- Page 1 N V R - Q 6 7 NVR-Q67 Network Video Recorder 3.5” HDD x 6, 2.5” HDD x 1 Gigabit Ethernet x 2 COM x 2, USB2.0 x 4 VGA x 1, DVI-D x 1 Display Port x 1 NVR-Q67 Manual 1st Ed. July 2013...
- Page 2 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Copyright Notice This document is copyrighted, 2013. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice.
- Page 3 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Acknowledgments All other products’ name or trademarks are properties of their respective owners. ...
- Page 4 1 CD-ROM for 2-port SC300 driver 1 DVD-ROM for Manual (in PDF Format) and Drivers 1 NVR-Q67 If any of these items should be missing or damaged, please contact your distributor or sales representative immediately.
-
Page 5: Table Of Contents
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Contents Chapter 1 General Information 1.1 Introduction..............1-2 1.2 Features ..............1-3 1.3 Specifications ............1-4 Chapter 2 Hardware Installation 2.1 Mechanical Drawing .......... - Page 6 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Boxer/ Industrial System 有毒有害物质或元素 部件名称 铅...
-
Page 7: Chapter 1 General Information
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Chapter General Information 1- 1 Chapter 1 General Information... -
Page 8: Introduction
10/100/1000Base-TX Ethernet RJ-45 ports. NVR-Q67 features desktop and rackmount form factor for network appliance applications. This NVR-Q67 supports up to six 3.5” Hard Disk Drive and one 2.5” internal System HDD bracket with 460W PSU. Moreover, the flexible expansion interfaces feature one PCI-E[x16], one PCI-E[x4], and two PCI slots. -
Page 9: Features
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 1.2 Features ® Intel Socket 1155 with 2nd Generation Core™ i5/i7 Processors ®... -
Page 10: Specifications
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 1.3 Specifications System CPU Intel® Socket 1155 with 2nd Generation Core™ i5/i7 Processors ... - Page 11 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Mechanical Power Button x 1, Reset Button x Front Panel 1, HDD light Indicator ...
-
Page 12: Chapter 2 Hardware Installation
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Chapter Hardware Installation Chapter 2 Hardware Installation... -
Page 13: Mechanical Drawing
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 2.1 Mechanical Drawing Chapter 2 Hardware Installation... -
Page 14: Open The Top Cover
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 2.2 Open The Top Cover 2.3 Installing the Rear 3.5” Hard Disk Drive Chapter 2 Hardware Installation... -
Page 15: Installing The Front 3.5" Hard Disk Drive
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 2.4 Installing the Front 3.5” Hard Disk Drive 2.5 Installing the Front 3.5”& 2.5”HDD Disk Drive Step 1: Release two screws on the top side of drive bay Chapter 2 Hardware Installation... - Page 16 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Step 2: Pull out the whole drive bay from the front side of the chassis Step 3: Lock the HDD on the HDD bracket with two screws Chapter 2 Hardware Installation...
- Page 17 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Step 4: Fasten the two screws on the both sides of bracket to the HDD case Step 5: Fasten six screws on the each side of bracket to 3.5”...
-
Page 18: Chapter 3 Driver Installation
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Chapter Driver Installation Chapter 3 Driver Installation... - Page 19 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 The NVR-Q67 comes with an AutoRun DVD-ROM that contains all drivers and utilities that can help you to install the driver automatically.
- Page 20 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 3.1 Installation Insert the NVR-Q67 DVD-ROM into the DVD -ROM drive and install the drivers from Step 1 to Step 8 in order. Step 1 – Install Chipset Driver Click on the Chipset folder and double click on the Setup.exe file...
- Page 21 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 For Realtek LAN Chip Click on the LAN folder and select the Realtek folder Select the OS folder your system is and double click on the setup.exe file located in each OS folder Follow the instructions that the window shows...
- Page 22 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Step 7 – Install ME Driver Click on the ME folder and double click on the Setup.exe file Follow the instructions that the window shows The system will help you install the driver automatically...
-
Page 23: Chapter 4 I/O Information
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Chapter I/O Information Chapter 4 I/O Information... -
Page 24: I/O Address Map
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 4.1 I/O Address Map Chapter 4 I/O Information... - Page 25 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Chapter 4 I/O Information...
-
Page 26: St Mb Memory Address Map
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 4.2 1 MB Memory Address Map Chapter 4 I/O Information... -
Page 27: Irq Mapping Chart
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 4.3 IRQ Mapping Chart Chapter 4 I/O Information... - Page 28 N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 Chapter 4 I/O Information...
-
Page 29: Dma Channel Assignments
N e t w o r k V i d e o R e c o r d e r N V R - Q 6 7 4.4 DMA Channel Assignments Chapter 4 I/O Information...
