Summary of Contents for Grundig 22 VLE 522 SG

  • Page 1 22 VLE 522 SG...

  • Page 2: Table Of Contents

    CONTENTS ­ - ------------------------------------------------------------------------------------------------------------------------------------ 4­ SETUP­AND­SAFETY 28­ USB­OPERATION ­ ­ File formats 6­ GENERAL­INFORMATION ­ Connecting external data media Special features of your TV Removing the external data media Receiving digital channels The file browser Grundig SCR system Settings in the USB setup menu Important notes on environmental Basic playback functions protection Additional playback functions Notes on still images 34­ TELETEXT­OPERATION ­ 8­ CONNECTION­AND­PREPARATION ­ TOP text or FLOF text mode Connecting the antenna and the power Additional functions adapter 35­ CONVENIENCE­FUNCTIONS ­ Inserting batteries into the r emote control Opening the SETTINGS menu 10­...
  • Page 3 CONTENTS ­ - ------------------------------------------------------------------------------------------------------------------------------------ 48­ SPECIAL­SETTINGS ­ Searching for digital television channels from a satellite automatically Searching for digital television channels from a satellite manually LNB settings Settings for motorised antennas (DiSEqC 1.2) Searching for digital terrestrial TV channels automatically Searching for digital terrestrial TV channels manually Tuning analogue television c hannels Changing stored analogue c hannels Displaying signal information 58­ INFORMATION ­ Product Fiche Other information Service information for dealers Environmental note Note for the Product Package Troubleshooting ­ 3 ENGLISH...
  • Page 4 SETUP­AND­SAFETY ­ - ----------------------------------------------------------------------------------------------------- Please note the following instructions when Make sure the power cord or the power sup- setting up the television set: ply unit (if provided) are not damaged. This television is designed to receive and dis- Only operate the television with the power play video and audio signals. supply/power cord provided. All other uses are expressly prohibited. Thunderstorms are a danger to all electrical The ideal viewing distance is five times the devices. Even when the television is switched d iagonal screen size. off, it can be damaged by a lightning strike to the mains or the antenna. Always disconnect Light falling on the screen impairs picture q uality.
  • Page 5 SETUP­AND­SAFETY ­ - ----------------------------------------------------------------------------------------------------- Do not connect any other equipment while the device is switched on. Also switch off other equipment before connecting it. Do not plug in the power cord of the device until you have connected the external equip- ment and the antenna. Make sure the mains plug is freely accessible. Keep the TV away from following devices as much as possible: cell phone, microwave and other devices that uses high frequency radio wave. Otherwise, TV may be malfunction due to radio wave interference. Do not expose the batteries to excessive heat such as direct sunlight, fire, etc. Do not use old and unused batteries together. Only replace the exhausted batteries with those having the same model, value and prop- erties. By ensuring proper disposal of these batteries, you will have contributed in prevention of po- tential hazards on the environment and human health that may arise from inappropriate dis- posal of the batteries. T his is a Class A product. During operation the device could cause radio interference. In this case the user may have to remedy this. Please contact your specialist dealer.

  • Page 6: General­information

    Detailed information on the individual DVB-T and DVB-C). Watching these channels television programmes are – when provided and the recording and playback functions are by the broadcasting station – are also avail- only possible with the appropriate CI module able in the electronic TV guide. and a SmartCard. Ask your specialist dealer. You can connect various data media, such as T he range of channels available from the pub- an external hard drive, a USB memory stick or lic broadcasting institutions (ARD with EinsEx- a digital camera, to the USB socket. Using the tra, EinsFestival or ZDF with ZDF Info and all file browser, you can then select and play the third party broadcasters) are not encrypted file formats of your choice (for example, MP4, and can be received without a SmartCard. MP3 or JPEG data). Grundig­SCR­system Y our TV supports SCR system (Satellite Channel Router). If your antenna installation is equipped with an Single Cable Distribution multiswitch, all television sets which are connected on this antenna can receive the television channels stand-alone. ­ 6 ENGLISH...

  • Page 7: Important Notes On Environmental Protection

    GENERAL­INFORMATION ­ - -------------------------------------------------------------------------------- Important­notes­on­ Notes­on­still­images environmental­protection Watching the same image for a long time on the screen may cause a still image remains feebly on The following information will help you to save the background. Feeble image(s) on the back- resources – and money as well. ground is originated from LCD/LED technology If you are not using your television set for and does not require any action under guaran- s everal days, you should pull out the mains tee. To avoid such cases and/or minimize the plug for environmental and safety reasons.

