Page 1 SyncMaster 400TS-3, 460TS-3 LCD Display User Manuals The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.
Page 2: Safety Instructions
Safety Instructions Notational Note These safety instructions must be followed to ensure your safety and prevent property damage. Make sure to read the instructions carefully and use the product in the correct manner. Warning / Caution Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment.
Page 3: Installation
Safety Instructions Do not touch the power plug with wet hands when removing or plug- ging the plug into the outlet. • Otherwise, this may result in electric shock. Make sure to connect the power cord to a grounded power outlet. •...
Page 4 Safety Instructions Ensure that at least two persons lift and move the product. • Otherwise, it may be dropped and cause personal injury, and/or dam- age the product. When installing the product in a cabinet or rack, make sure that the front end of the bottom of the product does not project out.
Page 5 Safety Instructions Ensure that the packaging vinyl is kept away from children. • Otherwise, it may result in serious harm (suffocation) if children play with it. If the height of your monitor is adjustable, do not place any object or part of your body on the stand when lowering it.
Page 6 Safety Instructions Others The product is a high voltage product. Do not disassemble, repair or modify the product yourself. • Otherwise, this may result in electric shock or fire. If the product needs to be repaired, contact a Service Center. If there is a strange smell or a strange sound or smoke is coming from the product, disconnect the power plug immediately and contact a Service Center.
Page 7 Safety Instructions Do not insert any metal, such as chopsticks, coins, pins and steel, or flammable objects, such as matches or paper, inside the product (through the ventilating openings, input and output terminals, etc). • If water or foreign material enters the product, disconnect the power cord and contact a Service Center.
Page 8 Safety Instructions Do not place any heavy items or toys or confectionery, such as cookies etc. that may attract the attention of children and to the product. • Your children may hang onto the product causing it to fall and this may result in personal injury or death.
Page 9 Safety Instructions Keep the small accessories in a location out of the reach of children. Be careful when adjusting the angle of the product or the height of the stand. • This may result in personal injury as your hand or fingers may be- come caught.
Page 10 Introduction Package Contents Checking the Contents of the Package Remove the lock from the package box, as shown in the figure above. Lift up the package box by Check the contents of the Remove the Styrofoam and holding the grooves on both package.
Page 11 Introduction Manuals Quick Setup Guide Warranty Card User's Guide (Not available in all loca- tions) Cables Power Cord D-Sub Cable USB Cable Others Remote Control Batteries (AAA X 2) (BP59-00138B) (Not available in all loca- tions) Sold separately Semi Stand KIT LAN Cable RGB to BNC Cable RGB to COMPONENT Ca-...
Page 12: Your Lcd Display
Introduction Sold separately Wall Mount KIT TV Tuner box RS232C Cable Note • Accessories that can be purchased with the product vary by country. Your LCD Display The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.
Page 13 Introduction However, the picture may display abnormally if the connected external input signal is different from the selected video signal. • MagicInfo can only be enabled when a network box is connected. • A TV tuner box (sold separately) must be connected to use the TV. D.MENU button Opens the on-screen D.MENU.
Page 14 Introduction POWER S/W ON [ I ] / OFF Switches the LCD Display On/Off. POWER The power cord plugs into the LCD Display and the wall outlet. TOUCH SCREEN USB HUB Connects to a network box (sold separately) or PC in order to use the touchscreen.
Page 15 Introduction Connect a DP cable to [DP IN] on the product and DP IN on another display. AV/COMPONENT AUDIO IN [R-AUDIO-L] Connect the [AV/COMPONENT AUDIO IN [R- AUDIO-L]] port on the monitor to the audio output port on the PC or on the external device using an audio cable.
Page 16 Introduction Note To use MagicInfo, the network box specified separately by Samsung must be installed inside the product and the MagicInfo output of the net- work box must be connected to the [HDMI IN 2 (MAGICINFO)] terminal. For more information on how to purchase and in- stall a network box, contact Samsung Electronics.
Page 17 Introduction To lock the product, follow these steps: Wrap the Kensington lock cable around a large, stationary object such as a desk or chair. Slide the end of the cable with the lock at- tached through the looped end of the Ken- sington lock cable.
Page 18: Remote Control
Introduction POWER Connect the [POWER] terminal of the product and the [POWER] terminal of the monitor using a power extension cable. POWER Connects to a mains socket via the power cord. POWER S/W ON [ I ] / OFF Turns the network box on or off. Note •...
Page 19 Introduction MENU RETURN EXIT MagicInfo Turns the product On. POWER Turns the product Off. Used to enter the password during the OSD adjustment or to use Number Buttons MagicInfo. Press to change the channel. The "-" button is used to select Digital channels. / GUIDE button Electronic Program Guide (EPG) display.
Page 20 Introduction You can select the PC, DVI, HDMI or DP(DisplayPort) external input directly in a mode other than TV mode. TV channels provide written information services via teletext. TTX/MIX - Teletext Buttons Note This function does not work for this LCD Display. MTS- MTS/DUAL You can select MTS (Multichannel Television Stereo) mode.
Page 21: Tilt Angle And Rotation
Enabled when a Network box is connected. User Installation Guide Note • Be sure to call an installation expert of Samsung Electronics to install the product. • The warranty becomes invalid if the product is installed by someone other than a professional authorized by Samsung Electronics.
Page 22: Embedded Mount Guide
When installing the product onto a vertical wall, be sure there is a 40 mm space or more behind the product for ventilation, as shown above, and maintain the ambient temperature at 35×C or lower. Note A Samsung Electronics service center can provide details. 2. Embedded Mount guide <Side view> <Top view>...
Page 23: Floor Mount Guide
When embedding the product in the floor, be sure there is a 50 mm space or more behind the product for ventilation, as shown above, and maintain the ambient temperature at 20×C or lower. Note A Samsung Electronics service center can provide details. Mechanical Layout (400TS-3)
Page 24: Installation Vesa Bracket
Distributor to place an order. After your order is placed, installation professionals will visit you and install the bracket. • At least 2 persons are needed in order to move the LCD Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions (400TS-3) (460TS-3)
Page 25: Accessories (Sold Separately)
Introduction Notice For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length. Accessories (sold separately) • Dimension with welcome board (400TS-3) (460TS-3)
Page 26: Wall Bracket Installation
Introduction • Dimension with other accessories Wall Bracket Installation • Contact a technician for installing the wall bracket.
