- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe...
- Page 3 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
- Page 4 ) shall be used. Alternative a fl exible cord be of synthetic rubber according to IEC 60245 (designation H05RR-F 3G 0.75mm ) shall be used. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of different countries from there.
-
Page 5: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ....................1 SAFETY PRECAUTIONS ................1 SPECIAL NOTES ON LCD MONITORS ............3 CUSTOMER SERVICE ..................3 CLEANING ....................... 3 BEFORE YOU OPERATE THE MONITOR ............4 FEATURES ...................... 4 CHECKING THE CONTENTS OF THE PACKAGE ......... 4 FITTING AND REMOVAL OF BASE : ProLite B2409HDS / ProLite B2409HDSD .. -
Page 6: For Your Safety
STOP OPERATING THE MONITOR IF YOU ARE AWARE OF ANY PROBLEMS If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fi re or electric shock. - Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 8: Special Notes On Lcd Monitors
Power Switch for some hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, fl ickering or not lighting up. Never attempt to replace it by yourself. -
Page 9: Before You Operate The Monitor
CHEKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. Power Cable*... -
Page 10: Fitting And Removal Of Base: Prolite B2409Hds / Prolite B2409Hdsd
FITTING AND REMOVAL OF BASE: ProLite B2409HDS / ProLite B2409HDSD CAUTION Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. Unplug the monitor before removal or installation to avoid electric shock or damage. -
Page 11: Fitting And Removal Of Base : Prolite E2409Hds
FITTING AND REMOVAL OF BASE : ProLite E2409HDS Put the monitor on a stable surface. The monitor may cause injury or damage if it falls CAUTION or is dropped. Do not give a strong impact to the monitor. It may cause damage. Unplug the monitor before removal or installation to avoid electric shock or damage. -
Page 12: Controls And Connectors : Prolite B2409Hds / Prolite B2409Hdsd
CONTROLS AND CONNECTORS : ProLite B2409HDS / ProLite B2409HDSD <Front> <Back> Power Switch ( Power Indicator NOTE Blue: Normal operation Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 1W when receiving no horizontal and/or vertical sync signal. -
Page 13: Controls And Connectors : Prolite E2409Hds
CONTROLS AND CONNECTORS : ProLite E2409HDS HDMI DVI-D D-SUB EARPHONE AUDIO IN <Front> <Back> Power Switch ( Power Indicator NOTE Blue: Normal operation Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 1W when receiving no horizontal and/or vertical sync signal. -
Page 14: Connecting Your Monitor : Prolite B2409Hds / Prolite B2409Hdsd
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama offi... -
Page 15: Connecting Your Monitor : Prolite E2409Hds
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama offi... -
Page 16: Computer Setting
Change to the desired signal timing listed on page 30: COMPLIANT TIMING. Windows 95/98/2000/Me/XP/Vista/7 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP/Vista/7 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 17: Adjusting The Hight And The Viewing Angle
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite B2409HDS / ProLite B2409HDSD For optimal viewing it is recommended to position yourself directly opposite to the full face of the monitor, then adjust the monitor’s height and angle to your own preference. Hold the panel so that the monitor does not topple when you change the monitor’s height or angle. -
Page 18: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 30. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 20 for SCREEN ADJUSTMENTS. -
Page 19: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Luminance Luminance Contrast Brightness Picture Mode Standard Adjustment Item Problem / Option Button to Press Too dull Contrast Too intense Too dark Brightness * Too bright Normal Mode1 Brightness of back-light is reduced. Direct Mode2 Brightness of back-light is reduced more than Mode1. Mode3 Brightness of back-light is reduced more than Mode2. - Page 20 Image Setup Image Setup Clock Phase H.Position V.Position Aspect Full Adjustment Item Problem / Option Button to Press Too narrow Clock* Too wide Phase* To correct fl ickering text or lines Too left H. Position* Too right Too low V. Position* Too high Full Expansion display...
- Page 21 Color Temp. Color Temp. Gamma Mode1 Color Temp. Warm User-R User-G User-B Adjustment Item Problem / Option Button to Press Mode1 Normal Gamma Mode2 Dark Mode3 High contrast Warm Greenish white Normal Yellowish white Bluish white Cool Color Temp. User-R Too weak User User-G...
