Cub Cadet 13WZ92AK056 Operator's Manual

Cub Cadet 13WZ92AK056 Operator's Manual

Hydrostatic lawn tractor
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
Hydrostatic Lawn Tractor — SLTX1054
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-05335
(November 3, 2009)

Advertisement

Chapters

Table of Contents
loading

Summary of Contents for Cub Cadet 13WZ92AK056

  • Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No. 769-05335...
  • Page 2: Table Of Contents

    Visit us on the web at www.cubcadet.com ◊ Call a Customer Support Representative at (800) 965-4CUB ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write us at Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019...
  • Page 3: Safe Operation Practices

    Important Safe Operation Practices WARNING! This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
  • Page 4 Slope Operation A missing or damaged discharge cover can cause blade contact or thrown object injuries. Slopes are a major factor related to loss of control and tip-over Stop the blade(s) when crossing gravel drives, walks, or accidents which can result in severe injury or death. All slopes roads and while not cutting grass.
  • Page 5 Service Children Tragic accidents can occur if the operator is not alert to the Safe Handling of Gasoline: presence of children. Children are often attracted to the machine and the mowing activity. They do not understand To avoid personal injury or property damage use extreme the dangers.
  • Page 6 Do not modify engine Periodically check to make sure the blades come to complete stop within approximately (5) five seconds after To avoid serious injury or death, do not modify engine in any operating the blade disengagement control. If the blades way.
  • Page 7 Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate DANGER—...
  • Page 8 2 — i ectiOn MpOrtant peratiOn ractices...
  • Page 9: Assembly & Set-Up

    Assembly & Set-Up Contents of Crate • One Lawn Tractor • One Oil Drain Tube • One Deck Wash Hose Coupler • One Lawn Tractor Operator’s Manual • One Kohler Engine Operator’s Manual Tractor Set-Up Shipping Brace Removal WARNING! Make sure the lawn tractor’s engine is Moving The Tractor Manually off, set the parking brake and remove the ignition Your tractor’s transmission is equipped with a hydrostatic...
  • Page 10 Connecting the Battery Cables Checking Tire Pressure WARNING! CALIFORNIA PROPOSITION 65 WARNING Do not overinflate tires. Check sidewall of tires for maximum psi. Equal tire pressure should Battery posts, terminals, and related accessories be maintained at all times. contain lead and lead compounds, chemicals known to the State of California to cause cancer and The tires on your tractor may be over inflated for shipping reproductive harm.
  • Page 11 Adjusting the Seat To adjust the position of the seat, pull up and hold the seat adjustment lever. Slide the seat forward or rearward to the desired position; then release the adjustment lever. Make sure seat is locked into position before operating the tractor. See Fig.
  • Page 12: Controls & Features

    Controls and Features Systems Indicator Monitor Fuel Tank Cap Ignition Switch Module Throttle/Choke Control Electric PTO Knob Fuel Level Indicator Drive Pedal Brake Pedal Reverse Pedal Parking Brake/ Cargo Net Cruise Control Lever Deck Lift Lever Seat Adjustment Lever Storage Bin Cup Holder Figure 4-1 Lawn Tractor controls and features are illustrated in Fig.
  • Page 13 Charge the battery as instructed in the Service The cargo net is located on the lower half of the dash and can be section of this manual or have the charging system checked by used for storage. your Cub Cadet dealer. 4 — c ectiOn OntrOls and...
  • Page 14 Fuel Level Indicator The Fuel Level Indicator is located on the left side of the tractor’s dash and indicates the amount of fuel in the gas tank. PTO / Blade Engage Knob Activating the PTO engages power to the cutting deck or other (separately available) attachments.
  • Page 15: Operation

