- Page 1 ELFW4017 40" FHD Digital LED TV INSTRUCTION MANUAL Please read all the instructions carefully before using this TV, and keep the manual for future reference.
-
Page 3: Table Of Contents
CONTENTS Important Safety Instructions Additional Safety Information Preparations What is Included Front View Rear View Wall Mounting Remote Control Connecting External Devices Operating Your TV Turning On/Off Your TV Setup Wizard Selecting The Input Source Channel Selection Volume Adjustment Customizing TV Settings Navigating the On-screen Display Picture Settings Audio Settings... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • Read these instructions – All the safety • Refer all servicing to qualified service and operating instructions should be read personnel. Servicing is required when before this product is operated. the apparatus has been damaged in any •... -
Page 5: Additional Safety Information
ADDITIONAL SAFETY INFORMATION To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical Safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. -
Page 6: Preparations
PREPARATIONS What is Included? TV Set Remote Control with Batteries ELFW4017 40"FHD Digital LED TV INSTRUCTION MANUAL QUICK START GUIDE Please read all the instructions carefully before using this TV, and keep the manual for future reference. Quick Start Guide... -
Page 7: Front View
PREPARATIONS Front View • Switch the TV between On / Standby mode. • SOURCE Press to select among different input signal sources. • MENU Display the OSD (on screen display) menu. • CH Press to select a channel. • VOL +/- Press to adjust the volume. •... -
Page 8: Rear View
PREPARATIONS Rear View 1. Headphone Socket 5. VGA Input Connect to the Headphones. Connect to a computer or other devices 2. Optical Output with a VGA interface. Connect a digital sound system to this 6. PC AUDIO Input jack. Connect to a computer audio output. 3. -
Page 9: Remote Control
PREPARATIONS Remote Control Power Button USB Button Picture Mode Button ASPECT Button Sound Mode Button Sleep Button Numeric Buttons Channel Setup Button Return Button Mute Button Volume Adjust Button Channel Selection Button Signal Source Button TV Setup Menu Button FREEZE Button MTS Button Information Button Return Button... - Page 10 PREPARATIONS Remote Control TV Operation Switch the TV between on and standby mode. Access into the USB directly. P.MODE Select picture mode: Dynamic/Movie/Natural/User/Standard. S.MODE Select sound mode: Standard/Music/Movie/User. SLEEP Set the TV sleep timer: off/5/10…/180/240 min. Select the aspect ratio settings:Normal/Wide/Zoom/Cinema/Just ASPECT Scan(only for HDMI Source)/Dot To Dot(only for VGA Source).
-
Page 11: Connecting External Devices
CONNECTING EXTERNAL DEVICES Blu-ray Player / Recorder Computer Game Console Satellite Video Camera Antenna Cable Satellite Receiver Headphones Digital Audio System HDMI Device... -
Page 12: Operating Your Tv
OPERATING YOUR TV Turning On/Off Your TV • Connect the power cord to the power socket after you have completed all the physical connections. At this stage, the TV will enter Standby Mode and the red LED indicator will illuminate. • In Standby Mode, press the button on the main unit or on the remote control to turn the TV on. -
Page 13: Selecting The Input Source
OPERATING YOUR TV Selecting The Input Source INPUT SOURCE • Press the SOURCE button on the main unit or on the remote control to Component display the Input Source list. HDMI1 • Press the buttons to select HDMI2 your desired input source among: HDMI3 TV/Component&AV/HDMI1/HDMI2/ HDMI3/VGA/USB and then press OK... -
Page 14: Customizing Tv Settings
CUSTOMIZING TV SETTINGS Navigating the On-screen Display • Press the MENU button to display the main menu. • Press the buttons to navigate and select the available menus. Picture Picture Picture Mode Standard Contrast Sound Mode Standard Audio Brightness Bass Audio Color Treble... -
Page 15: Picture Settings
CUSTOMIZING TV SETTINGS Picture Settings • Press the MENU button on the main unit or on the remote control then press the buttons to select Picture Picture Mode Standard PICTURE menu and then press the Contrast Brightness Audio or the OK button to enter. Color • Press the buttons to select the... -
