- Page 1 Dishwasher User’s Manual LDV42244 LDV42221 LDV63440 18 7608 0100_BLOMBERG_E5_EN/ 24-09-21.(11:40)
- Page 2 Dear Customer, Please read this user manual before using the product. Thank you for choosing this Blomberg product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents before using the product.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS Upper basket height adjustable rack ....26 Lower basket bottle wire ........26 Intended Use ............. 4 Upper basket multipurpose service rack ..26 Safety for children, vulnerable persons and pets 4 Adjusting the height of the upper basket ..27 Electrical safety .......... -
Page 4: Safety Instructions
This product must be used to Safety Instructions do the domestic type dishes • This section contains safety only. instructions that will help get This product is not suitable for protected against risks of commercial or collective use. personal injury or property damage. -
Page 5: Electrical Safety
Cleaning and user Do not use extension cords, maintenance works should multi-sockets or adapters to not be performed by children operate the product. unless they are supervised by Plug must be easily someone. accessible. If this is not Keep packaging materials possible, the electrical away from children. -
Page 6: Installation Safety
squeezed or crushed while serious burns and injuries, placing the product into its and harm your furniture. location after installation or Do not install the product cleaning procedures. close to heat sources (heater, stove and etc.) or under the Installation Safety cooking area of a hob. -
Page 7: Operational Safety
hose set. Do not make extension baskets. Do not sit or put at the hoses. other loads on the door; otherwise, the product may NOTICE Connect the water inlet tilt. hose directly to the water tap. Maximum washing capacity Pressure coming from the tap of the product is stated in the should be 0.03 MPa (0.3 bars) section called “Technical... -
Page 8: Maintenance And Cleaning Safety
Environmental Maintenance and cleaning safety Instructions Do not wash the product by Compliance with WEEE spreading or pouring water Directive and Disposing of onto it. the Waste Product Do not use sharp or abrasive This product complies with tools when cleaning the EU WEEE Directive (2012/19/ product. -
Page 9: Package Information
Package information Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities. -
Page 10: Technical Specifications
Technical specifications Note for test institutions: Data required for performance tests shall be provided upon request. Requests can Maximum washing capacity (check the be e-mailed to the following address: energy label and Programme data and dishwasher@standardloading.com average consumption values table given Do not forget to provide the code, stock on Quick Guide. -
Page 11: Your Dishwasher
Your dishwasher Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Cutlery basket (depends on model) 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid 12. Upper basket rail 13. -
Page 12: Installation
Installation Appropriate installation location In the area where this product is Read “Safety Instructions” section first! installed, there must not be a lockable, Installation procedures must always be sliding or hinged door that will restrict performed by the manufacturer, authorised full opening of the product’s door. -
Page 13: Aquavoid™ Plus
aquAvoid™ plus Permitted water temperature: up to 25°C ( 60°C for products equipped (depends on the model) with aquAvoid™ plus; please refer The aquAvoid™ plus system protects to aquAvoid™ plus section ) against water leaks that may occur at the The dishwasher may not be connected to hose inlet.Water contact with the valve box open warm water devices or flow-through... -
Page 14: Connection To The Drain
Connection to the drain Electrical connection Water discharge hose can directly be Connect the product to a grounded connected to the drain hole or sink’s outlet protected by a fuse complying drainage. See the installation manual with the values in the "Technical supplied with your machine for detailed specifications"... -
Page 15: Fitting A Different Plug
pin face of the plug. Fuse covers are available from any good electrical store. Fitting a different plug As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals on your plug, proceed as follows: Connect the green - yellow or green (earth) wire to the terminal in the plug... -
Page 16: Preparation
Preparation Read “Quick Guide - Adjusting Water Softening System” before this section! The regeneration of the water softening Read “Safety Instructions” section first! system can be done in all programmes Tips for energy saving during drying step. When regeneration occurs, duration, energy and water Following information will help you use the consumption of the programme increase. -
Page 17: Adding Salt
Adding salt Water softening system needs to be regenerated in order for the product to operate with the same performance continuously. Dishwasher salt is used for this purpose. Use only special softening salts produced particularly for the dishwashers in your machine. You can put about 2 kg of softening It is recommended to use granule- or salt into the salt reservoir. - Page 18 further questions. using detergent tablets. Do not put solvents into the detergent dispenser. There is the risk of explosion! Put the detergent into the detergent dispenser just before operating the machine as illustrated below. 1. Push the latch to right to open the detergent dispenser lid (A).
