCHEMATIC DIAGRAM – 5 (PT) CNA001 MC-Service – 20 –...
Page 21 WIRING - 4 (PT) <LH> CNA001 – 21 –...
Page 22: Schematic Diagram - 6 (Pt)
SCHEMATIC DIAGRAM – 6 (PT) <LH> CNA001 MC-Service – 22 –...
Page 23: Wiring - 5 (Deck)
WIRING - 5 (DECK) – 23 –...
Page 24 WIRING - 6 (DECK) <LH> MC-Service – 24 –...
Page 25: Ic Block Diagram
IC BLOCK DIAGRAM IC, LA1843 IC, LC72131D – 25 –...
Page 26 IC, BA3835F IC, BU2092F MC-Service – 26 –...
Page 27 IC, M61503FP – 27 –...
Page 28 IC DESCRIPTION IC, LC866548V-5P03 Pin Name Description Pin No. I-STEREO/I-DRF Stereo detected input / CD DRF input. I-IFC/I-SUBQ Tune IF count serial data input / CD SUBQ input. O-2PB DECK2 playback switch output. O-POWER System power supply ON/OFF output. O-CD-ON CD power ON/OFF output.
Page 29 Pin Name Description Pin No. P21/RDS FL segment output P21 / RDS input to diode (Not used). P20/FM1 FL segment output P20 / FM1 input to diode (Not used). P19/SW FL segment output P19 / SW input to diode (Not used). P18/LW FL segment output P18 / LW input to diode (Not used).
Page 30 ADJUSTMENT <TUNER / DECK / FRONT> MAIN C.B L802 L801 IC801 TP4 (DC BALANCE) SFR451 SFR452 TP3 (DC BALANCE) L951 TP2 (CLK) (3/3) (1/3) TP8 (RCH) TP9 (LCH) TP1 (VT) FFE831 (LH) DECK–1 P HEAD DECK–1 P HEAD DECK–2 R/P/E HEAD DECK–2 R/P/E HEAD D DECK C.B SFR1...
Page 31 < TUNER SECTION > 10. PB Frequency Response Check (DECK 1, DECK 2) Settings : • Test tape : TTA–300 1. Clock frequency Check • Test point :TP8(Lch), TP9(Rch) Settings : • Test point : TP2 Method : Play back the 315Hz and 8kHz signals of the test Method : Set to AM 1710kHz and check that the test point is tape and check that the output ratio of the 8kHz 2160kHz ±...
Page 32 MECHANICAL EXPLODED VIEW 1 / 1 AZG-1 ZD8RDM P.C.B FL401 P.C.B CHAS,MAIN ZZM-3 PR1NM PLATE,EARTH MECH 2ZM-3MK2 PR4NM <LH> – – MC-Service...
Page 33: Mechanical Parts List
8A-NF8-013-010 PANEL,FR U 8A-DB8-209-010 HLDR,PWB PT 8A-NF8-046-010 WINDOW,DISP H<LH> 8A-NF8-605-010 PT,ANF-8 LH<LH> 8A-NF8-012-010 WINDOW,DISP U 8A-NF8-604-010 PT,ANF-8 U 87-CE3-023-010 BADGE,AIWA 30N SILV 87-NF4-221-010 HLDR,CABLE 8A-NF8-009-010 PANEL,CD 87-085-185-010 BUSHING, AC CORD (E)<LH> 8A-NF8-007-010 PANEL,LEFT V-2 87-A91-422-010 BUSHING,AC CORD(U) 8A-NF8-005-010 PANEL,TOP 87-A80-092-010 AC CORD ASSY,E BLK SUN FAI<LH>...
Page 34: Tape Mechanism Exploded View
TAPE MECHANISM EXPLODED VIEW 1 / 1 TERMINAL,LB1 TERMINAL, IC, EW732 IC, EW732 P.C.B MC-Service – 34 –...
