- Page 1 ELX200 Passive Loudspeakers Installation manual...
-
Page 3: Table Of Contents
Tripod or pole mount Floor monitor Suspension Recommended configurations Basic stereo system using full-range systems Using full-range systems as stage monitors Stacking full-range systems with subwoofers Troubleshooting Technical data Dimensions Frequency response Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... -
Page 4: Safety
Electro-Voice installation guides. Do NOT use handles to suspend the loudspeaker. Handles on Electro-Voice loudspeakers are intended to only be used for temporary transport by people. Items, such as fiber rope, wire rope, cables, or other types of materials cannot be used to suspend loudspeaker from the handles. -
Page 5: Notices
ELX200 Passive Loudspeakers Safety | en Electro-Voice loudspeakers are easily capable of generating sound pressure levels sufficient to cause permanent hearing damage to anyone within normal coverage distance. Caution should be taken to avoid prolonged exposure to sound pressure levels exceeding 90 dB. -
Page 6: Description
| Description ELX200 Passive Loudspeakers Description Thank you for choosing an Electro-Voice passive loudspeaker system. Please take time to consult the manual to understand all the features built into your EV system and fully utilize its performance capabilities. ROCK SOLID SOUND: Electro-Voice ELX200 portable loudspeakers The ELX200 series is the newest member of the best-selling Electro-Voice portable loudspeaker family. -
Page 7: System Features
EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading. – Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX three-handle design for easy lifting. Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... - Page 8 Ideal for portable and installed applications. Lightweight, compact 15 mm wood enclosure with internal bracing with durable polyurea top-coat finish. – Professional-grade hardware: integrated M20 threaded pole mount plate and two-handle design for easy lifting. 2019-04 | 02 | F.01U.326.890 Electro-Voice Installation manual...
-
Page 9: Tripod And Floor Monitor Operation
Tighten the thumb screw (A) to secure the loudspeaker to the pole. The thumb screw is only available on the 12" and 15" full-range loudspeaker models. The 10" full-range loudspeaker does not have a thumb screw. Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... - Page 10 Tighten the thumb screw to secure the loudspeaker to the pole. The thumb screw is only available on the 12" and 15" full-range loudspeaker models. The 10" full-range loudspeaker does not have a thumb screw. 2019-04 | 02 | F.01U.326.890 Electro-Voice Installation manual...
-
Page 11: Floor Monitor
Safely route cables to prevent injury to performers, production crew, and audience members. Notice! Secure cables with wire ties or tape whenever possible. OPTIMAL COVERAGE Figure 3.2: Optimum coverage in monitor position (side view left and front view right) Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... -
Page 12: Suspension
Suspending any object is potentially dangerous and should only be attempted by individuals who have a thorough knowledge of the techniques and regulations of suspending objects overhead. Electro-Voice strongly recommends that loudspeakers be suspended taking into account all current national, federal, state, and local laws and regulations. It is the responsibility of the installer to ensure all loudspeakers are safely installed in accordance with all such requirements. - Page 13 Eyebolts must be fully seated and oriented in the plane of pull. Always use washers under the eyebolt to distribute the load on the enclosure. Figure 4.2: Eyebolt shown with washers (A) and without washers (B) Figure 4.3: Eyebolts shown orientated in the plane of pull (left correct, right incorrect) Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual...
- Page 14 | Suspension ELX200 Passive Loudspeakers Warning! Never exceed the limitations or maximum recommended working load for Electro-Voice loudspeakers. Disregarding this warning could result in serious injury or death. 5° MAX 5° MAX 5° MAX 5° MAX 90° 10° 90°...
-
Page 15: Recommended Configurations
Do not exceed the maximum load rating of the amplifier. Amplifier Load (per Output Channel) # of Speakers Nominal Minimum 8 Ohms 7.2 Ohms 4 Ohms 3.6 Ohms 2.7 Ohms 2.4 Ohms 2 Ohms 1.8 Ohms Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... -
Page 16: Using Full-Range Systems As Stage Monitors
Do not exceed the maximum load rating of the amplifier. Amplifier Load (per Output Channel) # of Speakers Nominal Minimum 8 Ohms 7.2 Ohms 4 Ohms 3.6 Ohms 2.7 Ohms 2.4 Ohms 2 Ohms 1.8 Ohms 2019-04 | 02 | F.01U.326.890 Electro-Voice Installation manual... -
Page 17: Stacking Full-Range Systems With Subwoofers
Not used Caution! Do not exceed the maximum load rating of the amplifier. Amplifier Load (per Output Channel) # of Subwoofer/Full-Range Nominal Minimum Combinations 4 Ohms 3.8 Ohms 2 Ohms 1.9 Ohms Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... -
Page 18: Troubleshooting
Most likely there is a break in the signal path. Poor system Check and correct the system grounding, as required. grounding or ground loop If these suggestions do not solve your problem, contact your nearest Electro-Voice dealer or Electro-Voice distributor. 2019-04 | 02 | F.01U.326.890 Electro-Voice Installation manual... -
Page 19: Technical Data
Shipping weight: 15.3 kg (33.7 lb) 17.1 kg (37.7 lb) 21.4 kg (47.2 lb) Full-space measurement. Maximum SPL is measured at 1 m using broadband pink noise at rated peak power rating. Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... -
Page 20: Dimensions
155 mm [6 in] 363 mm 253 mm [10 in] [14 in] 344 mm [14 in] 311 mm [12 in] 256 mm 629 mm [10 in] [25] in 163 mm [6 in] Figure 7.2: ELX200-12 dimensions 2019-04 | 02 | F.01U.326.890 Electro-Voice Installation manual... -
Page 21: Frequency Response
287 mm [10 in] [11 in] 229 mm 600 mm [9 in] 24 in 574 mm [23 in] 160 mm [6 in] Figure 7.5: ELX200-18S dimensions Frequency response Figure 7.6: ELX200-10 frequency response and impedance Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual... - Page 22 | Technical data ELX200 Passive Loudspeakers Figure 7.7: ELX200-12 frequency response and impedance Figure 7.8: ELX200-15 frequency response and impedance Figure 7.9: ELX200-12S frequency response and impedance 2019-04 | 02 | F.01U.326.890 Electro-Voice Installation manual...
- Page 23 ELX200 Passive Loudspeakers Technical data | en Figure 7.10: ELX200-18S frequency response and impedance Electro-Voice 2019-04 | 02 | F.01U.326.890 Installation manual...
- Page 24 | Technical data ELX200 Passive Loudspeakers 2019-04 | 02 | F.01U.326.890 Electro-Voice Installation manual...
- Page 26 TELEX 12000 Portland Avenue South Burnsville MN 55337 www.telex.com © Bosch Security Systems, LLC, 2021 202107271105...