-
Page 19: Tablet Detergents
temperature and time. 2. Set the water hardness to the highest level and perform an empty run. Tablet detergents 3. After the empty washing cycle, review the user manual and readjust the water In addition to the conventional tablet hardness level so as to suit the water detergents, there are also commercially available detergent tablets that show water supply. -
Page 20: Items Not Suitable For Washing In The Dishwasher
3. Slightly press the point (B) of the Decorative prints of chinaware as well reservoir lid to close it. as aluminium and silver items may get discoloured or tarnished after washing in the dishwasher just as it happens in handwashing as well. Some delicate glass types and crystals may become dull in time. - Page 21 Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware 21/EN...
-
Page 22: Cutlery Basket
Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash your Cutlery basket is designed to wash your dishes such as knife, fork, spoon, etc. in an dishes such as knife, fork, spoon, etc. in an efficient manner. -
Page 23: Collapsible Lower Basket Tines
Collapsible lower basket tines Collapsible lower basket tines (depends on model) (depends on model) There are foldable tines (A) located at There are foldable tines (A) located at the lower basket of the machine are the lower basket of the machine are designed for an easier placement of large designed for an easier placement of large pieces such as pans, bowls, etc. -
Page 24: Tray Wash Supports
Tray Wash Supports SoftTouch Accessory (depends on model) (depends on model) Use the supports to wash trays in the The SoftTouch Accessory found in the bottom basket. lower basket of your machine enables a See the Auxiliary functions section for safe washing for your fragile glasses. -
Page 25: Lower Basket Multipurpose / Height Adjustable Service Rack
Lower basket multipurpose / To close the racks: 1. Fold the rack (A). height adjustable service rack 2. Slide the rack up (B). (depends on model) This accessory located at the lower basket 3. Put the rack in vertical position (C). of your machine allows you to easily wash 4. -
Page 26: Upper Basket Height Adjustable Rack
Upper basket height adjustable Upper basket multipurpose rack service rack (depends on model) (depends on model) Use the lower and upper parts of the height This accessory located at the upper basket adjustable racks in the upper basket of of your machine allows you to easily wash the machine by sliding them down or up pieces such as extra long ladles and bread according to the heights of the glasses,... -
Page 27: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper To lower the basket, while it is in the basket uppermost position; 1. Hold the upper basket wires with both (depends on model) hands, slightly lift up the basket and The upper basket height adjustment simultaneously push and release the mechanism has been designed for you to latches shown in the figure (B). -
Page 28: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper Repeat the same operation if the height is not adequate. basket (depends on model) Upper basket height adjustment mechanism is designed so that you can create wide spaces on the upper or lower compartment of the machine by adjusting the basket upwards or downwards either while it is empty or full. -
Page 29: Bottle And Dish Holder On The Lower Basket
Bottle and Dish Holder on the Tray Washing Support (depends on model) Lower Basket You may use the tray washing supports (depends on model) if you want to wash a tray on your lower Bottle and dish holder (A) on the lower basket. -
Page 30: Height Setting With Empty Basket
Height setting with empty basket Collapsible upper basket wires (depends on model) (depends on model) In this model, the height setting of the You can use collapsible wires when you upper basket may be changed using the need a larger space for your dishes in the wheels which are mounted at two different upper basket of your machine. -
Page 31: Ceiling Cutlery Basket
Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc. -
Page 32: Operating The Product
Operating the product Programme selection Read “Safety Instructions” section first! 1. Press the On/Off button to turn on your Read “Quick Quide” before this machine. section. 2. Check the Salt and Rinse Aid indicators On/Off key and add salt and/or rinse aid if needed. When you press On / Off key, indicator lights illuminate on the display for ON 3. - Page 33 Auto Tablet Feature Half Load function (Depends on model) (Depends on model) Auto Tablet is a feature which detects It is used to operate the machine without the use of combined tablet detergents loading it completely. automatically. 1. Load your dishes in the machine as you Drying performance of these type of like.