  • Page 8: Connecting The Antenna And The Power Adapter

    CONNECTION­AND­PREPARATION ­ - ---------------------------------------------- Connecting­the­antenna­and­the­power­adapter 1 To receive digital satellite channels (DVB-S/ 3 Insert the plug of the power adapter cable S2), connect the satellite antenna cable to » « into the DC­IN socket of your television. the a ntenna socket »SATELLITE« on the tel- 4 Plug the power cord of the power adapter evision set.

  • Page 9: Inserting Batteries Into The R Emote Control

    CONNECTION­AND­PREPARATION ­ - ---------------------------------------------- Inserting­batteries­into­the­ Environmental­note ­ r emote­control This symbol on recharge- able batteries/batteries or on the packaging indicates that the rechargeable bat- tery/battery may not be disposed of with regular household rubbish. For certain r echargeable batteries/batteries, this sym- bol may be supplemented by a chemical symbol. Symbols for mercury (Hg) or lead (Pb) are provided if the rechargeable batter- ies/batteries contain more than 0.0005%...

  • Page 10: Connections On The Television Set

    OVERVIEW ­------------------------------------------------------------------------------------------------------------------------------------ Connections­on­the­television­set DC­IN PC-IN Socket for power adapter. V GA socket, video input for PC; AV1­/­S-VHS S CART socket (CVBS signal, S ockets for video input RGB signal); (YUV signal). V ideo and sound socket for S-Video camcorder. HDMI2 H DMI socket, audio/video input. Optic­Out S ocket for audio output ( optical) for PCM/AC3 s ignals. For connecting digital AV amplifiers or AV receivers. Audio S ocket for audio input for a PC; Sockets for audio input (YUV signal). ­ 1 0 ENGLISH...

  • Page 11: Controls On The Television Set

    OVERVIEW ­------------------------------------------------------------------------------------------------------------------------------------ Controls­on­the­television­set SATELLITE A ntenna socket for the satellite antenna (DVB-S/ /I­ S witches the television on and S2). back into standby mode. ANT­IN A ntenna socket for a DVB-T, ­ A djusts the volume; DVB-C and analogue Selects channels in steps. antenna. V­/­P­ ­ P re-selection for volume or chan- H eadphone jack (3.5 mm nel selection. jack plug); Switches the television on from S ockets for audio output. standby. USB1 ­ U SB socket for external ­ A djusts the volume; data media without a power Selects channels in steps.

  • Page 12: The Remote Control - Main Functions

    OVERVIEW ­------------------------------------------------------------------------------------------------------------------------------------ The­remote­control­–­Main­functions Switches on and off (Standby). Switches on from standby; Selects channel – directly. S witches between S elects the channel list teletext and TV mode. (»All«, »FAV 1« to »FAV 4«). O pens the »HDMI CEC De- vice List«. Exit the menu. Display information. ­ Z apping function; Opens the main menu. switches back one menu level in the menus. Opens the channel list. Opens the electronic Opens the TOOLS menu. TV guide. O pens menu for AV channels. Adjusts the volume. < Then select using » «, » «, > » « or » « and press »OK« Λ to confirm.

  • Page 13: The Remote Control - All Functions

    OVERVIEW ­------------------------------------------------------------------------------------------------------------------------------------ The­remote­control­–­­ All­functions ­ Selects pages in teletext; ­ (red)  (green) Selects/activates various functions  (yellow) in the menus.  (blue) S witches to double character size in teletext; selects the previous title/previous picture in the file browser. R efreshes a teletext page; selects the next track/next picture in the file browser. S tops scrolling through pages in t eletext; starts a fast reverse search in the file browser. R eveals answers in teletext; starts a fast forward search in the file browser. S tarts playing a programme from an external data medium. F reeze frame, if no external data medium is connected;...

  • Page 14: Initial Set-Up And Tuning T Elevision Channels

    SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- Selecting­language,­country­and­ Initial­set-up­and­tuning­ operating­mode ­ t elevision­channels 1 Switch on the television set from standby with T he television set is equipped with automatic » «, »1…0« or »P+« or »P-«. channel search, which searches for satellite – During initial set-up, the »Installation Guide« channels (DVB-S/S2), terrestrial channels (DVB- will be displayed. T), cable channels (DVB-C) and analogue chan- nels. Help:­ You start the search and the television channels If this menu is not displayed, restore the will be stored into the different Program Tables.

