Blu-ray Disc Player
©
Copyright 2009 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without
the prior permission of Philips.
Published by SL 0924 Service Audio
Version 1.0
TABLE OF CONTENTS
Technical Specifi cations ....................................................... 1-2
Safety Instruction, Warning & Notes ..................................... 1-3
QSG & DFU Instruction ........................................................... 2
Mechanical and Dismantling Instructions ................................ 3
Software Version & Upgrades, Region Code Change ............. 4
Trouble Shooting Chart ........................................................... 5
Set Wiring Diagram ................................................................. 6
Electrical Diagrams and PCB layouts ...................................... 7
Set Mechanical Exploded view & Parts List ............................ 8
Revision List ............................................................................ 9
Printed in The Netherlands
Subject to modification
BDP3000
/55/78/93/98/94/96
Page
CLASS 1
LASER PRODUCT
©
3141 785 34180

Advertisement

loading

Related Manuals for Philips BDP3000

Summary of Contents for Philips BDP3000

  • Page 1 LASER PRODUCT © Copyright 2009 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2 Specifi cations for BDP3000/55 Note • Specifi cation and design are subject to change without notice Play media Laser Specifi cation BD-Video, DVD-Video, DVD+R/+RW, DVD-R/- • Laser Type: RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD, • BD Laser Diode: InGaN/AIGaN Video CD/SVCD, Picture CD, MP3-CD, WMA-CD, •...
  • Page 3 Specifi cations for BDP3000/93 Note • Specifi cation and design are subject to change without notice Play media Laser Specifi cation BD-Video, DVD-Video, DVD+R/+RW, DVD-R/- • Laser Type: RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD, • BD Laser Diode: InGaN/AIGaN Video CD/SVCD, Picture CD, MP3-CD, WMA-CD, •...
  • Page 4 Specifi cations for BDP3000/98/94 Note • Specifi cation and design are subject to change without notice Play media Laser Specifi cation BD-Video, DVD-Video, DVD+R/+RW, DVD-R/- • Laser Type: RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD, • BD Laser Diode: InGaN/AIGaN Video CD/SVCD, Picture CD, MP3-CD, WMA-CD, •...
  • Page 5 Specifi cations for BDP3000/96 Note • Specifi cation and design are subject to change without notice Laser Specifi cation Play media BD-Video, DVD-Video, DVD+R/+RW, DVD-R/- • Laser Type: • BD Laser Diode: InGaN/AIGaN RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD, •...
  • Page 6 Safety instruction, Warning & Notes Safety instruction 1. General safety 2.Laser safety Safety regulations require that during a repair: This unit employs a laser. Only qualified service personnel . Connect the unit to the mains via an isolation transformer. may remove the cover, or attempt to service this device .
  • Page 7 Warning 1.General 2. Laser . All ICs and many other semiconductors are susceptible to . The use of optical instruments with this product, will electrostatic discharges (ESD). Careless handing during increase eye hazard. repair can reduce life drastically. Make sure that, during .
  • Page 8 - lead free BGA-ICs will be delivered in so-called respected by the workshop during a repair: ‘dry-packaging’ (sealed pack including a silica gel Use only lead-free solder alloy Philips SAC305 with pack) to protect the IC against moisture. After order code 0622 149 00106. If lead-free solder-paste is...
  • Page 9 The following excerpt of the Quick Start Guide serves as an introduction to the set. The complete Direction For Use can be download in different languages from www.philips.com/welcome BDP3000 Philips Customer Contact & Support site: www.p4c.philips.com Settings HDMI © 2009 Koninklijke Philips Electronics N.V.
  • Page 10 HDMI & AV OUTPUT L/R English Menu Language Video Setup Parental Control Audio Setup Screen Saver Change Password Preference Setup Normal Display Panel VIDEO & AV OUTPUT L/R Auto Standby EasyLink Setup VCD PBC Advanced Setup Menu Language Video Setup Parental Control Screen Saver Audio Setup...