Page 35: Tape Mechanism Parts List
TAPE MECHANISM PARTS LIST 1 / 1 < U: ZZM-3 PR1NM > REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 8Z-ZM3-227-010 BELT,MAIN M3 8Z-ZM3-233-010 SPR-T,BRG M3 8Z-ZM3-235-010 BELT,MAIN L 84-ZM2-227-310 SPR-C,AZIMUTH 8Z-ZM1-235-010 PULLEY,MOT 87-A90-403-110 HEAD,RPH MS15R 87-045-347-010 MOT,SHU2L 70 87-A90-404-010...
Page 36 TAPE MECHANISM EXPLODED VIEW 1 / 1 < LH : 2ZM-3MK2 PR4NM > PH(DECK 1) RPH(DECK 2) DECK C.B SOL 2 SOL 1 (DECK 2) (DECK 1) HEAD 1 C.B(DECK 1) HEAD 2 C.B(DECK 2) (DECK 1) (DECK 1) (DECK 2) (DECK 2) MC-Service –...
Page 37 TAPE MECHANISM PARTS LIST 1 / 1 < LH: 2ZM-3MK2 PR4NM > REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 82-ZM3-301-519 CHAS ASSY,M2 36 82-ZM1-236-019 CAPSTAN N 2-41.5 2 82-ZM1-258-110 SPR-T,PINCH L 37 82-ZM1-239-019 CAPSTAN N 2.2-41.7 3 82-ZM1-341-110 LVR ASSY,PINCH L2 38 82-ZM1-322-019...
Page 38 SPEAKER DISASSEMBLY INSTRUCTIONS Type.1 Type.4 Insert a flat-bladed screwdriver into the position indicated by the TOOLS arrows and remove the panel. Remove the screws of each speaker 1 Plastic head hammer unit and then remove the speaker units. 2 (() flat head screwdriver 3 Cut chisel How to Remove the PANEL, FR Type.2...
Page 39: Accessories / Package List
SPEAKER PARTS LIST SX-WNAJ50 (YUSL), SX-WNAJ50 (YLSL) REF. NO. PART NO. KANRI DESCRIPTION 1 8A-NS8-009-010 PANEL,FR U<YUSL> 1 8A-DS8-001-010 PANEL,FR<YLSL> 2 8A-DS8-004-010 PANEL,DUCT 3 8A-NS8-006-010 GRILLE,FRAME ASSY U<YUSL> 3 8A-DS8-005-010 GRILLE,FRAME ASSY <YLSL> 4 8A-DS8-009-010 PROTECTOR 5 88-NS5-610-010 CORD,SPKR 6 88-NS5-611-010 CORD,SPKR B/L 7 8Z-NSY-003-010 CORD,BUSH...
Page 40: Remote Controller
NSX-SZ50 HS,V SERVICE MANUAL BASIC TAPE MECHANISM : 2ZM-3MK2 PR4NM(HS) COMPACT DISC/ BASIC TAPE MECHANISM : 6ZM-3 PR2NM(V) STEREO CASSETTE RECEIVER BASIC CD MECHANISM : AZG-1 ZA3RDM REMOTE SYSTEM SPEAKER CASSEIVER CONTROLLER NSX–SZ50 CX–NSZ50 SX–WNSZ50 RC–ZAS01 • This Service Manual is the "Revision Publishing" and replaces "Simple Manual" NSX-SZ50 <HS,V>...
Page 41: Surround Speakers
SPECIFICATIONS Main unit CX-NSZ50 Cassette deck section FM tuner section <V> Track format 4 tracks, 2 channels stereo Tuning range FM1 (OIRT) Frequency response 50 Hz – 15000 Hz 65 MHz to 74 MHz (10 kHz step) Recording system AC bias FM2 (CCIR) Heads Deck 1: Playback head x 1...
Page 42: Protection Of Eyes From Laser Beam During Servicing
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully the CAUTION instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous WARNING! radiation exposure.
Page 43 NOTE ON BEFORE STARTING REPAIR 1. Forced discharge of electrolytic capacitor of power supply block When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across the electrolytic capacitors (C101, 102) even though AC power cord is removed.
