HP Compaq dx5150 SFF Hardware Reference Manual

Business desktop small form factor model
Hide thumbs Also See for Compaq dx5150 SFF:
Table of Contents

Advertisement

Quick Links

Hardware Reference Guide
HP Business Desktops
dx5150 Small Form Factor model
Document Part Number: 373997-002
February 2005
This guide provides basic information for upgrading this computer
model.

Advertisement

Table of Contents
loading

Related Manuals for HP Compaq dx5150 SFF

Summary of Contents for HP Compaq dx5150 SFF

  • Page 1 Hardware Reference Guide HP Business Desktops dx5150 Small Form Factor model Document Part Number: 373997-002 February 2005 This guide provides basic information for upgrading this computer model.
  • Page 2 Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and other countries. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Optional HP Modular Keyboard........
  • Page 4 Shipping Preparation ........... E–3 Index www.hp.com Hardware Reference Guide...

  • Page 5: Product Features

    Standard Configuration Features The HP dx5150 Small Form Factor features may vary depending on the model. For a complete listing of the hardware and software installed in the computer, run the Diagnostics for Windows utility. Instructions for using this utility are provided in the Troubleshooting Guide on the Documentation CD.

  • Page 6: Front Panel Components

    Optical Drive (CD-ROM, CD-R/RW, DVD-ROM, DVD-R/RW, or CD-RW/DVD Combo Drive) Microphone Connector Headphone Jack USB (Universal Serial Bus) Ports Hard Drive Activity Light Power On Light Power Button Optical Drive Activity Light Optical Drive Eject Button www.hp.com Hardware Reference Guide...

  • Page 7: Rear Panel Components

    Guide on the Documentation CD. The DVI–D connector will only work with flat panel displays. Hardware Reference Guide l Parallel Connector c Monitor Connector Y Headphone/Line-Out Connector Line-In Audio Connector Microphone Connector c Digital Video Interface (DVI–D) Monitor Connector www.hp.com Product Features...

  • Page 8: Standard Keyboard Components

    Used to open the Start menu in Microsoft Windows. Used in Keys* combination with other keys to perform other functions. 9 Alt Keys Used in combination with other keys; its effect depends on the application software you are using. *Keys available in select geographic regions. www.hp.com Hardware Reference Guide...

  • Page 9: Optional Hp Modular Keyboard

    Optional HP Modular Keyboard If the computer kit includes an HP Modular Keyboard, refer to the HP Modular Keyboard User Guide on the Documentation CD for component identification and setup information. Special Mouse Functions Most software applications support the use of a mouse. The functions assigned to each mouse button depend on the software applications you are using.
  • Page 10 Product Features www.hp.com Hardware Reference Guide...

  • Page 11: Hardware Upgrades

    Ä CAUTION: Before removing the computer access panel ensure that the computer is turned off and that the power cord is disconnected from the electrical outlet. Hardware Reference Guide Hardware Upgrades Appendix D, “Electrostatic Discharge” www.hp.com...

  • Page 12: Using The Small Form Factor Computer In A Minitower Configuration

    The Small Form Factor computer can be used in either a minitower or desktop configuration. To use it in the minitower configuration, you must purchase a tower stand from HP (part number 316593-001). CAUTION: If the computer is in the desktop configuration, ensure at Ä...

  • Page 13: Removing The Computer Access Panel And Front Bezel

    3. Loosen the thumbscrew on the rear of the computer 1, slide the Removing the Computer Access Panel Hardware Reference Guide then turn off any external devices. computer, and disconnect any external devices. access panel toward the rear of the computer 2, then lift it off. www.hp.com Hardware Upgrades...
  • Page 14 To re-install the front bezel, insert the two bezel bottom tabs, then rotate the front bezel forward to snap the three tabs on the top of the bezel in place. top of the bezel, then pull the bezel 2 away from the chassis. www.hp.com Hardware Reference Guide...