Page 16: Audio Settings
CUSTOMIZING TV SETTINGS Audio Settings • Press the MENU button on the main unit or on the remote control then press the buttons to select Picture AUDIO menu and then press the Sound Mode Standard Bass the OK button to enter. Audio Treble • Press the... -
Page 17: Time Settings
CUSTOMIZING TV SETTINGS Time Settings • Press the MENU button on the main unit or on the remote control then press the buttons to select Picture TIME menu and then press the Sleep Timer Time Zone Pacific Audio the OK button to enter. Daylight Saving Time • Press the buttons to select... -
Page 18: Setup Menu
CUSTOMIZING TV SETTINGS Setup Menu • Press the MENU button on the main unit or on the remote control then press the buttons to select Picture Menu Language English SETUP menu and then press the Transparency Zoom Mode the OK button to enter. Audio Wide Noise Reduction... -
Page 19: Lock Settings
CUSTOMIZING TV SETTINGS Lock Settings • Press the MENU button on the main unit or on the remote control and then press buttons to select LOCK menu. • Use the 0-9 buttons to input 4-digit password to enter the LOCK menu. • Press the buttons to select the following options and then press the buttons to adjust each option’s setting. -
Page 20: Parental Control
CUSTOMIZING TV SETTINGS Parental Control Press the MENU button on the main unit or on the remote control and then press the buttons to select LOCK menu. Use the 0-9 buttons to input 4-digit password to enter the LOCK menu. If used, this option feature can "block'' undesirable programming from appearing on the TV. - Page 21 PG-13 greater degree of offensive material suggested Cautioned than a PG rated program. Not for children under 17, strong element of Restricted sex and/or violence. No children under N o t f o r c h i l d r e n u n d e r 1 7 u n d e r a n y...
-
Page 22: Channel Settings
CUSTOMIZING TV SETTINGS Channel Settings • Press the MENU button on the main unit or on the remote control and then press the buttons to select Picture CHANNEL menu. Air/Cable Cable Auto Scan Audio • Press buttons to select the Favorite following channel options and then Show/Hide... -
Page 23: Usb Multimedia
USB MULTIMEDIA Viewing Pictures • Press the SOURCE button on the main unit or on the remote control C:\PICTURE\ Phot then press the buttons to select 2010100.jpg the USB mode and then press OK 2010100.jpg 2010101.jpg button. 2010102.jpg 2010103.jpg • Press the buttons to select PHOTO and then press OK button. -
Page 24: Troubleshooting
TROUBLESHOOTING If your TV does not operate normally or cannot be turned on, please check the following troubleshooting questions. Remember also to check any other connected electronic device, such as DVD or blu-ray player to pinpoint the problem. If the TV still fails to operate normally, please contact technical support (Refer to Warraty page). - Page 25 TROUBLESHOOTING Before contacting the service technician, perform the following simple checks. If any problem still persists, unplug the LED TV and call for assistance. PROBLEM POSSIBLE SOLUTIONS • Check that the main plug has been connected to a wall outlet. • Check that you have pressed the POWER on the No sound and picture front of the TV set.
- Page 26 TROUBLESHOOTING Note: When there is a problem in VGA mode ( only when VGA mode is applied). PROBLEM POSSIBLE SOLUTIONS • Adjust resolution, horizontal or vertical frequency. The signal is out of range • Check whether the signal cable is connected or loose. • Check the input source. Ve r t i c a l b a r o r s t r i p o n t h e • Set the auto configure or adjust clock, phase, or background, horizontal noise H/V position.
-
Page 27: Fcc Notes
• receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.” Please send all correspondence to: Element TV Company, LP. Customer Service 15930 Valley Blvd., City of Industry, CA 91744 customerservice@elementelectronics.com SPECIFICATIONS Panel Size 40 inches diagonally... - Page 28 This product contains electrical or electronic materials. The presence of these materials may, if not disposed of properly, have potential adverse effects on the environment and human health. Presence of this label on the product means it should not be disposed of as unsorted waste and must be collected separately.
