Page 1 HP 2533t Mobile Thin Client Maintenance and Service Guide...
Page 2 Corporation. SD Logo is a trademark of its proprietor. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
Page 3 Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.
Page 4 Safety warning notice...
Page 5: Table Of Contents
Table of contents 1 Product description 2 External component identification Top components ... 4 Display ... 4 TouchPad ... 5 Buttons ... 6 Keys ... 7 Lights ... 8 Front components ... 10 Right-side components ... 11 Left-side components ... 12 Rear components ...
Page 6 Unknown user password ... 28 Component replacement procedures ... 29 Serial number ... 29 Computer feet ... 30 Battery ... 30 Memory module ... 32 WLAN module ... 34 Flash drive ... 36 Optical drive ... 38 Switch cover and keyboard ... 40 USB board and optical drive bezel ...
Page 7 7 Screw listing Phillips PM2.5×6.0 captive screw ... 78 Phillips PM2.0×4.0 screw ... 79 Torx T8M2.0×5.0 screw ... 82 Torx T8M2.5×6.0 screw ... 84 Phillips PM2.5×11.0 captive screw ... 87 Phillips PM2.5×4.0 screw ... 88 Phillips PM2.0×6.0 screw ... 89 Phillips PM2.0×5.0 screw ...
Page 8 viii...
Page 9: Product Description
Primary storage device Optical drives Diskette drive Description HP 2533t Mobile Thin Client Via C7-M Ultra-Low Voltage (ULV) 1.00-GHz, 128-KB L2 cache, 400-MHz front side bus (FSB) Northbridge: Via CN896 Southbridge: Via VT8237S Via Chrome 9 Universal Memory Architecture (UMA) graphics subsystem integrated with 128-MB shared system memory 12.1-inch WXGA display assembly (1280 ×...
Page 10 VGA (Dsub 15-pin) supporting 1600 × 1200 external resolution at 75-GHz (hot plug/unplug with auto-detect) 3-pin AC power via the HP Smart Adapter HP 2400/2500 Series Docking Station (TV-out connector does not work) 4.21-inch × 10.71-inch keyboard with embedded numeric keypad Pointing stick with 2 pointing stick buttons...
Page 11 Category Description Security Supports Kensington security sock Optional removable active smart card reader, occupies the single PC Card slot Operating system Preinstalled: Windows® XP Embedded (XPe) in French, Japanese, Korean, Simplified Chinese, Spanish, Traditional Chinese, and U.S. English Serviceability End-user replaceable parts: AC adapter Battery (system) Flash drive...
Page 12: External Component Identification
External component identification Top components Display Item Component Wireless antennae (2) Internal microphone Chapter 2 External component identification Function Send and receive signals from one or more wireless devices. These antennae are not visible from the outside of the computer. NOTE: For optimal transmission, keep the areas immediately around the antennae free from...
Page 13: Touchpad
TouchPad Item Component Pointing stick* Left pointing stick button* TouchPad* Left TouchPad button* Right pointing stick button* TouchPad scroll zone Right TouchPad button* *This table describes factory settings. To view or change pointing device preferences, select Start > Control Panel > Printers and Other Hardware >...
Page 14: Buttons
Buttons Item Component Power button Info button Wireless button Presentation button TouchPad on/off button Volume mute button Volume scroll zone Chapter 2 External component identification Function ● When the computer is off, press the button to turn on the computer. ●...
Page 15: Keys
Keys Item Component Windows logo key Windows applications key Embedded numeric keypad keys Function keys Function Displays system information when pressed in combination with the key. Executes frequently used system functions when pressed in combination with a function key or the key.
Page 16: Lights
Lights Item Component Wireless lights* (2) Power lights† (2) Battery light Drive light TouchPad on/off light Caps lock light Num lock light Chapter 2 External component identification Function ● Blue: An integrated wireless device, such as a wireless local area network (WLAN) device, is on. ●...
Page 17 Item Component Volume mute light *The 2 wireless lights display the same information. The light on the wireless button is visible only when the computer is open. The wireless light on the front of the computer is visible whether the computer is open or closed. †The 2 power lights display the same information.
Page 18: Front Components
Front components Item Component Wireless light Power light Battery light Drive light Display release latch Chapter 2 External component identification Function ● Blue: An integrated wireless device, such as a wireless local area network (WLAN) device, is on. ● Amber: All wireless devices are off. ●...