Page 27: To Mount The Product On The Wall Bracket
Introduction • SAMSUNG Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. • This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.
Page 28: Wall Bracket Angle Adjustment
Introduction Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. LCD Display Wall Bracket Wall...
Page 29 Introduction Make sure to use the top center, and not the left or the right side of the product to adjust the angle. Remote Control (RS232C) Cable connections interface RS232C(9 pin) TxD(No.2) RxD(No.3) GND(No.5) Bits rate 9600 bps Data Bits 8 bit Parity None...
Page 30: Control Codes
Introduction Connector : 9-pin D-Sub Cable : Cross (reversed) cable -P1- -P1- -P2- -P2- FEMALE ---------> FEMALE <--------- ---------- • Connecting method Control codes • Get control Header command DATA Length CheckSum 0xAA command type • Set control Header command DATA DATA Length...
Page 31 Introduction Volume control 0x12 0~100 Input source control 0x14 Screen Mode control 0x18 Screen Size control 0x19 0~255 PIP on/off control 0x3C Auto adjustment control 0x3D Video wall Mode control 0x5C Safety Lock 0x5D - ID should show hexadecimal value of assigned ID, but ID 0 should be 0xFF. - Every communication will be made in hexadecimals and Checksum is the sum of all remainings.
Page 32 Introduction • DATA Header command Ack/Nak r-CMD Val1 Check Length 0xAA 0xFF ‘A’ 0x11 Power Power : Same as above • DATA Header command Ack/Nak r-CMD Val1 Check Length 0xAA 0xFF ‘N’ 0x11 ERR : Error code that shows what occurred error is •...
Page 33 Introduction • Input Source Control • Function Personal Computer changes input source of TV / Monitor. • Get Input Source Status Header command DATA Length CheckSum 0xAA 0x14 • Set Input Source Header command DATA DATA Length CheckSum 0xAA 0x14 Input Source Input Source : Input Source code to be set on TV / Monitor 0x14...
Page 34 Introduction Input 0xAA 0xFF ‘A’ 0x14 Source Input Source : Same as above • DATA Header command Ack/Nak r-CMD Val1 Check Length 0xAA 0xFF ‘N’ 0x14 ERR : Error code that shows what occurred error is • Screen Mode Control •...
Page 35 Introduction • DATA Header command Ack/Nak r-CMD Val1 Check Length 0xAA 0xFF ‘N’ 0x18 ERR : Error code that shows what occurred error is • Screen Size Control • Function Personal Computer recognizes the screen size of TV / Monitor. •...
Page 36 Introduction • Set the PIP ON / OFF Header command DATA DATA Length CheckSum 0xAA 0x3C PIP : The PIP ON / OFF code to set for the TV or Monitor 1 : PIP ON 0 : PIP OFF • DATA Header command...
Page 37 Introduction Auto Ad- 0xAA 0xFF ‘A’ 0x3D justment • DATA Header command Ack/Nak r-CMD Val1 Check Length 0xAA 0xFF ‘N’ 0x3D ERR : Error code that shows what occurred error is • Video Wall Mode Control • Function Personal Computer converts Video Wall Mode of TV / Monitor when Video Wall is ON. Only works with TV / Monitor where Video Wall is on.
Page 38 Introduction DATA Header command Ack/Nak r-CMD Val1 Check Length 0xAA 0xFF ‘N’ 0x5C ERR : Error code that shows what occurred error is • Safety Lock • Function Personal Computer turns Safety Lock function of TV / Monitor ON / OFF. Can operate regardless of whether power is ON / OFF.
Page 39: Connecting A Computer
Connections The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. Connecting a Computer There are several ways to connect the computer to the monitor. Choose one from the following options.
Page 40 LCD Display. Turn on the power switch. Note Contact a local SAMSUNG Electronics Service Center to buy optional items. Connecting to a PC to Use the TOUCH SCREEN To use the touch-screen functions, connect a PC to the product and connect [TOUCH SCREEN USB HUB] on the product to the USB port on the PC.
Page 41 Connections • When the graphics card supports DVI (digital) output (via a DVI cable) • Connect the [DVI IN] port of the product to the DVI port on your PC using the DVI cable. • Connect the [TOUCH SCREEN USB HUB] port of the product to the USB port on your PC using the USB cable.
Page 42 Connections • When the graphics card supports DVI (digital) output (via an HDMI-DVI cable) • Connect the [HDMI IN 1] / [HDMI IN 2] port of the product to the DVI port on your PC using the HDMI to DVI cable. •...
Page 43: Connecting To Other Devices
Connections • Connect or remove a USB device following the safe installation and removal instructions recom- mended by Microsoft. If there is any problem with the touch screen function or sound output after a USB device is connected, reconnect the USB cable or change the connection port. Connecting to Other devices Note •...
Page 44: Connecting To A Camcorder
Connections Connecting to a Camcorder Locate the AV output jacks on the camcorder. They are usually found on the side or back of the camcorder. Connect a video cable between the VIDEO OUTPUT jack on the camcorder and the [AV IN] on the LCD Display . Connect a set of audio cables between the AUDIO OUTPUT jacks on the cam- corder and the [AV /COMPONENT AUDIO IN [R-AUDIO-L]] on the LCD Display .
Page 45: Connecting Using A Dvi To Hdmi Cable
Connections Connect an HDMI cable to [HDMI IN 2 (MAGICINFO)] or [HDMI IN 1] on the product and the HDMI output port on a digital device. Press SOURCE on the product or remote control and select "HDMI1 / HDMI2" Note In HDMI mode, only PCM format audio is supported.
Page 46: Connecting A Dtv Set Top (Cable/Satellite) Box
Connections Connect a RGB to Component cable between the [RGB/COMPONENT IN] port on the LCD Display and the P , Y, P jacks on the DVD player. Connect a set of audio cables between the [AV/COMPONENT AUDIO IN [R- AUDIO-L]] on the LCD Display and the AUDIO OUT jacks on the DVD player. Note •...
