30" (76.2 CM) FREESTANDING GAS RANGES
CUISINIÈRE À GAZ AUTOPORTANTE DE 30" (76,2 CM)
INSTRUCCIONES DE INSTALACIÓN COCINAS
ELÉCTRICAS INDEPENDIENTES DE 30" (76,2 CM)
Table of Contents/Table des matières/ Tabla de contenidos
RANGE SAFETY ...................................... 2
INSTALLATION REQUIREMENTS .......... 4
Tools and Parts ...................................... 4
Location Requirements ......................... 4
Electrical Requirements ....................... 6
Gas Supply Requirements ................... 6
INSTALLATION INSTRUCTIONS ............ 8
Unpack Range....................................... 8
Install Anti-Tip Bracket .......................... 8
Make Gas Connection .......................... 9
and Engaged ....................................... 10
Level Range ......................................... 11
Electronic Ignition System .................. 11
Storage Drawer ................................... 13
Storage Drawer ................................... 13
Oven Door ........................................... 14
Complete Installation .......................... 14
GAS CONVERSIONS ............................. 15
Propane Gas Conversion .................... 15
Natural Gas Conversion ...................... 18
IMPORTANT:
Save for local electrical inspector's use.
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
IMPORTANT:
Conserver ces instructions à l'usage de l'inspecteur des installations électriques local
Installateur: Remettre les instructions d'installation au propriétaire.
Propriétaire: Conserver les instructions d'installation pour référence ultérieure.
IMPORTANTE:
Guarde para tener a disposición del inspector de electricidad local.
Instalador: Déjele las instrucciones de instalación al propietario.
Propietario: Guarde las instrucciones de instalación para futuras consultas.
W11333091B
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION
SÉCURITÉ DE LA CUISINIÈRE ............ 21
EXIGENCES D'INSTALLATION ............ 22
Outils et pièces .................................... 22
Exigences d'emplacement .................. 23
Spécifications électriques ................... 24
Spécifications de l'alimentation
en gaz .................................................. 25
INSTRUCTIONS D'INSTALLATION ...... 26
Déballage de la cuisinière ................... 26
Installation de la bride
antibasculement .................................. 27
Raccordement à la canalisation
de gaz .................................................. 28
Vérifier que la bride antibasculement
est bien installée et engagée .............. 29
Réglage de l'aplomb de la cuisinière .. 30
Système d'allumage électronique....... 30
Tiroir-réchaud ou tiroir de remisage
de qualité supérieure ........................... 32
Tiroir de remisage ................................ 33
Porte du four ....................................... 33
Achever l'installation ........................... 34
CONVERSIONS POUR
CHANGEMENT DE GAZ ....................... 35
Conversion pour l'alimentation
au propane .......................................... 35
Conversion pour l'alimentation
au gaz naturel ...................................... 39
SEGURIDAD DE LA COCINA ............... 42
REQUISITOS DE INSTALACIÓN .......... 44
Herramientas y piezas ......................... 44
Requisitos de ubicación ...................... 44
Requisitos eléctricos .......................... 46
Requisitos de suministro de gas ........ 46
INSTRUCCIONES DE INSTALACIÓN .. 48
Desembale la cocina ........................... 48
Instalación del soporte antivuelco ...... 48
Conexión del suministro de gas ......... 49
Verifique que el soporte anti-vuelco
esté instalado y enganchado .............. 50
Nivelación de la cocina ....................... 51
Sistema de encendido electrónico ..... 52
Cajón de calentamiento o cajón
de almacenamiento premium
(en algunos modelos) .......................... 54
Cajón de almacenamiento
(en algunos modelos) .......................... 54
Puerta del horno .................................. 54
Completar la instalación ..................... 55
CONVERSIONES DE GAS .................... 56
Conversión a gas propano .................. 56
Conversión a gas natural .................... 60
Advertisement
Table of Contents
Related Manuals for Whirlpool WFG535S0JV0
Summary of Contents for Whirlpool WFG535S0JV0
-
Page 1: Table Of Contents
INSTALLATION INSTRUCTIONS 30" (76.2 CM) FREESTANDING GAS RANGES INSTRUCTIONS D’INSTALLATION CUISINIÈRE À GAZ AUTOPORTANTE DE 30" (76,2 CM) INSTRUCCIONES DE INSTALACIÓN COCINAS ELÉCTRICAS INDEPENDIENTES DE 30" (76,2 CM) Table of Contents/Table des matières/ Tabla de contenidos RANGE SAFETY ........2 SÉCURITÉ... -
Page 2: Range Safety
RANGE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... - Page 3 IMPORTANT: Do not install a ventilation system that blows air downward toward this gas cooking appliance. This type of ventilation system may cause ignition and combustion problems with this gas cooking appliance resulting in personal injury or unintended operation. In the State of Massachusetts, the following installation instructions apply: Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by the State of Massachusetts.
