Chauvet GOBO SPLASH CH-324 User Manual

Troubleshooting
ü If the unit is not functional – check that the main power supply is on and check fuses.
ü If the unit is functional but the lamp does not light - the lamp may require replacing.
ü If after trying the above, you still have a problem, contact CHAUVET.
Contact Chauvet
USA
Technical Assistance: 1-800-762-1084 (954) 929-1115
E-Mail tech@chauvetlighting.com
Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
Never put any objects through the air grill on the top of the unit.
No user serviceable parts inside. Please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live= Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power 120V~60Hz AC
20mm Glass 5A Fast Blow
Fuse
Lamps 1 X 24V 250W
Part No. ELC3 24V 250W
(300 Hrs)
Dimensions 368 x 368 x 152mm / 14.5 x 14.5 x 6 in
Weight 8.5 kg / 18.7 lbs
User Information (Please complete for your records)
Data Purchased : / / Serial No. :
Dealer Stamp : Model : CH-324 Gobo Splash
230V~50Hz AC
20mm Glass 3.15A Fast Blow
Gobo Splash
CH-324
Users Guide
Please read these instructions carefully before use
World-wide Headquarters:
th
3000 North 29 Ct.,
Hollywood, Florida, USA 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
800-762-1084
www.ChauvetLighting.com
