REAR VIEW
Definition
Item
18
Antenna socket: Connects antenna cable to transceiver.
19
PA SP. jack: Connects external 8-ohm, 4-watt speaker.
To prevent acoustic feedback, separate the microphone from the
speaker when operating the PA at high output levels.
20
EXT. SP. jack: Connects optional 8-ohm 4-watt speaker to remotely
monitor the receiver.
When the external speaker is plugged in, the internal speaker is off.
21
POWER connector: Connects DC power to transceiver.