Page 44 In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not. 2-2. Regarding reset There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power cord is re-inserted, or the software reset (pressing the STOP key + POWER key) is performed.
Page 45: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C0017 87-012-368-080 C-CAP,S 0.1-50 Z F C0018 87-012-368-080 C-CAP,S 0.1-50 Z F 87-020-454-010 IC,DN6851 C0019 87-016-520-000 CAP,E 3300-65 M SMG 87-A21-417-010 IC,STK490-310 C0020 87-016-520-000 CAP,E 3300-65 M SMG 8A-NF8-613-010 C-IC,LC866548V-5P87...
Page 46 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C0304 87-010-178-080 C-CAP,S 1000P-50 K B C2012 C0661 87-012-157-080 C-CAP,S 330P-50 J CH GRM<V> C0307 87-010-263-080 CAP,E 100-10 M 11L SME C0662 87-010-178-080 C-CAP,S 1000P-50 K B C2012<HS> C0308 87-010-263-080 CAP,E 100-10 M 11L SME...
Page 47 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C0992 87-010-312-080 C-CAP,S 15P-50 J CH GRM C0256 87-010-405-040 CAP,E 10-50 M 11L SME C0993 87-010-178-080 C-CAP,S 1000P-50 K B C2012 C0259 87-010-405-040 CAP,E 10-50 M 11L SME C0995 87-010-178-080 C-CAP,S 1000P-50 K B C2012...
Page 48: Chip Resistor Part Code
REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION S0404 87-A91-024-180 SW,TACT KSHG611BT !PT0001 8A-NF8-608-010 PT,ANF-8 EZ<V> S0405 87-A91-024-180 SW,TACT KSHG611BT !PT0002 8A-NF8-673-010 PT,SUB ANF-8 (H)KAMI<HS> S0406 87-A91-024-180 SW,TACT KSHG611BT !PT0002 8A-NF8-662-010 PT,SUB ANF-8 (E)<V> S0407 87-A91-024-180 SW,TACT KSHG611BT !RY0002 87-A91-339-010 RELAY,AC DC12V G5PA-2<HS>...
Page 49: Transistor Illustration
TRANSISTOR ILLUSTRATION E C B E C B E C B B C E 2SB1370 KTA1266GR 2SC3331(T/U) CSC4115BC KTC3198GR CD1585BC CSA952K 2SA933S E C B S D G DTC114ES 2SJ460 2SK2158 2SA1235F KRA102S KTC3199GR 2SK2541 2SJ461-T1 KRA107S 2SC2714O 2SC3052F KRC102S RT1P141C CMBT5551 RT1N441C...
Page 50 FL (HNA-11MM30) GRID ASSIGNMENT/ANODE CONNECTION GRID ASSIGNMENT ANODE CONNECTION...
Page 51 WIRING-1 [MAIN C.B] IC991 MC-Service...
Page 52 SCHEMATIC DIAGRAM-1 [MAIN] (FUNCTION/AMP SECTION) MC-Service...
Page 53 SCHEMATIC DIAGRAM-2 [MAIN](TUNER SECTION) <V>...
Page 54 SCHEMATIC DIAGRAM-3 [FRONT, DECK] <HS> MC-Service...
Page 55 SCHEMATIC DIAGRAM-4 [FRONT, DECK] <V> MC-Service...
Page 56 WIRING-2 [FRONT C.B] R410 R411 S432 S430 S434 S435 S401 S419,LED607 S402 S416,LED603 S403 S404 S410 S405 S408 DISC-3 DISC CHANGE DISC-1 DISC-2 VIDEO/AUX CLEAR TUNER TAPE CLOCK ENTER S431 S433 LED604 LED606 S418,LED608 S411 S417 S409 S407 S420 S412 OPEN/CLOSE CD BLANKSKIP PLAY...
