1.3 LED Indicators
LED
POWER
1 - 5
LINK
100M
1.4 Specifications
10/100 Copper Ports
Compliance
Connectors
Pin assignments
Configuration
Transmission rate
Duplex support
Network cable
Switch Functions
Forwarding & filtering
Switching technology
Maximum packet length 1536 bytes
MAC Addresses Table
Port configuration
Flow control
Storm control
DC Power Input
Screwed terminal block 3P (Vin+, Vin-, Chassis Ground)
DC Jack Connector
Operating Voltages
Power Consumption
Mechanical
Dimension (base)
Housing
Function
Power status
Port 1 – Port 5
Link and activity status (Port 1 - Port 5)
100Mbps speed status (Port 1 - Port 5)
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Shielded RJ-45 jacks
Auto MDI/MDI-X detection
Auto-negotiation or software control
10Mbps, 100Mbps
Full/Half duplex
Cat.5 UTP up to 100 meters
Non-blocking, full wire speed
Store and forward
2K entries
Auto-negotiation for speed and duplex
IEEE 802.3x pause frame base for full duplex operation
Back pressure for half duplex operation
Broadcast packets are dropped when large consecutive broadcast packets are
received.
-D 6.3mm / + D 2.0mm
+7 ~ +30VDC
2.2W max.
40 x 80 x 95 mm (WxDxH)
Enclosed metal with no fan
-7-
