LG 60PK550C Service Manual
Hide thumbs
Also See for 60PK550C:
- Specifications (4 pages) ,
- Manual (361 pages) ,
- Owner's manual (360 pages)
Advertisement
Quick Links
PLASMA TV
SERVICE MANUAL
CHASSIS : PP01A/B/C
MODEL : 60PK550C
MODEL :
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL62881419(1107-REV00)
North/Latin America
Europe/Africa
Asia/Oceania
60PK550C-TA
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com
Advertisement
Related Manuals for LG 60PK550C
Summary of Contents for LG 60PK550C
- Page 1 Internal Use Only North/Latin America http://aic.lgservice.com Europe/Africa http://eic.lgservice.com Asia/Oceania http://biz.lgservice.com PLASMA TV SERVICE MANUAL CHASSIS : PP01A/B/C MODEL : 60PK550C 60PK550C-TA MODEL : CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL62881419(1107-REV00)
-
Page 2: Table Of Contents
CONTENTS ..........................2 SAFETY PRECAUTIONS ......................3 SPECIFICATION.........................4 ADJUSTMENT INSTRUCTION ....................7 BLOCK DIAGRAM ........................9 EXPLODED VIEW ........................10 SVC. SHEET ..........................- 2 - Copyright ©2010 LG Electronics Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes... -
Page 3: Safety Precautions
An other abnormality exists that must be corrected before the receiver is returned to the customer. Copyright ©2010 LG Electronics Inc. All rights reserved. - 3 - LGE Internal Use Only Only for training and service purposes... -
Page 4: Specification
4) Humidity : 10 % ~ 90 % Input Voltage AC 100 V - 240 V ~, 50 / 60 Hz Maker:SANKEN Copyright ©2010 LG Electronics Inc. All rights reserved. - 4 - LGE Internal Use Only Only for training and service purposes... - Page 5 SD Divx, MP3, JPEG SVC Only 42/50PJ350R-ZA : only apply for MP3, JPEG ( SD Divx Spec out ) Copyright ©2010 LG Electronics Inc. All rights reserved. - 5 - LGE Internal Use Only Only for training and service purposes...
- Page 6 Red/Green/Blue : 255 level pattern White coordinate 0.278 0.293 0.308 0.635 0.640 0.318 0.330 0.340 0.242 0.300 0.305 Green 0.595 0.600 Copyright ©2010 LG Electronics Inc. All rights reserved. - 6 - LGE Internal Use Only Only for training and service purposes...
-
Page 7: Adjustment Instruction
60PK55*R- (Especially digital pattern, cross hatch pattern), an after image may be made in the black level part of the screen. Copyright ©2010 LG Electronics Inc. All rights reserved. - 7 - LGE Internal Use Only Only for training and service purposes... - Page 8 (5) EDID Data FHD EDID DATA ( 50/60 inch – PK Tool ) <Analog(RGB): 128bytes> < HDMI 1 : 256bytes> Copyright ©2010 LG Electronics Inc. All rights reserved. - 8 - LGE Internal Use Only Only for training and service purposes...
-
Page 9: Block Diagram
MAX3232 TUNER REAR SIDE Interface Non_EU : AV IN(1) AV IN(1) HDMI1.3(2) TAFT-Z001D Variable OUT(1) COMPONENT(2) HDMI1.3(1) RGB(+Audio)(1) RS232C(1) USB(1) Copyright ©2010 LG Electronics Inc. All rights reserved. -9 - LGE Internal Use Only Only for training and service purposes... -
Page 10: Exploded View
X-RADIATION, Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. - 10 - LGE Internal Use Only Copyright ©2010 LG Electronics Inc. All rights reserved. Only for training and service purposes... - Page 11 EAX61365503(BPR) R142 H6 Revolution Circuit Diagram NONE_RGB ROM_SDA R143 NONE_RGB ROM_SCL R144 JK114 +5V_ST NONE_RGB DSUB_SDA R150 PSC008-02 NONE_RGB DSUB_SCL R543 [ Slim Jack : 6630TGA004Q ] [ Slim Jack : 6630G00001E ] READY [ Slim Jack : EAG59023302 ] EYE_SCL R544 +3.3V_MPLL...
- Page 12 EAX61365503(BPR) LVDS Block H6 Revolution Circuit Diagram KEY/IR Interface Power Block P202 SMAW200-H26S1 P203 ROM_TX ROM_RX 12507WS-12L P200 SMAW200-H18S1 +5V_ST P_SCL P_SDA +5V_MULTI TXCE0- TXCE0+ HOTEL +17V_TI +3.3V_MPLL TXCE1- TXCE1+ R224 HOTEL 4.7K R226 Q202 TXCE2- TXCE2+ HOTEL 2SC3052 4.7K R232 R231 TXCLKE-...
- Page 13 EAX61365503(BPR) H6 Revolution Circuit Diagram Audio Amp Tuner(7mm) AVSS This parts are Located TU300 on AVSS area. +3.3V_MST R302 TAFJ-Z001D(P) +5V_TU C332 L310 +3.3V_AVDD AVSS 0.033uF 120-ohm C316 4700pF +17V_TI AVSS NC_1 C333 C341 C307 C326 C313 R313 0.1uF 0.1uF 100uF 100uF L309...
- Page 14 EAX61365503(BPR) +3.3V_MST +3.3V_MST H6 Revolution Circuit Diagram DDR2_A[0-12] 20pF C454 SUB MICOM V_REF 12MHz R444 X400 +1.2V_MST +3.3V_MPLL Main Flash Memory 20pF C455 I2S_OUT Close to IC as close as possible C460 C462 C464 C466 C468 C470 C472 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF...
