- Page 1 HT202SF-X5_DKAZLLK_ENG_6572 DVD HOME THEATER SYSTEM OWNER’S MANUAL MODEL: LH-T2020X LH-T2020X SH22SF-S, SH22SF-W Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
- Page 2 CAUTION: The apparatus should not be exposed to water CAUTION (dripping or splashing) and no objects filled with liquids, such RISK OF ELECTRIC SHOCK as vases, should be placed on the apparatus. DO NOT OPEN CAUTION concerning the Power Cord Most appliances recommend they be placed upon CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK...
-
Page 3: Table Of Contents
Introduction Maintenance and Service Maintenance and Service ....3 Before use ......4 Refer to the information in this chapter before Front Panel/Rear Panel . -
Page 4: Before Use
Introduction Before use Types of Playable Discs To ensure proper use of this product, please read this (8 cm / 12 cm disc) owner’s manual carefully and retain it for future reference. Audio CD (8 cm / 12 cm disc) This manual provides information on the operation In addition, this unit can play a DVD-RW, DVD+RW and maintenance of your DVD/CD Receiver. -
Page 5: Front Panel/Rear Panel
Front Panel/Rear Panel STANDBY/ON DISC Tray PLAY STANDBY indicator OPEN/CLOSE button Lights red when the receiver is in Standby mode (off). VOLUME controller DISPLAY Window Remote sensor TUNING(-/+) USB Port MONO/ST./ /SKIP/SCAN PAUSE/STEP Connect to a USB port of . bb/BB> >... -
Page 6: Remote Control
Remote Control OPEN/CLOSE (Z Z ) POWER Opens and closes the disc tray. Selects the output source (CD/DVD) Plays the multimedia files. BAND ZOOM Select the System’s tuner (FM and AM SLEEP bands) Sets the System to turn off automatically at a specified time. -
Page 7: Installation And Setup
Installation and Setup TV Connection Make one of the following connections, depending on Video connection the capabilities of your existing equipment. Connect the MONITOR OUT jack from the DVD/CD Receiver to the VIDEO IN jack on the TV using the Tips: video cable supplied (V). -
Page 8: Optional Equipment Connection
Optional Equipment Connection Antenna Connection Connect the USB port of a USB Memory (or MP3 Connect the supplied FM/AM antenna for listening to player, etc.) to the USB port on the front of the the radio. unit. Connect the AM Loop aerial to the AM aerial connector. -
Page 9: Speaker System Connection
Speaker System Connection Connect the speaker cords to the speaker terminals. To obtain the best possible surround sound, adjust the speaker parameters (volume, distance, etc.). Notes: Be sure to match the speaker cable to the appropriate terminal on the components: + to + and –... -
Page 10: Displaying Disc Information On-Screen
Displaying Disc Information GENERAL OPERATION On - screen 1. Press SETUP. The Setup menu appears. 2. Use v / V to select the desired option then press You can display various information about the disc B to move to the second level. The screen shows loaded on-screen. -
Page 11: Display
DISPLAY Progressive Scan Progressive Scan Video provides the highest quality pictures with less flickering. If you are using the COMPONENT VIDEO OUT jacks, but are connecting the receiver to a standard (analog) television, set Progressive Scan to Off. If you are using the Component Video jacks for connection to a TV or monitor that is compatible with a progressive scan signal, set Progressive Scan to To Turn ON progressive scan:... -
Page 12: Audio
AUDIO 5.1 Speaker Setup Make the following settings for the built-in 5.1 channel Each DVD disc has a variety of audio output options. surround decoder. Set the receiver’s AUDIO options according to the type of audio system you use. 1. Press ENTER and 5.1 Speaker Setup menu appears. -
Page 13: Lock (Parental Control)
LOCK (Parental Control) Area Code Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 21. 1. Select “Area Code” on the LOCK menu then press B. 2. Follow the step 2 as shown previous paragraph (Rating). -
Page 14: Operation
Operation General features Buttons Operations Discs Z (OPEN / CLOSE) Opens or closes the disc tray. X (PAUSE) During playback, press X to pause playback. Press X repeatedly to play Frame-by-Frame. DivX SKIP (. / >) During playback, press SKIP (. or >) to go to the next chapter/track or to return to the beginning of the current chapter/track. -
Page 15: Additional Features
Notes on general features: Last Scene Memory Zoom may not work on some DVDs. This receiver memorizes the last scene from the last The A-B repeat function is available only in the disc that is viewed. The last scene remains in the current title. -
Page 16: Playing An Audio Cd Or Mp3/Wma File
Playing an Audio CD or MP3/WMA file Programmed Playback This unit can play Audio CDs or MP3/WMA files. The program function enables you to store your favorite tracks from any disc in the receiver memory. A MP3/ WMA/ Audio CD program can contain 300 tracks. -
Page 17: Viewing A Jpeg File
Viewing a JPEG file Zoom Each time press ZOOM the setting change in the This unit can play discs with JPEG files. following order. Before playing JPEG recordings, read the notes on Zoom on y Zoom off JPEG Recordings on the right. Press v/ /M to enlarge the video image. -
Page 18: Playing A Divx Movie File
Playing a DivX Movie file DivX disc compatibility with this player is limited as follows: Using this DVD/CD Receiver you can play DivX disc. • Available resolution size of the DivX file is under 1. Insert a disc and close the tray. The MOVIE menu 800x600 (W x H) pixel. -
Page 19: Presetting The Radio Stations
Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM and AM (MW). Preset radio stations in the DVD/CD Receiver’s Before tuning, make sure that you have turned down memory first (see “Presetting radio stations” on the the volume. -
Page 20: Sleep Timer Setting
On (XTS) → NORMAL → Pro (XTS-P)... Initial sound mode is BYPASS. XTS-P The unique sound quality of the LG Technology creates the optimum sound for you to play the perfect playback of the original sound and to feel the living sound source. -
Page 21: Reference
Reference Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian... -
Page 22: Troubleshooting
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Correction Symptom Cause • Plug the power cord securely into the • The power cord is disconnected. No power. wall outlet. • Insert a disc. (Check that the DVD or, •... - Page 23 Symptom Cause Correction • The antenna is positioned or connected Radio stations cannot • Connect the antenna securely. poorly. be tuned in. • Adjust the antennas and connect an external antenna if necessary. • The signal strength of the stations is too •...
-
Page 24: Specifications
Specifications Power supply Refer to main label Power consumption Refer to main label Net Weight 2.4 kg External dimensions (W x H x D) 360 x 63 x 307 mm Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal Operating humidity 5% to 85% Laser Semiconductor laser, wavelength 650 nm...