  • Page 11 The following excerpt of the Quick Start Guide serves as an introduction to the set. BDP3000 The complete Direction For Use can be download in different languages from www.philips.com/welcome Philips Customer Contact & Support site: www.p4c.philips.com Settings © 2009 Koninklijke Philips Electronics N.V. All rights reserved...
  • Page 12 HDMI & AV OUTPUT L/R English Menu Language Video Setup Parental Control Audio Setup Screen Saver Change Password Preference Setup Normal Display Panel Auto Standby VIDEO & AV OUTPUT L/R EasyLink Setup VCD PBC Advanced Setup Menu Language Parental Control Screen Saver Change Password Display Panel...
  • Page 13 The following excerpt of the Quick Start Guide serves as an introduction to the set. BDP3000 The complete Direction For Use can be download in different languages from www.philips.com/welcome Philips Customer Contact & Support site: www.p4c.philips.com Settings © 2009 Koninklijke Philips Electronics N.V. All rights reserved...
  • Page 14 HDMI & AV OUTPUT L/R English Menu Language Video Setup Parental Control Audio Setup Screen Saver Change Password Preference Setup Normal Display Panel VIDEO & AV OUTPUT L/R Auto Standby EasyLink Setup VCD PBC Advanced Setup Menu Language Parental Control Screen Saver Change Password Display Panel...
  • Page 15 The following excerpt of the Quick Start Guide serves as an introduction to the set. BDP3000 The complete Direction For Use can be download in different languages from www.philips.com/welcome Philips Customer Contact & Support site: www.p4c.philips.com Settings © 2009 Koninklijke Philips Electronics N.V. All rights reserved...
  • Page 16 HDMI & AV OUTPUT L/R English Menu Language Video Setup Parental Control Audio Setup Screen Saver Change Password Preference Setup Normal Display Panel VIDEO & AV OUTPUT L/R Auto Standby EasyLink Setup VCD PBC Advanced Setup Menu Language Parental Control Screen Saver Change Password Display Panel...
  • Page 17 Product overview Main unit • Turn on the disc player or switch to Front panel Description standby mode. display • When EasyLink is enabled, switch the LOADING Loading a disc. disc player and all EasyLink devices to UNSUPP The disc is not supported. standby.
  • Page 18 Enter values or letters (via SMS style entry). • Open or close the disc compartment. q TV CH +/- • Select a TV channel (applicable only to certain Philips brand TVs). • Stop play. • Pause play. • Turn on the disc player or switch to •...
  • Page 19 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step1: Remove 6 screws around the Top Cover, and then remove the Top Cover (Figure 1). Figure 1 Step2: If it is necessary to dismantle Loader or Front Panel, the Front door should be removed first.
  • Page 20 Mechanical and Dismantling Instructions Detailed information please refer to the model set. Dismantling Instruction Step3: If the tray can’t open in normal way, you can make it through the instruction as below (Figure 3). Note: Make sure to operate gently otherwise the guider would be damaged. Figure 3 Step4: Dismantling Front Panel, disconnect the connectors (J306, CN502), need release 5 snaps of Front Panel and 2 snaps of bottom cabinet , then gently pull the Panel out from the set.
  • Page 21 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. Step5: Dismantling Loader, disconnect the 1 connector (J303) aiming in the below figure, and remove 4 screws that connects the loader and the bottom cabinet. (Figure 5) Figure 5 Step6: Dismantling Main Board, first disconnect the connector (J320), and then remove 7 screws.
  • Page 22 4) Disconnect the power cord for a few seconds and connect again to turn on the player. C) Update software via USB Flash Drive: 1) Go to www.philips.com/support to check if the latest software version is available for this player. 2) Download the software onto a USB flash drive.
  • Page 23 Trouble shooting chart No display on VFD, and buttons do not work No display on VFD, and buttons do not work Check every supply voltage on main board is Refer to Power supply board part normal Check-28V,5V,+12V Fix the connection JP4 on front board voltage on the power and front board and XP2 on power board...