Page 57 SCHEMATIC DIAGRAM-5 [PT] WIRING-4 [DECK C.B] <HS> WIRING-3 [PT C.B] MC-Service...
Page 58 WIRING-5 [DECK C.B] <V> DECK 2 DECK 1 MC-Service...
Page 59: Ic Block Diagram
IC BLOCK DIAGRAM IC, LA1843 IC, LC72131D MC-Service...
Page 60 IC, BA3835F IC, BU2092F...
Page 61 IC, M61503FP MC-Service...
Page 62 IC DESCRIPTION IC, LC866548V-5P87 Pin No. Pin Name Description _______________ I-STEREO/I-DRF Stereo detected input/CD DRF input ______ I-IFC/I-SUBQ Tune IF count serial data input/CD SUBQ input O-2PB Deck 2 playback switch output _______ O-POWER System power supply ON/OFF output _______ O-CD-ON CD power ON/OFF output O-PLL_DATA...
Page 63 Pin No. Pin Name Description P22/PRO LOGIC FL SEGMENT output P22/PROLOGIC input to diode (not used) P21/RDS FL SEGMENT output P21/RDS input to diode P20/FM1 FL SEGMENT output P20/FM1 input to diode P19/SW FL SEGMENT output P19/SW input to diode P18/LW FL SEGMENT output P18/LW input to diode P17/AMST...
Page 64 ADJUSTMENT < TUNER SECTION > 9. Head Azimuth Adjustment (DECK 1, DECK 2) 1. Clock frequency Check Settings : • Test tape : TTA–330 MAIN C.B Settings : • Test point : TP2 • Test point : TP8(Lch), TP9(Rch) Method : Set to AM 1602kHz and check that the test point is •...
Page 65 MECHANICAL EXPLODED VIEW 1/1 AZG-1 ZA3RDM MAIN C.B BINDER WIRE HT-SINK HT-SINK PT C.B FRONT C.B HT-SINK HT-SINK CHAS,MAIN 6ZM-3 PR2NM <V> PLATE,EARTH MECH 2ZM-3MK2 PR4NM<HS> MC-Service...
Page 66: Mechanical Main Parts List
13 8A-NF8-048-010 PANEL,FR K<V> 46 8A-NF8-075-010 CABI,REAR HS W/O SPEC<HS> 14 8A-NF8-046-010 WINDOW,DISP H 46 8A-NF8-067-010 CABI,REAR VJSM<V> 15 87-CE3-023-010 BADGE,AIWA 30N SILV 47 8A-DB8-209-010 HLDR,PWB PT 16 8A-NF8-009-110 PANEL,CD 48 8A-NF8-008-010 PANEL,RIGHT V-2 17 8A-NF8-007-010 PANEL,LEFT V-2 49 87-NF4-221-010...
Page 67 TAPE MECHANISM MAIN PARTS LIST 1/1 <HS: 2ZM-3MK2 PR4NM> REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 82-ZM3-301-610 1H CHAS ASSY,M2 31 82-ZM1-255-310 0E SPR-E,LVR DIR 2 82-ZM1-258-210 0E SPR-T,PINCH L 32 82-ZM3-305-210 0E GEAR,CAM M2 3 82-ZM1-341-210 1A LVR ASSY,PINCH L2 33 82-ZM1-227-310 0E LVR,TRIG 4 82-ZM1-333-210 0E PLATE,LINK2...
Page 68: Tape Mechanism Exploded View
TAPE MECHANISM EXPLODED VIEW 1/1 <HS: 2ZM-3MK2 PR4NM> PH(DECK 1) RPH(DECK 2) DECK C.B CUSH-G,DIA3.7-8-3.2 CUSH-G,DIA3.7-8-3.2 HLDR,IC HLDR,IC CAPSTAN N 2.2-41.7 CAPSTAN N 2.2-41.5 HEAD 1 C.B(DECK 1) BELT D2 HEAD 2 C.B(DECK 2) (DECK 1) (DECK 1) (DECK 2) (DECK 2) SH,1.63-3.2-0.5 SLT MC-Service...