Page 19: Right-Side Components
Right-side components Item Component PC Card slot* SD Card Reader* Audio-out (headphone) jack Audio-in (microphone) jack USB port† External monitor port Vent Docking connector *To view the status of the PC Card Slot and SD Card Reader, go to Computer Setup (f10). †To view the status of the USB ports, use the USB Storage Options utility.
Page 20: Left-Side Components
Left-side components NOTE: Refer to the illustration that most closely matches your computer. Item Component Power connector RJ-11 (modem) jack Powered USB port* Vent USB port* *To view the status of the USB ports, use the USB Storage Options utility. Refer to the “Securing USB ports” section in the Administrator's Guide for additional information.
Page 21: Rear Components
Rear components Item Component RJ-45 (network) jack Security cable slot Function Connects a network cable. Attaches an optional security cable to the computer. NOTE: The security cable is designed to act as a deterrent, but it may not prevent the computer from being mishandled or stolen.
Page 22: Bottom Components
Bottom components Item Component Speaker Memory module compartment Vents (5) Battery release latches (2) Battery bay Flash drive bay Chapter 2 External component identification Function Produces sound. Contains a memory module slot and a WLAN module slot. CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module authorized for use in the computer by the governmental agency that regulates wireless devices in your country...
Page 23: Illustrated Parts Catalog
Illustrated parts catalog Serial number location When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer. Serial number location...
Page 24: Computer Major Components
Computer major components Item Description 12.1-inch, WXGA AntiGlare display assembly (includes display panel cable, 2 WLAN antenna transceivers and cables, and microphones) Display assembly subcomponents (not illustrated): Chapter 3 Illustrated parts catalog Spare part number 481103-001...
Page 25 Display bezel (includes HP logo and computer model number label) Display bezel adhesive Display panel cable Display enclosure (includes HP logo, wireless antenna transceivers and cables, and microphone receiver and cable) Display Hinge Kit (includes left and right hinges and brackets)
Page 26 Item Description 6-cell, 55.0-WH Li-ion 3-cell, 31.0-WH Li-ion (12) LED board (includes cable and Mylar cover) (13) Speaker (14) DVD-ROM Drive (includes bezel and bracket) (15) USB board (includes optical drive bezel and USB board cable) (16) Base enclosure (includes display latch switch, battery release latch, and rubber feet) Rubber Kit (not illustrated, contains 4 computer feet, 4 display bezel screw covers, and business card holder) (17)
Page 27: Plastics Kit
Plastics Kit Item Description Plastics Kit: PC Card slot bezel Flash drive compartment cover (includes 2 captive screws, secured by C-clips) Bluetooth module compartment cover (includes one captive screw, secured by a C-clip) Memory module compartment cover (includes one captive screw, secured by a C-clip) Rear cover (includes 2 captive screws, secured by C-clips) Spare part number 481105-001...
Page 28: Cable Kit
Cable Kit Item Description Cable Kit: Wireless antenna transceivers and cables Microphone receiver and cable LED board cable Modem module cable Miscellaneous parts Description 65-W, 3-prong, PFC AC adapter Power cord Screw Kit ● Phillips PM2.5×11.0 captive screw ● Phillips PM2.5×6.0 captive screw ●...
Page 29: Sequential Part Number Listing
Sequential part number listing Spare part Description number 441075-001 Broadcom 802.11a/b/g WLAN module for use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the United States 441075-002 Broadcom 802.11a/b/g WLAN module for use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde,...
Page 30 Spare part Description number 481095-001 1-GB solid-state, PATA flash drive (includes flash drive bracket) 481097-001 Display bezel (includes HP logo and model number label) 481098-001 Display hinges (includes left and right hinges and brackets) 481099-001 Display panel cable 481100-001 Display enclosure (includes wireless antenna transceivers and cables and microphone receiver and cable)
Page 31: Removal And Replacement Procedures
Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: ● Flat-bladed screwdriver ● Magnetic screwdriver ● Phillips P0 and P1 screwdrivers ● Torx T8 screwdriver Service considerations The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.
Page 32: Cables And Connectors
Cables and connectors CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the reassembly process. Improper cable placement can damage the computer. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion.
