Page 1
Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici. You may need / Usted puede necesitar / Articles dont vous pouvez avoir besoin: For easy installation of your Delta faucet you will need: ・To READ ALL the instructions completely before beginning.
Page 2
SHUT OFF WATER SUPPLIES. Remove old faucet. Place gasket (1) on bottom of new faucet. Place faucet through mounting holes in sink. Option: If sink is uneven, use silicone under the gasket (1). Secure faucet to sink using locknuts (2) provided. CIERRE LOS SUMINISTROS DE AGUA.
Page 3
CONNECT TO WATER SUPPLIES. Install Pop-Up Assembly (HOOK-UPS NOT PROVIDED). Apply silicone to underside of flange (1). Remove stopper (1) and flange (2). Insert body (2) into sink. Screw flange onto Screw nut (3) all the way down. Turn on hot and cold water supplies and flush water lines into body.
Page 4
*Install stems (1) correctly for Maintenance FLUSH SYSTEM/CHECK FOR LEAKS. proper handle rotation: SHUT OFF WATER SUPPLIES NOTE: Remove handles by hand turning Note: Turn faucet handles (1) to the full on mixed position. Turn on hot handle base counterclockwise. 1.
Page 5
▲ Specify Finish Especifíque el Acabado Précisez le Fini RP74426▲ Handle Assembly Conjunto de manija Montage de la manette RP74427▲ Lift Rod Barra de Alzar Tige de Manoeuvre RP74418 Stem Unit Assembly, Seat & Spring, Bonnet Nut & Washer Ensamble de la Unidad del Vástago, Asiento y Resorte, Bonete y Arandela Obturateur, siège et ressort, écrou à...
Dans le cas d’une utilisation commerciale, la garantie est d’un an à compter de la date d’achat. pour toutes les demandes en vertu de la garantie, sauf si le produit a été enregistré auprès de Delta Aucune garantie ne couvre les piles.