Page 47: Connecting To An Audio System
• Network boxes are sold separately. • For more information on how to purchase and install a network box, contact Samsung Electronics. Connecting the Power Connect the [POWER] terminal of the product and the [POWER] terminal of the installed network box using a power extension cable.
Page 48: Connecting To Magicinfo Out
Connections Connecting to MAGICINFO OUT Connect the [MAGICINFO OUT] terminal of the network box and the [HDMI IN 2 (MAGICINFO)] terminal of the monitor using the DP to HDMI cable. Connecting a LAN Cable Connect the LAN cable between the [LAN] port on the product and the [LAN] port on your PC.
Page 49: Connecting A Usb Devices
Connections Connecting a USB devices You can connect USB devices such as a mouse or keyboard. Connecting to a Network box to Use the TOUCH SCREEN Connect the [TOUCH SCREEN USB HUB] port of the product to the USB port on your PC using the USB cable.
Page 50: Using The Software
Prepare a blank disk and download the driver Program file at the Internet web site shown here. Internet web site : http://www.samsung.com/ Installing the Monitor Driver (Automatic) Insert CD into the CD-ROM drive. Click "Windows". Choose your monitor model in the model list, then click the "OK" button.
Page 51: Installing The Monitor Driver (Manual)
Using the Software Note This monitor driver is certified by Microsoft, and installing it will not damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Installing the Monitor Driver (Manual) ® Microsoft Windows Vista™‚ Operating System Insert your Manual CD into your CD-ROM drive.
Page 52 Note This monitor driver is under certifying MS logo, and this installation will not damage your system. The certified driver will be posted on Samsung Monitor homepage. Click "Update Driver..." in the "Driver" tab. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".
Page 53 Using the Software Select the model that matches your monitor from the list of monitor models on the screen, and click "Next". 10. Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence. ® ® Microsoft Windows XP Operating System...
Page 54 Using the Software Insert CD into the CD-ROM drive. Click "Start" → "Control Panel", then click the "Appearance and Themes" icon. Click "Display" icon and choose the "Settings" tab then click "Advanced...". Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Click "Update Driver..."...
Page 55 "OK" button. Note This monitor driver is certified by Microsoft, and this installation will not damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Click the "Close" button, then click the "OK" button continually.
Page 56: Microsoft ® Windows ® Millennium Operating System
Using the Software 10. Monitor driver installation is completed. ® ® Microsoft Windows 2000 Operating System When you can see "Digital Signature Not Found" on your monitor, follow these steps. Choose "OK" button on the "Insert disk" window. Click the "Browse" button on the "File Needed" window. Choose A:(D:\Driver), then click the "Open"...
Page 57 Using the Software Select the "Monitor" tab. Click the "Change" button in the "Monitor Type" area. Choose "Specify the location of the driver". Choose "Display a list of all the driver in a specific location...", then click "Next" button. Click the "Have Disk" button. Specify A:\(D:\driver), then click "OK"...
Page 58 Using the Software Touchscreen Installing the Touchscreen Driver Connect the monitor to your PC using the USB cable. Insert the driver installation CD into the CD-ROM drive. Click "Setup IRTOUCH USB" with the mouse. The driver will run. (Double-click the file in the "Touchscreen Driver"...
Page 59 Using the Software Click "Finish” (FIG.3) to complete the driver update. A taskbar balloon at the bottom, right corner of the screen will read "Found New Hardware" (FIG. 4). FIG. (3) FIG. (4) Touchscreen Control PanelInstalling the Driver Double-click the shortcut on the desktop, or go to “Start” -> “All Programs” -> ”IRTouchSystems” - >...
Page 60 Using the Software General Control Panel Menu FIG. (6) 1. Mapping The control panel can be used to make adjustments or configurations using a USB connection and supports multiple touchscreens connected to the same PC. The panel provides basic information for the touchscreen and allows for calibration.
Page 61 Using the Software Touch Sensitivity Settings Right Click Settings Beep Type Settings Beep Type Settings FIG. (7) Modes There are three touch modes : “Click on touch,” “Click on Release,” “Mouse Emulation.” 1. Click on touch A click is recognized when your finger contacts the touchscreen. Note that you cannot drag objects. The touchscreen responds fastest in this mode, which is recommended for big-button applications.
Page 62: Uninstalling The Driver
Using the Software Enable the right-click function. Press and hold any part of the screen for two seconds. The context menu will appear. The right-click function is available only in Mouse Emulation mode. You may adjust the "Delay” in “Right Click Settings” if you find the context menu appears too soon or late. Note The higher the value, the later the context menu will appear.
Page 63 Using the Software MDC (Multiple-Display Control) Installation Insert the installation CD into the CD-ROM drive. Click the MDC System installation Program. Note If the screen for installing the software does not appear, install it using the MDC System execution file in the MDC folder of the CD-ROM. If the installation wizard screen does appear, click "Next."...
Page 64: Installation Problems
Using the Software 10. If the installation is successfully completed, the quick MDC System execution icon will appear on the desktop. MDC execution icon may not appear depending on specification of computer system or monitor. If that happens, press F5 Key. Installation Problems The installation of MDC can be affected by such factors as the video card, motherboard and the network environment.
Page 65: Main Screen
Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a display. Main Screen Click Start > Program > Samsung > MDC System to start the program. Select a set to see the volume of the selected set within the slider.
Page 66: Port Selection
Main Icons Remote control Selection Buttons Safety Lock Refresh Port Selection Display Selection Lamp Control Info Grid Option... Control Tools Dropdown Selectors OSD Display Use the main icons to switch into each screen. Allows you to enable or disable the remote control signal receiving function of the display unit. Set the Safety Lock function.
Page 67 1. The Multiple Display Control is originally set to COM1. 2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu. 3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will be unavailable.
