Page 2: Limited Warranty
LIMITED WARRANTY Hawking Technology guarantees that every HSB2 WiFi Signal Booster is free from physical defects in material and workmanship under normal use for two (2) years from the date of purchase. If the product proves defective during this two-year warranty period, call Hawking Customer Service in order to obtain a Return Authorization number. - Page 3 Warning Statement: Federal Communication Commission Interference Statement Federal Communications Commission (FCC) Requirements, Part 15 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-
Page 9: System Requirements
Network/Operating Range: IEEE 802.11b WLAN Standard IEEE 802.11g WLAN Standard 2400 - 2500 MHz Frequency Response: +/- 1 dB Output Power: Max: 27dBm) Input Power: 8-18 dBm Max. Receiver Gain: 10-13 dBm, 12 dBm Typical Noise Figure: 3.5 dB typical Connectors: Input: Reverse SMA Jack Antenna: Reverse SMA Jack... - Page 10 High powered antenna to increase the distance of your WiFi device. SMA Connector – The standard antenna connector for WiFi devices. This is the most popular connector and comes standard with all Hawking Technologies equipment. TNC Connector – A type of antenna connector used by few wireless networking equipment manufacturers.