Page 33: Grounding Guidelines
Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions. A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry.
Page 34: Packaging And Transporting Guidelines
Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: ● To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
Page 35: Equipment Guidelines
Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. ● When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.
Page 36: Unknown User Password
Unknown user password If the computer you are servicing has an unknown user password, follow these steps to clear the password: NOTE: These steps also clear CMOS. Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 37: Component Replacement Procedures
Make special note of each screw size and location during removal and replacement. Serial number Report the computer serial number to HP when requesting information or ordering spare parts. The serial number is located on the bottom of the computer. Component replacement procedures...
Page 38: Computer Feet
Computer feet The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part number 481106-001. There are 4 rubber feet that attach to the base enclosure in the locations illustrated below. Battery Description 9-cell, 83.0-WH, Li-ion battery 6-cell, 55.0-WH, Li-ion battery 3-cell, 31.0-WH, Li-ion battery Before disassembling the computer, follow these steps:...
Page 39 Remove the battery (2) from the computer. Install the battery by inserting it into the battery bay until you hear a click. Component replacement procedures...
Page 40: Memory Module
Memory module Description 1024-MB (PC2-5300, 667-MHz, DDR2) Before removing the memory module, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 41 Remove the memory module (2) by pulling the module away from the slot at an angle. NOTE: The memory module is designed with a notch (3) to prevent incorrect installation into the memory module slot. Reverse this procedure to install the memory module. Component replacement procedures...
Page 42: Wlan Module
WLAN module Description Broadcom 802.11a/b/g WLAN modules: ● For use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the United States ● For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile,...
Page 43 Lift the front edge of the memory module compartment cover (2), swing it back, and remove the cover (3). The memory module compartment cover is included in the Plastics Kit, spare part number 481105-001. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module. NOTE: The black WLAN antenna cable is connected to the WLAN module “Main”...
Page 44: Flash Drive
Flash drive NOTE: All flash drive spare part kits include a flash drive bracket). Description 2-GB solid-state, PATA flash drive 1-GB solid-state, PATA flash drive Before removing the flash drive, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 45 Lift the flash drive straight up to disconnect it from the system board (1). NOTE: When installing the flash drive, be sure that the alignment pin on the system board is aligned with the hole (2) on the flash drive. Reverse this procedure to install the flash drive.
Page 46: Optical Drive
Optical drive Description DVD-ROM Drive (includes bezel and bracket) Before removing the optical drive, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 47 Remove the optical drive bracket (2). Reverse this procedure to reassemble and install an optical drive. Component replacement procedures...
Page 48: Switch Cover And Keyboard
Switch cover and keyboard Description Switch cover (includes display lid switch board and cable) Keyboards For use in the following countries or regions Brazil French Canada Japan Latin America Before removing the switch cover and keyboard, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer.
Page 49 Lift the front edge of the rear cover (2), swing it back, and remove it (3). The rear cover is included in the Plastics Kit, spare part number 481105-001. Position the computer with the front toward you. Loosen the five Phillips PM2.5×11.0 captive screws that secure the keyboard to the computer. Turn the computer display-side up, with the front toward you.
Page 50 Lift the switch cover (2) as far as the two switch cover cables allow. Lift the rear edge of the keyboard and swing it up and forward until it rests upside down on the palm rest. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and disconnect the keyboard cable (2) from the system board.
Page 51 Disconnect the display lid switch cable (1) and the LED board cable (2) from the system board. Remove the switch cover (3). Reverse this procedure to install the switch cover and keyboard. Component replacement procedures...
Page 52: Usb Board And Optical Drive Bezel
USB board and optical drive bezel Description USB board (includes optical drive bezel and cable) Before removing the USB board and optical drive bezel, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 53 Release the optical drive bezel (2) by sliding it out of the base enclosure. Remove the optical drive bezel from the optical drive bay. Remove the two Phillips PM2.0×4.0 screws (1) that secure the USB board to the optical drive bezel. Remove the USB board (2) from the optical drive bezel.
Page 54: Rtc Battery
Reverse this procedure to install the USB board and optical drive bezel. RTC battery NOTE: Removing the RTC battery and leaving it uninstalled for 5 or more minutes causes all passwords and CMOS settings to be cleared. Description RTC battery Before removing the RTC battery, follow these steps: Shut down the computer.