  • Page 24 Trouble shooting chart No audio output No audio output Check whether the audio signal is right from the U12.44 and Check the U12 power supply U12.45 Replace the U12 Check whether the audio Check the U12 power supply signal is right from the (U17.4=-12V and U17.8=12V) U11.7 and U11.1 Replace the U17...
  • Page 25 Trouble shooting chart Remote control does not work Remote control does not work Check whether the remote Replace the battery for remote controller’s battery controller exhausted or not. Check the U1 power supply is OK,U1.3 is Check the VCC net no front board about 5V Replace U1.
  • Page 26 Trouble shooting chart Can’t read disc or can’t open the disk door Can’t read disc or can’t open the disk door Check whether Check the connection of the 4PIN cable DVD loader running is from CN6 on the Power Board. normal Check 40pin cable from Fix the connection the 40pin cable...
  • Page 27 Trouble shooting chart No VFD display No VFD display Check whether the voltage Fix the connection power board +5Vstb on the front board is CN6& front board JP4 normal work or not. Check whether Check DC5V to AC 3V switch circuit voltage between F1&VFD F2 is AC3V...
  • Page 28 Trouble shooting chart Fan don’t work Fan don’t work Check on Power board Check R8 on Power board whether CN.1 is +11V Check cable Replace the cable connection fan to Power board CN1 Replace Fan...
  • Page 29 BDP3000 Wiring Diagram Ethernet L-R-CVBS-COAX HDMI Component DC in DC/DC 3.3V DC/DC 1.2V CLOCK SATA DDR2-0H MTK8520 ASA LOADER NAND FLASH DDR2-0L serial flash +12V DC/DC 1.8V +12V P.11 ResetBtn POW_SW switch board LED-2 front board LED-...
  • Page 30 Front Board Electric Diagram: +12V 3904 3904 0.1u 3904 VFD1 3.3uF/50V VFD20-0824 4.7K 3906 6.2V 3.3uF/50V 3904 -24V 1000pF 100k MCU CIRCUIT MXOUT MXIN +5VSTANBY 8MHz +5VSTANBY 27pF 27pF -24V RESET Circuit +5VSTANBY 22uF/50V 0.1uF R17 0R 0.1uF IR_IN M_IR PA3/PFD PA4/TMR D16311...
  • Page 31 Switch Board Electric Diagram: PLAY PICH=2.0 POW_SW LED2_5 47Pf CON1 47Pf SWITCH BOARD...
  • Page 32 Power Board Electric Diagram: U504 KA278R12 +12V CY504 102/400Vac R538 R512 BD501 KBP306 D503 CE503 R516 ZD508 R511 SR306 1000uF/16V 100k CE504 CE501 P6KE200 100K 1000uF/16V 100uF/400V R517 C511 470k 4.7UF R505 C501 222/1KV T501 EER28/28 +12V ZD503 CE507 27V 1/2W 47uF/35V CE505 ZD502...
  • Page 33 Power Board Electric Diagram for BDP3000/93: U504 U504 KA278R12 KA278R12 +12V CY504 CY504 C501 C501 102/400Vac 102/400Vac 103/1KV 103/1KV D505 D505 D507 D507 R511 R511 RL207 RL207 RL207 RL207 R512 R512 D503 D503 CE503 CE503 R516 R516 SR3100 SR3100 1000uF/16V...
  • Page 34 Main Board Electric Diagram: Power PWR1 CTP1 +5VIN 5V_USB 1.1V CON8P-2.54 CTP2 +5VIN CTP3 CB992 FB/0805 CTP4 0.1uF CE567 220uF/10V CTP5 1.1V_LX 1.1V_FB FB555 FB/0805 1.1V Power Circuit 10uH/LQH66SSN2R2M03 CTP6 CTP7 D519 CE594 CE595 CB940 + CE8 CB939 CB1001 0SR360 22uF/10V 22uF/10V 0.1uF...