Page 68 3) Image Size 4) On Timer 5) Off Timer 2. Selects displays you want to adjust using the Select button or checkboxes. System allows controlling some of the functions of the selected display. 1) Power On/Off - Turns the power of the selected display On/Off. 2) Volume - Controls the volume level of the selected display.
Page 69: Input Source
1) Source OSD - Sets whether the Source OSD will be displayed to indicate when the Source is changed. 2) Not Optimum Mode OSD - Sets whether the Optimum Mode OSD will be displayed to indicate if the current mode is not supported. 3) No Signal OSD - Sets whether the No Signal OSD will be displayed to indicate when there is no signal.
Page 70 • PC Mode Info Grid shows some basic information necessary to Input Source Control. - Changes the Input Source of the selected display to PC. - Changes the Input Source of the selected display to BNC. - Changes the Input Source of the selected display to DVI. - Changes the Input Source of the selected display to TV.
Page 71: Image Size
S-Video - Changes the Input Source of the selected display to S-Video. Component - Changes the Input Source of the selected display to Component. MagicInfo - The Input source of MagicInfo works only on MagicInfo model. HDMI1/HDMI2 - Changes the Input Source of the selected display to HDMI. - Switches the input source for the selected Display to DP.
Page 72 DP may not be supported depending on the product. The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Image Size Control is available only for the displays for which power status is ON. Image Size TV, AV, S-Video, Component, DVI(HDCP), HDMI1, HDMI2, DTV.
Page 73 Info Grid shows some basic information necessary to Time Control. 1) Set clock - Set the current time for the selected display (PC Time). - To change the current time, first change the PC Time. 2) Timer - Sets up Timer1, Timer2, Timer3 and Holiday Management. 3) Shows whether Timer is activated.
Page 74 - Selects the volume when the selected monitor is turned on. 4) Source - Selects the external input source that will be displayed when the selected monitor is turned on. 5) Holiday - Applies the Holiday Management function to the Timer. 6) Repeat - Available selections include Once, EveryDay, Mon~Fri, Mon~Sat, Sat~Sun, and Manual.
Page 75: Pip Source
Info Grid shows some basic information necessary to PIP Size Control. 1) PIP Size - Shows the current PIP Size of the display in use. 2) OFF - Turns off the PIP of the selected display. 3) Large - Turns on the PIP of the selected display and changes the size to Large. 4) Small - Turns on the PIP of the selected display and changes the size to Small.
Page 76 Info Grid shows some basic information necessary to PIP Source Control. 1) PIP Source - PIP Source can be controlled with turning on the LCD Display power. 2) PC - Changes the source of the PIP of the selected display to PC. 3) BNC - Changes the source of the PIP of the selected display to BNC.
Page 77 Basic information required to adjust the Picture is displayed in the main menu. Settings for the selected monitor will be displayed if one of the connected monitors is selected, and the default settings will be displayed if all monitors are selected by clicking All and Select. If a value is changed in this screen, the current mode will automatically switch to custom mode.
Page 78 1. Click Settings of the main icons and the Settings Control screen appears. Basic information required to adjust settings is displayed. Settings for the corresponding SET will be imported and displayed on the slider if a display ID is selected, and the default settings will be displayed if all display IDs are selected by clicking All and Select.
Page 79: Image Lock
Settings Audio 1. Click Settings of the main icons and the Settings Control screen appears. Basic information required to adjust Audio is displayed in the display window. Settings for the corresponding SET will be imported and displayed on the slider if a display ID is selected, and the default settings will be displayed if all display IDs are selected by clicking All and Select.
Page 80: Maintenance
Info Grid shows some basic information necessary to Settings Control. 1) Image Lock - Available only for PC, BNC. 2) Coarse - Adjusts Coarse of the selected display. 3) Fine - Adjusts Fine of the selected display. 4) Position - Adjusts Position of the selected display. 5) Auto Adjustment - Self-Adjust to the incoming PC signal.
Page 81 An "Info Grid" showing several basic data items appears. 1) Maintenance - Allows the Maintenance Control function for all input sources. 2) Lamp Control - Automatically adjusts the backlight of the selected display at a specified time. The Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control. - Allows you to adjust the backlight of the selected display regardless of the time.
Page 82: Video Wall
1) Scroll - This function is used to remove the afterimages that occur when a still screen is displayed on the selected display for a long time. 2) Pixel Shift - This allows the screen to be moved finely at the specified time interval. 3) Safety Screen - The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the monitor for a long time.
Page 83 1) Video Wall - A Video Wall is a set of video screens that are connected together, so that each screen shows a part of the whole picture or so that the same picture is repeated on each screen. 2) Video Wall Control - Video Wall properties can be configured.
Page 84 Natural 3) Video Wall (Screen divider) - The screen can be divided into. You can select a number of screens with a different layout when dividing. Select a mode from Screen divider. Select a display from Display Selection. The place will be set up by pressing a number in the selected mode. The maximum number of monitors that can be arranged: Horizontal X Vertical = 100 Up to 15 monitors can be arranged in a row.
Page 85 3. Selected one display (ID1) and add another display (ID3): The program, which was displaying the settings value of ID 1, fetches and displays the value of ID3. 4. If all sets are selected at the same time by clicking All and Select, the default value will be restored.
Page 86 Connect the first display device and the PC by entering the IP address. To connect to another display device, use an RS-232C serial cable. Refer to the figure above. Main Screen Click Start > Program > Samsung > MDC System to start the program. Select a set to see the volume of the selected set within the slider.
Page 87: Add A Device
Main Icons Lamp Control Add a Device Display Selection Remote Control Safety Lock Control Tools Fault Device Alert OSD Display Use the main icons to switch into each screen. You can add a device by entering the IP address configured on the monitor. Allows you to enable or disable the remote control signal receiving function of the display unit.
Page 88 1. Enter the IP address of the monitor to be connected and press the Add button to add the IP address. If you click the OK button, adding the monitor is completed. System 1. Click System in the main menu to open the system adjustment screen. Info Grid shows some basic information necessary to System.
Page 89 2. Selects displays you want to adjust using the Select All button or checkboxes. System allows controlling some of the functions of the selected display. 1) Power On/Off - Turns the power of the selected display On/Off. 2) Volume - Controls the volume level of the selected display. It receives the volume value of the selected display from the sets and displays it in the slider.