    This tractor is equipped with a safety interlock system for the protection of the operator. If the interlock system should ever Stopping the Engine malfunction, do not operate the tractor. Contact your Cub Cadet dealer. WARNING! If you strike a foreign object, stop the engine and disconnect the spark plug wire(s).
  • Page 16 Driving The Tractor Reverse Caution Mode The REVERSE CAUTION MODE position of the key switch module WARNING! Avoid sudden starts, excessive speed allows the tractor to be operated in reverse with the blades (PTO) and sudden stops. engaged. NOTE: Mowing in reverse is not recommended. Lightly press the brake pedal to release the parking brake.
  • Page 17 Driving On Slopes Cruise Control WARNING! Never engage the cruise control lever Refer to the SLOPE GAUGE on page 8 to help determine slopes while traveling in reverse. where you may operate the tractor safely. WARNING! Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1⁄2 To set the cruise control: feet every 10 feet).
  • Page 18 Mowing Pull the PTO/Blade Engage knob outward into the engaged (ON) position. See Fig. 5-3. WARNING! To help avoid blade contact or a thrown object injury, keep bystanders, helpers, children and pets at least 75 feet from the machine while it is in operation. Stop the machine if anyone enters the area.
  • Page 19: Maintenance & Adjustment

    Maintenance & Adjustments Maintenance Schedule Before Every Every Every Every Prior Each use 10 Hours 25 Hours 50 Hours 100 Hours to Storing Clean Hood/Dash Louvers Check Engine Oil Level Check Air Filter for Dirty, Loose or Damaged Parts Clean and Re-oil Air Filter’s Foam Precleaner Replace Air Filter Element Change Engine Oil and Replace Oil Filter Clean Battery Terminals...
  • Page 20 Hydrostatic Transmission Pop open the protective cap on the end of the oil drain valve to expose the drain port. See Fig 6-1. The hydrostatic transmission is sealed at the factory and is maintenance-free. The fluid level cannot be checked and the fluid cannot be changed.
  • Page 21 Lubrication Attach the hose coupler to the water port on your decks surface. See Fig. 6-2. WARNING! Before lubricating, repairing, or inspecting, always disengage PTO, set parking brake, stop engine and remove key to prevent unintended starting. Front Wheels Each of the front wheel axles and rims is equipped with a grease fitting.
  • Page 22 Adjustments Determine the approximate distance necessary for proper adjustment and proceed, if necessary. WARNING! Shut the engine off, remove the Locate the flange lock nut on the end of the deck hanger ignition key and engage the parking brake before rod.
  • Page 23 Leveling the Deck (Side to Side) Steering Adjustment If the cutting deck appears to be mowing unevenly, a side to side If the tractor turns tighter in one direction than the other, or if adjustment can be performed. Adjust if necessary as follows: the ball joints are being replaced due to damage or wear, the steering drag links may need to be adjusted.
  • Page 24: Service

    Service Cutting Deck Removal NOTE: If there is too much tension on the belt for it to be easily removed from the electric PTO clutch, carefully insert To remove the cutting deck, proceed as follows: a 3⁄8” drive ratchet wrench (set to tighten) into the square hole found in the left-hand deck idler bracket and pivot it Place the PTO/Blade Engage knob in the disengaged (OFF) toward the tractor’s right side to relieve tension on the belt.
  • Page 25 Pull the deck support pin outward to release the deck from the deck lift arm. See Fig. 7-3. Deck Lift Arm Deck Support Figure 7-5 Cutting Blades WARNING! Shut the engine off and remove ignition key before removing the cutting blade(s) for Figure 7-3 sharpening or replacement.
  • Page 26 Battery To properly sharpen the cutting blades, remove equal amounts of metal from both ends of the blades along the CALIFORNIA PROPOSITION 65 WARNING cutting edges, parallel to the trailing edge, at a 25° to 30° angle. Always grind each cutting blade edge equally to Battery posts, terminals, and related accessories maintain proper blade balance.
  • Page 27 Several components must be removed and special tools used in Deck Idler Pulley order to change the tractor’s transmission drive belt. See your Cub Cadet dealer to have the transmission drive belt replaced. Belt Guards Figure 7-8 Loosen, but do not remove the belt keeper rod on the pulley located near the back of the deck.
  • Page 28 To place the new belt begin by routing the belt around the Pull the right side of the belt and place the narrow V side of two outer spindle pulleys, then around the front spindle the belt into the PTO pulley. See Fig. 7-10. pulley as shown in Fig.
  • Page 29: Troubleshooting

