User Guide & Installation Manual
32 FORD PEDAL ASSEMBLY
HEXPBA02
WARNING
The master cylinder is suitable for 4-wheel disc or disc/drum brake setups. The bracket can be bolted or
welded to the left frame rail (boxed or stock).
The selection and installation of brake components should only be done by experienced professionals in the
proper installation and operation of braking systems. The installer must use his/her own discretion to
determine the suitability of the brake components and brake kits for every particular application.
1.) Pick a location that best lines up with a proper brake pedal location. The brake pedal mount can be bolted in or welded in on either
a channeled or a boxed frame rail. This kit is supplied with the correct hardware to bolt it into a channeled frame. If you are using a
boxed frame you will need to supply the correct hardware. Try to keep the master cylinder mounted as level as possible. When selecting
a pedal location you will need to make sure you have enough pedal travel. Make sure the pedal will bottom out the master cylinder
before the pedal touches the floor. Total pedal travel should be about 5 1/2". The pedal can be bent or modified for driver comfort but
avoid shortening the height of the pedal as this will result in increased pedal effort.
2.) Assemble the master cylinder to the brake pedal frame mount with the 3/8"-16 x 1-1/2" bolts, washers and nylock nuts. Torque
these to 18-24 ft. lbs. Assemble the brake pedal on to the brake pedal frame mount. Install the clevis on to the brake pedal and adjust
the pedal location so the center of the clevis pin is 1/2" forward from the center line of the brake pedal pivot.
3.) The push rod can now be cut to the correct length. NOTE: REMOVE THE RETAINING CLIP ON THE PUSH ROD WHILE MOCKING UP
YOUR INSTALLATION. Measure for the correct push rod length and cut it making sure you have a minimum of 1/2" of engagement in
the clevis.
4.) Once you have determined the correct location of the brake bracket, mark and drill the two 1/2" mounting holes in your frame and
bolt it into position with the two 1/2" bolts, washers and nylon lock nuts supplied. Torque these to 38-57 ft. lbs.
5.) Mark the location and angle of the pedal pad and weld the brake pedal pad mount to the brake pedal.
6.) Reinstall the retaining clip on the push rod and install it in the master cylinder piston. With the pedal returned to its non-depressed
position adjust the push rod plunger so there is slight free play between the plunger and the piston on the master cylinder.
7.) The brake pedal should be free to return when no pressure is applied, allowing the master cylinder push-rod to return to its
non-depressed position. Any preload will not allow the hydraulic system to function properly.
In some cases the master cylinder spring (internal) may not be strong enough to fully return the push rod; in this case an additional pedal
return spring can be used. When using an additional return spring the pedal should have an adjustable return stop on it. This will stop
the piston from excessively banging the snap ring located under the rubber boot on the master cylinder. Adjust the stop so the pedal
stops returning at the point when the master cylinder piston retracts against the snap ring.