Page 90 1) Source OSD - Sets whether the Source OSD will be displayed to indicate when the Source is changed. 2) Not Optimum Mode OSD - Sets whether the Optimum Mode OSD will be displayed to indicate if the current mode is not supported. 3) No Signal OSD - Sets whether the No Signal OSD will be displayed to indicate when there is no signal.
Page 91 1) Select or clear all the added devices; or refresh or delete selected devices. 2) The IP Address, ID (Ethernet or Serial), Mac Address and connection status of the connected monitor is displayed. 3) It can automatically check whether DHCP IP is set and then set the IP address. 4) It can automatically or manually set and then apply the IP Address, Subnet and Gateway of the selected monitor.
Page 92: Image Size
Info Grid shows some basic information necessary to Input Source Control. 1) PC - Changes the Input Source of the selected display to PC. 2) BNC - Changes the Input Source of the selected display to BNC. 3) DVI - Changes the Input Source of the selected display to DVI. 4) TV - Changes the Input Source of the selected display to TV.
Page 93 Info Grid shows some basic information necessary to Image Size Control. ( Power Status) - Shows the power status of the current display. 2) Image Size - Shows the current Image Size of the display in use. 3) Input - Info Grid displays only the displays whose Input Source is PC, BNC, DVI and DP. 4) PC Source - Click Image Size in the main menu to display the PC, BNC, DVI and DP tabs.
Page 94 HDMI2 may not be supported depending on the product. Time 1. Click Time of the main icons and the Time Control screen appears. Info Grid shows some basic information necessary to Time Control. 1) Clock Set - Set the current time for the selected display (PC Time). - To change the current time, first change the PC Time.
Page 95 1) On Time - Sets the time in hours, in minutes and as AM/PM for turning the selected monitor on. 2) Off Time - Sets the time in hours, in minutes and as AM/PM for turning the selected monitor off. 3) Volume - Selects the volume when the selected monitor is turned on.
Page 96 The Holiday Management function can be turned on or off in the Timer setup menu. The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Time Control is available only for the displays for which the power status is ON. Only enabled for a TV when Source is set to TV in On Time mode.
Page 97 PIP Source 1. Click PIP of the main icons and the PIP control screen appears. Info Grid shows some basic information necessary to PIP Source Control. 1) PIP Source - PIP Source can be controlled with turning on the LCD Display power. 2) PC - Changes the source of the PIP of the selected display to PC.
Page 98 1. Click Settings of the main icons and the Settings Control screen appears. Basic information required to adjust the Picture is displayed in the main menu. Settings for the selected monitor will be displayed if one of the connected monitors is selected, and the default settings will be displayed if all monitors are selected by clicking All and Select.
Page 99 Picture PC 1. Click Settings of the main icons and the Settings Control screen appears. Basic information required to adjust settings is displayed. Settings for the corresponding SET will be imported and displayed on the slider if a display ID is selected, and the default settings will be displayed if all display IDs are selected by clicking All and Select.
Page 100: Image Lock
Setting Audio 1. Click Settings of the main icons and the Settings Control screen appears. Basic information required to adjust Audio is displayed in the display window. Settings for the corresponding SET will be imported and displayed on the slider if a display ID is selected, and the default settings will be displayed if all display IDs are selected by clicking All and Select.
Page 101: Maintenance
Info Grid shows some basic information necessary to Settings Control. 1) Image Lock - Available only for PC, BNC. 2) Coarse - Adjusts Coarse of the selected display. 3) Fine - Adjusts Fine of the selected display. 4) Position - Adjusts Position of the selected display. 5) Auto Adjustment - Self-Adjust to the incoming PC signal.
Page 102 An "Info Grid" showing several basic data items appears. 1) Maintenance - Allows the Maintenance Control function for all input sources. 2) Lamp Control - Automatically adjusts the backlight of the selected display at a specified time. The Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control. - Allows you to adjust the backlight of the selected display regardless of the time.
Page 103: Video Wall
1) Scroll - This function is used to remove the afterimages that occur when a still screen is displayed on the selected display for a long time. 2) Pixel Shift - This allows the screen to be moved finely at the specified time interval. 3) Safety Screen - The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the monitor for a long time.
Page 104 1) Video Wall - A Video Wall is a set of video screens that are connected together, so that each screen shows a part of the whole picture or so that the same picture is repeated on each screen. 2) Video Wall Control - Video Wall properties can be configured.
Page 105 Natural 3) Video Wall (Screen divider) - The screen can be divided into. You can select a number of screens with a different layout when dividing. Select a mode from Screen divider. Select a display from Display Selection. The place will be set up by pressing a number in the selected mode. The maximum number of monitors that can be arranged: Horizontal X Vertical = 100 Up to 15 monitors can be arranged in a row.
Page 106 2. Selected one display: Fetches and displays the settings value for the selected display. 3. Selected one display (ID1) and add another display (ID3): The program, which was displaying the settings value of ID 1, fetches and displays the value of ID3. 4.
Page 107: Adjusting The Lcd Display
Adjusting the LCD Display Input Available Modes • PC / DVI / DisplayPort • • Component • HDMI • MagicInfo • Note • MagicInfo can only be enabled when a network box(sold separately) is connected. • A TV tuner box (sold separately) must be connected to use the TV. Source List Use to select PC, HDMI or other external input sources connected to the LCD Display.
Page 108 Adjusting the LCD Display Note The [RGB/COMPONENT IN] port is compatible with a PC or component input. However, the picture may not display normally if you select an input source different from the actual connected input source. Note The PIP function is not available when Video Wall is On. When external AV devices such as VCRs or DVDs are connected to the LCD Display, PIP allows you to watch video from those devices in a small window super-imposed on the PC Video signal.
Page 109 Adjusting the LCD Display • PC : DVI, AV, HDMI1, HDMI2, DisplayPort • DVI : PC • AV : PC • HDMI : PC • DisplayPort : PC Size Changes the Size of the PIP window. Position Changes the Position of the PIP window. Transparency Adjusts the Transparency of PIP windows.