  • Page 15: Tuning The Television Channels From Satellite (Dvb-S/S2)

    SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- ­ T uning­the­television­channels­ Advanced­installation from­satellite­(DVB-S/S2) 1 In the »Source Setup« menu, in the »Connec- tion Type« line, select the option »Satellite« You have two options for tuning digital satellite < > with » « or » «. channels. 2 Select the line »Advanced Installation« with A The easy installation, » « or » « and press »OK« to confirm. Λ w hich pre-configures all antenna settings for – T he menu appears. the satellite channels on Astra 19.2° East. B The advanced installation 08.08.2012 INSTALLATION c an be used if you wish to receive satellite 15:46...
  • Page 16 SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- 6­ Note: Select the line »DISEqC Mode« with » « or » «. It is possible, that some TV channels (tran- Λ Select »DiSEqC 1.0« or »DiSEqC 1.1« in sponders) cannot be found. This is caused a ccordance with the existing antenna system by a change in satellite parameters made <...

  • Page 17: Tuning Terrestrial Television Channels (Dvb-T)

    SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- Tuning­terrestrial­television­ Tuning­television­channels­from­ channels­(DVB-T) the­cable­provider­(DVB-C) 1 In the »Source Setup« menu, in the »Connec- 1 In the »Source Setup« menu, in the »Connec- tion Type« line, select the option »Cable« tion Type« line, select the option »Air« with < > with » « or » «. < > » « or » «. 2 S elect the line »Scan Type« with » « or » «.

  • Page 18: Changing The Program Table For The Digital Channels

    SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- Changing­the­program­table­for­ Selecting­channel­lists the­digital­channels 1 Open the menu with »MENU«. Channels which are found using the scan are 2 Select the »SOURCE SETUP« menu with » « saved in the »PROGRAM TABLE«. or » « and press »OK« to confirm. Λ – T he »SOURCE SETUP« menu appears. You can delete channels which are not required from the programe table, you can change the 3 S elect the line »Programe Table« with » « order of channels within the programe table and or »...
  • Page 19 SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- Deleting­channels­in­the­program­ 2 Select the sort criteria for satellite channels with » « (red), » « (green) or » « yellow); table    1 In the »PROGRAM TABLE« menu, select the Edit mode by pressing » « (red).  sort digital television channels from the cable provider with » « (blue). 2 Select the t elevision channel to be deleted  < > with »...
  • Page 20 SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- Enter­own­names­for­the­favourites­ 3 “Push” the channel into the favourites < > lists 1 to 4 with » « or » « and press »OK« lists­(max.­6­characters) to confirm. You can enter own names for all favourites lists. – T he position in the favourites list is marked 1 In the »PROGRAM TABLE« menu, switch over with »✔«. to the list view with » « (yellow). – Y ou can enter the same channel in more ● ● ● than one favourite list. 2 Select the desired favourites list with »1« till – Each favourite list can store up to 250 »4«.
  • Page 21 SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- ­ P icture­settings­ Notes: You can only select the »Mpeg NR« function 1 Open the menu with »MENU«. on digital and AV presets. 2 Select the menu item »PICTURE SETTINGS« »Mpeg NR« reduces any interference with » « or » « and press »OK« to confirm. Λ from artefacts (pixel blocks) from digital – T he »PICTURE SETTINGS« menu appears. programmes due to MPEG compression (such as from DVB-T receivers or 20.09.2010 15:46 DVD p layers).
  • Page 22 SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- Sound­settings­ Automatic­volume Television stations broadcast at different vol- 1 Open the menu with »MENU«. umes. The automatic volume limiting (AVL) func- 2 Select the menu item »SOUND SETTINGS« tion means the volume is kept the same when with » « or » « and press »OK« to confirm. Λ you switch between channels. – T he »SOUND SETTINGS« menu appears. 1 Select the line »AVL« with » « or » « and Λ < > select the option »On« with » « or »...
  • Page 23 SETTINGS ­----------------------------------------------------------------------------------------------------------------------------------------- Soundeffects Equalizer This menu offers three preset sound effects Equalizer offers a sound setting ”User” that you (Music, Natural and Speech) and one setting to can create. be created by you (User). Equaliser appears in the menu when »Sound mode« is selected as »Spatial« or »Normal«, 1 Select the line »Sound Preset« with » « or and »Sound Medium« as »User«. » «. Λ 1 Select »Equalizer« with » « or »...