- Page 22 OSD Setup OSD Setup H.Position V.Position Timeout Language English Adjustment Item Problem / Option Button to Press OSD is too left H.Position OSD is too right OSD is too low V.Position OSD is too high You can set the OSD display duration time Timeout between 5 and 60 seconds.
- Page 23 Others Others Reset Signal Select Auto HDMI audio Auto Information Input : HDMI Resolution : 1920(H) 1080(V) H.Frequency : 68KHz V.Frequency : 60Hz Adjustment Item Problem / Option Button to Press Factory-preset data is restored. Reset Return to Menu. Auto Select the signal input automatically.
-
Page 24: Screen Adjustments
Direct You can skip the Menu items and display an adjustment scale directly by using the following button operations. Volume: Press the + Button when the Menu is not displayed. Adjustment Item Problem / Option Button to Press Too soft Volume Too loud Only Analog Input... -
Page 25: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama. com). - Page 26 C Press the Auto Button. (Auto Adjust) D Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. E Adjust the V.Position so that the top and bottom of the picture frame will fi...
- Page 27 G Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern. NOTE In case the strong fl icker or blurs remain on a part of the screen, repeat steps F and NOTE G because the Clock may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from C again.
-
Page 28: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. -
Page 29: Trouble Shooting
MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check The picture does not appear. -
Page 30: Recycling Information
A strange noise is The Audio Cable is properly connected. heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. TROUBLE SHOOTING / RECYCLING INFORMATION... -
Page 31: Appendix
APPENDIX SPECIFICATIONS : ProLite B2409HDS Size Category 24" LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 23.6" (60cm) Pixel pitch 0.2715mm H × 0.2715mm V Brightness 300cd/m (Typical) Contrast ratio 1000 : 1 (Typical), ACR Function Available Viewable angle Right / Left : 85 degrees each, Up / Down: 80 degrees each (Typical) Response time 5ms (Black, White, Black), 2ms (Gray to Gray) -
Page 32: Specifications : Prolite B2409Hdsd
SPECIFICATIONS : ProLite B2409HDSD Size Category 24" LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 23.6" (60cm) Pixel pitch 0.2715mm H × 0.2715mm V Brightness 300cd/m (Typical) Contrast ratio 1000 : 1 (Typical), ACR Function Available Viewable angle Right / Left : 85 degrees each, Up / Down: 80 degrees each (Typical) Response time 5ms (Black, White, Black), 2ms (Gray to Gray) -
Page 33: Specifications : Prolite E2409Hds
SPECIFICATIONS : ProLite E2409HDS Size Category 24" LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 23.6" (60cm) Pixel pitch 0.2715mm H × 0.2715mm V Brightness 300cd/m (Typical) Contrast ratio 1000 : 1 (Typical), ACR Function Available Viewable angle Right / Left : 85 degrees each, Up / Down: 80 degrees each (Typical) Response time 5ms (Black, White, Black), 2ms (Gray to Gray) -
Page 34: Dimensions : Prolite B2409Hds / Prolite B2409Hdsd
DIMENSIONS : ProLite B2409HDS / ProLite B2409HDSD 561.0mm/22.1" 523.5mm/20.6" 68.0mm/2.7" ) : Maximum adjustment range DIMENSIONS : ProLite E2409HDS 561.0mm/22.1" 523.5mm/20.6" 68.0mm/2.7" 241.5mm/9.5" APPENDIX... -
Page 35: Compliant Timing
COMPLIANT TIMING PC Input Horizontal Vertical Video Mode Dot Clock Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 37.500kHz 75.000Hz 31.500MHz 640 × 480 31.500MHz 37.861kHz 72.809Hz 35.156kHz 56.250Hz 36.000MHz 40.000MHz SVGA 800 × 600 37.879kHz 60.317Hz 46.875kHz 75.000Hz 49.500MHz 48.363kHz 60.004Hz 65.000MHz VESA 75.000MHz 1024 ×...
