ION Audio
Block Rocker
Bluetooth M5
Service Manual
This document contains sensitive proprietary
information.
All recipients must have a current non-disclosure
agreement on file with ION Audio.
Do not make illegal copies of this document.
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by ION Audio. If you are not the authorized, intended
recipient, you are hereby notified that any review, dissemination, distribution or duplication of
this document is strictly prohibited. If you are not authorized, please contact ION Audio and
destroy all copies of this document. You may contact ION Audio at support@ionaudio.com.
© Copyright ION Audio
Confidential
[iPA66C2]
v1.0
2015.08.11
ATTENTION!
ION Audio Service Manual
Advertisement
Related Manuals for ION Block Rocker Bluetooth M5
Summary of Contents for ION Block Rocker Bluetooth M5
- Page 1 The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by ION Audio. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited.
- Page 2 As the owner of the copyright to the Manual, ION Audio does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of ION Audio.
- Page 3 REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED ION AUDIO SERVICE CENTER WILL VOID THE ION AUDIO WARRANTY. PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO...
-
Page 4: Safety Instructions
The product is exposed to water or excessive moisture, c. The AC power supply plug or cord is damaged, d. The product shows an inappropriate change in performance or does not operate normally, or e. The enclosure of the product has been damaged. Confidential ION Audio Service Manual... - Page 5 Bill of Materials (BOM) Part # Part Name Description Qty. DR001653 IPA66C2(EU) Top cover IPA66C2(EU) Top cover ASSY 10160196 Faceplate DN-MC7065,aluminium alloy T=1.5mmm,V1.3 10520174 gasket low-carbon steel,T=1.5mm,electroplating black zinc,V1.0 16120133 Plug with cable AN-WE133,UL1007,22#,200mm 20020151 top cover DN-PC2100,ABS,UL94HB,PANTONE 877C,ROHS,V1.0 20110095 lens IPA16, PMMA,transparent,polish,V1.1 20200064 switch cap DN-PN1060,ABS,UL94HB,white,887C silver,V1.0...
- Page 6 17010537 electrolytic capacitor 1000uF/25V,-10/+20%,-40/+105℃,Φ10*16mm,P=5mm 17020013 electrolytic capacitor 1uF/50V,±20%,-40/+85℃,Φ4*7mm,P=1.5mm 17020032 electrolytic capacitor 10uF/50V,±20%,-40/+85℃,Φ5*7mm,P=2.0mm 17020084 electrolytic capacitor 100uF/16V,±20%,-40/+105℃,Φ5*7mm,P=2mm 17020086 electrolytic capacitor 220uF/16V,±20%,-40/+105℃,Φ6.3*7mm,P=2.5mm 18040122 LED AN-L0122,DIP,BL-BB53C4,Φ3*5mm, blue light 18040122 LED AN-L0122,DIP,BL-BB53C4,Φ3*5mm, blue light 20260057 LED cover LED3B-10 30010004 heat-shrinkable tubing Φ2*10*0.20mm,UL,black 40040017 3.5 plug AN-J0418,PJK-0358,electroplating silve 40370363 male socket AN-JP518,XHS-2AW,2P,P=2.54mm...
- Page 7 14010172 NPN triode KTC2875-A-RTK/P,SOT-23,KEC 14040895 IC MCP6002 SOP8 14041011 IC TLV70433DBVR,SOP-5,TR 14041013 IC TLV70450DBVR,SOT23-5,TI,Mark:PAX 24010009 magnetic bead 600Ω@100MHZ,0.5A,±25%,0805,FB0805-601 24010033 magnetic bead CB1608-721,200MHZ,720Ω,0603 24040045 chip inductor 2.2UH 30MA 0805 26020814 FR4 doule side PCB board AN-B20565,PRE,130*132*1.6mm 40330016 coupler IPEX-001,SMD 50050031 SMD ceramic capacitors 33PF,VDC50,±5%,NPO,0603 50050036 SMD ceramic capacitors 47PF,VDC50,±5%,NPO,0603...
- Page 8 50050414 SMD ceramic capacitors 10UF,VDC50,±20%,X7R,0805 DR001654 IPA66C2(EU) Faceplate IPA66C2(EU) Faceplate ASSY 12030031 switch AN-S331,RF-1003-BB4,BBG8E2L1T 13110011 switching power supply AN-T90011,K48P160300-1,100-240VAC,16VDC,3A 16040942 Plug with cable AN-W4502,2P,22#,UL1007,150mm 16040943 Plug with cable AN-W4503,2P,22#,UL1617,170mm 16040944 Plug with cable AN-W4504,2P,22#,UL1007,100mm 20010138 Faceplate DN-PC1076,ABS,UL94V-2,ROHS,V1.0 30060095 foam 10*1000*1mm,EVA1030 30090009 bunch-strand 2.5*120mm,black 40010051 power socket...
- Page 9 CR010774 IPA56C2(EU) POWER SMT IPA56C2(EU) POWER SMT ASSY 11170009 chip resistor 1/8W,10Ω,±5%,0805 11170350 chip resistor 1/10W,0Ω,±5%,0603 11170364 chip resistor 1/10W,100Ω,±5%,0603 11170381 chip resistor 1/10W,680Ω,±5%,0603 11170398 chip resistor 1/10W,4.7KΩ,±5%,0603 11170455 chip resistor 1/10W,47.5Ω,1%,0603 11170502 chip resistor 1/10W,3.01KΩ,±1%,0603 11170505 chip resistor 1/10W,3.3KΩ,±1%,0603 11170536 chip resistor 1/10W,10KΩ,±1%,0603 11170543 chip resistor...
- Page 10 4.7uF/50V,±20%,-40/+85℃,Φ6*17mm 20320015 handle DN-PE2015,ABS,white 20460013 fastener KY-CLT-2 20660026 rail DN-PC6024,rail-1,ABS,UL94HB,silver,ROHS,V1.0 20660027 rail DN-PC6025,rail-2,ABS,UL94HB,silver,ROHS,V1.0 21010459 cabinet MDF,T=9MM,wrapping PVC,CARB,V1.0 22010916 Quickguide Start IPA66C2(EU),V1.0 22010949 warranty user manual ION,V14.9 22050006 drier 50g,silica gel,non-woven,DMT,SGS 23010533 package bag （290+390）*750*0.1mm, V1.1 23010562 package bag PE,120*280*0.06mm, V1.0...
- Page 11 90080001 destination sticker GA0/GA1/GA2,copperplate paper 90200056 mark sticker copperplate paper, BLACK&361C,Φ30mm,V1.0 90220078 specialized sticker ALESIS,30*30mm,copperplate paper,PANTONE 361C,V1.0 90250038 CARB sticker ION,copperplate sticker,78*23mm,laminating,V1.0 90270010 date sticker copperplate sticker,laminating,13*6mm,V1.1 GR000598 IPA66C2(EU) operational IPA66C2(EU) operational package ASSY package 16070017 power cord AN-W920,3C,1.0mm2,H05VV-F,1830mm,black, UK version...
- Page 12 16070050 power cord AN-W953,3G,0.75mm2,H05VV-F,1830mm,black,French version 16070080 power cord AN-W982,3C,0.75mm2,H05VV-F,1830mm,black, AU version 16070140 power cord AN-W1038,3G,0.75mm2,H05VV-F,1830mm,black, Isarel version 16070141 power cord AN-W1039,3G,0.75mm2,H05VV-F,1830mm,black, Swiss version 22150001 Support card ION serial,V1.1 90200071 mark sticker green round sticker...