    Troubleshooting Problem Cause Remedy Engine fails to start PTO/Blade Engage knob engaged. Place knob in disengaged (OFF) position. Parking brake not engaged. Engage parking brake. Spark plug wire(s) disconnected. Connect wire(s) to spark plug(s). Throttle control lever not in correct starting Place throttle lever to FAST position.
  • Page 30: Replacement Parts

    Replacement Parts Component Part Number and Description 759-3336 Spark Plug KH-32-883-03-S1 Air Filter and Pre-cleaner KH-12-050-01-S Oil Filter KH-25-050-22-S1 Fuel Filter 954-0642 Deck Drive Belt 942-0677B 2-in-1 Deck Blade 918-04126B Deck Spindle 734-04155 Deck Wheel Phone (800) 965-4CUB to order replacement parts or a complete Parts Manual (have your full model number and serial number ready).
  • Page 31 Component Part Number and Description 925-1707D Battery 751-0603A Fuel Tank Cap 946-04556 Throttle/Choke Control Cable 925-2054A Ignition Key 631-04070A Discharge Chute Assembly Phone (800) 965-4CUB to order replacement parts or a complete Parts Manual (have your full model number and serial number ready).
  • Page 32: Attachments & Accessories

    Attachments & Accessories The following attachments and accessories are compatible for Cub Cadet SLTX1054. Call (800) 965-4CUB or see your Cub Cadet dealer or the retailer from which you purchased your tractor for information regarding price and availability. CAUTION: Cub Cadet Series 1000 lawn tractors are NOT designed for use with any type of ground-engaging attachments (e.g.
  • Page 33 Notes...
  • Page 34 FEDERAL and/or CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS MTD Consumer Group Inc, the United States Environmental Protection Agency (EPA), and, for those products certified for sale in the state of California, the California Air Resources Board (CARB) are pleased to explain the emission (evaporative and/or exhaust) control system (ECS) warranty on your outdoor 2006 and later small off-road spark-ignited engine and equipment (outdoor equipment engine) In California, new outdoor equipment engines must be designed, built and equipped to meet the State’s stringent anti-smog standards (in other states, 1997 and later model year equipment must be designed, built, and equipped to meet the U.S.
  • Page 35 WARRANTED PARTS: The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if MTD Consumer Group Inc demonstrates that the outdoor equipment engine has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper mainte- nance was the direct cause of the need for repair or replacement of the part.
  • Page 36 Frame and Front Axle — Cub Cadet warrants the frame, and front cast iron dealer or retailer, with respect to any product, shall bind Cub Cadet.
  • Page 37 LEA Y SIGA TODAS LAS INSTRUCCIONES DE ESTE MANUAL ANTES DE PONER EN FUNCIONAMIENTO ESTA MÁQUINA. SI NO RESPETA ESTAS INSTRUCCIONES PUEDE PROVOCAR LESIONES PERSONALES. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Impreso en Estados Unidos de América Formulario No. 769-05335...
  • Page 38 Visite nuestro sitio web en www.cubcadet.com ◊ Llame al representante de Atención al Cliente al (800) 965-4CUB ◊ Localice a su distribuidor Cub Cadet más cercano llamando al (877) 282-8684 ◊ Escríbanos a Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019...
  • Page 39: Medidas Importantes De Seguridad