  • Page 35 Main Board Electric Diagram: DDR PART ACH 1.8V 1.8V U101 U102 U107A A_DQ0 A_RA0 A_DQ16 A_RA0 A_DQ4 A_RA1 A_DQ22 A_RA1 A_DQ0 CB198 A_DQ7 A_RA2 A_DQ21 A_RA2 VCC18IO ADQ0 A_DQ1 0.1uF 0.1uF A_DQ2 A_RA3 A_DQ19 A_RA3 VCC18IO ADQ1 A_DQ2 A_DQ3 A_RA4 A_DQ20 A_RA4 VCC18IO...
  • Page 36 U107B Main Board Electric Diagram: DDR PART BCH U103 U104 B_DQ0 B_RA0 B_DQ18 B_RA0 1.8V B_DQ0 B_DQ4 B_RA1 B_DQ20 B_RA1 BDQ0 B_DQ1 B_DQ2 B_RA2 B_DQ23 B_RA2 BDQ1 B_DQ2 B_DQ1 B_RA3 B_DQ19 B_RA3 AA25 BDQ2 B_DQ3 B_DQ6 B_RA4 B_DQ17 B_RA4 BDQ3 B_DQ4 CB129 CB154...
  • Page 37 Main Board Electric Diagram: AV OUTPUT FB200 FB/0603 AVDD33_APLL 3.3VA C201 U107C R243 Differential Signal ! 4.7uF CB202 R242 No Through Hole ! 0.1uF 0603-C R1235 100 ohm - Impedance D201 AVDD33_APLL AOMCLK_R TX2+ F_TX2+ AVDD33_APLL AOMCLK AOBCK_R L855 TDK ACM2012H-900-2P/0 AVSS33_APLL AOBCK FB201...
  • Page 38 Main Board Electric Diagram: FLASH R288 U107E R287 1.2VA 3.3V 3.3V CB311 SFCS SFCS U907 SFCK AVDD12_STX1 FB301 FB/0603 R1172 SFCK AVDD12_STX1 0.1uF SF DI AVDD12_SRX1 FB302 FB/0603 R304 SFCS SFDI AVDD12_SRX1 SFDO SF DI HOLD# RESET# RESET# (1,4,9) SFDO HOLD TP1026 SFCS2...
  • Page 39 Main Board Electric Diagram: PART 4 U107D 1.1V ETMDIO ETMDIO VCCK ETMDIO D516 ETMDC ETMDC VCCK ETMDC ETTXEN USBP0 USBP0 1:GND VCCK ETTXEN ETTXEN ETTXER USBP0 2:D+ VCCK ETTXER ETTXER ETTXCLK USBM0 USBM0 USBM0 ETTXCLK (9) VCCK ETTXCLK ETTXD0 USB_5V 3:D- ETTXD0 VCCK...
  • Page 40 7-10 7-10 Main Board Electric Diagram: VIDEO OUTPUT & SPDIF OUTPUT Low Impedance ow Impedance circuit with Real Line CB500 L871 R501 100R 0.1uF FB500R COAXOUT Hight Impedance Hight Impedance circuit with Broken Line ASPDIF R500 C501 VCC_CVBS 100pF 100R FB581 FB/0805 VCC_6363 COAXOUT OUTOUT...
  • Page 41 7-11 7-11 Main Board Electric Diagram: AUDIO OUTPUT AK4385 U914 +5VIN R1358 100R 78L05 L859 100uH AOMCLK +12V AOMCLK AOBCK AOBCK AOLRCK AOLRCK R1359 100R CE603 C611 C625 + CE604 Q213 220uF/10V 0.1uF 4.7uF 10uF/50V AOSDATA0 AOSDATA0 9012 AOSDATA1 AOSDATA1 AOSDATA2 AOSDATA2 AOSDATA3...
  • Page 42 7-12 7-12 Main Board Electric Diagram: LAN 8700 L3V3IO LAN3V3 FB578 3.3V FB579 L3V3IO LAN3V3 FB/0603 FB/0603 CE591 220uF/10v CE590 CB975 L3V3IO 220uF/10v 0.1uF CB976 CB977 CB978 CB979 CB980 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF R1294 L3V3IO 0805-R LAN3V3 R1296 PWFBOUT1 VDD_CORE R1299 NC/0R...