  • Page 15: Installing Additional Memory

    CAS latency 3 (CL = 3) contain the mandatory JEDEC SPD information 128Mbit, 256Mbit, 512Mbit, and 1Gbit non-ECC memory technologies single-sided and double-sided DIMMS DIMMs constructed with x8 and x16 DDR devices; DIMMs constructed with x4 SDRAM are not supported www.hp.com Hardware Upgrades...

  • Page 16: Dimm Sockets

    DIMMs in all sockets or use identical DIMM pairs in each pair of sockets, XMM1 and XMM2 black sockets and XMM3 and XMM4 blue sockets. Otherwise, the system may not operate properly. www.hp.com Hardware Reference Guide...
  • Page 17 Sockets XMM2 and XMM4 operate in memory channel B. DIMM Socket Locations Item Hardware Reference Guide Description DIMM socket XMM1, Channel A DIMM socket XMM2, Channel B DIMM socket XMM3, Channel A DIMM socket XMM4, Channel B www.hp.com Hardware Upgrades Socket Color Black Black Blue Blue...

  • Page 18: Installing Ddr-Sdram Dimms

    CAUTION: Check the position of all cables and wires before raising or Ä lowering the Easy Access drive bay to prevent damage. Appendix D, “Electrostatic Discharge” then turn off any external devices. any external devices. “Removing the Computer Access Panel and Front Bezel.” www.hp.com Hardware Reference Guide...
  • Page 19 4. Rotate the Easy Access drive bay to an upright position. Rotating the Easy Access Drive Bay 5. Locate the memory module sockets. WARNING: To reduce risk of personal injury from hot surfaces, allow Å the internal system components to cool before touching. Hardware Reference Guide www.hp.com Hardware Upgrades...
  • Page 20 2. is fully inserted and properly seated. Make sure the latches are in the closed position 3. install. not to pinch the cables in the chassis when lowering the Easy Access drive bay. www.hp.com Hardware Reference Guide...

  • Page 21: Installing An Expansion Card

    3. Remove the computer access panel. Refer to 4. Identify the slot into which you want to insert the expansion card. Hardware Reference Guide then turn off any external devices. any external devices. Computer Access Panel and Front Bezel.” www.hp.com Hardware Upgrades “Removing the 2-11...
  • Page 22 5. Release the slot cover retention latch that secures the PCI slot 6. Remove the slot cover by sliding the slot cover up and pulling it Removing the Expansion Slot Cover 2-12 covers by pulling the latch up 1. toward the inside of the chassis 2. www.hp.com Hardware Reference Guide...
  • Page 23 Insert the metal slot cover in the open slot, then push the expansion slot latch down to secure the slot cover in place. www.hp.com Hardware Upgrades 2-13...

  • Page 24: Removing An Expansion Card

    Be sure not to scrape the card against the other components. expansion slot cover to close the open slot. cards and expansion slot covers. www.hp.com “Removing the Computer Hardware Reference Guide...

  • Page 25: Installing Additional Drives

    The computer has two external drive bays. When installing additional drives, install guide screws to ensure the drive will line up correctly in the drive cage and lock in place. HP has provided extra guide screws (four 6-32 standard screws and four M3 metric screws), installed in the front of the chassis, behind the bezel.

  • Page 26: Locating Drive Positions

    3.5-inch device bezel (PN 316008-001). To verify the type, size, and capacity of the storage devices installed in the computer, run Computer Setup. Refer to the Computer Setup (F10) Utility Guide for more information. 2-16 www.hp.com Hardware Reference Guide...

  • Page 27: Removing An Optical Drive Or Diskette Drive

    Hardware Reference Guide then turn off any external devices. any external devices. “Removing the Computer Access Panel and Front Bezel.” end of the audio cable should remain connected to the audio connector on the system board. www.hp.com Hardware Upgrades 2-17...
  • Page 28 To replace the drive, reverse the removal procedures. ✎ When replacing the drive, transfer the four screws from the old drive to the new one. The screws take the place of drive rails. 2-18 and hold. drive out of the computer. www.hp.com Hardware Reference Guide...

