MS-ERX400
INSTALLATION INSTRUCTIONS
Important Safety Information
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
CAUTION
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.
What's In the Box
• Mounting gasket
• Mounting template
• Four 8-gauge, self-tapping screws
• Two screw covers
• Dust cover
• Network/power cable
Tools Needed
• Phillips screwdriver
• Electric drill
• Drill bit (size varies based on surface material and screws used)
• Rotary cutting tool or jigsaw
• Silicone-based marine sealant (optional)
July 2022
GUID-0E8EFC1A-5B75-4554-B74B-B79F5E3CC812 v3

Advertisement

loading

Related Manuals for Garmin FUSION MS-ERX400

Summary of Contents for Garmin FUSION MS-ERX400

  • Page 1 MS-ERX400 INSTALLATION INSTRUCTIONS Important Safety Information WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. CAUTION To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling, cutting, or sanding.

  • Page 2: Mounting Considerations

    Mounting Considerations • You must mount the remote control on a flat surface. • If there is not much clearance behind the mounting surface or you prefer to drill a smaller hole in the mounting surface, you can use an MS-ERX400 spacer accessory (010-12922-02) •...
  • Page 3 If you must extend the power and ground wires, you must use the appropriate gauge of wires. 18 AWG (0.82 mm ) wires are suitable for most installations. If you must extend the network cable, extension cables and couplers are available. See your Garmin ® dealer for details.
  • Page 4 MS-ERX400 remote control Wired network switch or wired network router Compatible stereo, such as an MS-RA770 Compatible stereo, such as an MS-RA670 Connecting to Power and the Network 1 Route the network/power cable to the stereo or to the network switch or router. NOTICE Do not connect the cable to the stereo until after you have connected the power wires to avoid possible damage to the stereo.

  • Page 5: Software Updates

    From -20 to 70°C (from -4 to 158°F) Water rating IEC 60529 IPX6 and IPX7 The device withstands incidental exposure to water of up to 1 m for up to 30 min, and is protected against powerful jets of water. For more information, go to www.garmin.com/waterrating.
  • Page 6 Dimensions Item Measurement 12.3 mm (0.48 in.) 10 mm (0.39 in.) 10.9 mm (0.43 in.) 49.1 mm (1.93 in.) 70 mm (2.76 in.) 110 mm (4.32 in.) 連絡地址 製造銷售:台灣國際航電股份有限公司 聯絡地址:新北市汐止區樟樹二路 68 號 電　　話:(02)2642-8999 客服專線:(02)2642-9199...
  • Page 7 , the Garmin logo, Fusion ® , and the Fusion logo, are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used without the express permission of Garmin. M/N: A03775...
  • Page 8 © 2020 Garmin Ltd. or its subsidiaries support.garmin.com...
