- Page 1 IRK75M Illuminated Mechanical Keyboard Model No.：IRK75MS Quick Installation Guide...
- Page 2 Illuminated Mechanical Keyboard CONTENTS English ....... 1-1 Quick Installation Guide 繁體中文 快速安裝手冊 ..........2-1...
-
Page 3: Specifications
Illuminated Mechanical Keyboard Illuminated Mechanical Keyboard Package Contents •Mechanical Keyboard x 1 •User Manual x 1 IRK75M Illuminated Mechanical Keyboard Model No.：IRK75M Quick Installation Guide System Requirements •Compatible with: Windows® 7 , Windows® 8.1 and Windows® 10 operating system. •Available USB Port Specifications •Interface: USB ( Full Speed ) •Key number: 104 Keys... -
Page 4: Hardware Installation
Illuminated Mechanical Keyboard •N-Key rollover ( NKRO) •Multimedia keys: 14 keys •Backlight effective keys: 8 keys •Voltage / Current: DC 5V / 250 mA Max. •Weight: approx. 870g •Cable length: approx. 180 cm •Dimension: 438 (L) X 136 (W) X 40.5 (H) mm Hardware Installation 1. - Page 5 Illuminated Mechanical Keyboard •Caps lock indicator •Scroll lock indicator •Windows lock indicator PS1 : 4 indicators blinking (slow): all key lock activated PS2 : 4 indicators blinking (fast): backlight customization mode / macro recording 2. Hotkeys Press “ “ and desired function key simultaneously to use hotkeys.
- Page 6 Illuminated Mechanical Keyboard 2.2 Backlight Function Keys Side Backlight “ + “ “：Turn side backlight on or off •“ “ + “ “：Side backlight effects ( 3 types ) •“ “：Adjust side backlight “ + “ “ + “ “ or “ •“...
- Page 7 Illuminated Mechanical Keyboard and profiles will be stored in slot 0~9 respectively after saving. Press Fn + 0~9 to switch between different backlight customization profiles. When in other backlight modes, pressing Fn+Del will switch back to most recent backlight customization profile. How to customize backlight: A.
- Page 8 Illuminated Mechanical Keyboard 2.3 Multimedia & function key “ + “ “：Launch Music Player •“ “ + “ “：Decrease Volume •“ “：Increase volume “ + “ •“ “ + “ “：Mute •“ “ + “ “：Multimedia Stop •“ “ + “ “：Multimedia Previous •“...
- Page 9 Illuminated Mechanical Keyboard “ + “ “：Macro recording function •“ ( Access and save macros to Y / U / I / O / P ) A. Press“ “ to enter macro recording mode “ + “ (all 4 indicators will start blinking rapidly) B.
- Page 10 Illuminated Mechanical Keyboard 包裝內容 •鍵盤 X 1 •使用說明書 x 1 IRK75M Illuminated Mechanical Keyboard Model No.：IRK75M Quick Installation Guide 系統需求 •微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10 •可用的USB傳輸埠 產品規格 •產品名稱: 背光機械鍵盤 •產品型號: IRK75MS •介面: USB •按鍵數: 104 鍵 •開關形式: Cherry機械開關...
- Page 11 Illuminated Mechanical Keyboard •按鍵行程: 4.0mm •全區防鬼鍵設計 (NKRO) •多媒體鍵: 14 鍵 •背光特效鍵: 8 鍵 •電壓/電流: DC 5V / 250 mA Max. •產品重量: 約 870 公克 •USB 線長: 約 180 公分 •產品尺寸: 438 (L) X 136 (W) X 40.5 (H)mm 硬體安裝 1. 開啟電腦電源。 2.
- Page 12 Illuminated Mechanical Keyboard 產品資訊 1. LED 指示燈 •數字鎖指示燈 •大小寫指示燈 •滾動鎖指示燈 •視窗鍵鎖指示燈 註一 : 4個LED同時閃爍(慢閃)，表示全鍵鎖鍵功能 註二 : 4個LED同時閃爍(快閃)，表示進入按鍵背光自定義模式或字串錄 製模式 2.功能快捷鍵 同時按壓 “ “ 鍵跟下列按鍵產生對應的快捷功能 2.1 設定鍵 “ + “ “ + “ “：全區防衝突功能 •“ (鍵盤內定值) “ + “ “ + “ “：USB標準規範六鍵輸出功能...
- Page 13 Illuminated Mechanical Keyboard 2.2 背光功能快捷鍵 側背光功能 “ + “ “：側背光開啟跟關閉 •“ “ + “ “：側背光3種特效切換 •“ “：調整側背光明亮度 ( 四階 ) “ + “ “ + “ “ or “ •“ 按鍵背光 “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 ) •“...
- Page 14 Illuminated Mechanical Keyboard 使用者可直接按壓FN+1/2/3/4/5/6/7/8/9/0 直接叫出啟動對應的自 訂背光組別, 當按下FN+Del時，會啟動最後一次切換的自訂背光組 別。 自訂背光設定方式： A. 同時按壓“ “ + “ “ ，切換進入按鍵1自訂背光 B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製 ( 4個指示燈快閃爍 ) C. 選擇按壓想要背光亮起的按鍵 D. 繼續按壓其他要設定的按鍵 E. 按壓已亮起的背光按鍵，可取消該鍵背光 F. 完成設定，同時按壓“ “ + “ “ + “ “儲存背光設定至...
- Page 15 Illuminated Mechanical Keyboard 2.3 多媒體及功能快捷鍵 “ + “ “：開啟多媒體撥放軟體 •“ “ + “ “：調整音量小聲 •“ “ + “ “：調整音量大聲 •“ “ + “ “：音量靜音 •“ “ + “ “：停止播放 •“ “ + “ “：回上一首 •“ “ + “ “：播放/暫停 •“ “...
- Page 16 Illuminated Mechanical Keyboard “ + “ “：字串錄製模式功能 •“ ( 分別存取於Y / U / I / O / P 5組按鍵中 ) A. “ “ 進入字串錄製模式 ( 4個LED燈快閃 ) “ + “ B. 按壓“ “ + “ “ ( U/I/O/P )指定要對應存取的按鍵 C. 進行字串錄製 (每組最多15個字元 ) D.
- Page 17 Technology Co., Ltd. Headquarter Office 7F., No. 786, Zhongzheng Rd., Zhonghe Dist., New Taipei City 23586, Taiwan Tel : +886-2-2225-5080 Fax : +886-2-2228-1712 www.i-rocks.com i-Rocks Korea www.i-rocks.co.kr i-Rocks Malaysia 57-A, Jalan SS21/1A, Damansara Utama, 47400, Petaling Jaya, Selangor, Malaysia Tel : +603-77339233 www.i-rocks.com...
