This Service manual is for HTS3105/98/75 First and Second Generation
models.
For First Generation model (HTS3105/98/75), the serial number begins with
NW1A xxxx xxxx (PSCI) and VN1A xxxx xxxx (PACH).
For Second Generation model (HTS3105/98/75), the serial number begins with
NW2A xxxx xxxx (PSCI) and VN2A xxxx xxxx (PACH).
© Copyright 2006 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in
a retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Published by KC-TE 0742 AV Systems
Version 1.3
Page
Contents
2
4
8
9
11
14
17
17
18
19
19
8
20
21
22
22
22
23
24
9
Printed in the Netherlands
HTS3105MKI
HTS3105MKII
Subject to modification
/
98/75
/
93/98/75
Page
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
39
40
41
42
43
43
44
45
EN 3139 785 31953
Advertisement
Table of Contents
Related Manuals for Philips HTS3105MKI/98
Summary of Contents for Philips HTS3105MKI/98
-
Page 1: Table Of Contents
For Second Generation model (HTS3105/98/75), the serial number begins with NW2A xxxx xxxx (PSCI) and VN2A xxxx xxxx (PACH). © Copyright 2006 Philips Consumer Electronics B.V. Eindhoven, The Netherlands. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips. -
Page 2: Technical Specifications And Connection Facilities
EN 2 3139 785 3195x Technical Specifications and Connection Facilities LOCATION OF PC BOARDS HTS3105 VERSION VARIA TIONS: HTS3105 Type /Versions: Features & Progressive Scan Line-Out TV-In Aux-In Y/Pb/Pr (YUV) Component Video Output CVBS SCART... - Page 3 3139 785 3195x EN 3 Technical Specifications and Connection Facilities 1. Specifications General: AMPLIFIER: Mains voltage : 120V/230V Output power Mains frequency : 50/60Hz Front : 100W RMS / channel Power consumption : 70W Rear : 75W RMS / channel <...
-
Page 4: Measurements Setup, Service Aid & Lead Free Requirements
EN 4 3139 785 3195x Measurements Setup, Service Aid & Lead Free Requirements 2. Measurements Setup, Service Aid & Lead Free Requirements MEASUREMENT SETUP Tuner FM Bandpass LF Voltmeter 250Hz-15kHz e.g. PM2534 e.g. 7122 707 48001 RF Generator e.g. PM5326 S/N and distortion meter e.g. - Page 5 3139 785 3195x EN 5 Measurements Setup, Service Aid & Lead Free Requirements SERVICE AIDS Service Tools: Universal Torx driver holder ........4822 395 91019 Torx bit T10 150mm ..........4822 395 50456 Torx driver set T6 - T20 ......... 4822 395 50145 Torx driver T10 extended ........
- Page 6 EN 6 3139 785 3195x Measurements Setup, Service Aid & Lead Free Requirements WAARSCHUWING WARNING Alle IC’s en vele andere halfgeleiders zijn All ICs and many other semi-conductors are gevoelig voor electrostatische ontladingen (ESD). susceptible to electrostatic discharges (ESD). Onzorgvuldig behandelen tijdens reparatie kan Careless handling during repair can reduce life de levensduur drastisch doen verminderen.
- Page 7 Due to lead-free technology some rules have to be respected by the workshop during a repair: • Use only lead-free solder alloy Philips SAC305 with order code 0622 149 00106. If lead-free solder-paste is required, please contact the manufacturer of your solder-equipment.
-
Page 8: 2.2 Service Hints
EN 8 3139 785 3195x Measurements Setup, Service Aid & Lead Free Requirements 2.2 Service Hints CAUTION CHARGED CAPACITORS ON THE SERVO BOARD MAY DAMAGE THE DRIVE ELECTRONICS WHEN CONNECTING A NEW DRIVE.THAT’S WHY, BESIDES THE SAFETY MEASURES LIKE • SWITCH OFF POWER SUPPLY •... -
Page 9: Directions For Use
3. Directions For Use The following except of the Quick Use Guide serves as an introduction to the set. The Complete Direction for the Use can be downloaded in different languages from the internet site of Philips Customer care Center: www.p4c.philips.com... - Page 10 EN 10 3139 785 3195x Directions for Use...
