5.14 Palm Rest

Parts have carbon finish for use with Evo Notebook N1020v models
for use only with TouchPad notebook models
for use only with Dual Stick notebook models
Parts have carbon finish for use with Evo Notebook N1000v models
for use only with TouchPad notebook models
for use only with Dual Stick notebook models
Parts have silver finish for use with Presario 1500 models with config. codes
beginning with "L"
for use only with models with a diskette drive
for use only with models without a diskette drive
Parts have silver finish for use with Presario 1500 models with config. codes
beginning with "K"
for use only with models with a diskette drive
for use only with models without a diskette drive
✎
When replacing the palm rest, ensure that the following
components are removed from the old palm rest and installed on
the new palm rest:
■
Diskette drive (Section 5.15)
■
TouchPad components (Section 5.16)
■
Display release assembly (Section 5.17)
1. Prepare the computer for disassembly (Section 5.3).
2. Close the computer.
3. Turn the computer bottom side up with the front facing
forward.
Maintenance and Service Guide
Palm Rests
Spare Part Number Information
Removal and Replacement Procedures
311293-001
311294-001
291645-001
291646-001
310692-001
310693-001
285533-001
285534-001
5–35