  • Page 24: Picture Settings

    TELEVISION­-­OPERATION -------------------------------------------------------------------------------- Basic­functions Selecting­a­preset­AV­channel 1 Open the »Select Source« menu with » «. Switching­on­and­off < 2 Select an AV preset with » «, » «, » « or Λ 1 Switch the television to standby with the pow- > » « and press »OK« to confirm. •­ OFF«. er switch »ON­ 3 Use »1…0« to switch back to the television 2 Press » «, »1…0« or »P+« or »P-« to switch channel. on the television from standby mode. Adjusting­the­volume 3 Press » « to switch the television to standby. ­– +­ 1 Adjust the volume with » «. Selecting­channels Switching­sound­on/off 1 Press »1…0« to select presets directly.

  • Page 25: Zoom Function

    TELEVISION­-­OPERATION -------------------------------------------------------------------------------- Audio­settings Zoom­function Various audio settings are available. This function allows you to enlarge the picture as required. 1 Open the Tools menu with »TOOLS«. 1 Open the Tools menu with »TOOLS«. 2 Select the menu item »Sound Preset« with » « or » «. 2 Select the menu item »Zoom« with » « or Λ » «. Λ < 3 Select the audio setting by pressing » « or >...

  • Page 26: Zapping Function

    TELEVISION­-­OPERATION -------------------------------------------------------------------------------- Zapping­function Electronic­TV­guide This function remembers the channel you are The electronic TV guide provides an overview of c urrently watching while you switch over to other all programmes that will be broadcast in the next ones (zapping). week (for digital channels only). 1 Press »1…0« or »P+«, »P–« to select the 1 Press »GUIDE« to display channel informa- channel to be stored in the zapping memory tion. and press » « to confirm. < Notes: 2 Press »1…0« or » «, »...

  • Page 27: Changing The Picture Format

    TELEVISION­-­OPERATION -------------------------------------------------------------------------------- Changing­the­picture­format »Panorama«­format­ This setting is suitable for films in an especially Basic setting is 16 : 9. wide format. 1 Select the picture format with » «. – T he picture format (for example »16:9«) is During programmes in 4:3 format, the picture is displayed. stretched horizontally if the »Panorama« function – Y ou can choose between the following is selected. The picture geometry is stretched p icture formats: horizontally. »Auto«­format »Overscan­off«­format The picture format is automatically switched to In this mode, HD pictures are not cropped by the »16:9« for 16:9 programmes. HDMI sockets or component sockets, and are displayed in their original size. This only applies The picture format is automatically switched to in HDMI mode and for resolutions of 720p or...

  • Page 28: File Formats

    USB­OPERATION ­--------------------------------------------------------------------------------------------------------------- File­formats Image­data Your television can display pictures in the formats Your television can work with the following file JPEG, PNG and BMP. formats using the USB sockets: JPEG stands for Joint Picture Experts Group. Video­data It denotes a process for compressing picture files. Special codecs for video compression and PNG and BMP are process used to save image d ecompression provide more memory space data with no, or very little, losses. without compromising the picture quality exces- Picture files can be stored with other types of sively.

  • Page 29: Connecting External Data Media

    USB­OPERATION ­--------------------------------------------------------------------------------------------------------------- Connecting­external­data­media­ Before connecting the external data medium it is recommended to switch the television to stand-by mode. Before removing the external data medium, the television set must be switched to standby, so that no data loss occurs. Notes: The »USB2« socket of the television set s upplies a maximum power of 500 mA in accordance with USB specifications. Exter- nal hard disks which require more power may therefore only be connected to the »USB1« of the television set.

  • Page 30: The File Browser

    USB­OPERATION ­--------------------------------------------------------------------------------------------------------------- The­file­browser­ Settings­in­the­USB­setup­menu The file browser displays video, audio and Selecting­the­menu p icture files stored on external data media. < > 1 Press » «, use » «, » «, » « or » « to Λ If an external data medium contains files in select the preset »USB« and press »OK« to d ifferent formats, you can, when necessary, filter confirm.

  • Page 31: Basic Playback Functions

    USB­OPERATION ­--------------------------------------------------------------------------------------------------------------- DivX ­VOD Basic­playback­functions­ ® You must have your device registered in order to 1 Select the data medium by pressing » «, play the protected video that you will buy from < > use » «, » «, » « or » « to select the option Λ DivX ® »USB« and press »OK« to confirm. – T he file browser appears. 1 Select »DivX VOD« with » « or » « and ® Λ confirm with »OK«. 2 Select the file format (video files, audio files, – Registration Code appears. picture files) with » « or » «. Λ 2 Visit “http://vod.divx.com” and register the 3 Switch to the folder/file list with »OK«.