-
Page 11: Dismantling Instructions & Service Positions
3139 785 3195x EN 11 Dismantling Instructions & Service Positions Dismantling Instructions Dismantling of the DVD Loader Tray Cover Dismantling of the Front Board, PSU Module & DVD Loader. 1) Insert a minus screwdriver and push the lever in the direction as shown in Figure 4-1 to unlock the tray before 1) Release 4 snap hooks to remove the Front Board. - Page 12 EN 12 3139 785 3195x Dismantling Instructions & Service Positions Dismantling of the Tuner Module & Mono Dismantling of the Amp-module Board Board. 1) Loosen 4 screws F and 2 screws G (See Figure 4-7 & Figure 4-8) to remove Amp-Module Board. 1) Loosen 1 screw to remove the Tuner Module.
- Page 13 3139 785 3195x EN 13 Dismantling Instructions & Service Positions Service Positions Insulation Sheet Insulation Sheet Mono Board Front Board Service Position - Front Board Service Position - Mono Board Insulation Sheet Amp Board Service Position -Amp-Board...
-
Page 14: Service Test Program
EN 14 3139 785 3195x Service Test Program Service Test Program To start service test program refers to Service Mode open the tray with remote control refers to Version or front panel key, while plugging xx refers to Software version number of BEA in the mains cord press 2, 5 8 on (counting up from 01 to 99) remote control, the tray will close... - Page 15 3139 785 3195x EN 15 Service Test Program 4.1.1 Reprogramming of DVD version Matrix 4.1.4 Procedure to upgrade the firmware After repair, the customer setting and region code may be lost. 1. Power up the set and open tray. Reprogramming will put the set back in the state in which it has left 2.
- Page 16 EN 16 3139 785 3195x Service Test Program Notes:...
-
Page 17: Block Diagram And Wiring Diagram
Block Diagram, Wiring Diagram 3139 785 3195x EN 17 Block Diagram 200 W Power Amplifier HEF4052B ERROR CONTROL Front Board 3139-248-3380x (MKI) MONO BD 3139-248-87551 (MKII) HTS3100_block_duagram_MK2.pdf_2006_04_13... -
Page 18: Wiring Diagram
Block Diagram, Wiring Diagram 3139 785 3195x EN 18 Wiring Diagram FL SR SL SW TUNER SCART 1501 TM10 Port_S TU_SCL AMPLIFIER BOARD TU_SDA Analog SW (3139 247 12701) TU_SD 1 GNDD Video Circuit TU_L SCLK GNDD TU_Stereo TU-R MONO BOARD LRCLK +5VL GNDD... -
Page 19: Circuit Diagram And Pwb Layout
Circuit Diagram and PWB Layout 3139 785 3195x EN 19 Front: Display 1701 B9 F715 D10 1702 F2 F716 C9 1703 E2 F717 C12 1705 E5 F718 B2 DISPLAY BOARD 1707 D2 F719 B2 1708 H2 F720 B3 +12VL 1709 B2 F721 D2 1710 H8 F723 D2... -
Page 20: Front: Display (Topview)
Circuit Diagram and PWB Layout 3139 785 3195x EN 20 Front: Display (topview) DisplayBd_Topview_33782.pdf_031806... -
Page 21: Front: Display (Bottom View)
Circuit Diagram and PWB Layout 3139 785 3195x EN 21 Front: Display (Bottom view) DisplayBd_Bottomview_33782.pdf_031806... -
Page 22: Front: Standby