Page 55: Display Assembly
Display assembly Description 12.1-inch, WXGA AntiGlare display assembly (includes 2 WLAN antenna transceivers and cables and microphones) Before removing the display assembly, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 56 Remove the wedge-shaped screw covers (1) and the four Torx T8M2.0×5.0 screws (2) that secure the display assembly to the computer. NOTE: The rubber screw covers are available in the Rubber Kit, spare part number 481106-001. Turn the computer right-side up, with the front toward you. Open the computer.
Page 57 Disconnect the microphone cable (5) from the system board. CAUTION: The display assembly will be unsupported when the following screws are removed. To prevent damage to the display assembly, support it before removing the screws. Remove the T8M2.5×6.0 screw (1) that secures the display assembly to the computer. Lift the display assembly (2) straight up and remove it.
Page 58 If it is necessary to replace the display bezel, display hinges, display panel cable, or display enclosure, remove the four rubber screw covers (1) and (2) and the four Torx T8M2.5×6.0 screws (3) that secure the display bezel to the display assembly. NOTE: The rubber screw covers (1) on the display bezel top edge are thicker than the rubber screw covers (2) on the display bezel bottom edge.
Page 59 Remove the display panel (2). Remove the two Phillips PM2.0×4.0 screws (1) that secure each display hinge to the display panel. Remove the display hinges (2). The left and right display hinges are available using spare part number 481098-001. If it is necessary to replace the display panel cable, turn the display panel upside down, with the display panel bottom edge toward you.
Page 60: Top Cover
Remove the display panel cable (4). The display panel cable is available using spare part number 481099-001. Reverse this procedure to reassemble and install the display assembly. Top cover Description Top cover Before removing the top cover, follow these steps: Shut down the computer.
Page 61 Lift the front edge of the Bluetooth module compartment cover (2), swing it up and forward, and remove the cover. Remove the following screw covers and screws: (1) Four rubber screw covers. The rubber screw covers are included in the Rubber Kit, spare part number 481106-001.
Page 62 Remove the two Torx T8M2.5×6.0 screws (2) and the Phillips PM2.0×6.0 screw (3) that secure the top cover to the computer. Lift the rear edge of the top cover (1) and swing it up and forward until it rests at an angle. Lift the front edge of the top cover (2) until it disengages from the base enclosure.
Page 63: Led Board
LED board Description LED board (includes cable and Mylar cover) Before removing the LED board, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 64: Speaker
Reverse the above procedure to install the LED board. Speaker Description Speaker Before removing the speaker, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 65: System Board
System board Description System board (includes processor, replacement thermal material, and replacement thermal material cleaning kit) Before removing the system board, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 66 Remove the three Torx8 T8M2.5×6.0 screws (3) that secure the system board to the base enclosure. Flex the left side of the base enclosure (1) until the RJ-11 jack and USB ports are clear of the openings in the base enclosure. Use the optical drive connector (2) to lift the left side of the system board (3) until it rests at an angle.
Page 67: Pc Card Assembly
PC Card assembly Description PC Card assembly Before removing the PC Card assembly, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 68 Detach the slot (1) on the PC Card assembly from the tab on the PC Card assembly connector on the system board. Remove the PC Card assembly (2). Reverse this procedure to install the PC Card assembly. Chapter 4 Removal and replacement procedures...
Page 69: Modem Module
Modem module NOTE: The modem module spare part kits do not include a modem module cable. The modem module cable is included in the Cable Kit, spare part number 481092-001. See Cable Kit spare part number information. Description For use in all countries and regions except Australia and New Zealand For use only in Australia and New Zealand Before removing the modem module, follow these steps: Shut down the computer.
Page 70 Disconnect the modem module cable (3) from the modem module. Remove the modem module. Reverse this procedure to install the modem module. Chapter 4 Removal and replacement procedures...
Page 71: Heat Sink
Heat sink Description Heat sink (includes replacement thermal material and replacement thermal material cleaning kit) 481110-001 Before removing the heat sink, follow these steps: Shut down the computer. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
Page 72 Remove the heat sink (2). NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink and system board each time the heat sink is removed. Thermal paste is located on the processor (1) and the section of the heat sink that services it (2). Thermal pads are located on the Northbridge chip (3) and the section of the heat sink that services it (4).