  • Page 32: Additional Playback Functions

    USB­OPERATION ­--------------------------------------------------------------------------------------------------------------- Additional­playback­functions Notes: Use » « to select »Up Folder«, when you Λ Depending on the file format, the following would like to return to the last folder. Use a dditional functions are available: »Root« (and then press »OK«) to return to Selecting­chapters­on­DivX ­files the main folder. ® (only video files) It is possible that files which are actually supported do not function correctly in USB 1 During playback, select the next chapter mode. This is because certain files are not...
  • Page 33 USB­OPERATION ­--------------------------------------------------------------------------------------------------------------- Selecting­a­track­or­picture­in­steps­ (SKIP) 1 During playback, select the next track/ picture with » «. 2 During playback, select the previous track/ picture with » «. – P layback begins with the track or picture you selected. Selecting­a­certain­passage­for­ playback­ (video files only) 1 During playback, press »OK«. 2 Enter the passage (time) with »1­...­0« and press » « (green) or »OK« to confirm.

  • Page 34: Top Text Or Flof Text Mode

    TELETEXT­OPERATION ­---------------------------------------------------------------------------------------------- Enlarging­the­character­height TOP­text­or­FLOF­text­mode If you have difficulty reading the text on the 1 Press »TXT« to switch on teletext. screen, you can increase the character height. 2 Select teletext pages directly with »1...0« 1 To enlarge the character height of a teletext or step by step with » « and » «. Λ page, keep pressing » «. Return to teletext page 100 with »?«. Note: Page­hold At the bottom of the screen there is an info A multiple page may contain several sub-pages, bar with red, green and – depending on the which are automatically scrolled by the broad- channel – yellow and blue panels. Similarly, casting station. the remote control also features buttons with 1 Stop the automatic scrolling of the sub-pages different colours with which these pages can...

  • Page 35: Opening The Settings Menu

    CONVENIENCE­FUNCTIONS ­------------------------------------------------------------------------ Opening­the­SETTINGS­menu Changing­the­audio­language (only for digital television channels) 1 Open the menu with »MENU«. You can define a primary and a secondary 2 Select the menu item »SETTINGS« menu with audio language. » « or » « and press »OK« to confirm. Λ – T he »SETTINGS« menu appears. 1 Select the line »Audio« with » « or » « and Λ press »OK« to confirm. 20.09.2010 – T he »Select Audio Language« menu 15:46 SETTINGS a ppears.

  • Page 36: Setting The Date And Time

    CONVENIENCE­FUNCTIONS ­------------------------------------------------------------------------ Setting­the­date­and­time Timer­functions Automatic­setting Entering­the­switch-off­time­­ (sleep­timer) Your television set detects the difference in time to Greenwich Mean Time (GMT) automatically, as In the »Sleep Timer« menu you can enter a time long as the channel selected transmits a time signal. for the television to switch off. After this time has elapsed, the television switches to standby 1 Select the line »Date & Time« with » « or mode. » « and press »OK« to confirm. Λ 1 Select the line »Sleep Timer« with » « or 2 Select the line »Auto« with » « or »...

  • Page 37: Parental Control Settings

    CONVENIENCE­FUNCTIONS ­------------------------------------------------------------------------ Parental­control­settings 6 Select the line »Volume« with » « or » « and Λ < > use » « or » « to set the volume. Authorising­programmes 7 Select the line »Set Hour« with » « or » « Λ There are films which may be wholly or partially and enter the time with »1…0«. unsuitable for children. 8­ Save the data with » « (green).  These programmes contain information which Note: marks the content or scenes with access levels of You can abort the entry by pressing » « (red). 4 to 18. You can select one of the access levels,  thereby authorising playback. 9 Press »EXIT« to end the setting. 1 Select the line »Parental Guidance« with Switch-off­timer »...
  • Page 38 CONVENIENCE­FUNCTIONS ­------------------------------------------------------------------------ Locking­keys­(Parental­lock) Locking­television­channels­ You can lock individual television channels, for When the key lock is activated, the buttons on example channels unsuitable for children, using the television set do not function. a personal PIN code. 1 Select the line »Keypad Lock« with » « or 1 Open the menu with »MENU«. » «. Λ 2 Select the menu item »SOURCE SETUP« with 2 Enter the PIN code »1234« with »1­...­0«. » « or » « and press »OK« to confirm. Λ 3­ Activate (On) or deactivate (Off) the key lock 3 Select the line »Program Table« with » < > « or with » « or »...

  • Page 39: Updating Software

    CONVENIENCE­FUNCTIONS ­------------------------------------------------------------------------ Updating­software (for digital channels only) 1 In the »SETTINGS« menu, select the line »Check For Updates updates« with » « or » « and press »OK« to confirm. Λ – A search for new software will be made and – if available – it will be installed. Note: If a search for software updates should be made automatically, select the line »Auto- <...

