One Stop Gardens 93358 Owner's Manual & Safety Instructions

Greenhouse 12' l x 10' wx 10'3" h
Hide thumbs Also See for 93358:

Advertisement

Quick Links

Download this manual
Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
93358
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
contact us as soon as possible.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Greenhouse
x
12' L
10' W
Shelving unit and pots not included.
x
10'3" H
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
20g

Advertisement

loading

Related Manuals for One Stop Gardens 93358

Summary of Contents for One Stop Gardens 93358

  • Page 1 12’ L 10’ W 10’3" H Shelving unit and pots not included. 93358 When unpacking, make sure that the product is intact and undamaged. If any parts are missing or broken, contact us as soon as possible. Read this material before using this product.

  • Page 2: Table Of Contents

    Indicates a hazardous situation which, if not avoided, could result in death or serious injury. Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. Addresses practices not related to personal injury. Page For technical questions,contact us. 93358...

  • Page 3: Safety

    Do not allow debris to accumulate on top of the greenhouse. If snowfall is expected, place additional supports (not provided) underneath the Crown. NEVER enter a greenhouse with accumulated debris on top. SAVE THESE INSTRUCTIONS. 93358 For technical questions, contact us. Page...

  • Page 4: Specifications

    12' L x 10' W x 10'  3 " H Window Dimensions 23-1/4" W x 31-1/4" L Door Dimensions 75-1/2" H x 35-1/2" W x 1-1/4" Thick Aluminum Frame Materials Transparent Polycarbonate Sheets Aluminum Thickness 0.038" Polycarbonate Sheet Thickness 0.165" Page For technical questions,contact us. 93358...

  • Page 5: Assembly

    At least two assistants will be necessary during assembly. • Assemble on a clear, calm day. Wind will damage the Greenhouse and make assembly difficult. • Ladders and gloves may need to be used.(not included) 93358 For technical questions, contact us. Page...

