HP Compaq d530 SFF Hardware Reference Manual

Business desktop
Hide thumbs Also See for Compaq d530 SFF:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
Hardware Reference Guide
HP Compaq Business Desktops
d530 Small Form Factor Model
Document Part Number: 317668-002
September 2003
This guide provides basic information for upgrading this computer
model.

Advertisement

Table of Contents
loading

Related Manuals for HP Compaq d530 SFF

Summary of Contents for HP Compaq d530 SFF

  • Page 1 Hardware Reference Guide HP Compaq Business Desktops d530 Small Form Factor Model Document Part Number: 317668-002 September 2003 This guide provides basic information for upgrading this computer model.
  • Page 2 Adobe, Acrobat, and Acrobat Reader are trademarks or registered trademarks of Adobe Systems Incorporated. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Upgrading the Hard Drive ......... . 2–26 Hardware Reference Guide www.hp.com Contents...
  • Page 4 Shipping Preparation ........... G–3 Index www.hp.com Hardware Reference Guide...

  • Page 5: Product Features

    Standard Configuration Features The HP Compaq Small Form Factor features may vary depending on the model. For a complete listing of the hardware and software installed in the computer, run the Diagnostics for Windows utility. Instructions for using this utility are provided in the Troubleshooting Guide on the Documentation Library CD.

  • Page 6: Front Panel Components

    Optical Drive (CD-ROM, CD-R/RW, DVD-ROM, DVD-R/RW, or CD-RW/DVD Combo Drive) Microphone Connector Headphone Jack USB (Universal Serial Bus) Ports Hard Drive Activity Light Power On Light Power Button Optical Drive Activity Light Optical Drive Eject Button www.hp.com Hardware Reference Guide...

  • Page 7: Rear Panel Components

    If you have installed an AGP and PCI graphics card, the connectors on both cards are active and can be used at the same time. Hardware Reference Guide n RJ-45 Network Connector l Parallel Connector c Monitor Connector h Headphone/Line-Out Connector Line-In Audio Connector Microphone Connector www.hp.com Product Features...

  • Page 8: Easy Access Keyboard

    Used to open the Start menu in Microsoft Windows. Used in combination with other keys to perform other functions. Used in combination with another key; its effect depends on the application software you are using. www.hp.com Hardware Reference Guide...

  • Page 9: Customizing The Easy Access Buttons

    Locks the computer if you are connected to a network domain, or allows you to switch users if you are not connected to a network domain. Launches the Run dialog box. Launches the Utility Manager. Activates the next Taskbar button. www.hp.com Product Features section to identify the Windows...

  • Page 10: Special Mouse Functions

    Each computer has a unique serial number that is located on the top cover or the back panel of the computer. Keep this number available for use when contacting customer service for assistance. Serial Number Location www.hp.com Hardware Reference Guide...

  • Page 11: Hardware Upgrades

    Ä CAUTION: Before removing the computer access panel ensure that the computer is turned off and that the power cord is disconnected from the electrical outlet. Hardware Reference Guide Hardware Upgrades Appendix F, “Electrostatic Discharge” www.hp.com...

  • Page 12: Using The Small Form Factor Computer In A Minitower Configuration

    The Small Form Factor computer can be used in either a minitower or desktop configuration. To use it in the minitower configuration, you must purchase a tower stand from HP (part number 316593-001). ✎ If the computer is in the desktop configuration, ensure at least 4 inches (10.2 cm) of space on all sides of the computer remains clear...

  • Page 13: Unlocking The Smart Cover Lock

    ■ ■ ■ ■ Ä CAUTION: The Smart Cover FailSafe Key is a specialized tool available from HP. Be prepared; order this key before you need one. To obtain a FailSafe Key: ■ ■ ■ Hardware Reference Guide Power outage...
  • Page 14 1. Turn off the computer and any external devices. Removing the Smart Cover Lock Screws 2. Remove the Smart Cover Lock. To reattach the Smart Cover Lock, secure the lock in place with the tamper-proof screws. www.hp.com Hardware Reference Guide...