Page 69 TAPE MECHANISM EXPLODED VIEW 1/1 <V: 6ZM-3 PR2NM> DECK C.B (DECK L SOL 2 only) SOL 1 (DECK L SIDE) (DECK R SIDE) LEVER EJECT R HEAD PLATE CAPSTAN N 2.2-41.7 SHLD M3 LEVER EJECT L CAPSTAN N 2-41.5 (DECK 2)
Page 70 TAPE MECHANISM MAIN PARTS LIST 1/1 <V: 6ZM-3 PR2NM> REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 86-ZM3-215-010 1E CHAS ASSY,RS 41 82-ZM1-216-310 0E GEAR,REEL 2 86-ZM3-202-010 0E BASE,HEAD S 42 86-ZM3-213-010 0E S-SCREW,HLDR,MOT 3 3 86-ZM3-205-010 0E SPR-C,RPH S 43 82-ZM1-225-210 0E GEAR,FR 4 82-ZM1-333-210 0E PLATE,LINK 2...
Page 71 SPEAKER DISASSEMBLY INSTRUCTIONS Type.1 Type.4 Insert a flat-bladed screwdriver into the position indicated by the TOOLS arrows and remove the panel. Remove the screws of each speaker 1 Plastic head hammer unit and then remove the speaker units. 2 ( – ) flat head screwdriver 3 Cut chisel How to Remove the PANEL, FR Type.2...
Page 72: Speaker Parts List
3 8A-DS8-005-010 GRILLE,FRAME ASSY 4 8A-DS8-009-010 PROTECTOR, 5 88-NS5-610-010 CORD,SPKR 6 88-NS5-611-010 CORD,SPKR B/L 7 8Z-NSY-003-010 CORD,BUSH 8 88-NS3-029-010 CORD,BUSH L 9 8Z-NS7-602-010 SPKR, W 160 10 8Z-NSY-604-010 SPKR, M 100 11 8Z-NSY-608-010 SPKR, CERAMIC ASSY 12 8A-NSJ-006-010 BADGE,AIWA S35 MC-Service...
Page 73 AZG-1 English SERVICE MANUAL CD-R/RW MECHANISM BASIC CD MECHANISM:KSM-880CAB TYPE ZD8RD YZD8RMDJM ZD8RMDJM ZD8RDNDM YKZD8RDF ZD8RDM YZD8RDM ZD8RN1DM YZD8RDJM MC-Service S/M Code No. 09-001-335-3N6...
Page 74 PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully the CAUTION instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous WARNING! radiation exposure.
Page 75 How to Adjust the Rotating Phase of the Gear, Main Cam 1) Push down the hooking catch of the CHAS. MECH, and remove the TRAY. 2) Align the arrow mark of the Gear, Main Cam with the black round mark of the CHAS, MECHA as shown below. 3) Confirm that the Slide, Mech Cam is located in the right position, then insert the TRAY gently.
Page 76 ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C109 87-010-992-080 C-CAP,S 0.047-25 B C110 87-010-196-080 CHIP CAPACITOR,0.1-25 87-A21-381-040 C-IC,LA9235M <YKZD88RDF,ZD8RD> 87-A21-556-010 C-IC,LC78641E C110 87-010-196-020 CHIP CAPACITOR,0.1-25 87-A21-414-010 IC,BA5927S <EXCEPT YKZD88RDF,ZD8RD> C111 87-010-260-080 CAP, ELECT 47-25V C112 87-010-197-020...
Page 77 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C207 87-010-196-080 CHIP CAPACITOR,0.1-25 CN202 87-A60-130-010 CONN,5P V <YKZD88RDF,ZD8RD> CN501 84-ZG1-647-010 CONN ASSY,2P C301 87-010-382-080 CAP, ELECT 22-25V <EXCEPT ZD8RN1DM,ZD8RNDM> C302 87-010-196-020 CHIP CAPACITOR,0.1-25 CN601 87-009-345-010 CONN,2P PH V <EXCEPT YKZD88RDF,ZD8RD>...