  • Page 40: Digi Link

    OPERATION­USING­EXTERNAL­DEVICES ­----------------------------- DIGI­LINK Searching­for­and­activating­­ external­devices Your television is equipped with You can connect up to 11 devices with DIGI LINK the DIGI LINK function. functions to your television. This function uses the CEC (Consumer Electronics Control) 1 Open the Tools menu with »TOOLS«. protocol. 2 Select the menu item »CEC« with » « or CEC allows external devices which are connect- » « and press »OK« to confirm. Λ ed to the »HDMI« sockets by an HDMI cable – T he »HDMI CEC Device List« appears.

  • Page 41: Device Operation

    « or » « Λ 20.09.2010 and press »OK« to confirm. 15:46 SOURCE SETUP – The external device switches itself off. Source HDMI1 DIGILINK Device Selection GRUNDIG DVD Remote Control RC Passthrough Device Standby Exit Back 4 Select the line »Remote Control« with » « or » «. Λ 5­ Select the type of operation (»RC <...

  • Page 42: High Definition Hd Ready

    OPERATION­USING­EXTERNAL­DEVICES ­----------------------------- High­definition­­ ­ HD­ready Connection­options Which television socket(s) you connect your Connect the corre- external devices to depends on the sockets sponding input sources the external device is equipped with and the (e.g. HDTV receiver or signals which are available. HD-DVD player) to the »HDMI« sockets (for Please note: With many external devices, the resolution of the video signal must be digital HDTV sources). adjusted to the input sockets of the television This ensures that you can view digital HDTV (see the operating manual of the external p rogrammes, even if they are copy-protected device). You can find out which values you (HDCP High Bandwidth Digital Content Protec-...

  • Page 43: Connecting External Devices

    OPERATION­USING­EXTERNAL­DEVICES ­----------------------------- Connecting­external­devices ...­using­the­SCART­socket­­ (CVBS/RGB­signal) ...­with­digital­audio/video­signals Suitable devices: Digital satellite receiver, Suitable devices: Digital satellite receivers, DVD player/recorder, set-top box, games con- Playstation, BluRay player, DVD player/ sole, video recorder, decoder. recorder, set-top box, notebook, PCs. Video signal: CVBS/RGB. Video signal: Digital video; resolution: stand- Audio signal: stereo, analogue. ard 576p; HDTV 720p, 1080i, 1080p. »AV1« preset. Audio signal: digital audio (stereo, multi-chan- 1 Connect the »AV1/S-VHS« socket on the nel compression, uncompressed). television and the corresponding socket on Presets »HDMI 1«, »HDMI 2«.

  • Page 44: Using A Dvd Player, Dvd R Ecorder, Video Recorder Or Set-Top Box

    OPERATION­USING­EXTERNAL­DEVICES ­----------------------------- Using­a­DVD­player,­ DVD­­ r ecorder,­video­recorder­­ or­set-top­box 1 Switch on the external device and select the function you wish to use. < > 2 Press » «, use » «, » «, » « or » « to Λ select the preset for the input signal (»AV1«, »AV2«, »S-VHS«, »HDMI1«, »HDMI2« or »Component«) and press »OK« to confirm. Headphones Connecting­the­headphones 1 Plug the headphone jack (3.5 mm ø jack plug) into the headphone socket on the left side of the television. Changing­the­headphone­volume 1 Open the menu with »MENU«. 2 Select the menu item »SOUND SETTINGS« with »...

  • Page 45: Hi-Fi System/Av Receiver

    OPERATION­USING­EXTERNAL­DEVICES ­----------------------------- Hi-fi­system/AV­receiver Playing­the­audio­signal­via­the­­ HiFi­system Connecting­the­hi-fi­system/­ 1­ Connect the » « socket on the television to AV­receiver the corresponding socket of the AV receiver 1­ Out« socket on the Connect the »Optic­ with an cable (digital audio signal). television to the corresponding socket of the Note: device with an optical digital cable (digital If this function is not activated, the audio sig- audio signal). nal is transmitted to the HiFi system/AV re- Setting­the­audio­format ceiver (connected to » « 3.5 mm ø jack plug) into the headphone socket on the left You can select whether the audio signal output side of the television.

