HP ProCurve Switch 2800 Series
Specifications
Ports
Physical characteristics
Dimensions
Weight
Memory and processor
Processor
Mounting
Performance
Latency
Throughput
Switching capacity
MAC address table size
Environment
Operating temperature
Operating relative humidity
Non-operating/Storage temperature
Non-operating/Storage relative humidity
Altitude
Acoustic
Electrical characteristics
Maximum heat dissipation
Voltage
Current
Power consumption
Frequency
Notes
Safety
HP ProCurve Switch 2824 (J4903A)
20 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T);
Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full;
1000Base-T: full only
1 RS-232C DB-9 console port
4 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port or an open mini-GBIC slot (for use with mini-GBIC
transceivers)
14.4(d) x 17.32(w) x 1.75(h) in. (36.58 x 43.99 x 4.45 cm) (1U height)
10.2 lb. (4.63 kg), Fully loaded
Motorola PowerPC MPC8245 @ 266 MHz, 8 MB flash, 64 MB
SDRAM
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
< 5.4 µs (64-byte packets)
up to 34.65 million pps (64-byte packets)
48 Gbps
16000 entries
32ºF to 131ºF (0ºC to 55ºC)
15% to 95% @ 104ºF (40ºC), non-condensing
-40ºF to 158ºF (-40ºC to 70ºC)
15% to 95% @ 149ºF (65ºC), non-condensing
up to 15000 ft. (4.6 km)
Power: < 53 dB; DIN 45635T.19 per ISO 7779 @ < 80°F (25°C)
341 BTU/hr (360 kJ/hr)
100-127 / 200-240 VAC
0.6 / 0.3 A
100 W
50 / 60 Hz
Maximum power rating is the worst-case theoretical maximum power
number with fully loaded PoE, 100% traffic, all ports plugged in, and
all modules populated.
HP ProCurve Switch 2848 (J4904A)
44 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T);
Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full;
1000Base-T: full only
1 RS-232C DB-9 console port
4 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port or an open mini-GBIC slot (for use with mini-GBIC
transceivers)
16.9(d) x 17.32(w) x 1.75(h) in. (42.93 x 43.99 x 4.45 cm) (1U height)
10.75 lb. (4.88 kg), Fully loaded
Motorola PowerPC MPC8245 @ 266 MHz, 8 MB flash, 64 MB
SDRAM
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
< 5.4 µs (FIFO 64-byte packets)
up to 69.3 million pps (64-byte packets)
96 Gbps
16000 entries
32ºF to 131ºF (0ºC to 55ºC)
15% to 95% @ 104ºF (40ºC), non-condensing
-40ºF to 158ºF (-40ºC to 70ºC)
15% to 95% @ 149ºF (65ºC), non-condensing
up to 15000 ft. (4.6 km)
Power: < 53 dB; DIN 45635T.19 per ISO 7779 @ < 80°F (25°C)
341 BTU/hr (360 kJ/hr)
100-127 / 200-240 VAC
0.6 / 0.3 A
100 W
50 / 60 Hz
Maximum power rating is the worst-case theoretical maximum power
number with fully loaded PoE, 100% traffic, all ports plugged in, and
all modules populated.
4