Page 110: Source Autoswitch Settings
Adjusting the LCD Display Edit Name Name the input device connected to the input jacks to make your input source selection easier. VCR / DVD / Cable STB / HD STB / Satellite STB / AV Receiver / DVD Receiver / Game / Camcorder / DVD Combo / DHR / PC / DVI PC / DVI Devices Note •...
Page 111: Source Autoswitch
Adjusting the LCD Display Source AutoSwitch When the Source AutoSwitch is On, the display video source will automatically be searched for active video. The Primary Source selection will be activated, if the current video source is not recognized. Sec- ondary source selection will become active, if no primary video source is available. If the primary or secondary source is not recognized, the display will search again, if no active video is found the display will show the no-input-signal message.
Page 112: Secondary Source
Adjusting the LCD Display Specify Primary Source for the automatic input source. Secondary Source Specify Secondary Source for the automatic input source. Picture [PC / DVI / DisplayPort / MagicInfo Mode] • If connected to a PC, set Edit Name to DVI PC, and enjoy video or audio content saved on the PC. •...
Page 113 Adjusting the LCD Display Information Recommended for communicating exact information (e.g. public information). Advertisement Recommended for displaying advertisements (e.g. videos or indoor or outdoor ads). Custom Custom By using the on-screen menus, the contrast and brightness can be changed to your personal preference. Note •...
Page 114: Color Tone
Adjusting the LCD Display Color Tone Note Not available when Dynamic Contrast is set to On. The Color tones can be changed. Cool Normal Warm Custom Note • If you set the Color Tone to Cool, Normal, Warm, or Custom, the Color Temp. function is disabled.
Page 115: Auto Adjustment
Adjusting the LCD Display Color Temp. is a measure of the 'warmth' of the image Colors. Note This function is enabled when Mode is set to Custom, and Dynamic Contrast and Color Tone are Off. Image Lock Image Lock is used to fine-tune and get the best image by removing noise that creates unstable images with jitters and shakiness.
Page 116: Signal Control
Adjusting the LCD Display Note • Not available when Dynamic Contrast is set to On. • Available in PC mode only. Signal Balance Selects either On or Off with the signal balance. Signal Control Note Available when Signal Balance is set to On. R-Gain G-Gain B-Gain...
Page 117: Pip Picture
Adjusting the LCD Display Size The Size can be switched. 16:9 PIP Picture Adjusts the PIP Screen Settings. Note • Available Modes: PIP On Contrast Adjusts the Contrast of the PIP window on the screen. Brightness Adjusts the Brightness of the PIP window on the screen. Sharpness Adjusts the Sharpness of the PIP window on the screen.
Page 118: Dynamic Contrast
Adjusting the LCD Display Note The Tint slider is only displayed when PIP input source is HDMI or AV. Dynamic Contrast Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to create an optimum contrast. Note This function is disabled when PIP or Energy Saving is On. Lamp Control Adjusts the inverter lamp in order to reduce energy consumption.
Page 119 Adjusting the LCD Display Reset the screen settings. Picture [ AV / HDMI / TV / Component Mode] Available Modes • PC / DVI / DisplayPort • • Component • HDMI • MagicInfo • Note • MagicInfo can only be enabled when a network box(sold separately) is connected. •...
Page 120 Adjusting the LCD Display Adjusts the Contrast. Brightness Adjusts the Brightness. Sharpness Adjusts the picture Sharpness. Color Adjusts the picture Color. Tint Adds a natural tone to the display. Note The tint slider is only displayed when input source is HDMI, Component or AV. Color Tone The Color tones can be changed.
Page 121 Adjusting the LCD Display Warm2 Note • If you set the Color Tone to Cool2, Cool1, Normal, Warm1, or Warm2, the Color Temp. function is disabled. • By adjusting the picture using the Color Tone function, Mode will change to Custom mode. Color Temp.
Page 122: Digital Nr (Digital Noise Reduction)
Adjusting the LCD Display • Zoom 1 and Zoom 2 are disabled for HD signals (1080i/p, 720p or 768p). • The Position and Reset functions are available in Zoom 1 or Zoom 2 modes. Digital NR (Digital Noise Reduction) Turns the Digital Noise Reduction feature Off/On. The Digital Noise Reduction feature allows you to enjoy clearer and crisper images.
Page 123: Film Mode
Adjusting the LCD Display Film Mode Film Mode calibrates unnatural pictures that may occur in a movie (which is in 24 frames). Moving subtitles may appear corrupted when this mode is enabled. (In HDMI mode, this function is available when the input signal is interlaced scan; it is not available in progressive scan.) PIP Picture Adjusts the PIP Screen Settings.
Page 124 Adjusting the LCD Display Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to create an optimum contrast. Note This function is disabled when PIP or Energy Saving is On. Lamp Control Adjusts the inverter lamp in order to reduce energy consumption. Note Not available when Dynamic Contrast is set to On.
Page 125 Adjusting the LCD Display • Note • MagicInfo can only be enabled when a network box(sold separately) is connected. • A TV tuner box (sold separately) must be connected to use the TV. Mode The LCD Display has a built-in high fidelity stereo amplifier. Standard Selects Standard for the standard factory settings.
Page 126: Auto Volume
Adjusting the LCD Display Emphasizes high frequency audio. Balance Allows you to Adjusts the sound balance between the left and right speakers. Auto Volume Reduces the difference in volume control between broadcasters. SRS TS XT SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers.
Page 127: Speaker Select
Adjusting the LCD Display Note Available when PIP is set to On. Main Speaker Select When you use the product with it connecting to a Home Theater, turn the internal speakers off so you can listen to sound from the Home Theater's (external) speakers. Internal Sound is outputted both from the Internal speaker and the External speakers, but the volume control is only available from the Internal speaker.
Page 128: Clock Set
Adjusting the LCD Display Note • MagicInfo can only be enabled when a network box(sold separately) is connected. • A TV tuner box (sold separately) must be connected to use the TV. Language You can choose one of 13 languages. Note The language chosen affects only the language of the OSD.