- Page 34 Interior Lighting Auto Door Opening (depends on the model) (Depends on the Model) Some models have interior lighting to “Auto Door Opening” feature of your illuminate the interior when the door is machine increases drying efficiency of your opened. machine and saves energy. There are two 1.
-
Page 35: Scheduling The Washing Time
Hygiene+ function 3. Set the desired time by pressing the (depends on the model) Time Delay key. Time will increase with Designed to be used when more hygiene increments of 30 minutes up to 6 hours is required for washing the dishes. This and after that in 1 hour increments up function increases the washing and rinsing to 24 hours every time you press the... -
Page 36: Adjusting The Amount Of Rinse Aid
where your machine is installed, Rinse Aid indicator ( ) temperature of the supply water and Please check the rinse aid indicator on the amount of the dishes. display to see whether there is adequate Pay attention not to open the door of amount of rinse aid in the dishwasher or the machine when it is running. -
Page 37: Water Cut-Off Warning
ProCare End of Programme indicator will light up when the washing programme is over. (depends on model) 1. Open the door of the machine. This programme is recommended to be 2. Press On/Off key to turn off your operated on each 1-2 months for machine machine. -
Page 38: Maintenance And Cleaning
Maintenance and Cleaning the filters cleaning Clean the filters at least once a week in order for the machine operates efficiently. Read “Safety Instructions” section first! Check if food residues are left on the filters. Unplug the product and turn off the If there are food residues on filters, take tap before attempting any cleaning them out and clean well under running... -
Page 39: Cleaning The Hose Filter
Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. Check the filter and the hose regularly and clean them if necessary. -
Page 40: Cleaning The Impellers
Cleaning the impellers Do not try to rotate the impeller by Clean the impellers at least once a week in holding its ends. Trying to rotate the order for the machine operates efficiently. end sections may cause the gear system within the impeller to break. Lower impeller Upper impeller Check if the holes on the lower impeller (1) -
Page 41: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 42 • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 43 There is a different odour in the machine A new machine has a peculiar odour. It will fade out after a couple of washes. • Filters are clogged. >>> Check if the filter system is clean. Clean the filter system regularly as illustrated in section “Cleaning and Care”.
- Page 44 • Opening of the detergent dispenser lid is prevented during washing. >>> Place the dishes in a way that will not prevent the detergent dispenser lid from opening and the water going into the machine from impellers. • Detergent is stored under unsuitable conditions. >>> If you are using powder detergent, do not store the detergent package in humid places.
- Page 45 Foam forms in the machine. • Dishes are washed with hand-wash detergent by hand but not rinsed before placing them into the machine. >>> Hand-wash detergents do not contain antifoam. There is no need to hand-wash the dishes before placing them into the machine. Removing the coarse soil on the dishes under tap water, with a tissue paper or fork will be sufficient.
-
Page 46: Guarantee
Guarantee Guarantee Details • Accessories and/or consumable items Your new Blomberg product is guaranteed including but not limited to ice trays, against faulty materials, defective scrapers, cutlery baskets, filters and components or manufacturing defects. light bulbs. The guarantee starts from the date of •... - Page 47 Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only. Does Blomberg offer replacements? This is a repair-only guarantee. On occasion the Manufacturer may at its sole discretion, replace your product with a new product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model, but when this is not possible, a model of similar specification will be provided.
- Page 48 When will the repair take place? Our engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours may be possible at the sole discretion of the Manufacturer but cannot be guaranteed. Whilst our Engineers will endeavour to minimize inconvenience and to meet requests for specific timed appointments, this cannot be guaranteed.
- Page 49 Should you experience any difficulty in obtaining service contact the Blomberg Customer Helpline on Tel: 0333 207 9870 or e-mail: customerservice@support.Blomberguk.com ………………………………………………..............