Page 73: Computer Setup
Computer Setup Starting Computer Setup Computer Setup is a preinstalled ROM-based utility that can be used even when the operating system is not working or will not load. NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your computer.
Page 74: Using Computer Setup
Using Computer Setup Navigating and selecting in Computer Setup The information and settings in Computer Setup are accessed from the File, Security, Diagnostics, and System Configuration menus. Open Computer Setup by turning on or restarting the computer, and then pressing "F10 = ROM Based Setup"...
Page 75: Computer Setup Menus
Computer Setup menus The menu tables in this section provide an overview of Computer Setup options. NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your computer. File menu Select System information Restore defaults Ignore changes and exit Save changes and exit...
Page 76: System Configuration Menu
System Configuration menu NOTE: Some of the listed System Configuration options may not be supported by your computer. Select Language (or press f2) Boot options Device configurations Built-In Device Options Port Options Chapter 5 Computer Setup To do this Change the Computer Setup language. ●...
Page 77: Specifications
Specifications Computer specifications Dimensions Depth Width Height (front to rear) Weight Equipped with DVD-ROM Drive, 9-cell battery, and WLAN module Equipped with DVD-ROM Drive, 6-cell battery, and WLAN module Equipped with DVD-ROM Drive, 3-cell battery, and WLAN module Equipped with 3-cell battery and WLAN module Input power Operating voltage Operating current...
Page 78: 12.1-Inch, Wxga Display Specifications
Nonoperating Random vibration Operating Nonoperating NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this range of temperatures. 12.1-inch, WXGA display specifications Dimensions Height Width Diagonal Number of colors Contrast ratio Brightness Pixel resolution Pitch Format Configuration...
Page 79: 8X Max Dvd-Rom Drive Specifications
8X Max DVD-ROM Drive specifications Applicable disc Access time Random Cache buffer Data transfer rate CD-R (24X) CD-RW (10X) CD-ROM (24X) DVD (8X) Multiword DMA mode 2 DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), CD-ROM (Mode 1 and 2), CD Digital Audio, CD-XA ready (Mode 2, Form 1 and Form 2), CD-I (Mode 2, Form 1 and Form 2), CD-RW, Photo CD (single and multisession), and CD-Bridge <...
Page 80: System Dma Specifications
System DMA specifications Hardware DMA DMA0 DMA1* DMA2* DMA3 DMA4 DMA5* DMA6 DMA7 *ExpressCard controller can use DMA 1, 2, or 5. Chapter 6 Specifications System function Not applicable Not applicable Not applicable Not applicable Direct memory access controller Available for ExpressCard Not assigned Not assigned...
Page 81: System Interrupt Specifications
System interrupt specifications Hardware IRQ IRQ0 IRQ1 IRQ2 IRQ3 IRQ4 IRQ5* IRQ6 IRQ7* IRQ8 IRQ9* IRQ10* IRQ11 IRQ12 IRQ13 IRQ14 IRQ15 *Default configuration; audio possible configurations are IRQ5, IRQ7, IRQ9, IRQ10, or none. NOTE: ExpressCards may assert IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10, IRQ11, or IRQ15. Either the infrared or the serial port may assert IRQ3 or IRQ4.
Page 82: System I/O Address Specifications
System I/O address specifications I/O address (hex) 000 - 00F 010 - 01F 020 - 021 022 - 024 025 - 03F 02E - 02F 040 - 05F 044 - 05F 062 - 063 065 - 06F 070 - 071 072 - 07F 080 - 08F 090 - 091...
Page 83 I/O address (hex) 220 - 22F 230 - 26D 26E - 26 278 - 27F 280 - 2AB 2A0 - 2A7 2A8 - 2E7 2E8 - 2EF 2F0 - 2F7 2F8 - 2FF 300 - 31F 320 - 36F 370 - 377 378 - 37F 380 - 387 388 - 38B...
Page 84: System Memory Map Specifications
System memory map specifications Size 640 KB 128 KB 48 KB 160 KB 64 KB 15 MB 58 MB 58 MB 2 MB 4 GB 64 KB Chapter 6 Specifications Memory address 00000000-0009FFFF 000A0000-000BFFFF 000C0000-000CBFFF 000C8000-000E7FFF 000E8000-000FFFFF 00100000-00FFFFFF 04800000-07FFFFFF 04800000-07FFFFFF 08000000-080FFFFF 08200000-FFFEFFFF FFFF0000-FFFFFFFF...