Page 129: Timer1 / Timer2 / Timer3
Adjusting the LCD Display Timer1 / Timer2 / Timer3 You can set the LCD display to automatically turn on or off at a specified time. Note • Only enabled when the clock is set using the Clock Set menu. • The Manual option allows you to select a day of the week.
Page 130: Menu Transparency
Adjusting the LCD Display You can delete selected holidays. Note • Only enabled when registered holidays are selected. • More than one holiday can be selected and deleted. • Delete All You can delete all the registered holidays. Menu Transparency Change the transparency of the background of the OSD.
Page 131: Energy Saving
Adjusting the LCD Display Note If you forgot your password, press the remote buttons INFO + EXIT + MUTE to reset the password to "0000." Lock This is the function that locks the OSD in order to keep the current settings or to prevent others from adjusting the settings.
Page 132 Adjusting the LCD Display Turns Off/On the Video Wall function of the selected display Off/On. • • Format The Format can be selected to see a divided screen. • Full Provides a full screen without any margins. • Natural Displays a natural image with the original aspect ratio intact. Horizontal Sets how many parts the screen should be divided horizontally.
Page 133: Screen Position
Adjusting the LCD Display Note If Horizontal is set to 15, the maximum value for Vertical is 6. Screen Position The screen can be divided into several images. A number of screens can be selected with a different layout when dividing. •...
Page 134 Adjusting the LCD Display • Horizontal Sets how many pixels the screen moves horizontally. Five adjustment levels: 0, 1, 2, 3, and 4. Vertical Sets how many pixels the screen moves vertically. Five adjustment levels: 0, 1, 2, 3, and 4. Time Set the time interval for performing the horizontal or vertical movement, respectively.
Page 135 Adjusting the LCD Display You can set the timer for Screen Burn Protection. If you start the operation to erase any residual image, the operation will be performed for the set period of time and then automatically finish. • • Mode You can change the Safety Screen Type.
Page 136: Side Gray
Adjusting the LCD Display This function prevents after-images on the screen by moving long black and white vertical lines. Eraser This function prevents after-images on the screen by moving a rectangular pattern. Pixel This function prevents after-images by moving many pixels on the screen. Side Gray Select the brightness of the grey for the screen background.
Page 137: Resolution Select
Adjusting the LCD Display Resolution Select When the picture is not displayed properly on the screen when setting the graphics card resolution of the computer to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz or 1366 x 768 @ 60Hz, by using this function(Resolution Select), you can have the picture displayed on the screen in the specified resolution.
Page 138: Osd Rotation
Adjusting the LCD Display OSD Rotation OSD Rotate Landscape Portrait Advanced Settings Configures the settings more elaborately. Fan & Temperature (Only Network model) Protects the product by detecting the fan speed and internal temperature. Fan Control Selects auto or manual for the fan speed settings. •...
Page 139: Temperature Control
Adjusting the LCD Display Note Enabled when Fan Control is set to Manual. Temperature Control Detects the product's internal temperature and specifies the desired temperature. The product is set to 77°C by default. Note • The picture will be dimmed if the temperature exceeds the specified temperature, and the product will automatically power off to prevent overheating if the temperature keeps rising.
Page 140: Button Lock
Adjusting the LCD Display • • Note When Auto Power is On, the product will power on automatically as soon as it is connected to power. Button Lock Locks or unlocks the monitor control buttons on the product. • • User Auto Color Auto Color Automatically adjusts the Colors.
Page 141: Lamp Schedule
Adjusting the LCD Display Sets the standby mode, which will be activated when no input signal is detected. • A message will read No Signal if no input signal is detected. • Power-saving mode will be activated if no input signal is detected. •...
Page 142: Not Optimum Mode Osd
Adjusting the LCD Display Not Optimum Mode OSD • • No Signal OSD • • MDC OSD • • Software Upgrade Performs a software upgrade. Connect the product to a computer via a digital signal such as DVI or HDMI. Click the BMP image file converted from an SW code.
Page 143: Setup Reset
Adjusting the LCD Display Note When there are two or more BMP images, they are displayed on the screen using a slideshow. • It is recommended that the playback interval between two BMP images in the slideshow should be one second. The image extraction probability will decrease with other playback intervals.
Page 144: Multi Control
Adjusting the LCD Display Reset all the settings for the display. Multi Control Available Modes • PC / DVI / DisplayPort • • Component • HDMI • MagicInfo • Note • MagicInfo can only be enabled when a network box(sold separately) is connected. •...
Page 145 Adjusting the LCD Display • Subnet Mask : Manually enter the Subnet Mask if IP Setting is set to Manual. • Gateway : Manually enter the Gateway if IP Setting is set to Manual. MagicInfo Available Modes • PC / DVI / DisplayPort •...
Page 146 Adjusting the LCD Display It is highly recommended not to turn off the AC power during an operation. • For pivoted LCD Displays, ticker transparency is not supported. • For pivoted LCD Displays, a screen resolution of up to 720*480(SD) is supported for movies. •...
Page 147 Adjusting the LCD Display In step 2 of MagicInfo Setup Wizard, you don’t have to go to Network Setting on the desktop to make your settings for TCP/IP. You just do that at step 2 of MagicInfo installation. 3. Select Language - step 3 When using multiple languages, you can choose and set a specific language among them.
Page 148 Adjusting the LCD Display Shows the settings that have been selected by the user. Note If the MagicInfo icon is not displayed on the notification area, double click the MagicInfo icon on the window desktop. The icon will appear.
Page 149: Troubleshooting
Troubleshooting Self-Test Feature Check Note Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself. Self-Test Feature Check Turn off both your computer and the LCD Display. Unplug the video cable from the back of the computer. Turn on the LCD Display.
Page 150: Symptoms And Recommended Actions
Troubleshooting • Do not use benzene, thinner or other flammable substan- ces. 2) Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel). • Never use acetone, benzene or thinner. (They may cause flaws or deformation of the screen sur- face.) •...