  • Page 29: Installing An Optional Optical Drive

    ✎ When replacing the drive, transfer the four screws from the old drive to the new one. The screws take the place of drive rails. Installing Guide Screws in the Optical Drive Hardware Reference Guide drive. www.hp.com Hardware Upgrades 2-19...
  • Page 30 3. Position the guide screws on the drive into the J-slots in the drive Installing the Optical Drive ✎ The drive release latch automatically locks in place when installing a drive. 2-20 bay 1. Then, slide the drive toward the rear of the computer 2. www.hp.com Hardware Reference Guide...
  • Page 31 Hardware Reference Guide connect the flat ribbon cable and audio cable to the system board. rear of the optical drive. not to pinch the cables in the chassis when lowering the Easy Access drive bay. www.hp.com Hardware Upgrades 2-21...

  • Page 32: Upgrading The Hard Drive

    4. Raise the Easy Access drive bay to the upright position. 5. Disconnect the power cable and data cable from the back of the 2-22 then turn off any external devices. any external devices. “Removing the Computer Access Panel and Front Bezel.” drive. www.hp.com Hardware Reference Guide...
  • Page 33 6. Press and hold the drive release latch 1. 7. Slide the drive to the right of the bay 2, then pull the drive from the bay 3. Removing the Hard Drive 8. To install a hard drive, reverse the above procedure. Hardware Reference Guide www.hp.com 2-23...
  • Page 34 Hardware Upgrades 9. Connect the power cable 1 and data cable 2 to the hard drive. Connecting the Power Cable and Data Cable 2-24 www.hp.com Hardware Reference Guide...
  • Page 35 Follow the instructions in the guide included with the Restore Plus! CD. When the restore process has completed, reinstall any personal files that you backed up before replacing the hard drive. Hardware Reference Guide system board connector. www.hp.com Hardware Upgrades 2-25...
  • Page 36 Start > Shut Down > Restart. Ctrl Follow the instructions to create RAID sets. For more detailed information, see the RAID installation guide at http://www.hp.com under support and drivers for the dx5150. www.hp.com to access the utility. to enter the RAID utility.

  • Page 37: Installing A Drive Into The 3.5-Inch Drive Bay

    3.5-inch device other than a diskette drive or hard drive, you must install the 3.5-inch device bezel (PN 316008-001). Contact an authorized HP reseller or service provider to order the appropriate bezel when reconfiguring the computer. Hardware Reference Guide www.hp.com...
  • Page 38 2. Disconnect the power cord from the power outlet and disconnect 3. Remove the computer access panel and front bezel. Refer to 2-28 then turn off any external devices. any external devices. “Removing the Computer Access Panel and Front Bezel.” www.hp.com Hardware Reference Guide...
  • Page 39 4. Remove the diskette drive bezel by pushing the tab inward 1 and pulling the diskette drive bezel 2 away from the front bezel. ✎ The type of bezel will vary depending on the computer configuration. Removing the Diskette Drive Bezel Hardware Reference Guide www.hp.com 2-29...
  • Page 40 Slide the drive 2 toward the back of the drive cage until the front screws are aligned with the front J-slots. Then lower the front of the drive. Continue to slide the drive all the way back until it locks into place. www.hp.com Hardware Reference Guide...
  • Page 41 If you are installing a 3.5-inch device other than a diskette drive or hard drive, you must install the 3.5-inch device bezel (PN 316008-001). Contact an authorized HP reseller or service provider to order the appropriate bezel when reconfiguring the computer.
  • Page 42 Hardware Upgrades 2-32 www.hp.com Hardware Reference Guide...