Page 85: Screw Listing
Screw listing This section provides specification and reference information for the screws and screw locks used in the computer. All screws listed in this section are available in the Screw Kit, spare part number 456615-001.
Page 86: Phillips Pm2.5×6.0 Captive Screw
Phillips PM2.5×6.0 captive screw Color Black Where used: (1) One captive screw that secures the Bluetooth module cover to the computer (screw is captured on the cover by a C-clip) (2) One captive screw that secures the memory module compartment cover to the computer (screw is captured on the cover by a C-clip) (3) One captive screw that secures the flash drive compartment cover to the computer (screw is captured on the cover by a C-clip)
Page 87: Phillips Pm2.0×4.0 Screw
Phillips PM2.0×4.0 screw Color Silver Where used: 2 screws that secure the WLAN module to the base enclosure Where used: 2 screws that secure the optical drive bracket to the optical drive Quantity Length 4.0 mm Thread Head diameter 2.0 mm 4.5 mm Phillips PM2.0×4.0 screw...
Page 88 Where used: 2 screws that secure the optical drive bezel to the computer Where used: 2 screws that secure the USB board to the optical drive bezel Where used: 4 screws that secure the display hinges to the display panel Chapter 7 Screw listing...
Page 89 Where used: One screw that secures the speaker to the base enclosure Where used: 2 screws that secure the modem module to the system board Phillips PM2.0×4.0 screw...
Page 90: Torx T8M2.0×5.0 Screw
Torx T8M2.0×5.0 screw Color Black Where used: 2 screws that secure the optical drive to the computer Where used: 4 screws that secure the display assembly to the computer Chapter 7 Screw listing Quantity Length 5.0 mm Thread Head diameter 2.0 mm 4.5 mm...
Page 91 Where used: One screw that secures the top cover to the base enclosure Torx T8M2.0×5.0 screw...
Page 92: Torx T8M2.5×6.0 Screw
Torx T8M2.5×6.0 screw Color Black Where used: One screw that secures the switch cover to the computer Where used: 2 screws that secure the display assembly to the computer Chapter 7 Screw listing Quantity Length 6.0 mm Thread Head diameter 2.5 mm 5.0 mm...
Page 93 Where used: 4 screws that secure the display bezel to the display enclosure Where used: 6 screws that secure the top cover to the base enclosure Where used: 2 screws that secure the top cover to the base enclosure Torx T8M2.5×6.0 screw...
Page 94 Where used: 3 screws that secure the system board to the base enclosure Chapter 7 Screw listing...
Page 95: Phillips Pm2.5×11.0 Captive Screw
Phillips PM2.5×11.0 captive screw Color Black Where used: 5 captive screws that secure the keyboard to the computer (screws are secured by C- clips) Quantity Length 11.0 mm Thread Head diameter 2.5 mm 5.0 mm Phillips PM2.5×11.0 captive screw...
Page 96: Phillips Pm2.5×4.0 Screw
Phillips PM2.5×4.0 screw Color Black Where used: 2 screws that secure the display panel to the display enclosure Chapter 7 Screw listing Quantity Length 4.0 mm Thread Head diameter 2.5 mm 5.0 mm...
Page 97: Phillips Pm2.0×6.0 Screw
Phillips PM2.0×6.0 screw Color Black Where used: One screw that secures the top cover to the base enclosure Where used: One screw that secures the top cover to the base enclosure Quantity Length 6.0 mm Thread Head diameter 2.0 mm 4.5 mm Phillips PM2.0×6.0 screw...
Page 98: Phillips Pm2.0×5.0 Screw
Phillips PM2.0×5.0 screw Color Silver Where used: 2 screws that secure the PC Card assembly to the system board Chapter 7 Screw listing Quantity Length 5.0 mm Thread Head diameter 2.0 mm 4.5 mm...
Page 99: Torx T8M2.0×10.0 Captive Screw
Torx T8M2.0×10.0 captive screw Color Black Where used: 4 captive screws that secure the heat sink to the system board (screws are secured by C- clips) Quantity Length 10.0 mm Thread Heat width 2.0 mm 4.5 mm Torx T8M2.0×10.0 captive screw...
