- Page 1 WA70F5G4 WA80F5G4 Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. F550_WA80F5G4DJW-03302A-04_EN (Australia).indd 1 F550_WA80F5G4DJW-03302A-04_EN (Australia).indd 1 2016-01-22 2016-01-22 2:51:20 2:51:20...
-
Page 2: Table Of Contents
contents SAFETY INSTRUCTIONS Safety instructions Description of part SETTING UP YOUR WASHER How to wash automatically depends on the laundry Control Panel Environment INSTALLATION & MAINTENANCE Levelling Connecting the water supply hose Assembling the rat protection panel (option) How to connect the drain hose (option) Calibration mode Adding detergent Adding fabric softener... - Page 3 safety instructions Please note that the following precautions for safety intend to prevent unpredictable danger and damage by helping the proper use in safety. When using hot water in washing, please make sure that the water should not exceed 50°C. •...
- Page 4 safety instructions 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
- Page 5 The use for business purposes qualifi es as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
-
Page 6: Description Of Part
setting up your washer DESCRIPTION OF PART The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Be sure to keep the lid closed Water supply hose (Cold) during washing and spinning. Water supply hose (Hot) Fabric softener dispenser... - Page 7 CHECKING BEFORE WASHING AND CARING FOR GARMENTS Must follow the checkpoints in order to avoid machine problems or damages on garments. • If the below problems are caused by customer’s faults, separate service fee will be charged. Checkpoints Before Starting Washing Check if the clothes are bleaching or not.
- Page 8 setting up your washer CARING FOR CLOTHES BEFORE WASHING Take out personal belongings from pockets. • Caution, Check the pockets! Hairpins and coins cause damages to clothes and washing machine. They make noise and problems to the machine. Must check the pocket. If pants zippers are open while washing, the spin basket may be damaged.
- Page 9 Curtains, fl oating garments or blue jeans shall be pressed not to fl oat on the water. • If they are floated on the water, press Start/Pause button to stop and press them to soak in the water. If the washing goes on with clothes floating on the water, it may cause damages to the clothes and the washing machine as well as unsatisfactory washing result.
-
Page 10: How To Wash Automatically Depends On The Laundry
setting up your washer HOW TO WASH AUTOMATICALLY DEPENDS ON THE LAUNDRY Before starting washing, check the following; • Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose. Washing for the fi... -
Page 11: Control Panel
CONTROL PANEL For more details, see control panel of your washing machine. Select the appropriate cycle for the type of load. The cycle you select determines the tumble pattern and spin speed for the cycle. Cotton - For most fabrics including cottons, linens, and normally soiled garments. - Page 12 setting up your washer Press the button repeatedly to cycle through the different water temperature options. Hot - Whites and heavily soiled, colorfast items. Temp. selection button Warm - Colorfast items. Cold - Brightly colored, very lightly soiled items. Press the button repeatedly to cycle through the different spin speed options. High - Use for underwear, t-shirts, jeans, and sturdy cottons.
- Page 13 CHILD LOCK This function is for protecting children, the elderly and the frail. 1. Press the Power button. 2. To activate the Child Lock function, press and hold both the Spin and Water Lavel buttons down simultaneously for 3 seconds. (If the Child Lock function is activated, the Child Lock icon blinks.) 3.
- Page 14 Downloading the Samsung Smart Washer app Download the Samsung Smart Washer app to your mobile phone from the Android market or Apple App store and install it. You can easily fi nd it by searching for “Samsung Smart Washer”. Using the Smart Check function 1.
-
Page 15: Environment
installation & maintenance The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. ENVIRONMENT Leave some space Maintain at least 10 cm between the washer and the wall. Place the washer on a sturdy fl at surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs. -
Page 16: Assembling The Rat Protection Panel (Option)
installation & maintenance 4. Connect the water supply hose to the adaptor. Pull down the part (c) of the water supply hose. When the part (c) is released, the hose is automatically connected to the adaptor making a ‘click’ sound. 5. -
Page 17: How To Connect The Drain Hose (Option)
Make sure that you install your washing machine correctly by running the Rinse+Spin cycle after the installation is complete. CALIBRATION MODE Your Samsung washing machine detects the laundry weight automatically. For more accurate weight detection, please run Calibration Mode after the installation. To run Calibration Mode, follow these steps: 1. -
Page 18: Adding Detergent
installation & maintenance ADDING DETERGENT 1. Open the detergent drawer and then add the powder detergent into the detergent compartment. 2. Add detergent evenly so that it doesn’t brim over the edge of the drawer. • Use a reasonable amount of detergent. If you use more detergent than the standard quantity or the water temperature is too low and the detergent does not dissolve in the water completely... -
Page 19: Cleaning The Filter
CLEANING THE FILTER Clean the filter net often to keep the washer clean. 1. Push the upper part of the Hygiene fi lter 2. Open the cover as shown in the fi gure. and pull in. 3. Clean the Hygiene fi lter. 4. -
Page 20: Troubleshooting
troubleshooting PROBLEM CHECK Washing machine won’t work • Is the water tap opened? • Is the washer plugged in? • Is the power cut off? • Is there enough water? Water dose not drain • Is the drain hose down? (No pump) •... -
Page 21: Washing Machine Won't Work
washing machine won’t work? PROBLEM CHECK The power is cut off. Is the electric voltage normal? Is the washer plugged in? Plug in the electric cord. Water does not drain. Is the drain hose down? Put the drain hose down. Is the drain hose folded? Unfold the drain hose. - Page 22 washing machine won’t work? PROBLEM CHECK The water leaks at the water supply Did you press the Start/Pause button after selecting the water hose connector. supply? If the Start/Pause button is not pressed, water is not supplied. Press the Start/Pause button. Is the faucet closed? ...
-
Page 23: Specifi Cation
specifi cation WA70F5G4, WA80F5G4 WA70F5G4 7.0kg Extra high 87 ℓ MAX. MASS OF DRY CLOTH IN kg WA80F5G4 8.0kg High 65 ℓ STANDARD WATER LEVEL WASH 300- 350W Medium 44 ℓ POWER CONSUMPTION SPIN 250W 34 ℓ DIMENSIONS(mm) 610*672*1100 (High) WASHING TYPE Stirring Type 610*672*1080 (Low) - Page 24 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT AUSTRALIA 1300 362 603 www.samsung.com/au/support NEW ZEALAND 0800 726 786 www.samsung.com/nz/support Code No. DC68-03302A-04_EN F550_WA80F5G4DJW-03302A-04_EN (Australia).indd 24 F550_WA80F5G4DJW-03302A-04_EN (Australia).indd 24 2016-01-22 2016-01-22 2:51:26 2:51:26...