Page 78 TRANSISTOR ILLUSTRATION E C B 2SA1235F 2SA1980Y/G 2SK2158 2SC3052F KTA1266GR DTC124XK...
Page 79: Block Diagram
BLOCK DIAGRAM RVDD MC-Service...
Page 80 WIRING TO MOTOR C.B PIN3 MC-Service...
Page 81: Schematic Diagram
SCHEMATIC DIAGRAM IC101 LC78641E M201 MOVE 3.6V VDD/2V MC-Service...
Page 82: Test Mode
TEST MODE 1. How to Start the CD Test Mode *1 ..When the focus search keeps running for 10 minutes or longer continuously, the driver IC heats up, and the protective circuit works so that the machine may stops operating. While pressing the CD function key, connect the AC power plug to wall outlet.
Page 83 WAVE FORM IC BLOCK DIAGRAM IC, BA5927S IC201 • (IN6-R) VOLT/DIV: 500mV TIME/DIV: 200mS IC201 ª (IN6-F) 1.6Vp-p 1.6Vp-p Between CN202 1 and 2 VOLT/DIV: 1V (2 Pin: 0 Level) TIME/DIV: 200mS IC101 % (FE) VOLT/DIV: 500mV TIME/DIV: 2mS IC, LA9235M 1.75Vp-p IC101 ^ (TE) VOLT/DIV: 200mV...
Page 84 IC DESCRIPTION IC, LC78641E Pin No. Pin Name Description Pin No. Pin Name Description PDO1 Internal VCO control phase comparator output pin. (Pull down) EFLG C1, C2 error correction monitor pin. (Not connected) Internal VCO control phase comparator output pin. TEST Test input pin.
Page 85 Pin No. Pin Name Description Synchronization signal detection output pin. FSEQ Outputs a high level when the synchronization signal detected from the EFM signal and the internally generated synchronization signal agree. (Not connected) Defect pin. Which becomes an input pin after reset and can be controlled externally. DEFECT This becomes the defect monitor pin under control by command.
Page 86: Mechanical Exploded View
MECHANICAL EXPLODED VIEW 1/1 P.C.B P.C.B P.C.B CUSHION,CD880 CUSHION,CD880 MC-Service...
Page 87 MECHANICAL PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 84-ZG1-225-010 BELT,SQ1.0-63.3 20 81-ZG1-255-110 PLATE,MAGNET MK2<EXCEPT ZD8RN1DM> 2 84-ZG1-673-010 F-CABLE,5P 1.25 210MM BLACK N 21 83-ZG3-604-010 RING,MAG 2 <EXCEPT ZD8RN1DM,ZD8RNDM> 22 83-ZG3-213-010 LVR,SW 2 84-ZG1-672-010 F-CABLE,5P 1.25 210MM WHITE N 23 84-ZG1-208-210...
Page 88: Cd Mechanism Exploded View
CD MECHANISM EXPLODED VIEW 1/1 P.C.B CD MECHANISM PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 91-564-722-110 CONN,PIN 6P 8 92-647-742-010 SPRING COMPRESSION 2 91-572-085-110 LEAF SWITCH 9 93-321-813-110 POLI WASHER 3 9X-264-655-010 SL MOTORR ASSY 10 92-647-407-010 GEAR A...
Page 89: Mechanical Section
REFERENCE NAME LIST ELECTRICAL SECTION MECHANICAL SECTION DESCRIPTION REFERENCE NAME DESCRIPTION REFERENCE NAME ANTENNAS ADHESHIVE SHEET ADHESHIVE CHIP AZIMUTH C-CAP CAP, CHIP BAR-ANT BAR-ANTENNA C-CAP TN CAP, CHIP TANTALUM BATTERY C-COIL COIL, CHIP BATT BATTERY C-DI DIODE, CHIP BEARING C-DIODE DIODE, CHIP BUTTON C-FET...
