- Page 1 Twin-tub Washing Machine with Pump User's manual This manual is for K-7WSP Please read this manual carefully before using. Retain it for future reference.
-
Page 2: Table Of Contents
Contents Names of the parts Safety precautions Installation and adjustment Preparation before washing The musts in washing Usage of the detergent Washing sequence Disposal after washing Trouble-Shooting *Answers to question Packing list *Specification... -
Page 3: Names Of The Parts
Names of the parts Wash selector Wash timer Water-filling entrance Control panel Overflow filter Water level adjusting lever Lint filter(Installed by user) Pulsator Wash tub Wash tub cover Drain hose Base frame Meaning and description of the symbols Warning sign Forbidding sign Please check if the power receptacle has good earthing condition before using to guarantee your safety. -
Page 4: Safety Precautions
Safety precautions Please insert the power cord into special receptacle with rated vol- tage.Be sure to use single-phase three pins receptacle.The earthing terminal of the receptacle must be earthed reliably.If possible,please adopt electric leakage protector. If the power cord is bad, to avoid risk it is required to replace it by the technicians of our special shop or the after-sale service department. - Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine.
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Usage of the drain hose The drainage shall be smooth with the drain hose. 1.The height of the drain hose shall be not be smooth enough and cause incomplete drainage. -
Page 7: How To Change The Direction Of The Drain Hoses
How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of spin tub Put soft items on the ground. Lean the machine down gently with the front surface facing the ground. -
Page 8: Preparation Before Washing
Preparation before washing Pay attention to followings before washing the laundries Check if Clear the the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc. a. Check if the laundries are applicable for washing with machine. b. -
Page 9: The Musts In Washing
The musts in washing Usage of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laun- dries with color or pattern as they are prone to lose color. -
Page 10: Washing Sequence
Washing sequence Wash timer (To set to below 2 minute, first set to 5 minute then turn it back. it can increase Water inlet the service life of the timer). WATER INLET WASH TIMER Wash 1. Fill the water and add the dissolved washing powder to make the water level reach the preset position. - Page 11 Spinning 1.Put the laundries into the spin tub evenly and smoothly. 2.Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland Proper The laundries are slanting (2) Close the inner and outer cover of the spin tub. Outer cover of The spin tub Inner cover of...
-
Page 12: Disposal After Washing
Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing. -
Page 13: Cleaning The Overflow Filter
Cleaning the overflow filter 2. Take off the corrugation pipe. Dismantle the upper part of the corrugation pipe inside overflow filter ( as indicated in Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water. 4. -
Page 14: Trouble-Shooting Answers To Question
Trouble-shooting Answers to question If the laundries fall to the outer side of the spin tub If the laundries fall to the outer side of the spin tub, Please come to the special maintenance department or after-sale service department of our company. Do not repair it by yourself. When the remained water is frozen Prevent the freezing (be sure to discharge the water completely after using) - Page 15 Trouble-shooting Answers to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
-
Page 16: Packing List
Packing list Name User's manual Water inlet hose Lint filter Gland Twin-tub washing machine Specification Water level/Water quantity (about) Injection pressure(MPa) Quantity One piece One piece One piece One piece One set Maximum/43L Medium/36L Minimum/30L 0.02 0.2...