  • Page 15: Removing The Computer Access Panel And Front Bezel

    Hardware Reference Guide unlock the lock. then turn off any external devices. computer, and disconnect any external devices. hold the latch 1 to release the computer access panel. then lift the access panel up and off the chassis. www.hp.com Hardware Upgrades...
  • Page 16 To re-install the front bezel, insert the two bezel bottom tabs, then rotate the front bezel forward to snap the three tabs on the top of the bezel in place. top of the bezel, then pull the bezel 2 away from the chassis. www.hp.com Hardware Reference Guide...

  • Page 17: Installing Additional Memory

    CAS latency 2 or 2.5 (CL = 2 or CL = 2.5) contain the mandatory JEDEC SPD information 128Mbit, 256Mbit, and 512Mbit non-ECC memory technologies single-sided and double-sided DIMMS DIMMs constructed with x8 and x16 DDR devices; DIMMs constructed with x4 SDRAM are not supported www.hp.com Hardware Upgrades...

  • Page 18: Dimm Sockets

    XMM1 and are adding a second DIMM, it is recommended that you install an identical DIMM into the XMM3 socket. If you are populating all four DIMM sockets, use identical DIMMs in each socket. Otherwise, the system will not operate in dual channel mode. www.hp.com Hardware Reference Guide...
  • Page 19 Sockets XMM3 and XMM4 operate in memory channel B. DIMM Socket Locations Item Hardware Reference Guide Description DIMM socket XMM1, Channel A DIMM socket XMM2, Channel A DIMM socket XMM3, Channel B DIMM socket XMM4, Channel B www.hp.com Hardware Upgrades Socket Color Black Blue Black Blue...

  • Page 20: Installing Ddr-Sdram Dimms

    CAUTION: Check the position of all cables and wires before raising or lowering the Easy Access drive bay to prevent damage. 2-10 Appendix F, “Electrostatic Discharge” unlock the lock. then turn off any external devices. any external devices. www.hp.com Hardware Reference Guide...
  • Page 21 5. Rotate the Easy Access drive bay to an upright position. Rotating the Easy Access Drive Bay 6. Locate the memory module sockets. Å WARNING: To reduce risk of personal injury from hot surfaces, allow the internal system components to cool before touching. Hardware Reference Guide www.hp.com Hardware Upgrades 2-11...
  • Page 22 8. Push the module down into the socket, ensuring that the module 2-12 the memory module into the socket 2. is fully inserted and properly seated. Make sure the latches are in the closed position 3. www.hp.com Hardware Reference Guide...

  • Page 23: Removing The Expansion Card Cage

    Easy Access drive bay. to relock the lock and enable the Smart Cover Sensor. unlock the lock. then turn off any external devices. any external devices. www.hp.com Hardware Upgrades 2-13...
  • Page 24 To replace the expansion card cage, reverse the above procedure. ✎ Ensure that the riser card seats properly into the PCI connector on the system board when reinstalling the expansion card cage. 2-14 straight up to remove it from the chassis. www.hp.com Hardware Reference Guide...

  • Page 25: Installing An Expansion Card

    7. Remove the slot cover by sliding it out 2. Removing the Expansion Slot Cover Hardware Reference Guide unlock the lock. then turn off any external devices. any external devices. you want to insert the expansion card. covers by rotating the latch outward. www.hp.com Hardware Upgrades 2-15...
  • Page 26 When you install an expansion card, make sure to line it up with the corner bracket, then press firmly on the card so that the whole connector seats properly in the expansion card slot. 10. Replace the expansion card cage. 2-16 expansion card. www.hp.com Hardware Reference Guide...

  • Page 27: Removing The Agp Card

    5. Locate the AGP card on the system board. 6. Lift up the slot cover retention latch that secures the AGP card. Hardware Reference Guide unlock the lock. then turn off any external devices. any external devices. www.hp.com Hardware Upgrades 2-17...
  • Page 28 Insert the metal slot cover in the open slot and slide the slot cover retention latch down to secure the slot cover in place. www.hp.com Hardware Reference Guide...

  • Page 29: Installing Additional Drives

    80-conductor IDE cable. Install guide screws to ensure the drive will line up correctly in the drive cage and lock in place. HP has provided extra guide screws (four 6-32 standard screws and four M3 metric screws), installed in the front of the chassis, behind the bezel. The hard drive uses 6-32 standard screws.

