All-in-One

Hard Floor

Cleaner

Complete cordless

cleaning across

all hard floors.

Extend your warranty

by 1 year at:

www.swan-brand.co.uk/

product-manuals/

User Manual

Please read all instructions before

using this product, and keep it stored

safely for future reference.

Support: customerservice@swan-brand.co.uk

Table of Contents

Summary of Contents for Swann DIRT MASTER CROSS OVER

Page 1 All-in-One Hard Floor Cleaner Complete cordless cleaning across all hard floors. Extend your warranty by 1 year at: www.swan-brand.co.uk/ product-manuals/ User Manual Please read all instructions before using this product, and keep it stored safely for future reference. Support: customerservice@swan-brand.co.uk...
Page 3: Table Of Contents
Contents Safety Instructions What’s in the package? Product View Digital Display Operation Assembly Filling up the Clean Water Tank Charging the Cleaner Cleaning Floor with the Cleaner Self-Cleaning Care and Maintenance Specifications and spares Recycling/Warranty Trouble Shooting Error Codes Name and Content of Hazardous Substances www.swan-brand.co.uk Helpline: 0333 220 6050...
Page 4: Safety Instructions
Safety Instructions • This product is for home • Do not use cleaner to pick use. Please do not use up things that are burning it outdoors. or smoking, such as hot ashes or cigarettes. • Do not disassemble, repair, or refit cleaner without •...
Page 5 Safety Instructions • Keep hair, fingers, and • Please keep cleaner away other parts of the body from any metal objects, away from openings such as coins and paper and moving parts of clips when the battery the appliance. pack is not in use. •...
Page 6: What's In The Package
What’s in the Package? n Body Main Body Handle Handle Li-ion Battery Pack Li-ion Batte Handle Main Body n Body Handle Handle Handle Li-ion Battery Pack Li-ion Batte Main Body Handle Li-ion Battery Pack n Body Handle Handle Li-ion Battery Pack Li-ion Batte Main Body Handle...
Page 7: Product View
Product View Power Button Eco/Max Mode Spray Trigger Handle Self-clean button Clean Water Tank Digital Display Voice switch Dirty Water Tank Release Button Dirty Water Tank Battery Pack Brush Guard Battery Release Button...
Page 8 Product View Snuffle Valve Tube Roller Brush Lock Battery Slot Tube Release Hole Holder Scroll Wheel Scraper Battery Scroll Pack Battery Wheel Indicator Charging Cable Socket...
Page 9: Digital Display
Digital Display The indicator will light up white when the cleaner is in Eco Mode. The indicator will light up white when the cleaner is in Max Mode. It shows the Working Time from “Switch on” to “now”. The indicator will light up white when UV lamp is working. The indicator will flash RED slowly when Clean Water Tank is short of water, please fill up with clean water.
Page 10: Operation
Assembly Take out the Handle, Main Body, Li-ion Battery Pack, Clean Water Tank, Dirty Water Tank Set, Roller Brush, Charging Station, Drying Tray and Cleaning Tool from the package. 2. Insert the handle into main body of cleaner until you hear a click. (Fig. 1) 3.
Page 11: Filling Up The Clean Water Tank
Filling up the Clean Water Tank The cleaning water tank is located on the back of the main body. Grasp the top of the water tank with your fingers and pull it upwards to remove it. (Fig. 1) 2. Unscrew the water cap counter-clockwise as below and add some water, then screw it and insert the clean water tank into the cleaner.
Page 12: Charging The Cleaner
Charging the Cleaner Insert the drying tray into the charging station as shown in Fig. 1. 2. Place the charging station near the wall, plug the DC power socket of the adapter into the DC power socket of the charging station, and then plug the adapter into the power socket.
Page 13: Cleaning Floor With The Cleaner
Cleaning Floor with the Cleaner Check the Handle, the clean water tank, the dirty water tank, the Li-ion battery pack, the roller brush, make sure all of them are installed correctly and tightly. 2. Press the switch button on the handle to turn on the cleaner. Press the Eco/ Max Mode button to switch the suction power.
Page 14: Self-Cleaning
Self-Cleaning The cleaner can clean the roller brush and pipeline automatically on the Self-Cleaning Base: Please make sure there is enough clean water in the clean water tank and empty dirty water tank before self-cleaning. 2. Place cleaner on the charging station (Fig. 1) and plug in the power supply. 3.
Page 15: Care And Maintenance
Care and Maintenance Please unplug the power supply, turn off the switch, and remove the battery pack out before care and maintenance. Daily care and maintenance Use a soft dry mop to wipe the main body, the charging station; use a soft moist cloth to wipe the brush base, scraper, infrared sensor.
Page 16 Care and Maintenance Pour the debris into the dustbin, pour the dirty water into washbasin. Clean the dirty water tank, the cap, and the HEPA with clean water. Charging Station & Drying Tray Cleaning Unplug the power supply and take the main body out before cleaning. Pour out the dirty water of Charging Station, use a soft dry mop to wipe the charging station and Drying Tray.
Page 17 Care and Maintenance Storage Please dry the main body, clean water tank, dirty water tank, brush base, HEPA, Charging Station and drying tray. Then store them appropriately. The roller brush can be stored in the drying tray. Important tips: • The Dirty Water Tank must be cleaned and dried after every single cleaning to avoid mildew or smell.
Page 18: Specifications And Spares
Specifications Product Model SC51010N Size of Main Unit 290 x 250 x 1150mm Net Weight 4.30KG Input 0.8A Power Consumption 150W Battery Type Li-ion Battery Battery Capacity 5000 mAh Battery Voltage 25.2V Clean Water Tank Capacity 680 ml Dirty Water Tank Capacity 450 ml Working Time 51-56 mins...
Page 19: Recycling/Warranty
Recycling The symbol on the product or its packaging indicates that this product may not be treated as household waste. Instead, it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by...
Page 20: Troubleshooting
Troubleshooting Problems Possible Reasons Solutions Cleaner cannot The power supply Please check the be charged. does not connect well. connection of power Cleaner isn’t connected supply. well with charging station. Please replace cleaner on the charging station. The handle The battery capacity Please check the control doesn’t is low.
Page 21 Troubleshooting Problems Possible Reasons Solutions The clean The clean water volume is Pour out water until water tank is higher than snuffle valve. the volume is lower leaking. The clean water tank is than snuffle valve. not installed well. Please re-install the The cap is not water tank.
Page 22: Error Codes
Error Codes Error Code Causes Solutions FF:01 Charging over voltage Replace the adaptor FF:02 Charging over current Replace the adaptor FF:03 NTC open/short circuit Replace the battery pack Internal disconnection of the FF:04 Replace the battery pack battery pack Rechargeable battery voltage FF:05 Replace the battery pack is too low...
Page 23: Name And Content Of Hazardous Substances
Name and Content of Hazardous Substances Content of Hazardous Substances Plastic Electronic Rubber Component Cables Metal Parts Adapter Shell Components Components Cadmium(Cd) • • • • • • • Lead(Pb) • • • • • • • Mercury(Hg) • • •...
Page 24 www.swan-brand.co.uk Helpline: 0333 220 6050 2 year Est. 1 931 GUARANTEE Scan this QR code We love we’re proud Find us on Facebook to hear about what we do of our quality our story Copyright © 2021 Swan Products Ltd. PO Box 3117, Stoke-on-Trent ST4 9GD...