  • Page 43: Specifications

    CAUTION: If the computer is in the desktop configuration, ensure at least Ä 4 inches (10.2 cm) of space on all sides remains clear and free of obstructions. HP dx5150 Small Form Factor Desktop Dimensions Height Width Depth Approximate Weight...

  • Page 44: Power Supply

    Specifications HP dx5150 Small Form Factor (Continued) Heat Dissipation Maximum Typical (idle) Power Supply Operating Voltage Range Rated Voltage Range Rated Line Frequency ✎ This system utilizes a passive power factor corrected power supply when used in the 230V mode. This allows the system to pass the CE mark requirements for use in the countries of the European Union.

  • Page 45: Battery Replacement

    Do not attempt to recharge the battery. Do not expose to temperatures higher than 60° C (140º F). Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water. Replace the battery only with the HP spare designated for this product. www.hp.com...
  • Page 46 Lift the battery out of its holder. b. Slide the replacement battery into position, positive side up. The battery holder automatically secures the battery in the proper position. www.hp.com Hardware Reference Guide...
  • Page 47 Removing a Coin Cell Battery (Type 2) Hardware Reference Guide a. To release the battery from its holder, squeeze the metal clamp that extends above one edge of the battery. b. When the battery pops up, lift it out. www.hp.com Battery Replacement...
  • Page 48 Push the other edge down until the clamp snaps over the other edge of the battery. setups, using Computer Setup. Refer to the Computer Setup (F10) Utility Guide. www.hp.com Hardware Reference Guide...

  • Page 49: C Security Lock Provisions

    ✎ If present, insert the cable lock in the location shown below. The cable lock can also be inserted in the secondary hole highlighted below. Installing a Cable Lock Hardware Reference Guide Security Lock Provisions www.hp.com...
  • Page 50 Security Lock Provisions Installing a Padlock www.hp.com Hardware Reference Guide...

  • Page 51: D Electrostatic Discharge

    Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis. Wrist straps are flexible straps with a minimum of 1 megohm +/- 10 percent resistance in the ground cords. To provide proper ground, wear the strap snug against the skin. www.hp.com...
  • Page 52 HP authorized dealer, reseller, or service provider. ✎ For more information on static electricity, contact an HP authorized dealer, reseller, or service provider. Use heelstraps, toestraps, or bootstraps at standing workstations. Wear the straps on both feet when standing on conductive floors or dissipating floor mats.

  • Page 53: Computer Operating Guidelines And Routine Care

    Never restrict the airflow into the computer by blocking any vents or air intakes. Do not place the keyboard, with the keyboard feet down, directly against the front of the desktop unit as this also restricts airflow. Never operate the computer with the cover or side panel removed.

  • Page 54: Optical Drive Precautions

    Clean the panel and controls with a soft, dry cloth or a soft cloth lightly moistened with a mild detergent solution. Never spray cleaning fluids directly on the unit. www.hp.com Hardware Reference Guide...

  • Page 55: Safety

    ■ Safety If any object or liquid falls into the drive, immediately unplug the computer and have it checked by an authorized HP service provider. Shipping Preparation Follow these suggestions when preparing to ship the computer: 1. Back up the hard drive files on PD discs, tape cartridges, CDs, ✎...
  • Page 56 Computer Operating Guidelines, Routine Care and Shipping Preparation www.hp.com Hardware Reference Guide...
  • Page 57 2–11 expansion slot cover 2–12 front bezel, removing 2–4 front panel components 1–2 guidelines battery replacement B–1 hard drive 3.5-inch 2–27 activity light 1–2 configuration 2–26 guide screws 2–28 installing SATA 2–30 www.hp.com Index D–1 2–12 2–13 Index-1...
  • Page 58 2–4 hard drive 2–23 optical drive 2–17 PCI Express expansion card 2–14 RJ-45 connector 1–3 SATA See hard drive security lock provisions C–1 serial connector 1–3 serial number location 1–5 shipping preparation E–3 USB 1–2 www.hp.com 1–3 Hardware Reference Guide...
