D-Link DCS-930L Quick Install Manual

Quick Install Guide
Wireless N Network Camera
Thank you for purchasing the DCS-930L Wireless N Network Camera. Follow the easy steps in
this guide to properly set up your camera. Please verify that all the package contents below
are available.
Package Contents
DCS-930L Wireless N Network Camera
Camera Stand and Mounting Kit
CAT-5 Ethernet Cable
Power Adapter
CD with drivers and software
If any of the above items are missing, please contact your reseller.
System Requirements
• Computer with Microsoft Windows® 7, Vista®, or XP
• PC with 1.3GHz or above; at least 128MB RAM
• Internet Explorer 6 or above , Firefox 3.5 or above, Safari 4 or above, Chrome 2 or above
• Existing 10/100 Ethernet-based network or 802.11n wireless network
DCS-930L
Installation
Step 1:
Connect the included Ethernet cable to the network cable connector located on the
bottom panel of the DCS-930L and attach it to the network.
Step 2:
Attach the external power supply to the DC power input connector located on the
bottom panel of the DCS-930L and connect it to your wall outlet or power strip. Power is
confirmed when the green LED Power Indicator located below the lens is lit.
Step 3:
Insert the DCS-930L Driver CD in the CD-ROM drive. If the CD Autorun function does
not automatically start on your computer, go to Start > Run. In the run box type
D:\autorun.exe (where D: represents the drive letter of your CD-ROM drive) and click
OK. When the autorun screen appears, click Install and follow the on-screen instructions.
Step 4:
Click on the Start button to start the wizard, and follow the instructions from the Installation
Wizard to finish setting up your camera.
WPS Setup
Alternatively, you may create a WPS connection if your router or access point supports
WPS. To create a WPS connection:
Step 1:
Press and hold the WPS button on the side of the camera for three seconds. The blue WPS
status LED above the button will blink.
Step 2:
Press the WPS button on your wireless router or access point within 60 seconds. On some
routers, you may need to log into the web interface and then click an onscreen button to
activate the WPS feature. If you are not sure where the WPS button is on your router or
access point, please refer to your router's user manual.
The DCS-930L will automatically create a wireless connection to your router. While
connecting, the green LED will flash and your camera will reboot.
mydlink Portal
After registering your DCS-930L camera with a mydlink account in the Camera Installation
Wizard, you will be able to remotely access your camera from the www.mydlink.com
website. After signing in to your mydlink account, you will see a screen similar to the
following:
Step 1:
Open Internet Explorer and go to http://www.mydlink.com, then sign into mydlink.
Step 2:
Select your camera from the device list, and your camera's Live View will appear.
Technical Support
Having trouble installing your new product? D-Link's website contains the latest
user documentation and software upd ates for D-Link products. U.S. and Canadian
customers can contact D-Link Technical Support through our website or by phone.
United States Canada
Telephone: (877) 453-5465 Telephone:
Internet: http://support.dlink.com Internet: http://support.dlink.ca
Copyright ©2010 All rights reserved. D-Link and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries.
Other trademarks are the property of their respective owners. Maximum wireless signal rate derived from IEEE Standard 802.11g and
802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network
traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will
adversely affect wireless signal range. Product specifications, size and shape are subject to change without notice, and actual product
appearance may differ from that depicted on the packaging. Visit dlink.com (US) or dlink.ca (Canada) for more details.
Version 1.0 | July 20, 2010 6DCS930LQ.01G
(800) 361-5265