Page 151: Problems Related To The Screen
Troubleshooting (Refer to Connecting a Computer) Problems related to the Screen Note Problems related to the LCD Display screen and their solutions are listed. The screen is blank and the power indicator is off. Ensure that the power cord is firmly connected and the LCD Display is on. (Refer to the Connecting a Computer) "No signal"...
Page 152: Problems Related To Audio
Troubleshooting The Color image is distorted by dark shadows. Adjust the Color Control option in the OSD adjustment menu. The Color white is poor. Adjust the Color Control option in the OSD adjustment menu. The Power Indicator blinks. The LCD Display is currently saving the changes made in the settings to the OSD memory. The screen is blank and the power indicator light blinks every 0.5 or 1 seconds.
Page 153 Troubleshooting The frequency can be changed by reconfiguring the video card. Note That video card support can vary, depending on the version of the driver used. (Refer to the computer or the video card manual for details.) How can I adjust the resolution? Windows XP: Set the resolution in the Control Panel →...
Page 154: Specifications
Specifications General General Model Name 400TS-3, 460TS-3 LCD Panel Size 400TS-3 40.0 inch / 101 cm 460TS-3 46.0 inch / 116 cm Display Area 400TS-3 885.6(H) mm x 498.15(V) 460TS-3 1018.08(H) mm x 572.67(V) Synchronization Horizontal 30 ~ 81 kHz Vertical 56 ~ 85 Hz Display Color...
Page 155: Environmental Considerations
Specifications Dimensions (W x H x D) / Weight 460TS-3 1104.0 mm x 721.0 mm x 311.0 mm / 43.4 x 28.4 x 12.2 inches (With Stand) 1104.0 mm x 658.0 mm x 134.0 mm / 43.4 x 25.9 x 5.3 inches (Without Stand) 33.6 Kg / 74.0 lbs (With Network Box) 31.3 Kg / 69.0 lbs (Without Network Box)
Page 156: Preset Timing Modes
Specifications video card installed in your computer. Use the software utility installed on your computer to set up this feature. PowerSaver 400TS-3 State Normal Op- Power saving Power off Power off eration mode (Power Swich) Power Indicator Blinking Amber 400TS-3 270 Watts 5 Watts 5 Watts...
Page 157 Specifications Display Mode Horizontal Vertical Fre- Pixel Clock Sync Polarity Frequency quency (Hz) (MHz) (H/V) (kHz) IBM, 640 x 480 31.469 59.940 25.175 IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284...
Page 158: For A Better Display
Information For a Better Display Adjust the computer resolution and screen injection rate (refresh rate) on the computer as described below to enjoy the best picture quality. You can have an uneven picture quality on screen if the best picture quality is not provided for TFT-LCD. •...
Page 159 Information Power Off, Screen Saver, or Power Save Mode • Turn the power off for 2 hours after 12 hours in use • Set the Monitor to power off with the PC Display Properties Power Scheme. • Use a Screen saver if possible - Screen saver in one Color or a moving image is rec- ommended.
Page 160 Information Change the characters Color periodically • Use Bright Colors with little difference in luminance. - Cycle : Change the characters Color and background Color every 30 minutes • Every 30 minutes, change the characters with movement. • Have the images and logo cycle periodically. - Cycle: Display moving image together with Logo for 60 seconds after 4 hours in use.
Page 161 Information • Apply the Screen Erasing function - Symptom: 2 Vertical blocks move while erasing the display...
Page 162 Appendix Contact SAMSUNG WORLDWIDE Note If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care Center. North America U.S.A 1-800-SAMSUNG (726-7864) http://www.samsung.com CANADA 1-800-SAMSUNG (726-7864) http://www.samsung.com MEXICO 01-800-SAMSUNG (726-7864) http://www.samsung.com Latin America ARGENTINA 0800-333-3733 http://www.samsung.com...
Page 163 SERBIA 0700 SAMSUNG (0700 726 http://www.samsung.com 7864) SLOVAKIA 0800 - SAMSUNG (0800-726 http://www.samsung.com/sk 786) SPAIN 902 - 1 - SAMSUNG (902 172 http://www.samsung.com 678) SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com SWITZERLAND 0848 - SAMSUNG (7267864, http://www.samsung.com/ch CHF 0.08/min) http://www.samsung.com/...
Page 164 UKRAINE 0-800-502-000 http://www.samsung.com/ua http://www.samsung.com/ua_ru BELARUS 810-800-500-55-500 MOLDOVA 00-800-500-55-500 Asia Pacific AUSTRALIA 1300 362 603 http://www.samsung.com NEW ZEALAND 0800 SAMSUNG (0800 726 http://www.samsung.com 786) CHINA 400-810-5858 http://www.samsung.com HONG KONG (852) 3698 - 4698 http://www.samsung.com/hk http://www.samsung.com/ hk_en/ INDIA 3030 8282 http://www.samsung.com...
Page 165 Appendix Middle East OMAN 800-SAMSUNG (726-7864) http://www.samsung.com KUWAIT 183-2255 http://www.samsung.com BAHRAIN 8000-4726 http://www.samsung.com EGYPT 08000-726786 http://www.samsung.com JORDAN 800-22273 http://www.samsung.com MOROCCO 080 100 2255 http://www.samsung.com SAUDI ARABIA 9200-21230 http://www.samsung.com U.A.E 800-SAMSUNG (726-7864) http://www.samsung.com Africa NIGERIA 0800-SAMSUNG (726-7864) http://www.samsung.com SOUTH AFRICA 0860-SAMSUNG (726-7864) http://www.samsung.com...
Page 166: Correct Disposal
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or con- sequential damages in connection with the furnishing, performance, or use of this material.
Page 167 Appendix TruSurround XT, SRS and the symbol are trademarks of SRS Labs, Inc. TruSurround XT technology is incorporated under license from SRS Labs, Inc.

This manual is also suitable for:

Syncmaster 400ts-3 Syncmaster 400ts-2

Samsung SyncMaster 460TS-3 User Manuals

Quick Links

Related Manuals for Samsung SyncMaster 460TS-3

Summary of Contents for Samsung SyncMaster 460TS-3

This manual is also suitable for:

Table of Contents