  • Page 30: Locating Drive Positions

    3.5-inch device bezel (PN 316008-001). To verify the type, size, and capacity of the storage devices installed in the computer, run Computer Setup. Refer to the Computer Setup (F10) Utility Guide for more information. 2-20 www.hp.com Hardware Reference Guide...

  • Page 31: Removing An Optical Drive Or Diskette Drive

    7. Return the Easy Access drive bay to the down position. Hardware Reference Guide unlock the lock. then turn off any external devices. any external devices. end of the audio cable should remain connected to the audio connector on the system board. www.hp.com Hardware Upgrades 2-21...
  • Page 32 To replace the drive, reverse the removal procedures. ✎ When replacing the drive, transfer the four screws from the old drive to the new one. The screws take the place of drive rails. 2-22 and hold. drive out of the computer. www.hp.com Hardware Reference Guide...

  • Page 33: Installing An Optional Optical Drive

    ✎ When replacing the drive, transfer the four screws from the old drive to the new one. The screws take the place of drive rails. Installing Guide Screws in the Optical Drive Hardware Reference Guide drive. www.hp.com Hardware Upgrades 2-23...
  • Page 34 3. Position the guide screws on the drive into the J-slots in the drive Installing the Optical Drive ✎ The drive release latch automatically locks in place when installing a drive. 2-24 bay 1. Then, slide the drive toward the rear of the computer 2. www.hp.com Hardware Reference Guide...
  • Page 35 Hardware Reference Guide connect the flat ribbon cable and audio cable to the system board. rear of the optical drive. not to pinch the cables in the chassis when lowering the Easy Access drive bay. www.hp.com Hardware Upgrades 2-25...

  • Page 36: Upgrading The Hard Drive

    (SATA) hard drives can be installed on this computer. If you are installing a SATA drive in your computer for the first time, refer to the white paper “Implementation of Serial ATA on HP Business Desktops” for more information. The white paper is located www.hp.com/support ✎...
  • Page 37 7. Press and hold the drive release latch 1. 8. Slide the drive to the right of the bay 2, then pull the drive from the bay 3. Removing the Hard Drive 9. To install a hard drive, reverse the above procedure. Hardware Reference Guide www.hp.com 2-27...
  • Page 38 Hardware Upgrades 10. Connect the power cable 1 and data cable 2 to the hard drive. Connecting the Data Cable and Power Cable (PATA Hard Drive) 2-28 www.hp.com Hardware Reference Guide...
  • Page 39 Hardware Upgrades Connecting the Data Cable and Power Cable (SATA Hard Drive) Hardware Reference Guide www.hp.com 2-29...
  • Page 40 The screws take the place of drive rails. You will need a Torx T-15 screwdriver to remove and re-install the guide screws. 2-30 system board connector. SATA hard drive connector PATA hard drive connector www.hp.com Hardware Reference Guide...

  • Page 41: Installing A Drive Into The 3.5-Inch Drive Bay

    (PN 316006-001). If you are installing a 3.5-inch device other than a diskette drive or hard drive, you must install the 3.5-inch device bezel (PN 316008-001). Contact an authorized HP reseller or service provider to order the appropriate bezel when reconfiguring the computer. ✎...
  • Page 42 2. Turn off the computer properly through the operating system, 3. Disconnect the power cord from the power outlet and disconnect 4. Remove the computer access panel and front bezel. 2-32 unlock the lock. then turn off any external devices. any external devices. www.hp.com Hardware Reference Guide...
  • Page 43 5. Remove the diskette drive bezel by pushing the tab inward 1 and pulling the diskette drive bezel 2 away from the front bezel. ✎ The type of bezel will vary depending on the computer configuration. Removing the Diskette Drive Bezel Hardware Reference Guide www.hp.com 2-33...
  • Page 44 Slide the drive 2 toward the back of the drive cage until the front screws are aligned with the front J-slots. Then lower the front of the drive. Continue to slide the drive all the way back until it locks into place. www.hp.com Hardware Reference Guide...
  • Page 45 If you are installing a 3.5-inch device other than a diskette drive or hard drive, you must install the 3.5-inch device bezel (PN 316008-001). Contact an authorized HP reseller or service provider to order the appropriate bezel when reconfiguring the computer.