    Medidas importantes de seguridad ADVERTENCIA: La presencia de este símbolo indica que se trata de instrucciones importantes de seguridad que se deben respetar para evitar poner en peligro su seguridad personal y/o material y la de otras personas. Lea y siga todas las instrucciones de este manual antes de poner en funcionamiento esta máquina.
  • Page 40 Esté atento a la cortadora y a la dirección de la descarga Los datos estadísticos muestran que los operadores de 60 de los aditamentos y no apunte a nadie. Nunca opere la años y mayores se ven involucrados en un alto porcentaje cortadora de césped sin que estén en su lugar apropiado la de lesiones relacionadas con tractores corta césped.
  • Page 41 Servicio No cambie a transmisión neutral para descender. El exceso de velocidad puede hacer que el operador pierda el control de la máquina, ocasionando lesiones graves e incluso la muerte. Manejo seguro de la gasolina: No remolque cargas pesadas detrás de los aditamentos Para evitar lesiones personales o daños materiales sea (carrito de basura cargado, podadora de rodillos, etc) en sumamente cuidadoso al manipular la gasolina.
  • Page 42 Antes de limpiar, reparar o inspeccionar la máquina, Según la Comisión de Seguridad de Productos para el compruebe que la(s) cuchilla(s) y todas las partes en Consumidor de los Estados Unidos (CPSC) y la Agencia movimiento se hayan detenido. Desconecte el cable de la de Protección Ambiental de los Estados Unidos (EPA), bujía y póngalo haciendo masa contra el motor para evitar este producto tiene una vida útil media de siete (7) años,...
  • Page 43 Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description LEA EL MANUAL(S) DEL OPERADOR leído, entienda, y siga todas las instrucciones en el manual(s) antes de procurar montar y funcionar PELIGRO—...
  • Page 44 2 — M ectiOn edidas iMpOrtantes de seguridad...
  • Page 45: Montaje Y Configuración

    Montaje y Configuración Contenido del cajón • Un tractor corta césped • Un tubo de drenaje de aceite • Un acoplador de manguera para lavado de plataforma • Un Manual del operador del tractor • Un Manual del operador del motor corta césped Kohler Configuración del tractor...
  • Page 46 Instalación del cable de la baterías Control de la presión de los neumáticos PROPUESTA 65 DE CALIFORNIA ¡ADVERTENCIA! La presión máxima de los ADVERTENCIA! neumáticos en cualquier circunstancia es de 30 psi. Los postes de la batería, Se debe mantener una presión uniforme para todos terminales y accesorios relacionados contienen los neumáticos en todo momento.
  • Page 47 Gasolina y aceite Vuelva a insertar el tornillo con reborde (con cada rueda de calibración) dentro del orificio de El tanque de combustible está ubicado debajo del guardabarros posicionamiento que deja aproximadamente ½ y posee una capacidad de tres galones y medio. Quite la tapa pulgada entre la parte inferior de la rueda y el de combustible girándola en sentido contrario al de las agujas pavimento.
  • Page 48: Controles Y Características

    Controles y Características Monitor del indicador de sistemas Módulo del Tapón del tanque de combustible interruptor de encendido Interruptor de Control del regulador/cebador la potencia de arranque (PTO) Indicador de nivel de combustible Pedal de la transmisión Pedal de freno Pedal de la marcha atrás Freno de mano /...
  • Page 49 Palanca de elevación de la plataforma Monitor del indicador de sistemas / Pantalla LCD del medidor horario Ubicada en el guardabarros derecho del tractor, la palanca de elevación de la plataforma se utiliza para cambiar la altura de la plataforma de corte. Para utilizarla, mueva la palanca hacia la izquierda, luego colóquela en la muesca que mejor se adapte a la aplicación deseada.
  • Page 50 Controle la batería como se indica en la sección Servicio de este manual o haga que el sistema de carga sea verificado por su distribuidor Cub Cadet . Cargo Neto La carga neta se encuentra en la mitad inferior de la raya y puede utilizarse para el almacenamiento.
  • Page 51: Funcionamiento