Page 100: Connector Pin Assignments
Connector pin assignments Audio-out (headphone) Audio-in (microphone) Chapter 8 Connector pin assignments Signal Audio out, left channel Audio out, right channel Ground Signal Audio signal in Audio signal in Ground...
Page 101: External Monitor
External monitor Signal Red analog Green analog Blue analog Not connected Ground Ground analog Ground analog Ground analog +5 VDC Ground Monitor detect DDC 2B data Horizontal sync Vertical sync DDC 2B clock External monitor...
Page 102: Modem)
RJ-11 (modem) Chapter 8 Connector pin assignments Signal Unused Ring Unused Unused Unused...
Page 103: Network)
RJ-45 (network) Universal Serial Bus Signal Transmit + Transmit - Receive + Unused Unused Receive - Unused Unused Signal +5 VDC Data - Data + Ground RJ-45 (network)
Page 104: Power Cord Set Requirements
Power cord set requirements The wide range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.
Page 105: Requirements For Specific Countries And Regions
Requirements for specific countries and regions Country/region Australia Austria Belgium Canada Denmark Finland France Germany Italy Japan Korea The Netherlands Norway The People's Republic of China Sweden Switzerland Taiwan The United Kingdom The United States The flexible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set fittings (appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used.
Page 106: 10 Recycling
NOTE: Materials Disposal. This HP product contains mercury in the backlight in the display assembly that might require special handling at end-of-life. Disposal of mercury may be regulated because of environmental considerations. For disposal or recycling information, contact your local authorities, or see the Electronic Industries Alliance (EIA) Web site at http://www.eiae.org.
Page 107 Perform the following steps to disassemble the display assembly: Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the display bezel until the bezel disengages from the display assembly.
Page 108 Disconnect all display panel cables (1) from the display inverter and remove the inverter (2). Remove all screws (1) that secure the display panel assembly to the display enclosure. Remove the display panel assembly (2) from the display enclosure. Turn the display panel assembly upside down. Remove all screws that secure the display panel frame to the display panel.
Page 109 Remove the display panel frame (2) from the display panel. Remove the screws (1) that secure the backlight cover to the display panel. Lift the top edge of the backlight cover (2) and swing it outward. Remove the backlight cover. Turn the display panel right-side up.
Page 110 Remove the backlight cables (1) from the clip (2) in the display panel. Turn the display panel upside down. WARNING! The backlight contains mercury. Exercise caution when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury. Remove the backlight frame from the display panel.
Page 111 Remove the backlight from the backlight frame. Disconnect the display panel cable (1) from the LCD panel. Remove the screws (2) that secure the LCD panel to the display rear panel. Release the LCD panel (3) from the display rear panel. Release the tape (4) that secures the LCD panel to the display rear panel.
Page 112: Index
Index AC adapter, spare part number 20, 21 antenna, disconnecting 35 audio, product description 2 audio-in jack location 11 pin assignments 92 audio-out jack location 11 pin assignments 92 base enclosure, spare part number 18, 21 battery removal 30 spare part numbers 17, 21, battery light 8, 10 Bluetooth module compartment cover...
Page 113 DVD-ROM Drive precautions 24 removal 38 spare part number 18, 21, specifications 71 electrostatic discharge 25 esc key 7 Ethernet, product description 2 external media cards, product description 2 external monitor port location 11 pin assignments 93 feet locations 30 spare part number 30 File menu 67 flash drive...
Page 114 packing guidelines 26 panels, product description 1 password clearing 28 passwords 67 PC Card assembly removal 59 spare part number 17, 22, PC Card slot 11 PC Card slot bezel, illustrated 19 pin assignments audio-in jack 92 audio-out jack 92 external monitor port 93 headphone jack 92 microphone jack 92...
Page 115 system DMA 72 system information 67 system memory map 76 thermal material, replacement 64 tools required 23 top components 4 top cover removal 52 spare part number 17, 22, TouchPad 5 TouchPad buttons 5 TouchPad components 5 TouchPad on/off button 6 TouchPad on/off light 8 TouchPad scroll zone 5 transporting guidelines 26...