-
Page 4: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Anti-tip bracket must be securely mounted to floor or wall. ■ The thickness of flooring may require longer screws to Gather the required tools and parts before starting installation. anchor bracket to the floor. Read and follow the instructions provided with any tools listed Parts needed here. - Page 5 Mobile Home - Additional Installation Requirements Cabinet Dimensions The installation of this range must conform to the Manufactured Home Construction and Safety Standard, Title 24 CFR, Cabinet opening dimensions shown are for 25" (64.0 cm) Part 3280 (formerly the Federal Standard for Mobile Home countertop depth, 24"...
-
Page 6: Electrical Requirements
Electrical Requirements Gas Supply Requirements WARNING WARNING Electrical Shock Hazard Explosion Hazard Plug into a grounded 3 prong outlet. Use a new CSA International approved gas supply line. Do not remove ground prong. Install a shut-off valve. Do not use an adapter. Securely tighten all gas connections. - Page 7 Flexible metal appliance connector: Gas Pressure Regulator If local codes permit, a new CSA design-certified, 4 to ■ 5 ft (122 to 152.4 cm) long, 1/2" (1.3 cm) or 3/4" (1.9 cm) The gas pressure regulator supplied with this range must be I.D.
-
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Unpack Range Install Anti-Tip Bracket WARNING WARNING Excessive Weight Hazard Use two or more people to move and install range. Failure to do so can result in back or other injury. 1. Remove shipping materials, tape and film from range. Tip Over Hazard 2. -
Page 9: Make Gas Connection
Floor Mountinge Make Gas Connection WARNING Explosion Hazard Rear position Front position Diagonal (2 options) Use a new CSA International approved gas supply line. Install a shut-off valve. Wall Mountine Securely tighten all gas connections. If connected to propane, have a qualified person make sure gas pressure does not exceed 14"... -
Page 10: Verify Anti-Tip Bracket Is Installed And Engaged
3. Use a 15/16" (2.4 cm) combination wrench and adjustable WARNING wrench to attach the flexible connector to the adapters. Check that connector is not kinked. Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. -
Page 11: Level Range
IMPORTANT: If there is a snapping or popping sound when Style 1: Ranges Equipped with a Storage Drawer: lifting the range, the range may not be fully engaged in the Use a 1/4" (6.4 mm) drive ratchet, wrench or pliers to adjust bracket. - Page 12 If the “low” flame needs to be adjusted: 4. Push the BAKE pad. 5. Press the START pad. The oven bake burner should light within 8 seconds. Under certain conditions, it may take the burner up to 50 to 60 seconds to light.
-
Page 13: Warming Drawer Or Premium Storage Drawer
If flame needs to be adjusted: To Replace: 1. Loosen the lock screw on the air shutter located at the rear 1. Align the forward drawer notches with the notches in the of the broil burner. drawer glides on both sides. Place the rear alignment tabs into the drawer glides on both sides. -
Page 14: Oven Door
To Replace: To Replace: 1. Lift up the front of the drawer and place the rear of the 1. Insert both hanger arms into the door. drawer inside the range so that the drawer stop notch is behind the drawer glide. 2. -
Page 15: Gas Conversions
GAS CONVERSIONS Gas conversions from Natural gas to Propane gas or from Propane Gas Conversion Propane gas to Natural gas must be done by a qualified installer. WARNING WARNING Explosion Hazard Use a new CSA International approved gas supply line. Tip Over Hazard Install a shut-off valve. - Page 16 3. Remove plastic cover from gas pressure regulator cap. 4. Turn gas pressure regulator cap counterclockwise with a 5/8" (1.6 cm) combination wrench to remove. NOTE: Do not remove the spring beneath the cap. Side view before A. Orifice spud C.
- Page 17 4. Remove 2 screws from the front tabs of the flame spreader. 11. Insert the tabs on the rear of the flame spreader into the rear Lift the front of the flame spreader and pull forward to of the oven. remove tabs from rear of oven and set it aside on a covered 12.
-
Page 18: Natural Gas Conversion
Complete Installation (Natural Gas to Propane Gas) To Convert Gas Pressure Regulator (Propane Gas to Natural Gas) 1. Refer to the “Make Gas Connection” section for properly connecting the range to the gas supply. 1. Remove storage drawer, warming drawer, or premium storage drawer. - Page 19 3. Apply masking tape to the end of a 9/32" (7 mm) nut driver To Convert Oven Bake Burner (Propane Gas to to help hold the gas orifice spud in the nut driver while Natural Gas) changing it. Press nut driver down onto the gas orifice spud and remove by turning it counterclockwise and lifting out.
- Page 20 8. Replace the “57” spud with a “49” spud. Install the Natural 3. Use a 3/8" (1 cm) combination wrench and turn the Propane gas bake burner orifice spud, turning it clockwise until snug. gas broil burner orifice hood counterclockwise to remove. The hood will be stamped with a “090.”...
- Page 21 ©2019 All rights reserved. Used under license in Canada. Tous droits réservés. Utilisé sous licence au Canada. W11333091B Todos los derechos reservados. Usado en Canadá bajo licencia. 05/19...