Circuit Diagram and PWB Layout 3139 785 3195x EN 22 Front: Standby Front: Standby (Top View) Front: Standby (Bottom View) 1801 A2 1802 A1 2801 A1 3801 A2 6801 B2 F801 A1 F802 A1 F803 A1 1801 1802 F801 SKQNAB F802 F803 3801... -
Page 23: Mki Mono Board: Circuit Diagram (Part 1)
Circuit Diagram and PWB Layout 3139 785 3195x EN 23 MKI Mono Board: Circuit Diagram (Part 1) 1101 D1 2241 I7 6100 I10 1102 G1 2242 I8 6105 A1 +S_V33 1103 H1 2243 I8 6106 A1 B_Cb 1105 I9 2245 I9 7102 A2 +4.5V 1108 I10... -
Page 24: Mki Mono Board: Circuit Diagram (Part 2)
Circuit Diagram and PWB Layout 3139 785 3195x EN 24 MKI Mono Board: Circuit Diagram (Part 2) 1201 C10 T222 C9 1202 C10 T236 A3 2110 C8 T237 B2 +3V3_D +3V3_D 2252 A3 T238 F3 2280 2279 2253 B3 T240 D6 2254 B3 +3V3_D 7207... -
Page 25: Mki Mono Board: Circuit Diagram (Part 3)
Circuit Diagram and PWB Layout 3139 785 3195x EN 25 MKI Mono Board: Circuit Diagram (Part 3) 1300 A1 3364 I6 1301 C1 3365 A9 1302 F1 3366 A10 1303 G1 3368 B9 1304 H1 4300 C3 2306 A2 4301 D3 2307 C2 4302 D10 2308 C6... -
Page 26: Mki Mono Board: Circuit Diagram (Part 4)
Circuit Diagram and PWB Layout 3139 785 3195x EN 26 MKI Mono Board: Circuit Diagram (Part 4) 1400 B1 F405 B4 1401 E1 F406 C4 1402 C1 F407 C4 1403 B4 F408 B3 2400 A4 F411 D2 2401 F4 F412 E2 4403 +5VL 2402 A3... -
Page 27: Mki Mono Board: Circuit Diagram (Part 5)
Circuit Diagram and PWB Layout 3139 785 3195x EN 27 MKI Mono Board: Circuit Diagram (Part 5) 1501-1 B12 1501-2 E12 1502 G12 2500 B2 2501 B13 2502 B10 2503 B13 2504 B10 For Scart version only 2505 C13 2506 C13 SCART 1 2507 C13 2508 D13... -
Page 28: Mki Layout: Mono Board (Top View)
Circuit Diagram and PWB Layout 3139 785 3195x EN 28 MKI Layout: Mono Board (Top view) MonoBd_Topview_33803.pdf_031806... -
Page 29: Mki Layout: Mono Board (Bottom View)
Circuit Diagram and PWB Layout 3139 785 3195x EN 29 MKI Layout: Mono Board (Bottom view) MonoBd_Bottomview_33803.pdf_031806... -
Page 30: Mkii Mono Board: Circuit Diagram (Part 1)
Circuit Diagram and PWB Layout 3139 785 3195x EN 30 MKII Mono Board: Circuit Diagram (Part 1) 1101 D1 2249 I12 6106 B13 1102 G1 2250 I10 7103 A5 1103 H1 2251 I11 7104 C3 1105 I8 3101 A13 7105 D3 RFVDD3 RFV33 5128 600R... -
Page 31: Mkii Mono Board: Circuit Diagram (Part 2)
Circuit Diagram and PWB Layout 3139 785 3195x EN 31 MKII Mono Board: Circuit Diagram (Part 2) 1201 C9 T221 C9 1202 C10 T222 C9 2252 A3 T236 A3 +3V3_D +3V3_D 2253 B3 T237 B2 2254 B3 T238 F3 2279 2280 +3V3_D 2255 B3... -
Page 32: Mkii Mono Board: Circuit Diagram (Part 3)
Circuit Diagram and PWB Layout 3139 785 3195x EN 32 MKII Mono Board: Circuit Diagram (Part 3) 1300 A1 3364 I6 1301 C1 3365 A9 1302 F1 3366 A10 1303 G1 3368 B9 1304 H1 3369 H10 2306 A2 3370 I10 2307 B2 4300 C3 2308 C6... -
Page 33: Mkii Mono Board: Circuit Diagram (Part 4)
Circuit Diagram and PWB Layout 3139 785 3195x EN 33 MKII Mono Board: Circuit Diagram (Part 4) 1400 B1 7411 D7 1401 D1 7412 E7 1402 C1 7413 A2 1403 A4 F400 A3 2400 A3 F401 A3 2401 F3 F402 B3 2402 B3 F403 B4 2403 B5... -
Page 34: Mkii Mono Board: Circuit Diagram (Part 5)