  • Page 46: Working With The Multibay

    If you have installed a SATA hard drive that is not automatically recognized by the computer, refer to the white paper “Implementation of Serial ATA on HP Business Desktops” for operating system instructions. The white paper is located at Working with the MultiBay The MultiBay is pre-installed in some models of the computer.

  • Page 47: Hot-Plugging" Or "Hot-Swapping" Multibay Drives

    ■ If the computer is running a preinstalled operating system supplied by HP, you can insert or remove any drive except a hard drive while the computer is on, off, or in Standby. Partitioning and Formatting a MultiBay Hard Drive 1.

  • Page 48: Uninstalling The Multibay Security Screw

    FailSafe Key. ✎ If a FailSafe Key was not provided with the computer, contact an authorized HP reseller or service provider. Order PN 166527-001 for the wrench-style key or PN 166527-002 for the screwdriver bit key. Uninstalling the MultiBay Security Screw 2-38 www.hp.com...

  • Page 49: Inserting A Drive Into The Multibay

    If the device does not start, ensure that the necessary device drivers are installed on the system. If they are not available, they may be downloaded, at no cost, from the HP Web site at Hardware Reference Guide through the operating system, then turn off any external devices.

  • Page 50: Removing A Drive From The Multibay

    3. Slide the eject lever to the left to eject the drive from the Removing a Drive from the MultiBay 2-40 through the operating system, then turn off any external devices. Refer to the “Uninstalling the MultiBay Security Screw” for instructions on removing the MultiBay security screw. MultiBay. www.hp.com section Hardware Reference Guide...

  • Page 51: Specifications

    ✎ If the computer is in the desktop configuration, ensure at least 4 inches (10.2 cm) of space on all sides remains clear and free of obstructions. HP Compaq d530 Small Form Factor Desktop Dimensions Height Width Depth (depth will increase if the computer is...
  • Page 52 Specifications HP Compaq d530 Small Form Factor Power Supply Operating Voltage Range Rated Voltage Range Rated Line Frequency ✎ This system utilizes a passive power factor corrected power supply when used in the 230V mode. This allows the system to pass the CE mark requirements for use in the countries of the European Union.

  • Page 53: B Pata Hard Drive Installation Guidelines

    Using the Cable-Select Feature with Parallel ATA (PATA) Devices Optional drives are available from HP in kits that include a special drive cable. The configuration of the drive employs a cable-select feature that identifies the drive as device 0 (primary drive) or device 1 (secondary drive).
  • Page 54 “no fixed disk found” error message. B–2 If using multiple devices, HP recommends that the devices be split between the primary and secondary channels for optimum performance. Use an additional cable to connect the additional device to the system board.

  • Page 55: Battery Replacement

    Do not attempt to recharge the battery. Do not expose to temperatures higher than 60° C (140º F). Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water. Replace the battery only with the HP spare designated for this product. www.hp.com...
  • Page 56 Lift the battery out of its holder. b. Slide the replacement battery into position, positive side up. The battery holder automatically secures the battery in the proper position. www.hp.com Hardware Reference Guide...
  • Page 57 Removing a Coin Cell Battery (Type 2) Hardware Reference Guide a. To release the battery from its holder, squeeze the metal clamp that extends above one edge of the battery. b. When the battery pops up, lift it out. www.hp.com Battery Replacement...
  • Page 58 Computer Setup. Refer to the Computer Setup (F10) Utility Guide. to relock the lock and enable the Smart Cover Sensor. www.hp.com Hardware Reference Guide...

  • Page 59: D Security Lock Provisions

    ✎ If present, insert the cable lock in the location shown below. The cable lock can also be inserted in the secondary hole highlighted below. Installing a Cable Lock Hardware Reference Guide Security Lock Provisions www.hp.com...
  • Page 60 Security Lock Provisions Installing a Padlock www.hp.com Hardware Reference Guide...