  • Page 43 7-13 7-13 Front Board Print-layout (Top and Bottom side):...
  • Page 44 7-14 7-14 Power Board Print-layout (Bottom side): Switch Board Print-layout (Bottom side):...
  • Page 45 7-14 7-14 Power Board Print-layout for BDP3000/93 (Bottom side):...
  • Page 46 7-15 7-15 Main Board Print-layout (Top side):...
  • Page 47 7-16 7-16 Main Board Print-layout (Bottom side):...
  • Page 48 Exploded view for BDP3000/93: PAC6 PAC9 PAC10 PAC7 PAC11 PAC12 PAC5 PAC8 PAC4 PAC3 PAC2 PAC1 PAC1. D-Box PAC6. Accessory Bag PAC7. Main Set PAC2. Right Buffer PAC9. Battery PAC10. AV Cable PAC8. Poly Bag PAC3. Left Buffer PAC4. QSG PAC11.
  • Page 49 Exploded View for BDP3000: It's a general mechanical exploded view for BDP3000, pls refer to the model set for detailed information. ASSY 1 includes components:2.3.4.5.22...
  • Page 50 BDP3000/55 SERVICE PARTLIST ELECTRICAL PARTLIST ASSY-PW BD COMPONENT PARTLIST 12NC No. Description Q'ty 12NC NO. Description Q'ty 996510025839 ASSY-MAIN BOARD 996510026648 BD501 RECTIFIER BRIDGE KBP306G 996510025842 ASSY-SW BOARD D501 996510013568 DIODE FR107 996510025843 ASSY-FE BOARD D502 996500014043 DIODE FR102 (FAST RECOVERY)
  • Page 51 BDP3000/93 SERVICE PARTLIST ELECTRICAL PARTLIST ASSY-PW BD COMPONENT PARTLIST 12NC No. Description Q'ty 12NC NO. Description Q'ty 996510025839 ASSY-MAIN BOARD D501 996510013568 DIODE FR107 996510025842 ASSY-SW BOARD D502 996500014043 DIODE FR102 (FAST RECOVERY) 996510025843 ASSY-FE BOARD D503 996500025702 DIODE SR3100...
  • Page 52 BDP3000/98 SERVICE PARTLIST ELECTRICAL PARTLIST ASSY-PW BD COMPONENT PARTLIST 12NC No. Description Q'ty 12NC NO. Description Q'ty 996510025839 ASSY-MAIN BOARD BD501 996510026648 RECTIFIER BRIDGE KBP306G 996510025842 ASSY-SW BOARD D501 996510013568 DIODE FR107 996510025843 ASSY-FE BOARD D502 996500014043 DIODE FR102 (FAST RECOVERY)
  • Page 53 BDP3000/94 SERVICE PARTLIST ELECTRICAL PARTLIST ASSY-PW BD COMPONENT PARTLIST 12NC No. Description Q'ty 12NC NO. Description Q'ty 996510025839 ASSY-MAIN BOARD BD501 996510026648 RECTIFIER BRIDGE KBP306G 996510025842 ASSY-SW BOARD D501 996510013568 DIODE FR107 996510025843 ASSY-FE BOARD D502 996500014043 DIODE FR102 (FAST RECOVERY...
  • Page 54 BDP3000/96 SERVICE PARTLIST ELECTRICAL PARTLIST ASSY-PW BD COMPONENT PARTLIST 12NC No. Description Q'ty 12NC NO. Description Q'ty 996510025839 ASSY-MAIN BOARD BD501 996510026648 RECTIFIER BRIDGE KBP306G 996510025842 ASSY-SW BOARD D501 996510013568 DIODE FR107 996510025843 ASSY-FE BOARD D502 996500014043 DIODE FR102 (FAST RECOVERY)
  • Page 55 REVISION LIST Version 1.0 * Initial release for BDP3000/55/93/98/94/96...
