Operation
Recommendations
Use COOL in summer.Use HEAT in winter.
Use DRY in spring,autumn and in damp climate.
(1) Unit start
Press ON/OFF button, unit starts.
Previous operation status appears on display
(Not Timer setting). Power indicator lights up.
(2) Select operation mode
Press MODE button. For each press, operation
mode changes as follows:
The function of code A
AUTO COOL
DRY
HEAT
FAN
The function of code B
COOL
DRY
HEAT
Unit will run in operation mode displayed on LCD.Stop display at your desired mode.
(3) Select temp. setting
Press TEMP button
Every time the button is pressed, temp. setting
increases 1 C.
If button is kept depressed, temp.setting will
increase quickly.
Every time the button is pressed, temp. setting
decreases 1 C.
If button is kept depressed, temp. setting will
decrease quickly.
Unit will start running to reach the temp. setting
on LCD.
(4) Fan speed selection
Press FAN button. For each press,
fan speed changes as follows:
Wire controller
AUTO
LOW
AUTO
MID
HIGH
Remote controller
The function of code A
The function of code B
A
A
U
U
T
T
O
O
LOW
MID
HIGH
AUTO
LOW
MID
HIGH
AUTO
Auto running: During the Auto running mode, air conditioning running and can auto-select the cooling,
heating, fan mode according to the room temperature.
Fan running: The AC only have air supply running no cooling and heating running at the condition, AC
can't have auto air supply running, and can't display the setting temperature value on the LCD.
During the heating running, after start the AC, in order to prevent cooled air, AC can stop for a while be-
fore send heat air.
During the dehumification running, when the room temp. setting temp. , not setting condition according
to the air speed.
A
U
T
O
MODE
FAN
SWING
AUTO
HEALTH
2
TEMP
4
TEMP
ON
CLOCK
3
SET
1
OFF
SWING
TIMER
SLEEP
5
MODE
SLEEP
HEAT
FILTER RESET
RESET
AM
HEALTH
FRESH
5
ON/OFF
CLOCK
SET
1
TIMER
HIGH/SO
FILTER
HEAT
LIGHT
LOCK
RESET
CODE
Unit runs at the speed displayed on LCD.In HEAT
mode, warm air will blow out after a short period
of time due to cold-draft prevention function.
In DRY mode, when room temp. becomes 2 C
higher than temp. setting, unit will run intermitte-
ntly at LOW speed regardless of FAN setting.
(5) Unit stop
Press ON/OFF button.
Only time and room temp remains on LCD.
All indicators go out.
Vertical flap closes automatically.
Hints
Wire controller can memorize each operation
status.
When starting it next time, just press ON/OFF
button and unit will run in previous status.
5
Operation
Set Clock correctly before starting Timer operation.
You can let unit start or stop automatically at following time: Before
A
you wake up in the morning, or get back from outside or after you
fall asleep at night.
TIMER ON/OFF
(1)After unit start, select your
desired operation mode.
Operation mode will be displayed
on LCD.Power indicator lights up.
(2)TIMER mode selection
FAN
4
Press TIMER button to change
TIMER mode.Every time the
button is pressed, display
changes as follows:
The function of code A
ON
OFF
The function of code B
OFF
ON
Select your desired TIMER mode (ON or OFF)
(3)Timer setting
Press TIME
Every time the button is pressed, time increases 10min.If button is kept
depressed, time will change quickly.
Every time the button is pressed, time decreases 10min.If button is kept depressed,
time will change quickly.
Time will be shown on LCD. It can be adjusted within 24hours.
(4)Confirming your setting
After setting correct time, press SET button to confirm "ON" or "OFF" stops flashing.
Time displayed: Unit starts or stops at x hour x min (ON or OFF). Timer mode indicator lights up.
To cancel TIMER mode
Just press TIMER button several times until TIMER mode disappears.
According to the seting timing open, close sequence, can realize first open then colse the unit or first
close then open the unit.
Hints:
Wire controller possesses memory function, when use TIMER mode next time, just
press SET button after mode selecting if timer setting is the same as previous one.
Wire remote controller or remote controller can memorize each working condition. Next time
open the unit, only need to press the ON/OFF key, the AC can work according to last time
working condition.(Timing, Sleeping and Swing mode not included.)
From Timing close to timing open, can setting sleep mode.
Please close health function first before setting Timer, then you can do the TIMER ON
operation.Please do not use the health function when in TIMER ON state.
MODE
FAN
TEMP
HEALTH
CLOCK
2
SET
TIMER
3
ON
HEAT
FILTER RESET
AM
AM
ON
blank
OFF
ON/OFF
blank
button.
6
A
SWING
TEMP
ON
SET
1
OFF
SWING
FAN
4
SLEEP
MODE
SLEEP
RESET
HEALTH
FRESH
CLOCK
SET
4
TIMER
HIGH/SO
1
FILTER
HEAT
RESET
CODE
LIGHT
LOCK