Circuit Diagram and PWB Layout 3139 785 3195x EN 34 MKII Mono Board: Circuit Diagram (Part 5) 1501-1 B12 1501-2 E12 1502 G12 2500 B2 2501 B13 2502 B11 2503 B13 2504 B11 For Scart version only 2505 C13 2506 C13 2507 C13 SCART 1 2508 D13... -
Page 35: Mkii Layout: Mono Board (Top View)
Circuit Diagram and PWB Layout 3139 785 3195x EN 35 MKII Layout: Mono Board (Top view) HTS3100_MK2_3139_243_33892_01_TopView.pdf_082206... -
Page 36: Mkii Layout: Mono Board (Bottom View)
Circuit Diagram and PWB Layout 3139 785 3195x EN 36 MKII Layout: Mono Board (Bottom view) HTS3100_MK2_3139_243_33892_01_BottomView.pdf_082206... -
Page 37: Psu Circuit Diagram
Circuit Diagram and PWB Layout 3139 785 3195x EN 37 PSU Circuit Diagram (For information only) PSU: Europe PSU Module AP.pdf_R-98_1925_031806... -
Page 38: Overview - Modulator, Input/Output And Headphone/Line Output Connectors
Overview - Modulator, Input/Output and Headphone/Line Output 3139 785 3195x EN 38 Connectors For information only (Amp Board) TAS5508-5142V6REF2 +3.3V 100nF 100nF CHANNEL 1-2 PVDD PWM_A PVDD GVDD PWM_B PWM_C GVDD PWM_D CH1+ OUT_A CH1- OUT_B TP22 TP22 J101 J101 CH 1 TP23 TP23... -
Page 39: Power Output Stage (Btl)
Overview - Modulator, Input/Output and Headphone/Line Output 3139 785 3195x EN 39 Connectors For information only (Amp Board) POWER OUTPUT STAGE (BTL) L170 L170 C113 C113 100nF 100nF 0603 0603 PVDD L171 L171 C115 C115 100nF 100nF 0603 0603 GVDD L130 L130 10uH... -
Page 40: Power Supplies
Overview - Modulator, Input/Output and Headphone/Line Output 3139 785 3195x EN 40 Connectors POWER SUPPLIES PVDD C950 C950 C951 C951 C952 C952 C954 C954 C953 C953 C955 C955 R901 R901 100nF 100nF 10nF 10nF 100nF 100nF 10nF 10nF 100nF 100nF 10nF 10nF 0603... -
Page 41: Amp Board Layout : Topview
Overview - Modulator, Input/Output and Headphone/Line Output 3139 785 3195x EN 41 Connectors Amp Board Layout : Topview Pg4_A774_PCB_004 (2.00).pdf_Topview_031806... -
Page 42: Amp Board Layout : Bottomview
Overview - Modulator, Input/Output and Headphone/Line Output 3139 785 3195x EN 42 Connectors Amp Board Layout : Bottomview hts3105ampbdbtm.pdf_Bottomview_031806... -
Page 43: Exploded View & Spare Parts List
Exploded View & Spare Parts List 3139 785 3195x EN 43 Exploded View of the Set Figure 9-1... -
Page 44: Spare Part List
EN 44 3139 785 3195x Exploded View & Spare Parts List HTS3105/75 MISCELLANEOUS 0110 313924410911 COVER TRAY HTS3105 PNT PRT 0127 313924410091 KNOB VOLUME CHROME 0190 313911327763 SHIELD SMPS LX3900SA 0325 313924712641 BOX SPK ASSY SW-3105 P 0326 313924712631 BOX SPK ASSY CS-3105 P 0331 242207600546 FM AERIAL 24AWG BK B 0331 242207600852... -
Page 45: 11 Revision List
Revision List 3139 785 3195x EN 45 11 REVISION LIST 11.1 Manual 3139 785 31951 1. Additional of HTS3105/75 2. Additional of HTS3105/75 for Reprogramming of DVD version Matrix in page 15 of documents. 3. Revise of spare parts list for HTS3105/75 11.2 Manual 3139 785 31952 1.