  • Page 6: Parts List

    2' 8″ Gable Post Front Center-Right 2' 8″ Brace 6' 1″ Gable Post Front-Left Front/Rear 1' 5″ 6' 7″ Gable Post Diagonal Strut Front-Right Side Diagonal 1' 5″ 7' 7″ Gable Post Strut For technical questions, contact us. Page 6 93358...
  • Page 7 Record Serial Number here： for illustration purposes only and are not available individually as replacement parts. Note:If product has noserial number record Specify UPC 193175344700 when ordering parts. month and year of purchase instead. For technical questions, contact us. 93358 Page 7...
  • Page 8 Phase 1: Base Assembly All parts in this phase are fastened using 32 Normal Bolts (52) and 32 Nuts (54).
  • Page 9 Connectors (68, 6 9 ） to secure the pieces together. Front Floor Plate (1a, 2a) Rear/Side Floor Plates (3 – 6) 1" gravel outside greenhouse Base Plate ground (66, 6 7 ) 93358 For technical questions, contact us. Page 9...
  • Page 10 Phase 2: Floor Plate Installation Grey parts are in place before this phase. Hold-down Connector (47) (Rear) attachment Floor Plate (Right) Base Plate gravel a. Slide Connector (47) under lip. b. Insert Regular Bolt (52). c. Fasten with Nut (54) (Front) All parts in this phase are fastened using...
  • Page 11 Plates overlap. 8. Secure the Rear Floor Plates to the Base Plates using two Hold-down Connectors (47) in the locations shown; see illustration and inset on facing page. 93358 For technical questions, contact us. Page 1 1...
  • Page 12 Phase 3: Corner Post Installation Grey parts are in place before this phase. Hold-down Connector (47) attachment with Strut (45，46) Floor Plate Base Plate gravel a. Slide Connector (47) under lip. b. Insert Brace Bolt (53). c. Slide Strut (45, 46) over Bolt. (Rear) d.
  • Page 13 Corner Post (7) on the right side. ,and Nuts (54); see inset on facing page. Keep in mind that the connections will be Allow Rear Braces to hang free. reversed compared to the left side. BOTTOM 93358 For technical questions, contact us. Page...
  • Page 14 Phase 4a: Ceiling Plate Assembly, Front 1. Insert Normal Bolts (52) 3. Slide the Bolt heads on the Front-left Ceiling Plat (24 through all holes in the ) into the slot of the Right Door Rail (27) front of the Front Ceiling Plates (24 from the left edge until it rests against the Front- , 25), as shown.
  • Page 15 Side Ceiling Plate with Brackets (12). Plain Side Ceiling Plate (13) and Side Ceiling Plate with 2. Secure in place with two Normal Bolts (52),as Brackets (12). shown in the inset above. 93358 For technical questions, contact us. Page...
  • Page 16 Phase 5: Ceiling Plate Installation Grey parts are in place before this phase. Means that the nearby Bolt will be removed and then re- attached at the same location. Parts in this phase are fastened using 2 Normal Bolts (52), (Left) (Front) 8 Brace Bolts (53),...
  • Page 17 Make sure that the arrows on both of the Rear Braces the Bolt, and secure with a Nut (52). (31) are pointing towards the Corner Posts (7). Secure the other end of that Side Ceiling Plate (12, 13) similarly. 93358 For technical questions,contact us. Page...
  • Page 18 (The Side Post (14) in this paragraph is the middle not equal, adjust the frame as needed until square. Some two behind the Green house) Nuts (54) may need to be loosened to adjust the frame. Tighten all Nuts after adjustment. For technical questions, contact us. 93358 Page...
  • Page 19 Phase 6: Post Installation Grey parts are in place before this phase. Means that the nearby Bolt will be removed (Rear) and then re-attached at the same location. Means that the bolt underneath will be loosened, a Post will slide over the bolt head, and then it will be re-tightened.
  • Page 20 Phase 7: Brace Installation Grey parts are in place before this phase. Means that the nearby Bolt will be removed and then re-attached at the same location. (Rear) (Right) (Left) Parts in this phase are fastened using 2 Normal Bolts (52), 20 Brace Bolts (53), and 66 Nuts (54).
  • Page 21 Front Floor Plates (1a, 2a) and to the inside of the Front Ceiling Plates (24, 25). Install the Posts with the cut-outs at top and oriented as shown in the illustration above. 93358 For technical questions, contact us. Page...
  • Page 22 Phase 8: Gable and Crown Installation Grey parts are in place before this phase. Means that the bolt underneath will be loosened, a Post will slide over the bolt 52(X2) head, and then it will be re-tightened. 52(X3) (Rear) 　 52(X4) 53　...
  • Page 23 4. Connect the Rear Crown with Brackets (10) and the Front Crown (11) with Normal Bolts (52), and then use Normal Bolts (52) and Nuts (54) to fix the connected (10, 11) to the top of Crown Beams (8,9). 93358 For technical questions, contact us. Page...
  • Page 24 Window Support Beam (41) and flat side of the Window Support Beam are both facing the inside of the greenhouse. Thread Nuts (54) onto the Normal Bolts and finger tighten them for now. 93358 For technical questions, contact us. Page...
  • Page 25 Phase 9: Rafter and Brace Installation Grey parts are in place before this phase. Means that the bolt underneath will be loosened, a Rafter will slide over the bolt head, and then it will be re-tightened. (Rear) (Right) Parts in this phase are fastened using 28 Normal Bolts (52), (Left) 20 Brace Bolts (53),...
  • Page 26 Window Pane. Secure it in place with Nuts (54). Press on the heads of the Bolts through the Window Pane to allow the Nuts to thread on properly. (View from underneath window, flat side of pieces.) Page 26 For technical questions, contact us. 93358...
  • Page 27 6. Loosen the Nuts (54) holding the Window Support Beam in place and slide the Window Support Beam up to touch the window. Secure it in place. 7. Repeat the steps in this phase for all four windows. (View from end of Crown.) 93358 For technical questions, contact us. Page...
  • Page 28 Phase 11: Door Assembly and Installation (back) (front) (Profiles exaggerated for clarity.)
  • Page 29 Door Panels (78). Slide the Door Panels into the door between the Door Frame (35-37) pieces. 6. Attach the other Side Door Frame (33) to the Center Door Frames (36) in the same way. 93358 For technical questions, contact us. Page...
  • Page 30 Phase 12: Panel Installation 70/71/76 X = Panel fixtures(51) Location O = Panel Connector (42) Location 74 / 73 warning 57/58 label location...

  • Page 31: Maintenance

    Greenhouse. 3. WHEN STORING: Keep the Greenhouse If a problem occurs with the Greenhouse, have it in a box and in a clean, dry location. corrected before further use. Do not use damaged equipment. 93358 For technical questions,contact us. Page...

  • Page 32: Warranty

    Limited 90 Day Warranty We sellers make every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