    NOTA: NO deje el control del obturador activado mientras funciona mal, no se debe hacer funcionar el tractor. Póngase en opera el tractor. Si lo hace, se generará una mezcla “rica” de contacto con su distribuidor Cub Cadet. combustibles, lo cual hará que el motor pierda intensidad. •...
  • Page 52 Conducción del tractor Modo de precaución en marcha atrás ¡ADVERTENCIA! La posición MODO DE PRECAUCIÓN EN MARCHA ATRÁS del Evite arrancar súbitamente, módulo del interruptor de llave permite operar el tractor desarrollar excesiva velocidad y detenerse de en marcha atrás con las cuchillas (toma de fuerza - PTO) repente.
  • Page 53 Conexión de potencia de arranque (PTO) El MODO DE PRECAUCIÓN EN MARCHA ATRÁS permanece activado hasta que: Al conectar la potencia de arranque (PTO) se suministra Se coloque la llave en la posición CORTE NORMAL o alimentación a la plataforma de corte o a otros accesorios en la posición STOP (detención) o (disponibles por separado).
  • Page 54 Funcionamiento de los faros delanteros Activación del control de crucero ¡ADVERTENCIA! Nunca enganche la palanca de Los faros se encienden (ON) cada vez que se rota la llave de control de crucero mientras se desplaza en marcha encendido sacándola de la posición STOP (detención). Los faros atrás.
  • Page 55: Mantenimiento Y Ajustes

    Tenga cuidado y evite quemarse con o individuo especializado en reparaciones de motores. Las reparaciones cubiertas por la garantía deben ser llevadas a el aceite caliente. cabo por un distribuidor de Cub Cadet.
  • Page 56 Abra el capó del tractor y ubique el puerto de drenaje de Cuando termine de drenar el aceite, empuje el extremo de aceite del lado izquierdo del motor. Vea la Fig. 6-1. la válvula de drenaje de aceite hacia adentro, hasta que las lengüetas calcen en su lugar.
  • Page 57 Smart Jet™ Gire la llave de encendido a la posición STOP (detención) para apagar el motor del tractor. La plataforma de su tractor está equipada con un puerto de Desconecte el agua y retire el acoplador de la manguera agua sobre su superficie como parte del sistema de lavado de la desde el puerto de agua que se encuentra en la superficie plataforma.
  • Page 58 Ajustes Determine la distancia aproximada necesaria para un ajuste adecuado y, de ser necesario, proceda. ¡ADVERTENCIA! Apague el motor, retire la llave de encendido Localice la tuerca de seguridad con brida en el extremo de y coloque el freno de mano antes de realizar ajustes. Proteja sus la barra de suspensión de la plataforma.
  • Page 59 Delante del eje, mida la distancia horizontal desde descarga hidrostática abierta) el freno necesita ajustes. Consulte el interior de la llanta izquierda hasta el interior de la con su distribuidor Cub Cadet para realizar un ajuste correcto del llanta derecha. Anote la distancia. freno.
  • Page 60: Servicio

    Servicio Extracción de la plataforma de corte NOTA: Si hay demasiada tensión en la correa para que sea quitada fácilmente del embrague eléctrico del PTO, inserte Para extraer la plataforma de corte, proceda de la siguiente cuidadosamente” llave de trinquete de impulsión un 3⁄8 manera: (fije para apretar) en la perforación rectangular encontrada en el soporte más ocioso de la cubierta izquierda y gírelo...
  • Page 61 Cuchillas de corte Tire hacia afuera el pasador de soporte de la plataforma para separar la misma del brazo de elevación de la ¡ADVERTENCIA! plataforma. Vea la Fig. 7-3. Apague el motor y extraiga la llave de contacto antes de retirar las cuchillas de corte para afilado o reemplazo.
  • Page 62 Batería Para afilar las cuchillas de corte de forma adecuada, extraiga cantidades iguales de metal de ambos extremos ¡ADVERTENCIA PROPOSICIóN 65 DE de las cuchillas a lo largo de los bordes cortantes, de forma paralela al borde de caída, a un ángulo de 25° a 30°. Afile CALIFORNIA! Los bornes de la batería y los siempre cada borde de las cuchillas de corte de forma...
  • Page 63 Guardia varios componentes y se requieren herramientas especiales. Figura 7-7 Solicite a su distribuidor Cub Cadet que realice el reemplazo de la correa de transmisión. Afloje, pero no quite al protector de la correa en la polea más ociosa situada cerca de la parte posterior de la cubierta.
  • Page 64 Para colocar la nueva correa comience encaminando la correa alrededor de las dos poleas de huso externas, entonces alrededor de la polea de huso delantera según las indicaciones de Fig. 7-8. Frente polea Cubierta de la del husillo polea poleas Exterior del husillo poleas Figura 7-8...
  • Page 65: Solución De Problemas

