- Page 1 ImageFlat F791 Mutiscanning Color Monitor User's Guide www.hyundaiQ.com...
- Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 DECLARATION OF CONFORMITY HYUNDAI ImageQuest CO., LTD. Ami-ri Bubal-Eub Ichon-Si Kyungki-Do 467-860 KOREA declare under our sole responsibility that the product: Kind of equipment COLOR MONITOR T ype-Designation C17F06091 to which this declaration relates is in conformity with the following standard(s) or other normative document(s)
-
Page 4: Table Of Contents
F791 ImageFlat Color Monitor Contents 1. Introduction ......1/19 2. Safety Information ....1/19 3. Installing the monitor ....3/19 3-1. Packing List ........3/19 3-2. Fastening the swivel and tilt base ..4/19 3-3. Selecting a suitable location ..4/19 3-4. Connecting the monitor ....5/19 3-5. -
Page 5: Introduction
ImageFlat Color Monitor 1. Introduction This manual contains instructions for installing and operating Hyundai ImageFlat F791. Hyundai ImageFlat F791 is a highly ergonomic color display unit; • 17” diagonal Flat(16” viewable) 0.25mm dot pitch CDT • Supporting high screen refresh rates and full scan flicker-free picture quality •... - Page 6 F791 ImageFlat Color Monitor Cleaning and Maintenance • To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning. • Do not use alcohol (methyl, ethyl or isopropyl) or any strong dissolvent. Do not use thinner or benzene, abrasive cleaners or compressed air.
-
Page 7: Installing The Monitor
F791 ImageFlat Color Monitor 3. Installing the The following items should be found in the packaging. monitor 3-1. Packing List Japan Attached Signal Cable America/Canada Europe South Africa Australia Monitor Korea Tilt and Swivel Compact Disc Power cord Above power cord can be changed upon different voltage areas. Please contact your dealer if anything is missing or damaged. -
Page 8: Fastening The Swivel And Tilt Base
F791 ImageFlat Color Monitor 3-2. Fastening the swivel and tilt base • Place the base against the bottom of the monitor so that the base fasteners are aligned with appropriate slots. • Push the base towards the front of the monitor until the latch locks into position. -
Page 9: Connecting The Monitor
F791 ImageFlat Color Monitor 3-4. Connecting the Before you start cabling your monitor, check that monitor the power is off on all units. To avoid any possibility of electric shock, always connect your equipment to properly earthed outlets. 5/19... - Page 10 F791 ImageFlat Color Monitor Insert the 15-pin signal cable connector to the VGA connection on your computer and screw it down. Plug the display unit’s power cable first to the back of the display unit. Then plug the power cable to a 100V - 240V earthed electrical outlet or to the system unit, if it has an outlet for the display power cable.
-
Page 11: Setting The Refresh Rate
F791 ImageFlat Color Monitor 3-5. Setting the refresh Follow the instructions below to set your refresh rate in Windows 98. rate Go to the configuration window (Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’ tab. Click on the ‘Advanced’ button. Click on ‘Adapter’... -
Page 12: Adjusting The Picture
F791 ImageFlat Color Monitor 4. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. 93.8K 8/19... -
Page 13: Using The On Screen Display
F791 ImageFlat Color Monitor 4-1. Using the On Screen Push the MENU button to call the OSD to the screen. The resolution and Display frequency are displayed at the top of the menu box for your information. Push the button to choose the item you want to adjust. The selected item is highlighted. -
Page 14: Osd Adjustments
F791 ImageFlat Color Monitor 4-3. OSD Adjustments The OSD adjustments available to you are listed below. H. SIZE You can play the movie Adjusts the horizontal size of the entire screen image. file to see how to adjust the picture image by H. - Page 15 F791 ImageFlat Color Monitor PIN BALANCE If the sides of the picture are bowed to the right or to the left, you can correct the pincushion balance by using this adjustment. V. MOIRE Clears vertical moire if a series of concentric circles or arcs appear on your screen.
- Page 16 F791 ImageFlat Color Monitor H. LINEARITY If either left or right side of the picture is out of proportion to the other, you can correct horizontal linearity by using this adjustment. V. LINEARITY If top and bottom side of the picture is out of proportion to the center area, you can correct vertical linearity by using this adjustment.
- Page 17 F791 ImageFlat Color Monitor COLOR CONTROL Color temperature affects the tint of the 93.8K 75 image. With lower color temperatures the image turns reddish and with higher temperatures bluish. There are three color settings available: 9300K, 6500K or USER. With the USER setting you can set individual values for red, green and blue.
- Page 18 F791 ImageFlat Color Monitor If you have tilted, swiveled or moved the display unit, you can perform demagnetization. During this process the picture is distorted for a few seconds. After demagnetizing, the color impurities have disappeared if caused by stray magnetic fields. Do not use the degauss feature more than once every half hour.
-
Page 19: Display Power Management
F791 ImageFlat Color Monitor 5. Display power If the power management function of your computer is enabled, your monitor management turns on and off automatically. You can control power management features from your computer. Reducing power Your computer may have power management features which enable the computer consumption or monitor to enter a power saving mode when the system is idle. -
Page 20: Troubleshooting
F791 ImageFlat Color Monitor 6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by reading followings. Problem Possible solution Blank screen If the power LED is not lit, push the power switch to turn the monitor on. - Page 21 F791 ImageFlat Color Monitor Problem Possible solution The display does The video signal from the computer does not comply with VESA not enter power DPMS standard. Either the computer or the graphics adapter is not management using the VESA DPMS power management function. mode Screen flickers The screen may seem to flicker when the refresh rate is less than...
- Page 22 F791 ImageFlat Color Monitor Contacting service If the above troubleshooting hints do not help you find a solution to the problem, contact an authorized service agent. If the monitor is sent for service, use the original package if possible. Unplug the display unit from the power outlet and contact a service agent when: •...
-
Page 23: Specifications
F791 ImageFlat Color Monitor 7. Specifications 17"(viewable size : 16") Picture tube Dot pitch 0.25 mm Anti-Static, anti-glare, TCO treatment coated. Display area factory preset area : 305X229 mm Number of color Infinite Input signals R.G.B Analog, 15 pin D-sub Frequency rate Horizontal : 30 to 97kHz, Vertical : 50 to 150Hz Maximum bandwidth...