  • Page 46: Connecting A Pc

    OPERATION­AS­A­PC­MONITOR ­ - --------------------------------------------------------- Connecting­a­PC 20.09.2010 15:46 SOURCE SETUP 1 Connect the »PC-IN« socket on the television to the corresponding socket on the PC using a VGA cable (video signal). Source 2 Connect the »Audio« socket on the televi- sion to the corresponding socket on the PC Auto Ajust using a suitable cable (audio signal). Extended settings Note: Auto Ajust Mode Adjust your PC to the monitor (for example, Position 50H - 50V picture resolution 1280 x 768, picture fre- Size quency 60 Hz).

  • Page 47: What Is A Common Interface

    OPERATION­WITH­A­COMMON­INTERFACE ­ - ----------------- What­is­a­Common­Interface? Access­control­for­CI­module­and­ smart­card C ommon Interface (CI) is an interface for DVB receivers. 1 Open the menu with »MENU«. E ncrypted channels can only be viewed 2 Select the menu item »SOURCE SETUP« with with a CA module suitable for the encryp- » « or » « and press »OK« to confirm. Λ tion system and in conjunction with the – T he »SOURCE SETUP« menu appears.

  • Page 48: Searching For Digital Television Channels From A Satellite Automatically

    ­ S PECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Searching­for­digital­television­ 7 Select the line »Scan Mode« with » « or » «. channels­from­a­satellite­ Λ < > Select the scan mode with » « or » « automatically (for unencrypted channels, for encrypted Satellite data changes frequently, new channels channels only, or both).

  • Page 49: Searching For Digital Television Channels From A Satellite Manually

    ( Radio), or both (Radio + TV). < > in the satellite system with » « or » «. If 5 Start the scan with » « (red). you are using a satellite antenna with an  – T he »Results« menu appears, and the scan Single Cable Distribution multiswitch, select for TV channels begins. the setting »Grundig SCR«. After it, please perform the »User Band«, »KB Frequency« Note: and »LNB Selection« settings in the You can abort the search by pressing submenus. The necessary parameters you »EXIT«. will get from the operator of the satellite 6 Press »EXIT« to end the setting. antenna. Use only this specification! – » LNB Selection«: If more than one satellites are used in the current SCR system, select »1/2« to»2/2« for the satellite corresponding to the relevant <...

  • Page 50: Settings For Motorised Antennas (Diseqc 1.2)

    SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Settings­for­motorised­antennas­ Notes: Use installation equipment supported / (DiSEqC­1.2) suggested by your Multiswitch. Your television set supports motorised satellite Other users / receivers connected to the systems in compliance with DiSEqC 1.2. This system may be affected if the specified user function allows the satellite antenna to be oper- band number and frequency is changed ated via the television set. during installation. 1 Open the menu with »MENU«. User band and User band frequency is 2 Select the menu item »SOURCE SETUP« with specified on the Multiswitch used; and » « or » « and press »OK« to confirm. Λ each user / receiver uses a specified user – T he »SOURCE SETUP« menu appears. band and user band frequency.
  • Page 51 SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- DiSEqC­1.2­Settings Searching­for­television­chan- nels­from­the­cable­provider­ You can adjust the alignment of the satellite an- tenna to each individual satellite. These settings automatically will be saved so that the antenna can later be 1 Open the menu with »MENU«. easily guided to each saved alignment. 2 Select the menu item »SOURCE SETUP« with 1 Select the line »DiSEqC 1.2 SETTINGS« with » « or » « and press »OK« to confirm. Λ » « or » « and press »OK« to confirm. Λ – T he »SOURCE SETUP« menu appears. – T he »DiSEqC 1.2 SETTINGS« menu ap- 3 Select the line »Source« with » «...
  • Page 52 SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Searching­for­television­channels­ Note: from­the­cable­provider­manu- You can accelerate the search. To do this, you need information about the frequency ally and network ID. You are usually able to get 1 Open the menu with »MENU«. this data from your cable operator or find it 2 Select the menu item »SOURCE SETUP« with in forums on the Internet. For example, the frequency 402MHz and network ID 61441 » « or » « and press »OK« to confirm. Λ...

  • Page 53: Searching For Digital Terrestrial

    SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Searching­for­digital­terrestrial­ 6 Select the line »Scan Typ« with » « or » « Λ < > and set the option »DTV« with » « or » «. TV­channels­automatically 7 Start the scan with » « (red).  1 Open the menu with »MENU«. – A ll channel and favourites lists will be 2 Select the menu item »SOURCE SETUP« with d eleted and compiled anew. » « or » « and press »OK« to confirm. Λ Note: – T he »SOURCE SETUP« menu appears.