  • Page 61: E Port Security Bracket

    Installing the Port Security Bracket 1. Insert the tabs on the bottom half of the port security bracket into Hardware Reference Guide Port Security Bracket the slots on the back of the chassis 1 and rotate the bracket toward the chassis 2. www.hp.com...
  • Page 62 Port Security Bracket 2. Connect the cables to the computer. www.hp.com Hardware Reference Guide...
  • Page 63 4. Slide the computer access panel back 2 about 0.5 inch (1.25 cm), Hardware Reference Guide hold the latch 1 to release the computer access panel. then lift the access panel up and off the chassis. www.hp.com Port Security Bracket...
  • Page 64 Port Security Bracket 5. Position the top of the port security bracket over the cables rotate the the bracket into place 2. www.hp.com Hardware Reference Guide...
  • Page 65 Port Security Bracket 6. Replace the computer access panel. Hardware Reference Guide www.hp.com...

  • Page 66: Removing The Port Security Bracket

    1. On the top of the computer, locate the cover latch. Pull up and 2. Slide the computer access panel back 2 about 0.5 inch (1.25 cm), hold the latch 1 to release the computer access panel. then lift the access panel up and off the chassis. www.hp.com Hardware Reference Guide...
  • Page 67 Port Security Bracket 3. Rotate the top of the bracket away from the chassis. Hardware Reference Guide www.hp.com...
  • Page 68 Port Security Bracket 4. Disconnect the cables from the computer. www.hp.com Hardware Reference Guide...
  • Page 69 Port Security Bracket 5. Push on the tabs to release the bottom of the bracket from the chassis 1. Rotate the bracket away from the chassis 2. Hardware Reference Guide www.hp.com...
  • Page 70 Port Security Bracket E-10 www.hp.com Hardware Reference Guide...

  • Page 71: F Electrostatic Discharge

    Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis. Wrist straps are flexible straps with a minimum of 1 megohm +/- 10 percent resistance in the ground cords. To provide proper ground, wear the strap snug against the skin. www.hp.com...
  • Page 72 HP authorized dealer, reseller, or service provider. ✎ For more information on static electricity, contact an HP authorized dealer, reseller, or service provider. Use heelstraps, toestraps, or bootstraps at standing workstations. Wear the straps on both feet when standing on conductive floors or dissipating floor mats.

  • Page 73: G Routine Computer Care And Shipping Preparation

    Never restrict the airflow into the computer by blocking the front vents or air intake. Do not place the keyboard, with the keyboard feet down, directly against the front of the desktop unit as this also restricts airflow. Keep the computer away from excessive moisture, direct sunlight, and extremes of heat and cold.

  • Page 74: Optical Drive Precautions

    ■ Safety If any object or liquid falls into the drive, immediately unplug the computer and have it checked by an authorized HP service provider. Do not move the drive during operation. This may cause it to malfunction during reading.

  • Page 75: Shipping Preparation

    Do not use a diskette on which you have stored or plan to store data. the computer. their power sources, then from the computer. packing boxes or similar packaging with sufficient packing material to protect them. in this guide. www.hp.com Appendix A,...
  • Page 76 Routine Computer Care and Shipping Preparation www.hp.com Hardware Reference Guide...
  • Page 77 1–2 electrostatic discharge 2–1 expansion card cage, removing 2–13 expansion card, installing 2–15 expansion slot cover 2–15 FailSafe Key 2–3 formatting MultiBay hard drive 2–37 front bezel, removing 2–6 front panel components 1–2 function keys 1–4 www.hp.com Index F–1 Index-1...
  • Page 78 2–37 installing 2–39 partitioning 2–37 removing 2–40 security screw 2–38 numeric keys 1–4 optical drive activity light 1–2 ATA B–2 connecting cables 2–25 eject button 1–2 guidelines G–2 installing 2–23 precautions G–2 removing 2–21 www.hp.com 1–3 Hardware Reference Guide...
  • Page 79 D–1 security screw, MultiBay 2–38 serial connector 1–3 serial number location 1–6 shipping preparation, guidelines G–3 Smart Cover FailSafe key 2–3 lock 2–3 removing 2–4 status lights 1–4 USB 1–2 2–14 Windows Logo key 1–4 www.hp.com 1–3 1–5 Index Index-3...