    Solución de Problemas Problem Cause Remedy Palanca de potencia de arranque (PTO) / Coloque la perilla en la posición de El motor no arranca enganche de cuchilla conectada. desconexión (OFF). No está colocado el freno de mano. Coloque el freno de mano. Se ha desconectado el cable de la bujía.
  • Page 66 Problem Cause Remedy El motor vacila a altas La separación de la bujía es muy pequeña. Retire la bujía y reajuste la separación. revoluciones El motor funciona con Bujía sucia, averiada o exceso de separación. Reemplace la bujía. Ajuste la separación de dificultad en ralentí...
  • Page 67 Piezas de reemplazo Componente Número de pieza y Descripción 759-3336 Bujía (Champion RC12YC) KH-32-883-03-S1 Limpiador de Aire Elemento con Pre-Filtro KH-12-050-01-S Filtro de Aceite KH-25-050-22-S1 Filtro de Combustible 954-0642 Correa de Tracción (Plataforma de Corte) 942-0677B 2-in-1 Cuchilla de Plataforma 918-04126B Husilla de Plataforma Llame por teléfono al (800) 965-4CUB para solicitar piezas de reemplazo o un Manual de Piezas de Repuesto completo (tenga el...
  • Page 68 Componente Número de pieza y Descripción 734-04155 Rueda de Plataforma (Frente) 925-1707D Batería 751-0603A Tapa del Tanque de Combustible 746-04556 Cable de Control de Regulador/ Cebador 925-2054A Llave de Encendido 631-04070A Asamblea de Canal de Descarga Llame por teléfono al (800) 965-4CUB para solicitar piezas de reemplazo o un Manual de Piezas de Repuesto completo (tenga el número de modelo y número de serie de su máquina a mano).
  • Page 69 PRECAUCIóN: Cub Cadet tractores del césped de la serie 1000 no están diseñados para su uso con cualquier tipo de acoplamiento de tierra adjuntos(por ejemplo, caña o arado de vertedera). El uso de este tipo de equipo se anulará la garantía del tractor.
  • Page 70 DECLARACIÓN FEDERAL y/o DE CALIFORNIA SOBRE GARANTÍAS EN EL CONTROL DE EMISIONES SUS DERECHOS Y OBLIGACIONES EN CUANTO A LA GARANTÍA MTD Consumer Group Inc, la Agencia de Protección Medioambiental de los Estados Unidos (EPA), y para aquellos productos certificados para su venta en el es- tado de California, el Departamento de los Recursos del Aire de California (CARB) se complacen en explicar la garantía que cubre al sistema de control (ECS) de emisiones (evaporativas y/o de escape) de su equipo y motor (motor de equipos de exteriores) de encendido por chispa para todo terreno, pequeño, de exteriores del año 2006 y años posteriores En California, los nuevos motores de equipos de exteriores deben estar diseñados, construidos y equipados para cumplir con las...
  • Page 71 Durante la totalidad del período de garantía del motor y equipo para todo terreno arriba mencionado, MTD Consumer Group Inc mantendrá un suministro de piezas bajo garantía suficiente para satisfacer la demanda esperada de tales piezas. Cualquier pieza de reemplazo se podrá usar para el cumplimiento del mantenimiento o las reparaciones bajo garantía y se suministrarán sin cargo para el propietario.
  • Page 72 Cub Cadet. El recurso Bastidor y eje frontal - Cub Cadet garantiza el bastidor, y eje de pivote de exclusivo es reparar o reemplazar el producto según lo anteriormente hierro fundido frontal contra defectos en los materiales y mano de obra establecido.