  • Page 54: Searching For Digital Terrestrial

    SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Searching­for­digital­terrestrial­ Tuning­analogue­television­ TV­channels­manually ­ c hannels 1 Open the menu with »MENU«. This setting is only necessary if you cannot re- ceive any digital channels and you have not car- 2 Select the menu item »SOURCE SETUP« with ried out an analogue search during initial setup. » « or » « and press »OK« to confirm. Λ The television channels can be set directly or – T he »SOURCE SETUP« menu appears. using the scan.
  • Page 55 SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Tuning­the­television­channels­by­ 4 Select the line »Automatic Channel Search« entering­the­channel­numbers with » « or » « and press »OK« to confirm. Λ 1 Open the menu with »MENU«. 20.09.2010 SOURECE SETUP 2 Select the menu item »SOURCE SETUP« with 15:46 » « or » « and press »OK« to confirm. Λ – T he »SOURCE SETUP« menu appears. Source 3 Select the line » Analogue Manual Tuning« Automativ Channel Search with » « or »...

  • Page 56: Changing Stored Analogue C Hannels

    SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Entering­channel­names­(8­digit­ Note: If you wish to remedy other television maximum) channels, repeat steps 4 to 7. 1 In the »PROGRAME TABLE« menu, select the 8­ Press »EXIT« to end the setting. < t elevision channel with » «, » «, » « or Λ > » « and press » « (red) to confirm.  Changing­stored­analogue­ 2 Open the input keyboard with » « (green).

  • Page 57: Displaying Signal Information

    SPECIAL­SETTINGS ­ - --------------------------------------------------------------------------------------------------------- Creating­lists­of­favourites Displaying­signal­information You can select your favourite channels and save (for digital channels only) them in up to four favourites lists (Fav 1 to Fav 4). 1 Open the menu with »MENU«. 1 In the »PROGRAME TABLE« menu, switch 2 Select the menu item »SOURCE SETUP« with over to the list view with » « (yellow).  » « or » « and press »OK« to confirm. Λ 2 Select the preferred channel with » « 3 Select the line »Signal Information« with or » «. Λ »...

  • Page 58: Product Fiche

    INFORMATION ­--------------------------------------------------------------------------------------------------------------------- Product­Fiche Digital­reception­ranges Satellite: GRUNDIG­22­VLE­522­SG Ku band: 10,700 MHz – 12,750 MHz Modulation: D VBS QPSK, DVBS2 QPSK, Energy­Efficiency­class: 8 PSK IF band: 950 MHz – 2,150 MHz Screen­size: Signal level: -25dBm to -65 dBm 55 cm/22 inch Cable: Power­consumption: O verall band: 110 MHz – 862 MHz O n mode 22 W / 30 W max. Modulation: 1 6QAM, 32QAM, 64QAM, Annual­power­consumption 128QAM and 256QAM 33 kWh Symbol rate: 4.0 Msym/s to 7.4 Msym/s Stand-by­power­consumption Terrestrial­(DVB-T): < 0.50 W V HF/UHF band, Bandwidth 7 MHz Maximum­resolution:...

  • Page 59: Service Information For Dealers

    INFORMATION ­--------------------------------------------------------------------------------------------------------------------- Service­information­for­dealers Note­for­the­Product­Package The product complies with the Packaging materials of your product are recy- following EU directives and clable. Please ensure that packaging materials regulations: of your product are disposed of separately in accordance with the regulations set by the local 2006/95/EC: Directive on the harmonisation of the laws of Member States re- authorities in order to have the packaging mate- lating to designed for use within certain voltage rials included in the environmental friendly recy- limits. cling process. 2004/108/EC: Directive relating to electro- magnetic compatibility.
  • Page 60 INFORMATION ­--------------------------------------------------------------------------------------------------------------------- Troubleshooting If the information provided below does not help, please consult an authorised GRUNDIG dealer. Please bear in mind that malfunctions can also be caused by external devices such as video recorders or satellite receivers. Problem Possible­cause Remedy Screen lit (snow), but no Antenna cable Is the antenna cable connected? s tation visible No TV channel tuned Start a channel scan Insufficient contrast in picture The picture settings are not correct Adjust the brightness, contrast or c olour setting Problem at station Try another channel Picture and/or sound distorted Interference from other devices Place the device in a different position Ghosting, reflection Channel setting Automatic or manual tuning/fine tuning Antenna Have antenna cable or system checked No colour Colour intensity too low Turn up the colour Adjust TV standard (if setting option Select the correct colour standard is available) Problem at station Try a different channel Picture but no sound...
